Ener-G+ HEA 21523, HEA 22000BHR User Manual
HEA 21523
INFRARED
GAZEBO HEATER
CHAUFFERETTE INFRAROUGE
POUR GAZEBO
User manUal
manUel de l'UtilisateUr
I N FRARED GAZEBO HEATER
I N S T R U C T I O N M A N U A L
PAGE 3www.EnErgplus.com
CONTENT
CONTENT
1. Components 4
2. Assembly 5
3. For your safety 6
4. Cleaning and storage 8
5. Specifications 9
6. Warranty 10
FRANÇAIS 11
I N FRARED GAZEBO HEATER
PAGE 4 EnErg+
1. COMPONENTS
1. Make sure that all the parts are present and that there are no missing parts. Please
empty the packing box thoroughly and make sure that all the parts are present and
that there are no missing parts.
2. Do not PLUG THE UNIT IN UNTIL THE UNIT IS COMPLETELY ASSEMBLED AND
MAKE SURE THERE IS NO DAMAGE to the unit and power cord.
IF THERE IS ANY DAMAGE OR MISSING PARTS, PLEASE CONTACT ENERG+
CUSTOMER SERVICE AT 866-967-7333. (SEE WARRANTY SECTION)
I N S T R U C T I O N M A N U A L
PAGE 5www.EnErgplus.com
2. ASSEMBLY
MAKE SURE THE HEATER IS NOT FUNCTIONING BEFORE YOU HANG IT ON A GAZEBO,
UNDERNEATH A BALCONY OR A ROOF.
1. Make sure Hook B is well attached to the heater.
2. Attach Hook ’B’ onto a secure post, beam or any solid attachment object. You can
also attach hook ‘B’ on Hook ‘A’ going around an obstacle to install the heater.
NOTE: wait until the heater heating element has cooled down before moving it.
3. Connect the heater to an AC 120V/60Hz wall outlet.
4. Pull on the switch cord to activate the heater. Pull again to close it.
REMEMBER, portable electric heaters are designed for spot heating or as a supplementary
heat source. They are not intended to be the main source of heat during cold months.
Overheat protection shut–off
If the heater overheat temperature is reached, it will automatically shut off.
The heater can only resume operation when the user resets the unit. Please inspect and
remove any objects on or adjacent to the heater that may cause high temperature.
To reset the heater:
1. Turn the heater off.
2. Unplug the heater.
3. After 5-10 minutes, plug the unit in again and operate normally.
Caution: You must always make sure there is at least 3 ft/50 cm of empty space above
the heater.
If you must use an extension cord, the cord should be at least NO .14 AWG and rated for
no less than 1875 W.
I N FRARED GAZEBO HEATER
PAGE 6 EnErg+
3. FOR YOUR SAFETY
IMPORTANT INSTRUCTIONS
1. ONLY USE THE UNIT ON A SECURED AND SOLID ATTACHMENT POINT.
2. This heater is not intended for use in bathrooms, laundry areas or similar indoor locations where there may be moisture. Never place heater where it may fall into a pool,
bathtub or other water receptacle.
3. This unit is intended for household use only. DO NOT use the unit in such areas as
construction sites, greenhouses, barns or stables or any place that has flammable
materials.
4. DO NOT use the unit in an unventilated area.
5. A heater has hot, arcing and sparking parts inside. Do not use it in areas where
gasoline,paint or flammable liquids are used or stored.
6. DO NOT move the unit when it is still connected to an electrical outlet and always wait
for the unit to cool down before moving, cleaning and storing.
7. DO NOT touch the heater when in use. Please wait at least 10 minutes before
touching it.
8. Extreme caution is necessary when any heater is used near a child or someone physically disabled.
9. ALWAYS UNPLUG HEATER WHEN NOT IN USE.
10.DO NOT LEAVE THE UNIT UNATTENDED WHEN IN OPERATION.
11.The unit must have a minimum clearance of 180cm from the bottom of the unit to the
floor and 30cm from the top of the unit to the attachment point.
12.This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. Use handles (not provided) when moving this heater, Keep combustible materials such as furniture, pillows, bedding, papers, clothes and curtains at least 3 feet
(0.9m) from the front of the heater.
