Patented DFR™ technology fan
Stunning Red+Green lighting effects
Perfect for chassis and gaming rigs
ENERMAX D.F.VEGAS DUO 12cm LED fan is equipped with the
latest patented DFRTM(Dust Free Rotation) technology, which allows
the fan to swiftly blow away the dust from the fan blades.
D.F.VEGAS DUO features red, green and duo color LED, offering
the user to choose between 13 different switchable lighting modes.
The unique lighting effects will enable you to create a personalized
look that matches your style. APS (Adjustable Peak Speed) and PWM
control provide greater flexibility in selecting the preferred fan
speed to reach the balance between cooling performance and silent
operation.
Features
Patented DFRTM technology* instantly blows away the dust to prolong the lifespan
How it works
○
After 6 months
1. Patented DFR blows away the dust (full speed)
Within 10 sec.
*Automatic LED self-testing will be activated during the DFR™ mode
2. Shift back to normal spin
After 10 sec.
With DFR™ technology Without DFR™ technology
(more dust accumulates)
Patented Circular Type LED with 24 diodes and 13 Vegas LED modes (manually switchable)
Single Red
Single Green
Dual Color
Sparkle
1
2
3
＊Vegas mode autoplays Sparkle, All on and Flash LED effects.
All on
4
5
6
7
8
9
Flash
FLASH
FLASH
FLASH
＊Vegas
10
11
12
VEGASVEGAS
VEGAS
VEGAS
VEGAS
VEGAS
＊Quick Off :
Press the LED control button for
3 seconds for “OFF” mode.
＊Memory Function :
13
OFF
Selected mode will resume when
system starts.
Focus Blades with light reflex strips create exceptional, curved rays of light
Reflecting Surface None-Reflecting Surface
Shockproof rubber pads minimize vibration during operation
Page 3
Patented APS (Adjustable Peak Speed) Control
provides 3 peak rpm options
APS control allows users to adjust their preferred fan "peak"
speed by shifting the speed control.
The control switch is located on the side of the frame, making
the fan speed adjustment much easier and safer.
RPM
Highest
Lowest
DFR™
APS Control
*Ultra Silent:
*Silent:
*Performance :
800~1100 rpm
800~1300 rpm
800~1500 rpm
PWM speed control keeps your system
cool and silent at all times
0% 20% 100%
Duty Cycle(%)
2nd generation of patented Twister Bearing™ technology for long lifetime and low noise
MTBF≧160k hours
Ultra Silent: 16dBA
Detachable blade for easy cleaning
Specifications
Model Number
Dimension (mm)
APS Mode
Speed (RPM)
Air Flow (CFM)
3
Air Flow (m
Static Pressure (mm-H
/h)
2
Noise (dBA)
Rated Voltage (V)
Input Current (A)
Input Power (W)
MTBF (hrs)
LED Color
Number of built-in LEDs
LED Type
Connector
Accessory
Barcode
Box Dimension
Gross Weight / unit
Carton Dimension
Q'ty / carton
Gross Weight / Carton
O)
Ultra Silent
800 ~ 1100
33.21 ~ 45.33
56.43 ~ 77.02
0.979 ~ 1.297
16 ~ 18
12
0.21
2.5
Patented circular type LED with 13 modes
8 x screws , 1 x adhesive tape, 1 x 4 pin fan power adaptor
EAN: 4713157722324 UPC: 816163008551
UCDFVD12PUCDFVD12P
120(W) x 120(H) x 25(D)
Silent
800 ~ 1300
33.21 ~ 53.66
56.43 ~ 91.17
0.979 ~ 1.425
16 ~ 20
12
0.23
2.8
≧160,000 @25°C
2 colors (Red and Green)
24 (12*red + 12*green)
1 x 4 pin PWM connector
Shipping Information
120 x 182 x 28 mm
0.21 kg
490 x 340 x 260 mm
60 pcs
12.5 kg
Performance
800 ~ 1500
33.21 ~ 61.92
56.43 ~ 105.20
0.979 ~ 1.898
16 ~ 22
12
0.25
3.0
www.enermax.com
©
2016 ENERMAX TECHNOLOGY CORPORATION. All rights reserved. Specifications are subject to change without notice. Content of delivery might differ
in different areas or from illustrations. Some trademarks may be claimed as the property of others.
September 2016
