H.264 Pentaplex DVR
User’s Manual
Version 1.8
DR-116Q shown
DR-104Q
DR-108Q
DR-116Q
4 8 16
120
240
240
No. of channels
Pictures per Second
The SECO-LARM policy is one of continual development. For that reason, SECO-LARM reserves the right to change prices and specifications without notice.
SECO-LARM is not responsible for misprints.
Tel:
Fax:
16842 Millikan Avenue
Irvine, CA 92606
1-949-261-2999
1-800-662-0800
1-949-261-7326
Web: www.seco-larm.com
Email: info@seco-larm.com
DVR User’s Manual
1
DVR User’s Manual
2
Caution and Preventive Tips
Handle with care, do not drop the unit
Mount the unit in an equipment rack or place it on a solid, stable surface
Indoor use only. Do not place the unit in a humid, dusty, oily, or smoky site
Do not place it in an area with poor ventilation or in an area close to fire or other sources of
heat. Doing so may damage the unit as well as cause fire or an electric shock
When cleaning is necessary, shut down the system and unplug the unit from the outlet
before uncovering the top cover. Do not use liquid cleaners or aerosol cleaners. Use only
a damp cloth for cleaning
Always shut down the system prior connecting or disconnecting accessories, with the
exception of USB devices
This symbol intends to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature accompanying the
appliance.
This symbol intends to alert the user to the presence of unprotected “Dangerous
Voltage” within the product’s enclosure that may be strong enough to cause a
risk of electric shock.
DVR User’s Manual
3
Important Information
Before proceeding, please read and observe all instructions and warnings in this manual.
Retain this manual with the original bill of sale for future reference and, if necessary, warranty
service. When unpacking your unit, check for missing or damaged items. If any item is missing,
or if damage is evident, DO NOT INSTALL OR OPERATE THIS PRODUCT. Contact your
dealer for assistance.
Rack Mounting
Consult with the supplier or manufacturer of your equipment rack for the proper hardware and
procedure of mounting this product in a safe fashion. Avoid uneven loading or mechanical
instability when rack-mounting units. Make sure that units are installed to get enough airflow
for safe operation. The maximum temperature for rack-mounted units is 40 °C. Check product
label for power supply requirements to assure that no overloading of supply circuits or over
current protection occurs. Mains grounding must be reliable and uncompromised by any
connections.
DVR User’s Manual
4
Table of Content
1. Overview ....................................................................................................................... 7
2. System Setup ................................................................................................................ 8
2.1 Position the DVR ................................................................................................. 8
2.2 Select Video Format ............................................................................................ 8
2.3 Connect Devices to the DVR ............................................................................... 9
2.4 Rear Panel Connections ...................................................................................... 9
3. General System Setup ............................................................................................... 11
3.1 Front Panel Introduction .................................................................................... 11
3.1.1 LED Definition ...................................................................................... 11
3.1.2 Function Keys ....................................................................................... 12
3.2 Entering OSD Setup Menu ................................................................................ 16
3.2.1 User Management ................................ ................................ ................ 17
3.3 Power Up / Shutdown the DVR .......................................................................... 18
3.4 System Date / Time Setting ............................................................................... 19
3.4.1 Set Date / Time ..................................................................................... 19
3.4.2 Daylight Saving Time ............................................................................ 20
3.4.3 Network Time Protocol Setup ............................................................... 21
3.5 Record Schedule / Quality Setting ..................................................................... 22
3.5.1 Record Mode Setup ............................................................................. 22
3.5.2 Schedule Setup .................................................................................... 23
3.5.3 Preset Record Configuration ................................................................ 23
3.5.4 Per Camera Configuration .................................................................... 24
3.5.5 Record Event Video Only ..................................................................... 24
3.5.6 ezRecord Setup .................................................................................... 25
3.5.7 Data Lifetime ........................................................................................ 26
3.5.8 Circular Recording ................................................................................ 26
3.5.9 Audio Recording ................................................................................... 26
3.5.10 Purge Data ........................................................................................... 27
3.6 Event Setting ..................................................................................................... 28
3.6.1 Internal Buzzer ..................................................................................... 28
3.6.2 Event Icon ............................................................................................ 28
3.6.3 Email Notice ......................................................................................... 28
3.6.4 Email Attachment ................................................................................. 29
3.6.5 Alert Notification Setup ......................................................................... 29
3.6.5.1 Alert Configuration Set .......................................................... 29
3.6.5.2 Alert Notification .................................................................... 29
3.6.5.3 Alert IP .................................................................................. 30
3.6.5.4 Alert Port ............................................................................... 30
DVR User’s Manual
5
3.6.5.5 Alert Interval .......................................................................... 30
3.6.6 Event Full Screen ................................................................................. 30
