ENHWI-3GN3
3G MOBILE BROADBAND WIRELESS N150
ROUTER plus REPEATER
The Encore’s ENHWI-3GN3 is a 3G-enabled Wireless-N Router that supports home network with superior throughput, performance and unparalleled wireless range. With ENHWI-3GN3, you can share one 3G Wireless internet subscription to others through wired and wireless LAN. It supports 3G USB Modem Adapters from wide selections of 3G br oa dband carr iers all o ver t he wor ld. A free dom to roam to where your 3G cell subscription site is available and still share and enjoy the Wireless-N’s speed and accuracy. Unlike other wireless 3G routers, the Encore’s ENHWI-3GN3 comes with a WAN port. With WAN port, you are not limited to just 3G connection ; you can still hook up your home or home-offic e DSL or Cable Modem broadband internet connections. With ENHWI-3GN3 you can build a hot spot within home, office, apartment, school, café, construction site, etc. wherever your subscriptio n 3G wireless ISP tower can roam.
With 2 LAN ports, you are not limited to a wireless LA N alone, you can use these ports for your wire d network devices like Encore network printers, Encore Network Attached Storage and many more networking accessories. On top of the popular WPA, WPA2 and WEP wireless security the ENHWI-3GN3 is equipped with a one touch “push-n-connect” button wireless security using the latest
®
technology. The Router function ties it all together and lets your whole network shares a
WPS high-speed cable, DSL and wireless 3G Internet connection s.
The ENHWI-3GN3 is also a Wireless Repeater than can be used to extend your wireless LAN to a remote area with one simple setup switching from Router to Repeat er M ode .
ENHWI-3GN3 Specification Sheet
www.encore-usa.com
Key Features
Bundled with Smart Wizard that helps you set up your router with ease equipped with user friendly step-by-step screen-guided instructions.
Supports up to 4 wireless (SSID) connections that can be used to separate your wireless sharing with groups such as Guests, Family Members, Neighbors, etc., each group can have own connection policies. Easy to install, no need to be a geek to get this feature up and runnin g.
Supports URL Filtering (or web site address filtering) and Keyword Filtering. This easy to set up feature can be use to control internet access use fo r Parent al G uid ance or P arental Control, web site or URL blocking such as specific web sites containing harmful images, etc. Keyword blocking such as harmful words blocking.
Supports Bandwidth Control or Priority Queuing, use mostly for bandwidth hungry applications such as WiFi Multimedia, Audio/Video Streaming and much more.
Compatible with IEEE 802.11n Draft 2.0 Specifica ti on s, pro vi des wir el ess sp eed up to 150 Mbps physical data rate
2x 10/100 Mbps Fast Ethernet port wired LAN with Auto MDI-X function
1x 10/100Mbps WAN port for DSL or Cable Modem with Auto MDI-X function
1x USB Port for 3G USB Modem Adapter (3G USB Modem not included)
Supports wireless data encryption with 64/128-bit WEP standard for security
Supports enhanced security with WPA-PSK, WPA2-PSK, Auto WPA and WPA2
Supports WPS™ (Wi-Fi Protected Setup Specification Windows) PIN and PBC
Web-based configuration tools and manage me nt using popular WEB Browsers
Supports PPPoE / PPTP / L2TP protocol for xDSL ISP connection
Supports NAT feature to share one public IP address to all LAN private users
Supports DHCP Server / Client
Supports Firewall protection, Virtual server mapping, Special application setting
Supports UPnP
AP Router to Repeater Mode. ENHWI-3GN3 can be a wireless repeater too. Just switch mode
from AP Router Mode to a Wireless Repeater Mode
ENHWI-3GN3 Specification Sheet
www.encore-usa.com
HARDWARE SPECIFICATIONS
MCU Memory
Flash Memory Physical Interface
LEDs Status
Power Requirements
RT3050, 320MHz embedded RF/MAC/BBP 32MB SDRAM
4MB WAN: 1x 10/100 Fast Ethernet RJ-45 LAN: 2x 10/100 Fast Ethernet RJ-45 Reset button Power Port Jack
Press-n-Connect Push Button USB Port (for 3G USB Modem Adapter)
Power Status WAN (For DSL and Cable Modem WAN hookup)
Internet Connection Detector 10/100Mbps LAN1 & LAN2
WLAN (Wireless connection) 3G Network
Power Supply: (Full Range) 200 to 240 VDC ± 10 (ETSI) 100 to 120 VDC ± 10 (FCC)
Input: 12 VDC/1.25 A
Note:
1. WAN can either be USB port or WAN port. USB is the default WAN.
RF SPECIFICATION
Frequency Band
Modulation Technology
Operating Channels
2.4002.484 GHz
OFDM: BPSK, QPSK, 16-QAM, 64-QAM
DBPSK, DQPSK, CCK
3G / 3.5G: WCDMA (HSDPA), CDMA2000 & TD-SCDMA
11 for North America, 14 for Japan and 13 for Europe
ENHWI-3GN3 Specification Sheet
www.encore-usa.com
Wireless Settings
W ireless Mode – 802.11b / 802.11g /802.11n Draft 2.0
Channel Selection (Varies by Country or Region)
Channel Bandwidth (Auto 20/40 MHz, 20MHz, 40MHz)
Transmission Rate
- 11g: Best=54, 48, 36, 24, 18, 12, 11, 9, 6, 5.5, 2, 1 in Mbps
Guard Interval 800 ns Guard Interval 400 ns
MCS
20MHz
40MHz
20MHz
40MHz
Index
(Mbps)
(Mbps)
(Mbps)
(Mbps) 0 6.5 13.5 7.2 15 1 13 27 14.4 30 2 19.5 40.5 21.7 45 3 26 54 28.9 60 4 39 81 43.3 90 5 52 108 57.8 120 6 58.5 121.5 65 135 7 65 135 72.2 157.5
Receive Sensitivity (Typical)
Available Transmit Power
Antenna X1
IEEE802.11n - MCS0@ -91dBm, MCS7@ -74dBm
IEEE802.11g - 6Mbps@ -90dBm, 54Mbps@ -70dBm
IEEE802.11b - 1Mbps@ -90dBm, 11Mbps@ -87dBm
IEEE802.11n - MCS7@ 15dBm
IEEE802.11g - 6~54 Mbps@ 15dBm
IEEE802.11b - 1, 11Mbps@ 16dBm
Peak Gain = 2 dBi with SMA connector
Environmental and Physical
Temperature Range 0 to 45° C - Operating, -10 to 70 ° C - Storage
Humidity (non-condensing)
Dimensions 138mm (L) x 97mm (W) x 25mm (H)
15%95% typical
ENHWI-3GN3 Specification Sheet
www.encore-usa.com
Currently Supported 3G USB Modems
Vendor Model Number Vendor Model Number
AT&T (Sierra Wireless USA)
Huawei
USB 305
E169G E170 E172 E176 E220 E272 Vodafone K3565
EMOBILE
D02HW
D12HW D21HW D22HW D23HW D11LC D12LC
D21LC
BandRich (BandLuxe)
Sierra
Option
Novatel
NU Sony Ericsson
ZTE
E1750 C100S C120 C270 Aircard 888U (Aircard 888)
ICON 225 (GIO
225)
Ovation MC950D MU-Q101
MD300 MF626 Vodafone K3565-Z Vodafone K3520-Z
Docomo
SoftBank
WILLCOM
WILLCOM CORE 3G IIJ mobile ASUS
b-mobile3G
L-02A A2502 L-05A C01LC C01SW AX530S WS002IN USB-WSIM NS001U HX001IN HX002IN 110FU T500
BM-DL3-150H BM-DC1-500M
NOTE: The table shown above lists 3G USB modems that are currently supporting at time of this writing. Please check our web site frequently for updates. More and more 3G USB Modems will be added from time to time.
ENHWI-3GN3 Specification Sheet
www.encore-usa.com
SOFTWARE FEATURES
Router and Gateway
Topology
Operating Modes
LAN
WAN
Router
Infrastructure AP / Router / WDS
DHCP Server
Static Routing Table
UPnP
PPTP, PPPoE, 3G, L2TP
Static IP
DHCP Client
Clone MAC
NAT/ NAPT
Static Routing
Dynamic Route
Virtual Server Mapping
IP Address Mapping
Port Forwarding
Port Triggering
Special Application
ALG (Application Layer Gateway), supports (RTP/RTSP,
AOL, FTP, CMP, WMP/MMS, NetMeeting, SIP)
DNS Relay
DDNS
Time Zone (NTP client)
Firewall
VPN
Ping blocking
DoS (Blocking Ping, Port scan, Sync Flood)
MAC / IP Filtering
ICMP Blocking
SPI (Stateful Packet Inspection)
DMZ (Demilitarized Zone) Host
Policy Based Parental Controls
Port Range / Service Filtering
Internet Domain Restriction
Dynamic URL Filtering / Keyword Filtering
VPN pass-through (PPTP, L2TP, IPSEC)
ENHWI-3GN3 Specification Sheet
www.encore-usa.com
Wireless
Power Saving Mode (Green Technology)
64/128 bit WEP Encryption
WPA Persona l (WPA-PSK using TKIP or AES)
WPA Enterprise (WPA-EAP using TKIP)
802.1x Authenticator
Hide SSID in beacons
Press and Connect Push Button
WDS
ACL control
Best channel selection
Speed / Bandwidth monitor
QoS
WMM (Wi-Fi Multimedia)
Application base
o Priority Queue o Bandwidth Allocation
ENHWI-3GN3 Management
Configuration Web-based configuration (HTTP) using popular web browsers Firmware Upgrade
Administrator Setting
Reset Setting
System monitoring
Via webpage upgrade
Auto recovery once fir mware upgrade fail
Administrator password change
Idle time out
Reboot
Reset to Factory Default
Speed and Bandwidth monitoring
Scheduling
Easy access
Install smart wizard
Enable Firewall
Enable power saving
Users can type the router’s model name to access the
User Interface main page.
Guide the users with ease for a user-friendly the initial router setup
