Encore IEEE 802.11GWIRELESS BROADBAND ROUTER User Manual

IEEE 802.11g

Wireless Broadband Router

User’s Guide

Regulatory notes and statements

Wireless LAN, Health and Authorization for use

Radio frequency electromagnetic energy is emitted from Wireless LAN devices. The energy
levels of these emissions however are far much less than the electromagnetic energy emissions
from wireless devices like for example mobile phones. Wireless LAN devices are safe for use
frequency safety standards and recommendations. The use of Wireless LAN devices may be
restricted in some situations or environments for example:

·On board of airplanes, or

·In an explosive environment, or

·In case the interference risk to other devices or services is perceived or identified as harmful
In case the policy regarding the use of Wireless LAN devices in specific organizations or

environments (e.g. airports, hospitals, chemical/oil/gas industrial plants, private buildings etc.)
is not clear, please ask for authorization to use these devices prior to operating the equipment.

Regulatory Information/disclaimers

Installation and use of this Wireless LAN device must be in strict accordance with the
instructions included in the user documentation provided with the product. Any changes or
modifications made to this device that are not expressly approved by the manufacturer may
void the user’s authority to operate the equipment. The Manufacturer is not responsible for any
radio or television interference caused by unauthorized modification of this device, of the
substitution or attachment. Manufacturer and its authorized resellers or distributors will assume
no liability for any damage or violation of government regulations arising from failing to
comply with these guidelines.

USA-FCC (Federal Communications Commission) statement

This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions:

1. This device may not cause interference, and

2. This device must accept any interference, including interference that may cause undesired
operation of this device.

i

FCC Radio Frequency Exposure statement

This Wireless LAN radio device has been evaluated under FCC Bulletin OET 65 and found
compliant to the requirements as set forth in CFR 47 Sections 2.1091, 2.1093, and 15.247 (b) (4)
addressing RF Exposure from radio frequency devices. The radiated output power of this
Wireless LAN device is far below the FCC radio frequency exposure limits. Nevertheless, this
device shall be used in such a manner that the potential for human contact during normal
operation is minimized.

When nearby persons has to be kept to ensure RF exposure compliance, in order to comply with
RF exposure limits established in the ANSI C95.1 standards, the distance between the antennas
and the user should not be less than 20 cm.

FCC Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.

This equipment generates, uses, and can radiate radio frequency energy. If not installed and
used in accordance with the instructions, it may cause harmful interference to radio
communications.

However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try and correct the
interference by one or more of the following measures:

1. Reorient or relocate the receiving antenna.

2. Increase the distance between the equipment and the receiver.

3. Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.

4. Consult the dealer or an experienced radio/TV technician for help.

Export restrictions

This product or software contains encryption code that may not be exported or transferred from
the US of Canada without an approved US Department of Commerce export license.

ii

Safety Information

Your device contains a low power transmitter. When device is transmitted it sends out radio
frequency (RF) signal.

CAUTION: To maintain compliance with FCC’s RF exposure guidelines, this equipment
should be installed and operated with minimum distance 20cm between the radiator and your
body. Use on the supplied antenna. Unauthorized antenna, modification, or attachments could
damage the transmitter and may violate FCC regulations.

The antenna(s) used for this transmitter must be installed to provide a separation distance of at
least 20 cm from all persons and must not be co-located or operating in conjunction with any
other antenna or transmitter.

CE Mark Warning

This is a Class B product. In a domestic environment, this product may cause radio interference,
in which case the user may be required to take adequate measures.

Protection requirements for health and safety – Article 3.1a

Testing for electric safety according to EN 60950 has been conducted. These are considered
relevant and sufficient.

Protection requirements for electromagnetic compatibility – Article

3.1b

Testing for electromagnetic compatibility according to EN 301 489-1, EN 301 489-17 and EN
55024 has been conducted. These are considered relevant and sufficient.

Effective use of the radio spectrum – Article 3.2

Testing for radio test suites according to EN 300 328-2 has been conducted. These are
considered relevant and sufficient.

CE in which Countries where the product may be used freely:

Germany, UK, Italy, Spain, Belgium, Netherlands, Portugal, Greece, Ireland, Denmark,
Luxembourg, Austria, Finland, Sweden, Norway and Iceland.

France: except the channel 10 through 13, law prohibits the use of other channels.

iii

TABLE OF CONTENT

ABOUT THIS GUIDE .................................................................................... 1

Purpose........................................................................................................................................ 1

Overview of this User’s Guide................................................................................................... 1

INTRODUCTION ........................................................................................... 2

Applications................................................................................................................................2

Features....................................................................................................................................... 3

UNPACKING AND SETUP.............................................................................. 4

Unpacking................................................................................................................................... 4

Setup ...........................................................................................................................................4

HARDWARE INSTALLATION......................................................................... 5

Front Panel.................................................................................................................................. 5

Rear Panel...................................................................................................................................6

Hardware connections ................................................................................................................ 6

Connect the Router using LAN ............................................................................................... 6

Connect the Router using Wireless LAN ................................................................................ 7

Check the installation ................................................................................................................. 7

PC NETWORK TCP/IP SETTING ................................................................. 8

Windows 95/98/ME.................................................................................................................... 8

Windows 2000............................................................................................................................9

Windows XP............................................................................................................................. 10

WIRELESS BROADBAND ROUTER CONFIGURATION ................................. 11

Login to the Wireless Broadband Router through WLAN....................................................... 11

Login to the Wireless Broadband Router through LAN ..........................................................11

Using the Web Browser............................................................................................................ 11

Configuration Menu.................................................................................................................. 12

Setup Wizard ............................................................................................................................ 13

WAN Setting ............................................................................................................................ 23

DHCP Client or Fixed IP.......................................................................................................23

PPPoE with Obtain IP Automatically.................................................................................... 24

PPPoE with Specify IP .......................................................................................................... 25

PPTP/L2TP with Obtain IP Automatically ........................................................................... 26

PPTP/L2TP with Specify IP.................................................................................................. 26

BigPond Cable....................................................................................................................... 27

Wireless setting......................................................................................................................... 28

Basic....................................................................................................................................... 28

iv

Security.................................................................................................................................. 29

Advanced ............................................................................................................................... 32

LAN Setting.............................................................................................................................. 33

Basic....................................................................................................................................... 33

DHCP..................................................................................................................................... 34

Access Control Setting ............................................................................................................. 35

Filter....................................................................................................................................... 35

Virtual Server......................................................................................................................... 40

Special AP.............................................................................................................................. 41

DMZ....................................................................................................................................... 42

Firewall Rule.......................................................................................................................... 43

System Setting.......................................................................................................................... 44

Password................................................................................................................................44

Time....................................................................................................................................... 45

Device Information................................................................................................................46

Log......................................................................................................................................... 47

Log Setting............................................................................................................................. 48

Statistic................................................................................................................................... 49

Restart.................................................................................................................................... 49

Configuration.........................................................................................................................51

UPnP...................................................................................................................................... 51

Ping Test ................................................................................................................................52

Remote Management.............................................................................................................53

TECHNICAL SPECIFICATIONS ................................................................... 54

v

ABOUT THIS GUIDE

Congratulations on your purchase of this IEEE 802.11g Wireless Broadband Router. This
integrated access device combines Internet gateway functions with wireless LAN and Fast
Ethernet switch. It provides a complete solution for Internet surfing and office resources
sharing, and it is easy to configure and operate for every users.

Purpose

This manual discusses how to install the IEEE 802.11g Wireless Broadband Router.

Overview of this User’s Guide

Introduction. Describes the Wireless Broadband Router and its features.
Unpacking and Setup. Helps you get started with the basic installation of the Wireless Router.
Identifying External Components. Describes the front panel, rear panel and LED indicators

of the Wireless Router.
Connecting the Router. Tells how you can connect the Wireless Router to your xDSL/Cable

Modem.
Technical Specifications. Lists the technical (general, physical and environmental,

performance and Routers settings) specifications of the Wireless Broadband Router.

1

INTRODUCTION

With the explosive growth of the Internet, accessing information and services at any time, day
or night has become a standard requirement for most people. The era of the standalone PC is
waning. Networking technology is moving out of the exclusive domain of corporations and into
homes with at least two computers.

This integrated access device combines Internet gateway functions with wireless LAN and Fast
Ethernet switch. Designed for the business and home, it saves you the cost of installing a
separate modem and ISP line for each computer, while providing ready connection for the users,
with or without the network wires.

Broadband network access is also gaining ground. However, allowing more than two computers
to access the Internet at the same time means less affordable, higher costs. Thus, there is a need
to share one legal IP address over a single Internet connection to link the home with the Internet.

The scarcity of IP addresses and using a shared Internet connection through an Internet sharing
device can solve high network access costs. All linked computers can make full use of
broadband capabilities over such a device.

This device not only comes equipped with a wide range of features, but also can be installed
and configured right out of the box. This device supports a simple local area network and
Internet access share, offering great cost savings.

The local area network connects up home computers while also allowing any of the computers
to access the Internet, share resources, or play online games—the basis of the family computing
lifestyle.

Applications

Broadband Internet access: Several computers can share one high-speed broadband

connection through wireless or wired (WLAN, LAN and WAN-Internet).

Resource sharing: Share resources such as printers, scanners and other peripherals.
File sharing: Exchange data, messages, and distribute files thus making good use of hard disk

space.
Online gaming: Through the local area network, online gaming and e-commerce services can

be easily setup.
Firewall: A built-in firewall function — for security and anti-hack system.

2

Features

9 Compliant with IEEE 802.11g and 802.11b Devices
9 Built-in 4 x 10/100Mbps Auto-MDIX LAN Ports
9 Built-in 1 x 10/100Mbps Auto-MDIX WAN Port (Internet)
9 Supports Cable/DSL Modems with Dynamic IP, Static IP, PPPoE, L2TP, PPTP or BigPond

Connection Types

9 DHCP Server Feature Allocates up to 253 Client IP Addresses
9 Supports 64/128-bit Wired Equivalent Privacy (WEP)
9 Supports WPA, WPA2, WPA-PSK and WPA2-PSK Advanced Security
9 Supports MAC Address, Protocol Filters and UPnP (Universal Plug & Play)
9 Traffic Control with Virtual Server, Virtual PC mapping and DMZ
9 Provides Additional Security with SPI / NAT firewall and Attack Alert via emails
9 Provides Additional Security of Enable/Disable SSID, Password Protection
9 Flash Memory for Firmware Upgrade, Save/Restore Settings, and Traffic Log
9 Compliant with Windows 95/98/NT/2000/XP, Linux and Mac OS
9 Easy Management and Remote Management via Web Browser (HTTP)
9 Range for Indoor of 30 ~ 50 meters (depends on the environment)
9 Range for Outdoor of 50 ~ 200 meters (depends on the environment)

3

UNPACKING AND SETUP

This chapter provides unpacking and setup information for the IEEE 802.11g Wireless
Broadband Router.

Unpacking

Open the box of the Wireless Broadband Router and carefully unpack it. The box should
contain the following items:

 One IEEE 802.11g Wireless Broadband Router
 One 2dBi dipole antenna
 One CD-ROM with User’s Guide
 One AC Power adapter

If any item is found missing or damaged, please contact your local reseller for replacement.

Setup

The setup of the Wireless Broadband Router can be performed properly using the following
methods:

 The power outlet should be within 1.82 meters (6 feet) of the Broadband Router.
 Visually inspect the DC power jack and make sure that it is fully secured to the power

adapter.

 Make sure that there is proper heat dissipation from and adequate ventilation around the

Broadband Router. Do not place heavy objects on the Broadband Router.

 Fix the direction of the antennas. Try to place the Wireless Router in a position that can

best cover your wireless network. Normally, the higher you place the antenna, the better the
performance will be. The antenna’s position enhances the receiving sensitivity.

4

HARDWARE INSTALLATION

Front Panel

The figure below shows the front panel of the Wireless Broadband Router.

Figure 1. Front panel

POWER

This indicator lights green when the hub is receives power, otherwise it is off.

Status

This indicator blinks green means the Internet Broadband Router is working successful.
Otherwise, this indicator always on or off means the function of the Internet Broadband Router
is fail.

WAN (Link/ACT)

The indicators light green when the WAN port was connected to an xDSL/Cable modem
successfully.

The indicators blink green while the WAN port was transmitting or receiving data on the
xDSL/Cable modem.

WLAN (ACT)

This indicator lights green when there are wireless devices connected and transmitting data to
the Wireless Router.

LAN (Link/ACT)

These indicators light green when the LAN ports were connected successfully.
These indicators blink green while the LAN ports were transmitting data.

5

Rear Panel

The figure below shows the rear panel of the Wireless Broadband Router.

Figure 2. Rear Panel

Antenna

There are one 2 dBi Gain Antenna in the rear panel for wireless connection.

LAN (1-4)

Four RJ-45 10/100Mbps Auto-MDIX ports for connecting to either 10Mbps or 100Mbps
Ethernet connections.

WAN

In the four port broadband router, there is an RJ-45 10/100Mbps Auto-MDIX port for the WAN
that will fit the xDSL/Cable modem’s specification need.

DC IN

Plug the power adapter to this power jack

RESET

Use a pin-shape item to push to reset this device to factory default settings. It will be useful too
when the manager forgot the password to login, but the setting will be back to default setting.

Hardware connections

Connect the Router using LAN

1. Plug in one end of the network cable to the WAN port of the Wireless Internet Broadband

Router.