3.6.7 Event Duration ...................................................................................... 30
3.6.8 Per Channel Config .............................................................................. 30
3.6.8.1 Channel Select ...................................................................... 31
3.6.8.2 Video Loss Detect ................................................................. 31
3.6.8.3 Motion Detect ........................................................................ 31
3.6.8.4 Motion Detect Indicator ......................................................... 31
3.6.8.5 Detection Configuration ......................................................... 31
3.6.8.6 Alarm In ................................................................................. 32
3.6.8.7 Alarm Out .............................................................................. 32
4. Basic Operation .......................................................................................................... 33
4.1 View Live / Playback Video ................................................................................ 33
4.1.1 Viewing Modes ..................................................................................... 33
4.1.2 Digital Zoom ......................................................................................... 34
4.1.3 View Live Cameras .............................................................................. 34
4.1.4 View Recorded Video ........................................................................... 34
4.1.5 Taking Snapshots ................................................................................. 36
4.2 Sequence........................................................................................................... 37
4.2.1 Sequence with Main Monitor ................................................................ 37
4.2.2 Sequence with Call Monitor(8CH & 16CH models only) ....................... 37
4.3 Search Recorded Video ..................................................................................... 38
4.3.1 Search by Time .................................................................................... 38
4.3.2 Calendar Search .................................................................................. 39
4.3.3 Search by Event ................................................................................... 40
4.4 Video Export ...................................................................................................... 41
4.4.1 ezBurn Introduction ................................ ................................ .............. 41
4.4.2 Export Normal Video ............................................................................ 42
4.4.3 Export Event Video ............................................................................... 42
4.5 Dome Control ..................................................................................................... 43
4.5.1 Dome Connection ................................................................................. 43
4.5.2 Dome Protocol Setup ........................................................................... 43
4.5.3 RS485 Setup ........................................................................................ 44
4.5.4 Dome Controlling Keys ......................................................................... 44
4.5.5 Setting Preset Points ............................................................................ 46
4.5.6 Calling Preset Points ............................................................................ 47
4.6 System Log Exportation ..................................................................................... 47
5. Remote Monitoring Software ..................................................................................... 48
5.1 Remote Monitoring System Requirements ........................................................ 48
5.2 Installation of Software ....................................................................................... 49
DVR User’s Manual
6
5.2.1 Change Internet Settings ...................................................................... 49
5.2.2 Install the Remote Monitoring Software ................................................ 51
5.2.2.1 Login / Logout ......................................................................... 52
5.2.2.2 Software Upgrades ................................................................. 53
5.3 Basic Operation ................................................................................................. 53
5.3.1 View Live Video .................................................................................... 53
5.3.1.1 Select Display Mode ............................................................... 54
5.3.1.2 Operating Cameras with Dome Control .................................. 54
5.3.2 Instant Recording ................................................................................. 55
5.3.2.1 Record Video Instantly ............................................................ 55
5.3.2.2 Playback Instant Recorded Video ........................................... 55
5.3.3 Playback Video ................................................................ ..................... 56
5.3.3.1 Playback Remote Video .......................................................... 56
5.3.3.2 Playback Local *.drv Files ....................................................... 57
5.3.3.3 Playback Controls ................................................................... 57
5.3.4 Verify Digital Signature ......................................................................... 59
5.3.5 Search from Event List ......................................................................... 59
5.3.6 Take a Snapshot ................................................................................... 59
5.3.7 Health Status ........................................................................................ 60
5.3.8 Normal and Dual Streaming ................................................................. 60
5.3.9 Remote Monitoring Software Trouble Shooting Guide ......................... 61
6. iPhone and Smart Phone Monitoring ........................................................................ 62
Appendix A: Recommended HDDs ................................................................................ 64
Appendix B: Remote Controller ..................................................................................... 65
Appendix C: Setting up a DVR behind a Router............................................................ 67
DVR User’s Manual
7
1. Overview
Lite H.264 DVR is an integrated digital video recorder that combines the
features of a time-lapse audio / video recorder, a multiplexer, and a video
server to create a single security solution.
