Page 1
(Continued)
Problem: Billy Fun Wheels does not react, or reacts poorly to
operation by controller.
Cause: High-frequency interference occurred near to high-voltage
lines,
transformers and some types of building.
Action: Avoid these if possible, or choose another place to operate
Billy Fun Wheels.
Problem: Loss of control.
Cause: Another radio control vehicle using the same frequency is
operated near your vehicle. Please Note: do not use Billy Fun
Wheels near each other. Out of sight or the control range of distance.
(1 to 25 feet.)
Action: Move to another place where radio frequency interference
from another device or vehicle is not present.
Care of Unit:
Billy Fun Wheels can be wiped clean with any household multipurpose cleaner and disinfectant. We recommend Simple Green, which
is a non toxic biodegradable all-purpose cleaner.
Do not submerge the unit, as it will damage the contents and the
electrical components.
Do not use abrasive cleaners, as they will scratch the surface of the
unit.
For Technical Support:
Call our Technical Service Department
Monday through Friday, 9 a.m. to 5 p.m. (EST)
1-800-TEC-TOYS or 1-800-832-8697
Billy Fun Wheels #2102
USER’S GUIDE
50 Broadway
Hawthorne, NY 10532
Tel. 914.747.3070 / Fax 914.747.3480
Toll Free 800.832.8697
www.enablingdevices.com
Page 2
Radio control monster truck!
Activate our specially designed controller and Billy Fun Wheels will
go forward, backward, right and left. Push the red button in the middle
of the controller and you will hear the horn beep while mini headlights
light up and the engine roars when moving forward. A warning signal
plays when the truck reverses. A great toy for teaching directionality.
Truck Size: 6"L x 5 1/2"W x 5 1/4"H; Controller Size: 6"Diameter x 2
3/4"H. Requires 4 AA and 3 AAA Batteries.
Operation:
1. Billy requires 4 AA batteries (Not included). Use alkaline batteries
only (e.g. Duracell or Energizer brand). Do not use rechargeable
batteries or any other type of batteries because they supply lower
voltage and the unit will not perform properly. Never mix old and
new batteries together or different brands or types together.
2. To install the batteries in the car, first turn the car over. Next
remove the screw holding the battery compartment door and lift
the cover off. Pull the battery holder out and install 4 AA batteries
following proper (+) & (-) battery placement. Replace holder and
battery cover. Turn the car’s ON/OFF switch located on the bottom
of the car to ON.
3. To install the battery for the big button remote control, turn the
remote over and locate the small screw on the battery cover door.
Using a Phillips head screwdriver open the compartment and
install 3 AAA batteries paying close attention to proper battery
polarity. Replace the battery compartment cover and secure with
the screw. Set the On/Off toggle switch to On.
4. This big button controller allows the user to move Billy Fun
Wheels forward, reverse, left or right. Push the red button in the
middle of the controller and you will hear the horn beep while mini
headlights light flash. Slight pressure on the control button in any
of the four directions will drive Billy Fun Wheels in that direction.
Once you release pressure on the button Billy Fun Wheels will
stop.
5. When you are finished using Billy Fun Wheels turn the On/Off
switch on the car and controller to Off, this will help conserve
battery power. If Billy Fun Wheels is not going to be used for a
long period of time, e.g. one month or longer, we recommend
removing the batteries from the car and controller during storage to
prevent battery drain or leakage, which can cause damage to Billy
Fun Wheels and big button controller.
6. Billy Fun Wheels has an adjustable front wheel alignment
adjustment knob located directly under the front wheels. This only
needs adjustment if the car’s front wheels are knocked out of
alignment, which will cause the car to run to the left or right. You
can also adjust the wheel alignment to the extreme left or right to
make the car drive in a circle.
Troubleshooting:
Problem: Billy Fun Wheels is not running.
Action: Make sure batteries in the car and the controller are fresh and
installed following proper (+) & (-) battery placement.
Problem: Billy Fun Wheels is running intermittently.
Action: Replace batteries in the big button remote control and car.
Weak batteries will severely limit the normal transmitting range of
your remote control.
(Continued on back page)
Rev 9/3/10