2. Plug in the other end of the network cable to the Ethernet port of the xDSL or Cable modem.

3. Use another network cable to connect to the Ethernet card on the computer system; the other

end of the cable connects to the LAN port of the Internet Broadband Router. Since the
Wireless Broadband Router has four ports, you can connect up to four computers directly to
the unit. There you do not have to buy a switch to connect these computers since one
Internet Broadband Router functions both as a connection-sharing unit and as a switch.

6

Connect the Router using Wireless LAN

Figure 3. Connecting the WLAN Router

1. Plug in one end of the RJ45 network cable to the xDSL/Cable Modem.

2. Plug in the other end of the RJ45 network cable to the Wireless Internet Broadband Router

WAN port.

Check the installation

The control LEDs of the Wireless Internet Broadband Router are clearly visible and the status
of the network link can be seen instantly:

1. With the power source on, once the device is connected to the broadband modem, the Power,

CPU, LAN, WLAN and WAN port link LEDs of the Internet Broadband Router will light
up indicating a normal status.

2. While the WAN is link up to the ADSL/Cable modem, the WAN port’s Link/ACT LED will

light up.

3. While the LAN is link up to the computer system, the LAN port’s Link/ACT LED will light

up.

7

PC NETWORK TCP/IP SETTING

The network TCP/IP settings differ based on the computer’s operating system
(Win95/98/ME/NT/2000/XP) and are as follows.

Windows 95/98/ME

1. Click on the “Network neighborhood” icon found on the desktop.

2. Click the right mouse button and a context menu will be show.

3. Select “Properties” to enter the TCP/IP setting screen.

4. Select “Obtain an IP address automatically” on the “IP address” field.

Figure 4. Windows 95/95/Me IP setup

5. Select “Disable DNS” in the “DNS” field.

Figure 5. Windows 95/98/Me DNS setup

8

6. Select “None” for the “Gateway address” field.

Figure 6. Windows 95/98/Me Gateway setup

Windows 2000

Double click on the “My computer” icon on the desktop. When “My computer” window
opens, open the “Control panel” and then open the “Network dialup connection” applet.
Double click on the “Local area network connection” icon. Select “Properties” to enter the
TCP/IP setting window.

1. In the “Local area network status” window, click on “Properties.”

2. In the “Local area network connection” window, first select TCP/IP setting and then select

“Properties.”

3. Set both “IP address” and “DNS” to Automatic configuration.

Figure 7. Windows 2000 IP and DNS setup

9

Windows XP

Point the cursor and click the right button on the “My Network Place” icon.
Select “properties” to enter the TCP/IP setting window.

1. Set “IP address” to “Obtain an IP address automatically.”

2. Set “DNS” to “Obtain DNS server address automatically.”

Figure 8. Windows XP IP and DNS setup

10

WIRELESS BROADBAND ROUTER CONFIGURATION

First make sure that the network connections are functioning normally.
This Wireless Broadband Router can be configured using Internet Explorer 5.0 or newer web

browser versions.

Login to the Wireless Broadband Router through WLAN

Before configuring the Wireless Broadband Router through WLAN, make sure that the SSID,
Channel and the WEP is set properly.

The default setting of the Wireless Broadband Router that you will use:

 SSID: default
 Channel: 6
 Security: disable
 IP Address: 192.168.1.1

Login to the Wireless Broadband Router through LAN

Before you configure this device, note that when the Wireless Broadband Router is configured
through an Ethernet connection, make sure the host PC must be set on the IP sub-network that
can be accessed by the xDSL/Cable modem. For example, when the default network address of
the xDSL/Cable modem Ethernet interface is 192.168.1.x, then the host PC should be set at

192.168.1.xxx (where xxx is a number between 2 and 254), and the default subnet mask is

255.255.255.0.

Using the Web Browser

1. Open Internet Explorer 5.0 or above Internet browser.

2. Enter IP address

http://192.168.1.1 (the factory-default IP address setting) to the URL web

address location.

Figure 9. Web address

3. When the following dialog box appears, enter the user name and password to login to the

main configuration window, the default username and password is “admin”.

Figure 10. Login

Note: If needed to set a password, then refer to the System – Password Setting.

11

After entering the password, the main page comes up, the screen will display the device
information.

Figure 11. Device information

Configuration Menu

When the main page appears, find the Configuration menu in the left side of the screen. Click
on the setup item that you want to configure. There are six main options: WAN, Wireless, LAN,
Access Control, System and Wizard as shown in the Configuration Menu screen.

Figure 12. Configuration Menu

12
