Cerámicas Aparici, S.A. | TILES WHITE BODY FOR WALLS
1
TECHNICAL SHEET
BRAND
CERAMICAS APARICI, S.A.
Ctra. Castellón - Alcora, km 12
12130 San Juan de Moró (Castellón) SPAIN
PRODUCT
NAME: GATSBY WHITE TIN, GREEN TIN &
CHARCOAL TIN
SIZE (cm): 20,1 x 20,1
TYPE
OF
PRODUCT
TYPE: Dry-pressed ceramic tiles, with water absorption
Eb> 10% TYPE WHITE BODY
USE: For internal and external walls.
GROUP: BIII
REFERENCED
RULES
ISO-13006:2012 and UNE EN 14411:2013
Characteristics
Test Method
Requirements
Values Compliance
A) DIMENSIONS AND SURFACE QUALITY
Length and width
The work size shall be chosen as follows for:
a) modular tiles:
EN ISO 10545-2
In order to allow a
nominal joint width
of between 2 and 5
mm
PASS
b) non-modular tiles:
EN ISO 10545-2
So that the
difference between
the work size and
the nominal size is
note more than 2%
(maximum 5 mm)
PASS
The permissible deviation of the
average size for each tile (2 or 4
sides) from the work size (W)
Requirements for nominal size N
7cm≤N<15cm
N≥ 15 cm
EN ISO 10545-2
± 0,75 mm
± 2,0 mm ó ± 0,5%
PASS
Thickness
a) The thickness shall be specified
Declared thickness
SEE BOX
b) The permissible deviation, of the
average thickness of each tile from
the work size thickness
Requirements for nominal size N
7cm≤N<15cm
N≥ 15 cm
EN ISO 10545-2
± 0,5 mm
± 0,5 mm ó ± 10%
PASS
Cerámicas Aparici, S.A. | TILES WHITE BODY FOR WALLS
2
Straightness of sides (facial sides)
The maximum permissible
deviation from straightness, related
to the corresponding work sizes.
Requirements for nominal size N
7cm≤N<15cm
N≥ 15 cm
EN ISO 10545-2
± 0,5 mm
± 1,5 mm ó ± 0,3%
PASS
Rectangularity
The maximum permissible
deviation from rectangularity,
related to the corresponding work
sizes.
Requirements for nominal size N
7cm≤N<15cm
N≥ 15 cm
EN ISO 10545-2
± 0,75 mm
± 2,0 mm ó ± 0,5%
PASS
Surface quality
EN ISO 10545-2
A minimum of
95% of the tiles
shall be free from
visible defects that
would impair the
appearance of a
major area of tiles.
PASS
Cerámicas Aparici, S.A. | TILES WHITE BODY FOR WALLS
3
B) PHYSICAL PROPERTIES
Water absorption (in % by mass)
EN ISO 10545-3
Eb > 10%.
When the average
exceeds 20%, this
shall be indicated.
Individual
mínimum value
9%)
PASS
Breaking strength, for:
a) Thickness ≥ 7,5 mm
EN ISO 10545-4
Not less than
600 N
>600 N
b) Thickness < 7,5 mm
EN ISO 10545-4
Not less than
200 N
>200 N
Flexural tensile strength or modulus of rupture
a) Thickness ≥ 7,5 mm
EN ISO 10545-4
Minimum
12 N/mm
2
PASS
b) Thickness < 7,5 mm
EN ISO 10545-4
Minimum
15 N/mm
2
PASS
Coefficient of linear thermal expansion
from ambient temperature to 100º C
EN ISO 10545-8
Declared
Value
5,8- 6,1 x10 -6 (ºC-1 )
Thermal shock resistance
Internal uses
External uses
EN ISO 10545-9
Pass
according to EN
ISO 10545-9
PASS
NOT PASS
Crazing resistance
Glazed tiles
EN ISO 10545-11
Pass
according to EN
ISO 10545-11
PASS
Frost resistance
Internal uses
External uses
EN ISO 10545-12
Pass
according to EN
ISO 10545-12
PASS
NOT PASS
Bond strength/adhesion , for:
cementitious adhesives
EN 12004:2007 +A1:
2012, 4.1
Declared
Value
Type C1
>0.5 N/mm2
Reaction to fire
Class A1
A1
C) CHEMICAL PROPERTIES
Resistencia a productos químicos
Resistance to household chemicals
and swimming pool slats
EN ISO 10545-13
Minimum GB
GA
Resistance to staining, for:
Glazed tiles
EN ISO 10545-14
Minimum 3
5