Its outstanding triplex operation enables users to view live video, search and
playback any recorded video by date/time or event, and remotely monitor the
unit via internet on PC, MEANWHILE the recording of the DVR unit is
ongoing simultaneously.
Lite H.264 DVR is enhanced to provide H.264 compression mode. Moreover,
a marvelous implementation is the brand-new experience of Graphical User
Interface (GUI) that optimizes the monitoring controls of the unit.
Lite H.264 DVR is pre-installed with remote viewing and configuration
software, which is a Web-browser plug-in allowing users to view live or
recorded video images, and enables remote configuration. The remote
software is stored in Lite H.264 DVR and deployed over a LAN, WAN or
Internet connection to remote Windows-based computers. This simplifies the
installation and maintenance of the software components so all remote users
are using the same software coming from the unit.
DVR User’s Manual
8
2. System Setup
The notices and introduction on system installation will be described
particularly in this chapter. Please follow the description to operate the unit.
In order to prevent the unit from data loss and system damage that caused by
a sudden power fluctuation, use of an Uninterruptible Power Supply (UPS) is
highly recommended
2.1 Position the DVR
First, note to position / mount the DVR in a proper place and be sure to power
off the unit before making any connections. The placed location should avoid
hindering or blocking the unit from airflow. Enough airflow is needed to
protect the unit from overheating. The maximum allowable temperature of
operating environment is 40°C.
The unit utilizes heat-conducting techniques to transfer internal heat to the
case, especially to the bottom side of the unit.
NOTE: Be sure the rubber feet are not removed, and always leave a
space for air ventilation on the unit’s bottom side.
2.2 Select Video Format
The DVR is designed to operate under either NTSC or PAL video formats.
The switch is on the rear panel.
DVR User’s Manual
9
2.3 Connect Devices to the DVR
This section lists some important notices that should be read before making
any connection to the DVR.
Connecting Required Devices
Before power up the unit, cameras and a monitor should be connected to the
unit for basic operation. If needed, connect a call monitor for displaying full
screen video of all installed cameras in sequence.
Connecting Short-term Device
If any short-term devices shall be installed to the DVR as parts of the unit
system, such as USB ThumbDrive® or any USB devices, etc, make sure
those devices are connected only after the unit is powered up. The reason is
because the DVR can recognize the external devices only after the power-up
process is done completely.
2.4 Rear Panel Connections
There are various connectors on the rear panel for the DVR installations. The
following shows the detailed description of each connector.
Main Monitor (BNC/ VGA)
BNC and VGA output connectors are offered for
connecting to a main monitor. The main monitor displays
live image and playback recorded video in either
full-screen or split-window format. VGA output connector
is optional.
Call Monitor (8CH and 16CH models only)
The call monitor is used to display full screen video of all
installed cameras in sequence. The BNC call monitor
connector allows users to connect the DVR with an
optional call monitor.
Video In
A group of BNC connectors is offered for video input
streams from installed cameras. The number of
connectors is equal to the number of channels.
