Exclusive self-cleaning solution
Super high 3,500 RPM Twister Bearing fan
Perfect for overclocking and gaming system
D.F. STORM – a high speed 3,500 RPM fan, equipped with
leading Twister Bearing technology. This industrial-grade fan
features the patented DFRTM technology, which allows the
fan to blow away dust to prolong its lifespan. D.F. STORM
also incorporates the patented APS PWM control for 3
different RPM ranges: 1500-2200/2800/3500, enabling
users to adjust the fan speed range according to their
system needs.
Features
Patented DFRTM technology instantly blows away the dust to prolong the lifespan
How it works
○
After 6 months
1. Patented DFR blows away the dust (full speed)
Within 10 sec.
3,500 RPM for industrial application
Designed for extreme applications and conditions
(hardcore gaming rigs, servers, industrial systems,
supercomputing, etc). The maximum 3,500 RPM is
set for extraordinary high cooling performance.
* Please use the 4-Pin adaptor included to power
the fan directly from the power supply unit when
the Turbo Mode (1500-3500RPM) is selected.
2. Shift back to normal spin
After 10 sec.
With DFR technology Without DFR technology
(more dust accumulates)
Super 3500 RPM
Page 3
Storm-Flow blades generate +30% airflow and enhance airflow momentum
Innovative Storm-Flow blade design comes with sophisticated inclination inlet & outlet angles, which generates up
to 30% more airflow than normal blades. The extremely strong airflow (up to 263.48m
(up to 11.13mm-H
2O) make D.F. STORM ideal for extreme applications
3
/h) and high static pressure
D.F. STORM
Patented APS (Adjustable Peak Speed) with
control switch provides 3 peak RPM options
With LED indicator and the APS switch, users can easily
indentify the current RPM setting
APS PWM Control
*Performance :
*Overclocking :
*Turbo :
1500~2200 RPM (Blue
1500~2800 RPM (Green
1500~3500 RPM (Red
indicator)
indicator)
indicator)
Normal Blade
RPM
DFR
Highest
PWM speed control keeps your system
cool and silent at all times
Lowest
0% 30% 100%
Duty Cycle(%)
Patented Twister Bearing technology for long lifetime and low noise
Smooth and persistently reliable operation thanks to the patented Twister Bearing technology. Along with more industrial grade
components (double-layer PCB, larger magnet, etc.) to ensure 160,000 hours MTBF even at high operating temperatures.
MTBF≧160k hours
Detachable blade for easy cleaning
Page 4
Specifications
Shockproof rubber on screw minimizes
vibration during operation
Model Number
Dimension (mm)
Speed Mode
Speed (RPM)
Air Flow (CFM)
Air Flow (m
3
/h)
Static Pressure (mm-H
Noise (dBA)
Rated Voltage (V)
Input Current (A)
Input Power (W)
MTBF (hrs)
Connector
Accessory
UCDFS12PUCDFS12P
120(W) x 120(H) x 25(D)
Performance
1500~2200
72.47~100.23
123.12~170.29
2
O)
2.514 ~4.348
23~28
Overclocking
1500~2800
72.47~130.23
123.12~221.26
2.514~7.972
23~32
Turbo
1500~3500
72.47~155.08
123.12~263.48
2.514~11.131
23~38
12
0.40
4.8
0.70
8.4
1.10
13.2
≧160,000 @25°C
1 x 4 pin PWM connector , 1 x 4 pin fan power adaptor
8 x screws , 4 x isolator-mounts
1 x adhesive tape
Shipping Information
Barcode
Box Dimension
Gross Weight / unit
Carton Dimension
Q'ty / carton
Gross Weight / Carton
EAN: 4713157722225 UPC: 816163008322
120 x 182 x 28 mm
240 g
490 x 340 x 260 mm
60 pcs
14 kg
www.enermax.com
©
2016 ENERMAX TECHNOLOGY CORPORATION. All rights reserved. Specifications are subject to change without notice. Content of delivery might differ
in different areas or fro m illustrations. Some trademarks m ay be claimed as the property of o thers.
Oct. 2016
