Enabling Devices Switch Adapted Aqua Dome Multisensory Therapeutic Learning Toy User Guide User Guide

Aqua Dome #1691

USER’S GUIDE

A soft rainbow of slowly changing lights glimmer through gently flowing
water, while soothing music completes this multi-sensory experience of
sight, sound and touch. The Aqua Dome is capability-switch adapted and
can be used with or without music. Size: 14"L x 14"W x 7"H. Requires 6 C
Batteries. Weight: 3 lbs.

Operation:

1. The Aqua Dome requires 6 C size batteries Use alkaline batteries only
(e.g. Duracell or Energizer brand). Do not use rechargeable batteries or
any other type of batteries because they supply lower voltage and the
unit will not perform properly. Never mix old and new batteries together
or different brands or types together.

Operation:

1. To install the batteries, carefully turn the unit over to reveal the battery

compartments. Next remove the screws from the covers and lift off.
Next install 6 C cell batteries into the holder. Use alkaline batteries
only (e.g. Duracell or Energizer brand). Do not use rechargeable
batteries or any other type of batteries because they supply lower
voltage and the unit will not perform properly. Never mix old and new
batteries together or different brands or types together. Please note to
follow proper (+) & (-) battery polarity. Replace covers and screws.

2. Fill the Aqua Dome with water, until the base below the dome is just

covered with water. Do not fill passed this or the water will overflow. To
use the Aqua Dome with an external switch first set the ON/OFF switch
to OFF. There is also a switch to turn the Music ON or OFF. If you want
music then set this to ON. If not set the Music switch to OFF.

3. Plug your external capability switch (Not Included) into the female 1/8"

cord jack which runs out from under the base of the unit. Make sure
to plug your switch in all the way. There should be no gaps. Activating
your switch will start a soft rainbow of slowly changing lights glimmer
through gently flowing water, while soothing music completes this
multi-sensory experience of sight, sound and touch. Once the switch is
released all will stop. For continuous play without an external switch,
turn the built in ON/OFF switch to ON. Music can also be turned ON or
OFF.

Troubleshooting:

Troubleshooting:

Troubleshooting:Troubleshooting:

Problem:

Problem: Aqua Dome does not turn on when switch is depressed.

Problem:Problem:

Action #1:

Action #1: Make sure that your switch is plugged in all the way. Any gaps

Action #1:Action #1:
will interrupt electrical connection.

Action #2:

Action #2: Make sure batteries are fresh.

Action #2:Action #2:

Action #3:

Action #3: Try a different switch with Aqua Dome to rule it out as the source

Action #3:Action #3:
of the problem.

Problem:

Problem: The water does not flow.

Problem:Problem:

Action #1:

Action #1: Check and or replace the 6 C cell batteries with fresh batteries.

Action #1:Action #1:

Action # 2:

Action # 2: Make sure you have enough water in the base for the pump to

Action # 2:Action # 2:
run.

Action # 3:

Action # 3: Turn unit OFF. Gently blow into the hole on top of the dome (you

Action # 3:Action # 3:
should hear a bubbling noise). Pump should now be primed and working
properly.

Care of Unit:

Care of Unit:

Care of Unit:Care of Unit:
Empty the water from The Aqua Dome when you are finished using it, and
then wipe the inside with a paper towel or cloth, and let air dry.

Aqua Dome can be wiped clean with any household multi-purpose cleaner
and disinfectant.

Do not submerge the unit in any fluids, as it will damage the contents and
the electrical components.

Do not use abrasive cleaners, as they will scratch the surface of the unit.
