Wall-Plate Cameras
Manual
Features:
1
/
3.2
" 1.3MP Sony STARVIS CMOS
2.4mm Wide angle lens
Weatherproof construction
Vandal-resistant design
Adjustable mounting angle
Includes: 1 camera, 1 single-gang plate,
1 slimline plate, and angled mounting rings
2DNR (2D Digital Noise Reduction)
WDR (Wide Dynamic Range)
12VDC Operating voltage
Model # Lens Image Sensor Resolution Video Output Format
EV-5105-N1SQ
2.4mm
1
/
3.2
" 1.3MP Sony
STARVIS CMOS
1000TVL NTSC
EV-T5105-N2SQ 720p HD-TVI
ENFORCER Wall-Plate Cameras
2 SECO-LARM U.S.A., Inc.
Dimensions:
Specifications:
Parts List:
1x Camera 1x Angled rubber ring (EV-5105-N1SQ) 1x Slimline plate
2x Mounting screws 1x
A
ngled aluminum ring (EV-5105-N1SQ) 1x Single-gang plate
1x
A
luminum hex nut 2x Angled aluminum rings (EV-T5105-N2SQ) 1x Manual
Model EV-5105-N1SQ EV-T5105-N2SQ
Type Wall-plate camera
Plate type 1 Single-gang, 1 slimline
Image sensor
1
/
3.2
" 1.3MP Sony STARVIS CMOS
Resolution 1000 TV Lines 720p
Video output format NTSC HD-TVI
Effective pixels 1280x960
2DNR Yes
WDR Yes
960H* Yes No
Scanning system 2:1 Interface
Sync Internal
Video output 1.0Vp-p Composite video, 75Ω
Lens 2.4mm
Viewing angle 150°
FPS 30FPS
F Stop 2.2
Minimum illumination 0.001Lux
Gamma correction 0.45
S/N Ratio 120dB 50dB
Gain control Auto
Operating voltage 12VDC
Current draw 80mA 90mA
IP Rating IP67 IP65
Operating temperature -22°~176° F (-30°~80° C)
Dimensions
Camera 1
1
/8"x11/8"x11/2" (28x28x38 mm) 11/8"x11/8"x17/8" (28x28x48 mm)
Single-gang plate 23/4"x41/2" (70x114 mm)
Slimline plate 11/2"x41/2" (38x114 mm)
23/4" (70mm)
Single-gang plate
*In order to take full advantage of 960H resolution, the camera must be used with a 960H DVR
11/2" (38mm)
Slimline plate
41/2"
(114mm)
Camera body
EV-T5105-N2SQ
11/8"
(28mm)
15
/16"
(
24mm)
17/8" (48mm)
11/4"
(32mm)
Camera body
EV-5105-N1SQ
11/8"
(28mm)
7
/8"
(
22mm)
11/2" (38mm)
7
/8"
(22mm)