DVR User’s Manual
10
Alarm I/O & RS485
A D-Sub connector is provided to offer users the
flexibility to connect the DVR to Alarm I/O and
RS-485 devices. Refer to Setup Guide for
detailed pin definitions.
LAN Connector (RJ-45)
The DVR is capable of networking. Once the unit is
connected to the LAN network, users can remotely
access the unit through the remote software on a PC.
USB Connector (x1)
There is one USB port provided to allow users to connect
a PS/2 mouse via a USB converter.
Power Jack
The DVR has a free voltage DC power connection jack.
Please connect the power adapter shipped with the unit.
Audio In
Audio In connectors are offered for connecting
audio source devices to the unit. 4CH models
offer RCA connectors while 8CH and 16CH
models offer a D-Sub connector.
4CH models
8CH & 16CH models
Audio Out – Main & Call
Main & Call Audio Out RCA connectors are
provided for connecting the DVR to audio output
devices (e.g. amplified speakers). “Main” will
output audio from the main monitor, whereas
“Call” will output audio form the call monitor.
NOTE: Call Audio Out RCA connector is only available for 8CH and
16CH models.
DVR User’s Manual
11
3. General System Setup
Before operating the DVR, some general configuration should be setup first.
The following subsections will introduce function keys on the front panel and
general configuration of the DVR.
The regular displayed OSD information and its displayed positions are shown
as following figure. Title of the channel will be displayed on the top-left corner
of the window, either in full screen mode or in multiple channel mode. The
current operating mode, including Call mode, Dome Control mode, Playback
mode, Freeze mode and Sequence mode, will be displayed on the
bottom-left corner of the screen. The date/ time information will be display on
the bottom-right corner of the screen. On the upper-right corner will show the
authority level of login account. Under logout condition, the icon will show “N”.
Ch1
►*1
N
2008/05/09 PM04:31:22
3.1 Front Panel Introduction
The front panel controls enable users to control the unit and preset the
programmable functions.
3.1.1 LED Definition
The LEDs on the front panel of the DVR are described as follow.
Power LED
The LED lights up when the correct power is connected to the unit.
REC LED
The LED blinks while the DVR is recording.
Alarm LED
The LED lights up when an alarm is triggered.
Network LED
The LED lights up when the DVR is connected to a network and
blinks when the data is being transferred.
DVR User’s Manual
12
3.1.2 Function Keys
This section describes the functional keys on the front panel of the DVR.
Refer to the Setup Guide for the graphical illustration of functional keys.
CHANNEL
In both Live and Playback modes, press the CHANNEL key to view the
corresponding video in full screen. The number of the CHANNEL keys
corresponds to the number of cameras supported by the unit.
In Dome Control mode, the key “1” is used to access the Set/Go preset
menu; the key “2” is used to hide or display the hint screen.
In OSD virtual keyboard, press keys 1~9 to input number 1~9, and press
key 10 to input number 0.
DOME
Press the key to enter dome control mode. Please refer to Section Dome
Control for detailed controlling operation.
In OSD virtual keyboard, press this key to go backspace.
MODE
Press repeatedly to select for wanted monitor display format. The available
view modes includes: full-screen, 4-window (2× 2), 9-window (3× 3) and
16-window (4×4). Refer to Section Viewing Modes for detailed information.
SEQ (Sequence)
Press to start automatic sequence display of video from all installed cameras.
MENU
Press this key to enter the OSD setup menu.
COPY
In Playback mode, press COPY to select the start and end time of the export
video. Refer to Section Video Export for detailed information.
CALL (8CH and 16CH models only)
In Live mode, press this button to enter call monitor control mode.
In Dome Control mode, press CALL in association with ENTER to enter
the OSD setup menu of the dome camera.
DVR User’s Manual
13
In OSD virtual keyboard, press this key to input a period mark “.”.
DVR User’s Manual
14
PLAY/STOP
Press this key to switch between live image and playback video.
NOTE: According to record setting, part of the latest video cannot be
played back because the video is still saved in the buffer.
