ENFORCER EV-2706-NFGQ, EV-2706-NFWQ, EV-2706-PFGQ, EV-2706-PFWQ, EV-2726-NFGQ User Manual

Note: Products with model numbers that end with “Q” or that have a round gree n “ Q” sticker are RoHS compl i ant.

Varifocal V andal Rollerb al l Cameras

Manual

NTSC Models

PAL Models

Features

EV-2706-NFGQ

EV-2706-PFGQ

700 TVL, Gray Housing

EV-2706-NFWQ

EV-2706-PFWQ

700 TVL, White Housing

EV-2726-NFGQ*

EV-2726-PFGQ*

700 TVL, 3D-DNR, 2D-DNR, WDR, Gray Housing

EV-2726-NFWQ*

EV-2726-PFWQ*

700 TVL, 3D-DNR, 2D-DNR, WDR, White Housing

*Includes built-in OSD (On-Screen Display) controller

3X Series – clear images in nearly any lighting situation

• 1/3” Sony CCD

• 2.8~12mm Lens

• 3-Axis ball mount for wall or

ceiling mounting

• 960H High resolution

• Weatherproof (IP65)

• Split-glass design to

eliminate IR reflection

• Vandal-resistant design

ENFORCER Varifocal Vandal Ball-Mount Dome Cameras

2 SECO-LARM U.S.A., Inc.

Model

NTSC

EV-2706-NFGQ
EV-2706-NFWQ

EV-2726-NFGQ
EV-2726-NFWQ

PAL

EV-2706-PFGQ
EV-2706-PFWQ

EV-2726-PFGQ
EV-2726-PFWQ

Type

Vandal Rollerball Camera

CCD

1

/3” Sony Super HAD II

Resolution

700 TV lines

Pickup
elements

NTSC

976x494 pix els

PAL

976x582 pix els

3D-NR

No

Yes

WDR

No

Yes

OSD Control

No

Yes

960H*

Yes

Scanning system

2:1 Interlace

Sync

Internal

Video output

1V p-p composite output, 75 ohms

Lens

2.8~12mm

# of IR LEDs

36 (850nm)

IR Range

Up to 100’ (30m)

Minimum
illumination

LEDs OFF

0.02 Lux

0.03 Lux

LEDs ON

0 Lux

Gamma corre cti o n

0.45

S/N Ratio

>52dB

DSS (Digital Slow Shutter)

N/A

256x

Shutter c o ntrol

Auto Elect ric Shutter (AES), 1/ 60~1/100, 000 s

Gain control

Auto

White balan ce

Auto

Operating voltage

12VDC ±10%

Current draw

LEDs OFF

100mA

150mA

LEDs ON

400mA

450mA

IP Rating

IP65

Operating temperature

-4°~131° F (-20°~55° C)

Dimensions

411/16”x37/8” (119x98 mm)

Cable length

34” (86cm)

Weight

1-lb, 13-oz (820g)

Dimensions:

Specifications:

Parts List:

1 x Camera

1 x Manual
4 x Screws
4 x Screw anchors
1 x DC Plug with
terminal block
1 x Small screwdriver
1 x Hex wrench
2 x Rubber plugs

Zoom

411/16” (119mm)

Focus

37/8”

(98mm)

Optional Mounting

Brackets (sold separately):

Wall Mount

Ceiling Mount

Conduit Box

Gray: EV-DWLGQ

White: EV-DWLWQ

Gray: EV-DCLGQ

White: EV-DCLWQ

Gray: EV-DSLGQ

White: EV-DSLWQ

Conduit Drop

Gray: EV-DDLGQ

White: EV-DDLWQ

*In order to take full advantage of 960H re solution, the camera must be used with a 960H DVR.
