Caution:
This sensor was not designed to prevent bodily injury or loss of life.
This sensor was not designed for use in environments where explosive gases may be present.
Use of this sensor in certain security applications may be regulated by local laws or codes. SECO-LARM
is not responsible for compliance with such laws or codes.
E-936-S35RRGQ
35ft Retro-Reflective Photoelectric Beam Sensor
Manual
Features:
Up to 35ft (11m) sensing range
Weatherproof (IP66) construction for
indoor/outdoor usage
Pre-wired 6-foot cord
Bracket and mounting hardware included
for both sensor and reflector
Adjustable sensing range
Compact size
Typical Applications:
Sensor for garage doors or outdoor gates
Entry detection for store fronts
Assist in measuring parking distance
Light on type
IMPORTANT: The E-936-S35RRGQ conforms
to UL325-2016 for gate operators that use the
N.C. or 10kΩ resistor for monitoring.
ENFORCER 35ft Retro-Reflective Photoelectric Beam Sensor
2 SECO-LARM U.S.A., Inc.
Dimensions:
Reflector
Transmitter/Receiver
215/32″
(63mm)
3
/16″
(5mm)
19/16″
(40mm)
25/16″
(58mm)
113/16″
(30mm)
13
/16″
(20mm)
25/8″
(66mm)
13
/16″
(20mm)
19
/32″
(15.1mm)
3
/8″ (10mm)
21/32″
(52mm)
21/16″
(53mm)
61/2′ (2m) cable
1
/4″ (6mm) diameter
3
/16″ (4.5mm) thru holes
Parts List:
1x
Transmitter/Receiver
1x
Reflector
4x
Lock Washers
4x
Hex Nuts
1x
Sensor Mounting Bracket
1x
Reflector Mounting Bracket
4x
Flat Washers
1x
Manual
2x
Sensor Mounting Screws
2x
Reflector Mounting Screws
Mounting the Sensor:
Wiring:
Note:
325 ft (100 m)
Connection (5 wires)
Brown
12-30V DC
24~30V AC (60Hz), 83mA
(Non-polarized)
Blue
Gray (N.O.)
White (COM)
Black (N.C.)
Multi-voltage
circuit
Relay Output
10kΩ
Type
Retro-reflective
Sensing range
0.5~35 ft (0.2~11 m)
Operating voltage
12-30V DC/24-30V AC 60Hz, 83mA
Current draw
Standby
60mA@12VDC
Active
25mA@12VDC
Response time
10ms (max.)
Light source
IR LED
LED indicators
Yellow LED (alignment), Red LED (power on, triggered off)
Trigger output
SPDT Relay output
(NO/NC/COM, with built-in 10KΩ resistor on N.O. output)
Switching capacity
2A@30VAC/VDC
Enclosure
IP66 Weatherproof
Operating temperature
-4°~131° F (-20°~55° C)
Mounting brackets for sensor and reflector
Included
Specifications:
