Enduraplas Gold Series, Pro Series Owner's Manual

GOLD SERIES

SS055FG212V

SSP055FG412V60

PRO SERIES

OWNER’S MANUAL

Product Codes:

SSR025FG212V, SSR055FG212V, SSR075FG212V,

SSR100FG212V, SSP025FG412V60,

SSP055FG412V60, SSP075FG412V60,

SSP100FG412V60

Version 1.1 Copyright © Enduraplas. All Rights Reserved.

English

CONTENTS

INTRODUCTION 3

WARNINGS 4 - 5

GETTING STARTED 6 - 9

CALIBRATING 10 - 11

MAINTAINING 12 - 13

CLEANING 14 - 15

STORING/WINTERIZING 16 - 17

TROUBLESHOOTING 18 - 19

WARRANTY 20 - 23

!

PARTS BREAKDOWNS  GOLD SERIES 24 - 25

PARTS BREAKDOWNS  PRO SERIES 26 - 31

2 Gold Series & Pro Series UTV Sprayers

INTRODUCTION

Congratulations! You now own an Enduraplas sprayer. Durable

design and construction assure you a lifetime of extreme
performance. No sprayer is tougher. No sprayer will last longer.

Take a look through this owner’s manual to learn how the pros
use their Enduraplas sprayer.

English

Watch Instruction Videos:

www.youtube.com/enduraplas

Discover More Helpful Tips:

blog.enduraplas.com/spraying

3Version 1.1

English

WARNINGS

1. When connecting this sprayer to your UTV (or vehicle), ensure
that you have read the UTV’s Owner’s Manual and that you
comply with all the weight restrictions as specified by the
UTV’s manufacturer, as overloading can cause injury or death.
Remember that 1 gallon of water weighs 8.33 pounds.

2. To ensure your own safety and that of others, you must
comply with all relevant environmental, work place health,
safety legislation and codes of practice.

3. Select and wear appropriate Personal Protection Equipment in
accordance with the label of the product you intend to use.

4. Care should be taken when spraying in windy conditions
as spray drift may contaminate the air and may affect the
operator or damage adjacent non-target vegetation. It is
recommended that a speed of 6mph is not exceeded.

5. Once the spraying operation has been completed,
decontaminate the spray tank and spray accessories. Dispose
of tank rinsing’s in compliance with current environmental,
work place health and safety regulations.

6. Personal Protection Equipment must still be worn while
decontaminating your sprayer as per warning 3 above.

7. Improper or careless use of this sprayer can cause serious
injury. Minors should never be allowed to use this sprayer.
This sprayer should not be used when bystanders or animals
are in the area. This sprayer should never be used while
children are in the area.

8. Never leave the sprayer unattended without turning off the
pump, relieving the line pressure, and flushing the sprayer of
any harmful chemicals.

9. You must be in good mental health to operate this sprayer
and not be under the influence of alcohol or any drugs
that could impair your vision, physical strength, dexterity,
judgment, or other mental capacity.

!

4 Gold Series & Pro Series UTV Sprayers

10. No modifications and/or alterations may be made to this
sprayer. Any such modifications not only void the sprayer
warranty but can make the unit dangerous to anyone
operating the pump.

11. Always inspect hoses and piping to avoid burst injuries.

English

Watch Instruction Videos:

www.youtube.com/enduraplas

Discover More Helpful Tips:

blog.enduraplas.com/spraying

5Version 1.1

English

GETTING STARTED

Gold Series & Pro Series

1) Unpack hardware and other accessories.

2) On 55, 75 and 100 gallon models, there

are extra mounting points. Use these to
mount a boom.

3) There is also a secondary plumbing port

for mounting a boom.

4) Fill the tank with water.

6 Gold Series & Pro Series UTV Sprayers

GETTING STARTED

Gold Series & Pro Series

5) Obtain the wire harmness and connect it

to the bullet connector at the pump.

6) Hook up the other end to the battery.

English

7) You can also use a 12 volt power plug.
We recommend using the allogator clips for
appropriate pressure.

8) Before running the pump, make sure the

regulator is fully open to avoid premature
wear or damage to the pump.

7Version 1.1

English

GETTING STARTED

9) Sqeeze the hand gun trigger to start

discharge.

10) Adjust pressure to your desired setting.

Whenever possible, maintain pressure
settings that do not cause the pump to
pulsate to maximise the life of the pump.

Connecting a Spray Boom

Please refer to the selected spray boom owner’s manual that

came with the boom.

8 Gold Series & Pro Series UTV Sprayers

English

GETTING STARTED

Hooking up a Boomless Nozzle to your Pro Series

1) Unwrap the boomless nozzle and bolt it

onto the centre of the bar on the back.

2) Run the hose underneath the tank and
plumb them to the pressure regulator,
securing them with the hose clamps.

3) Right-Left pumbing is shown. For further

options, please watched the video on how
to hook up your boomless nozzle.

Watch Instruction Videos:

www.youtube.com/enduraplas

Discover More Helpful Tips:

blog.enduraplas.com/spraying

9Version 1.1

English

CALIBRATING

1) Measure Nozzle Spacing

Measure the distance between each nozzle
to determine the length of your travel
distance.

Nozzle spacing = Distance to travel

(16” = 255’) (18” = 227’) (20” = 204’)
(22” = 185’) (24” = 170’)

*Distances shown with 110° nozzles

2) Measure Appropriate Travel Distance

Mark the distance with flags or between
fence posts. A tape measure capable of
measuring farther than 200 ft. will make
this step easier.

3) Drive Measured Distance - Timed

Driving the sprayer at the intended
spraying speed, time how long it takes
to travel between the marked distance.
Repeat this procedure and average the two
measurements.

4) Set Correct Spraying Pressure

With the sprayer parked and the pump
running, set the ideal or intended pressure.

10 Gold Series & Pro Series UTV Sprayers

For Your Safety, Watch Video:

blog.enduraplas.com/spraying

5) Catch Output From Each Nozzle

Catch the output in a container (marked in
ounces) for the same number of seconds
it took to drive in step 3. Calculate the
‘average nozzle output’ by adding the
individual outputs and then dividing by the
number of nozzles tested.

6) Clean Nozzles - If Needed

If any one nozzle’s output deviates from
the manufacturers’ guidelines by more
than 10%, the nozzle should be replaced or
cleaned. A toothbrush works perfect.

English

7) Analyze Results

The ounces captured per nozzle equals the
gallons-per-acre application rate.
(eg: 16 ounces = 16 gallons-per-acre)

8) Compare Recommended Rate

If the gallons-per-acre rate is not within
5% of the intended rate, you will have to
adjust the pressure you spray at or the
speed you travel. You will have to repeat
steps 3 - 7.

11Version 1.1

English

MAINTAINING

Keeping your sprayer in good condition will help you lengthen
the life of the sprayer. Everyone knows a well maintained piece of
equipment ensures a longer life span. Sprayer maintenance can
seem a huge task if you don’t have the right tools.

Cleaning Your Tank, Hoses & Fittings

Turn the page to see how the pros clean the tank

on their sprayer equipment.

Watch Instruction Videos:

www.youtube.com/enduraplas

Discover More Helpful Tips:

blog.enduraplas.com/spraying

12 Gold Series & Pro Series UTV Sprayers

If required

English

If damaged

Every 250 operating

hours o once a year

After the first 5

operating hours

Weekly or every 40

operating hours

At the end of work

and/or daily

Before starting work

X

pump manual.

X

X X

X X

Read and follow all maintenance and care instructions in the

The information applies in normal operating conditions. The specific intervals must be shortened

accordingly for longer daily working hours. If the machine is only used occasionally, the intervals can

Visual inspection (condition, leaks)XClean

be extended accordingly.

Complete machine

CleanXDrain

Tank, hoses and fittings

Filter basket (inside lid) Clean

CleanXReplace

In-line filter Clean

Spray lance nozzle

All accessible screws and nuts Re-tightenXSafety labels ReplaceXPump Maintain

13Version 1.1

English

CLEANING

1) Drain Tank and Rinse

Rinse all liquid out of the tank. When
flushing the sprayer, pay attention to
where the chemical will run. Always clean
in an area that will not contaminate water
supplies, streams or crops.

2) Pressure Wash Inside Tank

After draining the tank, rinse the inside
by spraying clean water with a pressure
washer.

3) Add Clean Water

It’s now time to shut the pump off and fill
the tank with clean water.

4) Flush Clean Water Through System

Turn the pump on and spray the clean
water through the boom and hand wand.

14 Gold Series & Pro Series UTV Sprayers

For Your Safety, Watch Video:

blog.enduraplas.com/spraying

5) Add Cleaning Solution and Water

Add the recommended cleaning solution to
the tank of water. To mix, run the agitator
inside the sprayer.
Operate for 5 - 10 minutes to mix the
cleaning solution with the water.

6) Let Sprayer Sit For 8 Hours

With the water and cleaning solution left
in the sprayer tank, let it sit for about eight
hours. This will allow the solution to remove
any herbicide from the residues inside the
tank.

English

7) Clean Nozzles, Screens, and Filters

It’s now time to rinse all nozzles, screens
and filters. To clean thoroughly, put them in
a bucket of cleaning agent and water.

8) Rinse Entire System with Water

When all nozzles, etc. are back in place,
give the entire system a complete rinse
to ensure all cleaning solution is flushed
through the unit.

15Version 1.1

English

STORING/WINTERIZING

1) Drain Tank

Fill the tank with clean water, start the
pump and open all spray ends. If you have
a spray gun or boom, make sure you spray
until clean water is coming through.

2) Blow out Plumbing Lines

Using compressed air, blow out the hose
lines to remove all water from the system.

3) Flush with Anti-freeze

Pour a small amount of anti-freeze into
the tank and run the pump until there is no
more of this colored liquid coming through
the spray ends.

4) Store Sprayer Inside

Turn off the sprayer ends so the remaining
anti-freeze does not leak out. If you have
a boom attachment that hangs lower than
the sprayer, we would suggest you set the
sprayer on a few pallets.

16 Gold Series & Pro Series UTV Sprayers

Winterizing a Spray Boom

Please refer to the selected spray boom owner’s manual that

came with the boom.

English

Watch Instruction Videos:

www.youtube.com/enduraplas

Discover More Helpful Tips:

blog.enduraplas.com/spraying

17Version 1.1

English

TROUBLESHOOTING

CONDITION CAUSE REMEDY

Pump will not
prime

Pressure drops/
fluctuates during
standard
operation

1) Insufficient motor
RPM

2) Air leak on suction
plumbing

3) Blocked/Restricted
intake hose

4) Filter cap disengaged

5) Filter gasket

damaged/missing

1) Restriction on suction
line

2) Pump sucking air

3) Plugged filter

4) Damaged regulator

1) Increase motor RPM

until pump primes

2) Tighten/replace
fittings & hose clamps.
Verify suction hoses are
in good condition

3) Remove blockage
from suction line,
ensure line is not
kinked

4) Lock filter cap into
position

5) Replace filter gasket

1) Inspect tank and

suction lines and
remove restriction

2) Tighten fittings

3) Remove and clean

filter mesh and housing

4) Remove regulator
stem and inspect for
broken parts/pieces

Pressure gauge
not registering

18 Gold Series & Pro Series UTV Sprayers

1) Plugged with debris 1) Unthread, check and
clean pressure gauge

CONDITION CAUSE REMEDY

English

Hand gun loses
pressure

1) Debris in hose or

nozzle

2) Pump losing prime

3) Pump pressure

dropping/fluctuating

1) Unthread nozzle tip
and clean

2) See Remedy for
‘Pump will not prime or
loses prime’

3) See Remedy for
‘Pressure drops/
fluctuates during
standard operation’

Watch Instruction Videos:

www.youtube.com/enduraplas

Discover More Helpful Tips:

blog.enduraplas.com/spraying

19Version 1.1

English

LIMITED WARRANTY

1. Poly Tank Limited Warranty - Subject to other terms in this Limited

WARRANTY

Warranty, Manufacturer warrants to the original end user that this
Tank will be free from material defects caused during the
manufacturing process for a period of 5 years from the Purchase
Date provided such warranty to the original end user shall be
extended to 10 years from the Purchase Date if the original end
user registers the Tank with Manufacturer within 30 days of the
Purchase Date. To register the Limited Warranty, registration must
be completed in accordance with the requirements set forth at
enduraplaswarranty.com

Other Products and Parts Limited Warranty - Subject to other
terms in this Limited Warranty, Manufacturer warrants to the
original end user that products and parts manufactured by
Manufacturer (other than tanks) will be free from material defects
caused during the manufacturing process for a period of 1 year
from the Purchase Date unless otherwise expressly stated in
writing by Manufacturer that an extended warranty applies.

2. Other Warranties Disclaimed and Excluded

THERE ARE NO WARRANTIES, EXPRESS OR IMPLIED,
WHICH EXTEND BEYOND THE LIMITED WARRANTY HEREIN
STATED, AND MANUFACTURER EXPLICITLY DISCLAIMS AND
EXCLUDES ANY AND ALL OTHER WARRANTIES INCLUDING
BUT NOT LIMITED TO WARRANTIES OF MERCHANTABILITY,
FITNESS FOR PARTICULAR PURPOSE, CUSTOM OR USAGE
OF TRADE, AND COURSE OF DEALING. NO AGENT,
EMPLOYEE OR REPRESENTATIVE OF MANUFACTURER HAS
AUTHORITY TO BIND MANUFACTURER TO ANY
REPRESENTATION OR WARRANTY EXCEPT AS STATED IN
THIS LIMITED WARRANTY.

20 Gold Series & Pro Series UTV Sprayers

3. Limitation of Liability under the Limited Warranty - In addition to
those warranties disclaimed and excluded in clause 2 above,
Manufacturer expressly further limits its warranty and liability
under the Limited Warranty as set forth below in this clause 3.

3.1. The liability of Manufacturer under this Limited Warranty is

excluded to the extent that any defect has been caused or
contributed to by:

a) any accident, contamination, tampering, willful damage,

abuse, modification, improper storage, improper use
(including but without limitation the storage of material) or
negligent act of, or omission by, any person other than
Manufacturer;

b) the improper installation of the Goods, or deterioration of

the base on which any of the Goods rest or are mounted
to;

c) any damage to the Goods caused by storm, wash away,

landslide, mudslide, lightning, or any other natural
phenomenon, vermin or other pests, and any
undermining of the base of the Tank through any cause
whatsoever;

d) the repositioning of the Goods from their original

installation;

e) weathering or degradation of the Goods due to extreme

climatic conditions;
f) improper installation of extra fittings;
g) any staining or discoloration, including from trees or ash

fall-out from fires or other causes;
h) a Tank not being placed on a base that is free of any

protruding objects of any kind;
i) a Tank being used for any purpose other than the storage

of suitable liquids at the ambient temperatures.

English

21Version 1.1

English

3.2. Without limiting the generality of clause 3.1:
a) Manufacturer will not be liable for any personal injury,

indirect or incidental damages, consequential losses, loss
of liquids, loss of profit or any like claims whatsoever
arising from any use of, or incidental to, or repairs to any
of the Goods by a party other than Manufacturer;

b) to the extent that any component or material (including,

but without limitation the polyethylene) used in the
manufacture of any of the Goods is supplied and/or
manufactured by a third party, the liability of Manufacturer
is limited to Manufacturer’s right of redress (if any)
against the third-party supplier/manufacturer;

c) Tanks feature a vented lid at the time of manufacture.

Any subsequent pressurization of the Tank by removing
the vent, sealing the vent, or otherwise will cause this
Limited Warranty as to such Tank to be null and void.

d) The liability of Manufacturer under this Limited Warranty

is limited to, at Manufacturer's discretion:

e) providing a replacement Good (including shipping but

excluding other replacement costs);

f) refunding an amount equal to a sum equal to the current

Retail price divided by the months in the warranty,
multiplied by the months remaining in the warranty
period;

g) repairing the Good at no cost.

4. Proof of Purchase - The original invoice or other similar proof of
purchase of the applicable must be provided by Purchaser to
Manufacturer when making a claim under this Limited Warranty.
Warranty claims must be received in writing by Manufacturer
within the Limited Warranty period.

22 Gold Series & Pro Series UTV Sprayers

5. Claims and Questions - If you have questions about this Limited

Warranty or to make a warranty claim, contact Manufacturer at:
[e-mail]

6. Definitions - For this Limited Warranty the following definitions

apply:

a) Manufacturer means Enduraplas LLC.
b) Purchase Date means the date upon which the

applicable goods were purchased by the original end
user.

c) Purchase Price means the actual price paid for the Tank

by the original Purchaser.

d) Tank means the storage Tank manufactured by

Manufacturer and purchased by the original end user
Purchaser being the subject matter of the Limited
Warranty.

e) Good(s) mean Tanks and/or other products or parts

manufactured by Enduraplas LLC.

f) Limited Warranty means this written Limited Warranty.

English

7. State Law - Some states do not allow the exclusion or limitation of

incidental or consequential damages, so the above limitation and
exclusion may not apply to certain parties. Some states do not
allow limitation on how long an implied warranty lasts, so the
above limitation may not apply to certain parties. This limited
warranty gives specific legal rights and other rights, which vary
from state to state, may also apply.

8. Governing Law - This Limited Warranty will be governed by the

laws of the State of Minnesota, without giving effect to any choice
of law rule that would cause the application of the laws of any
other jurisdiction

23Version 1.1

English

40 2

4

5

20

17

12

31

10

29

16

33

32

38

22

19

1

9

3439

7

14

11

13

36

37

8

15

29

25

28

6

3

21

18

38

23 27 26

23

28

35

24

OVERVIEW

GOLD SERIES UTV SPRAYER

24 Gold Series & Pro Series UTV Sprayers

PARTS LIST

English

ITEM NO.

1

2

3

4

5

6

7

8

9

10

11 CVS34BX1

12

13

14

15

16

17

18 CFPS01M01B

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

AZFS055

AMTHSSCGY2

AMTHSS055FG

CA3511221

CA300116

CPLF019

APD02G060P

CA309A53

CA9620422

CVAM100

CVSW038

CFBE00M01BA

CFPS00M01B

AZKS0001

CPPDD016

CVSTAL26

CFPT01B

CVGC100

CHMS900213

CHBZ021525

CHNZN0225

CHMS900523 10-24 x 1 PHMSPH SS Screw

CHWSK903

CHBZ020725

CHWZF025

CFBE02B02BC

CLUESB020002

CFCC003

CLUESB020002

CLUESB020001

CLUPCB01

CLUESB020001

CFCC002

CLUESB020001

CA006220

CFCC001

CXSC0002

ASWC01

PART #

Description

55 gal Flat Pack Frame

Cover for 55 SS tank

55 gal spot sprayer tank

8 inch lid

8 inch filter basket

Stallion 2 in Blank Cap

2GPM 60PSI Pump

1 & 2 GPM Black Filter

1 & 2 GPM Regulator

100 PSI Pressure Gauge

1/4" Female x 1/4"Female T-handle Ball Valve

3/8 FPT X 3/8 MPT SWIVEL

.25MPT x .375 HB 45 Brass Elbow

.25 MPT x .375 HB

Stainless Suction Hose Holder Bracket

Shurflo Swivel Elbow with .37 HB

spray gun 18 inch barrel

3/8" MPT x 3/8" Hose Barb Straight

3/8 Hose Barb Tee

Wand Clip

10-32 - 1/2 Pan head screw

5-16 x 3.5 Bolt Grade 5

5/16 Nylock nut

10 X .75 Fender Washer SS

5/16 x 1-1/2 bolt

5/16 Flat washer

1-2" thru tank elbow

.5 EPDM Hose-pump to tank

CLAMP FOR 1/2 HOSE

.5 EPDM Hose-suction inside tank

.375 EPDM Hose-from regulator to HBTEE

5 Meters Coiled Hose

.375 EPDM Hose-from HB Tee to Shutoff valve

CLAMP FOR 3/8 HOSE

.375 EPDM Hose-Shutoff Valve to Quick Connect

Brass Unions 10MM Heavy Combined

12-8 Clamp Cobra for coiled hose

Cable Tie 8"

Wire Harness Kit

QTY.

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

2

2

4

14

4

4

10

20

2

2

5

1

1

1

1

6

1

1

2

6

1

GOLD SERIES UTV SPRAYER

25Version 1.1

English

DETAIL

SCALE

DETAIL

SCALE

OVERVIEW

10

PRO SERIES UTV SPRAYER

32 8

35

11

Detail View
ASBB30

Detail View A

7

9

27

33

39

Detail View
CA463CDP02

5

2

6 4 3 1

3 4

3

12

26 Gold Series & Pro Series UTV Sprayers

DETAIL VIEW A

36 25 38 23 18 19 16 17

English

29

31

30

22 21

3

22

14

24

PRO SERIES UTV SPRAYER

40

37

26

13

34

19 20

42

27Version 1.1

English

PARTS LIST

PRO SERIES UTV SPRAYER

ITEM NO.

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

29

30

31 CFPS01M01B

32

33

34

35

36

37

38

39

40

42

AZFS055

CHBZ020725

CHNZN0225

CHWZF025

AZKS0005

CHBZ020925

AMTHSS055FG

AMTHSSCGY2

CA300116

CA3511221

CPLF019

CHBZ021525

AZKS0001

AZKS0002

CA463CDP02

APD04G060P

CPPDD003

CHMS900523 10-24 x 1 PHMSPH SS Screw

CHWSK903

CHMS900213

AZKS0011

CHBZ020325

CFBE02B02BC

CA309B53

CLUESB020002

CLUESB020002

CPFG15

CVSTAL26SH

CVSW038

ASWC01

CLUESB020004 .75 EPDM Hose Pro Valve Return to Tank

CLUESB020002

CXSC0002

CLUESB020001

CFCC002

CFCC003

CFCW001

CLUPCB01

CFCC001

PART #

Description

55 gal Flat Pack Frame

5/16 x 1-1/2 bolt

5/16 Nylock nut

5/16 Flat washer

Boomless Nozzle Rail 55Gal

5-16 x 2 Bolt

55 gal spot sprayer tank

Cover for 55 SS tank

8 inch filter basket

8 inch lid

Stallion 2 in Blank Cap

5-16 x 3.5 Bolt Grade 5

Stainless Suction Hose Holder Bracket

S.S. MOUNT PLATE FOR PRO SERIES VALVES

Pro Valve Bank

4GPM PSI QA Pump

5900 Series 1/2" Straight

10 X .75 Fender Washer SS

10-32 - 1/2 Pan head screw

Pro Wand Holster PROHSTR

5-16 x .75 Hex Bolt

1-2" thru tank elbow

Suction Filter Quick Coupler

.5 EPDM Hose-pump to tank

.5 EPDM Hose-suction inside tank

3/4 Press fit hose grommet

SPRAY GUN 9 INCH BARREL

3/8 FPT X 3/8 MPT SWIVEL

3/8" MPT x 3/8" Hose Barb Straight

Wire Harness Kit

.5 IN EPDM Hose Pump to Pro Valve supply

Cable Tie 8"

.375 EPDM Hose BN30 to Pro Valve

CLAMP FOR 3/8 HOSE

CLAMP FOR 1/2 HOSE

Clamp for 3/4 hose

5 Meters Coiled Hose

12-8 Clamp Cobra for coiled hose

QTY.

