INSTALLATION GUIDE
VALENCIA & PROFESSIONAL SERIES
SHOWER DOOR HANDLE
Unpack handle, and check if any components are missing.
Handle rail ( x1)
Stando ( x2)
Washer PVC 12.5 mm (x4)
Washer flat (x4)
Washer PVC 21 mm (x4)
Door knob (x2)
Remove handle knob and washers of both grub screws as
shown picture on the right.
From the outside of the door, position the handle through
the holes in the glass.
Ensure the hole in the glass is well covered by the PVC and
the flat washers.
Stando
Washer
PVC
Grub
screw
Door
knob
Washer
Flat
Washer
PVC
Handle
rail
Flat &
21 PVC Washer
Edge
Glass hole
Edge
Grub
screw
Page 2
Page 2Kohler Co. 1090694-A02-B 09/05/2012
CLEANING INSTRUCTIONS
Slide Washer PVC 21 mm, then Flat washer followed by the
washer PVC 12.5 mm, onto each grub screw.
Fit both door knobs and tighten to secure handle in place..
Wipe clean using non abrasive soap and damp cloth.
Use a soft cloth to wipe dry.
Do not use harsh chemicals and cleaners that are not
recommended to use on anodized aluminium surfaces.
Always read the label instructions on any cleaner carefully
before applying it to the surface.