FREEZE
Press FREEZE while viewing live image, the live video will be frozen. The
date / time information shown on the monitor will continue updating. Press
FREEZE again to return to live mode.
Press FREEZE while playing the recorded video, the playback video will
be paused. Press LEFT / RIGHT to move the recorded video reverse /
forward by single step. Press FREEZE again to continue playing video.
SEARCH
In both Playback and Live mode, press SEARCH to enter the Search
menu to search and playback recorded video by date/time or events.
Press twice to instantly playback the latest recorded videos.
ESC
Press to cancel or exit from certain mode or OSD setup menu without
changing the settings made previously.
If password protection is enabled, press ESC for five seconds to lock up
functions of certain keys, including PLAY, MENU, SEARCH, DOME and
CALL. Once users lock up the functions of these keys, enter proper
username and password to unlock.
NOTE: Please go to the <System Setup> <User Management>
menu to enable or disable the password protection.
Direction Keys
In Zoom mode, press these keys to move to desired directions.
In the OSD setup menu, the LEFT/ RIGHT keys are used to move the
cursor to previous or next fields. To change the value in the selected field,
press UP/ DOWN keys.
ENTER / ZOOM
In OSD setup menu or selection interface, press this key to make the
selection or save settings.
In live full screen view mode, press this key to view a 2× zoom image;
DVR User’s Manual
15
press it again to exit Zoom mode.
DVR User’s Manual
16
3.2 Entering OSD Setup Menu
The configuration of the DVR can be customized by entering the intuitive
Graphical User Interface (GUI) OSD setup menu. Collaborating with a USB
mouse, setting up the DVR can be easy as operating on a PC. Press MENU
and input a valid username. There are two preset accounts: “admin” and
“user”. “admin” can be inputted via pressing the hot key MENU, while “user”
can be inputted via pressing the hot key SEARCH. Move to <OK> and press
ENTER to proceed.
Input Username
A B C D E F G H I J K L M N O P Q R S T U V W X Y
Z
a b c d e f g h i j k l m
n o p q r s t u v w x y z 0 1 2 3 4 5 6 7 8 9 . !
@
# − _ , “ + = *
◄ ►
Backspace Delete
Cancel
OK
The next step is to enter a corresponding password. The preset password for
“admin” is “1234”, and the password “4321” is for “user”.
Password Verification
_______
Press Channel Keys To Enter Password
(4-8 Digits)
Press ◄ Key To Delete
NOTE: It is strongly suggested to change the preset password to
prevent unauthorized access to the unit.
An icon displayed at the upper-right corner of the screen will show the
authority level of the account. Under logout condition, the icon will show “N”.
When an account is logged in, its authority level number (1~8) will be shown.
Before completely logout, other functions can also be accessed without
having to login again. There are two ways to logout: manually logout by
pressing ESC key at Live mode, or auto logout when keys are not pressed for
5 minutes at Live/ Menu mode.
DVR User’s Manual
17
3.2.1 User Management
The DVR provides the option to create up to seven sets of usernames and
passwords with customized authority, excluding the preset “admin” account.
From the Main Menu, select <System Setup> <User Management> and
the menu is as the following:
User Management
Password Protection
Account Setup
Authority Setup
Load Default Setting
ON
No
Password Protection
Select <ON> to request for username and password for accessing functions
listed in Authority Setup menu, or select <OFF> to allow free access.
Account Setup
Setup customized username, password, and authority level in this menu. The
username is case sensitive. The authority level is ranked from level 1~8, and
level 8 has highest authority. Alternatively, select <Disable> to suspend the
account.
NOTE: The username and authority level of the preset “admin”
account cannot be changed.
Authority Setup
Setup the allowed authority level for accessing the functions listed in this
menu. The functions include: Playback/Search, Dome Control, Call Control,
Export Data, Menu Access, System Setup, Monitor Setup, Camera Setup,
Record Setup, Sequence Setup, Event Setup, Database Setup,
Configuration and Shutdown. The authority level is ranked from level 1~8,
and level 8 has highest authority. Alternatively, select <Disable> to allow free
access.