1

8

19

20

1

2

1

1

1

1

1

4

1

1

1

1

1

4

6

2

1

5

1

1

1

1

1

1

1

1

1

1

1

3

2

2

5

1

1

2

28 Gold Series & Pro Series UTV Sprayers

DETAIL VIEW ASBB30

English

ITEM NO.

1

2

3

4

5

6

PART #

CA404072N

CHUZ010925

CFCC002

AXKS0003L

CNBC010

CFPS00M01B

DESCRIPTION

1/4"NPT X QA Swivel

.25 Steel U-bolt with Plate

CLAMP FOR 3/8 HOSE

Pro Boomless Nozzle Bracket-Bent

FC Boomextender 1.0 GPM Green

.25 MPT x .375 HB

QTY.

2

1

2

1

2

2

3

6

4

5

2

1

PRO SERIES UTV SPRAYER

ASBB30

29Version 1.1

English

DETAIL VIEW CA463CDP02

PRO SERIES UTV SPRAYER

ITEM NO.

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

5

PART #

CA461031.010

CFBP00M

CA463080

CV2241GXB100

CA464402.151

CA463001.A10

CA10012

CA10002

CA463000.040

CA463080.A19

CA463911.100

CA2002040

Pro Valve Bolt

3 Pt Lock Nut

Pro Valve Washer

CAG10041

CA106413

CA463080510

14

DESCRIPTION

Manifold Body for 3-way outlet

1/4 NPT Hex Brass Plug

Pressure Relief Control Valve asm.

Pressure gauge 100psi Glycerin filled

Single Auxiliary Cock for Valve

3/8" Hose barb for valve 463

Large Fork Pin

Small Fork Pin

1 inch Male BSP adapter

3/4" Hose barb for valve 463

Mounting Bracket

Fly Nut 1 inch

Bolt for Pro Valve Bank

Lock Nut on Pro Valve Bank

Waher on Pro Valve Bank

Gasket 20mm, hosetail

Hosetail - 1/2 diameter for Fly nut 1 inch

Valve Stem Kit for 463080

2 1 3

QTY.

1

1

1

1

3

3

1

5

1

1

4

1

4

4

4

1

1

1

17 1215131610411867

18

9

CA463CDP02

Handle Only
Part # CPXP02

30 Gold Series & Pro Series UTV Sprayers

English

Watch Instruction Videos:

www.youtube.com/enduraplas

Discover More Helpful Tips:

blog.enduraplas.com/spraying

PRO SERIES UTV SPRAYER

31Version 1.1

English

ACTIVATE YOUR 10YEAR
WARRANTY

How to Activate

To double your 5-year tank warranty, visit

enduraplaswarranty.com and register this product.

Watch Instruction Videos:

www.youtube.com/enduraplas

Discover More Helpful Tips:

blog.enduraplas.com/spraying

32 Gold Series & Pro Series UTV Sprayers

English

STAY CONNECTED

Want to be kept up-to-date on the latest news and information
from Enduraplas? Enduraplas has several ways to get easy access
to news alerts and instant updates on what’s happening in the
world of Enduraplas. Join the Enduraplas Community and connect
with other Enduraplas fans, participate in giveaways, see videos
of Enduraplas products in action, give us input on Enduraplas
products, share your Enduraplas photos, and much more.

FIND US ON FACEBOOK

@enduraplas

WATCH US ON YOUTUBE

YouTube.com/enduraplas

#EngineeredforEndurance

FIND US ON INSTAGRAM

@enduraplas

FIND US ON TWITTER

@enduraplas

33Version 1.1

Enduraplas®

1 [phone]

[e-mail]

www.enduraplas.com

113 1st Street, Neche

ND 58265, USA

Watch Instruction Videos:

www.youtube.com/enduraplas

Discover More Helpful Tips:

blog.enduraplas.com/spraying

Version 1.1 Copyright © Enduraplas. All Rights Reserved.