NOTE: The “Menu Access” cannot be set to <Disable>. When the
account does not have authority to access certain functions, an error
message will be displayed on the screen.
Load Default Setting
Select <Yes> to load the default setting.
DVR User’s Manual
18
3.3 Power Up / Shutdown the DVR
If the DVR must be shutdown for any reason, please use the proper shut
down and power up procedures to avoid damaging the DVR.
Power Up the Unit
Simply plug in the power adapter that came with the package and the DVR
will start to boot.
The color bar and system checking information will be shown on the monitor
and then disappear when the unit has been completely powered up.
Restart / Shutdown the Unit
Press MENU and input the username and password that has sufficient
authority to access the OSD setup menu. Select <Shutdown> in Main Menu
and press ENTER to enter the Shutdown menu, which displays as follows.
Shutdown
Power Off
Reboot
Execute
Execute
<Power Off>
Select this item to shut down the unit. Do not remove the power during shut
down until the message “You can safely turn off DVR now!” displays.
<Reboot>
Select this item to reboot the unit. The color bar and system checking
information are displayed on the monitor until the unit is completely restarted.
DVR User’s Manual
19
3.4 System Date / Time Setting
Users can set the current date, time and other OSD parameters in Date/Time
menu (under System Setup menu). The login account should have authority
to access the System Setup menu. In OSD setup menu, select <System
Setup> and press ENTER, then select <Date/Time> to access the Date/Time
menu; the menu displays as follows.
Date/Time
Date
Time
Time Zone
Date/Time Display
Date Display Mode
Time Display Mode
Date/Time Order
Daylight Saving Time Setup
Network Time Protocol Setup
2008/02/21
PM10:39:26
OFF
1 Row
Y/M/D
12 HR
Date First
3.4.1 Set Date / Time
Set Date / Time
Select <Date> / <Time> and press ENTER to adjust the settings. LEFT /
RIGHT keys are used to move the cursor to previous or next field, ENTER is
for selecting, and UP / DOWN are used to change the value in the selected
field.
NOTE: The new date / time setting applies to record new video. The
date and time of previously recorded video will not be changed.
NOTE: If time settings have to be changed in any case, it is strongly
recommended to format the HDDs to avoid database corruption.
Date / Time Display
Users are allowed to set the time OSD displays in 1 or 2 rows. Use the UP /
DOWN keys to change the setting.
DVR User’s Manual
20
Date Display Mode
This function allows users to set the OSD display type of the date. There are
three options to select from: <Y/M/D>, <M/D/Y> or <D/M/Y>. “Y” represents
“Year”, “M” represents “Month” and “D” represents “Day”.
Move to the item and press ENTER, the option starts blinking. Use UP /
DOWN keys to change the setting.
Time Display Mode
Users can set the time format to <12 hour> or <24 hour>. Use the UP /
DOWN keys to change the format.
Date / Time Order
The item is used to set the order of date / time display to <Date First> or
<Time First>. Use UP / DOWN keys to change the setting.
3.4.2 Daylight Saving Time
Daylight Saving Time
The item is for those people who live in certain regions to observe Daylight
Saving Time. Select <ON> to enable, or <OFF> to disable the function.
If the function is disabled, the DST Start / End time and DST Bias will be
grayed out and cannot be accessed.
NOTE: If this function is enabled, the date/ time information will be
shown on the screen with a DST icon when playing back recorded
video or searching video in the event list. “S” indicates summer time
and “W” indicates wintertime.
DST Start / End
The items are used to program the daylight saving duration. Use LEFT /
RIGHT keys to move the cursor to the next or previous field, UP / DOWN to
change the settings in the selected field.
DST Bias
The item allows users to set the amount of time to move forward from the
standard time for daylight saving time. The available options are in minutes.
Loading...
