Mini Gum Ball Switches #783R, B, G, Y, P
USER’S GUIDE
For Technical Support:
For Technical Support:
For Technical Support:For Technical Support:
Call our Technical Service Department
Monday through Friday, 9 a.m. to 5 p.m. (EST)
1-800-832-8697
customer_support@enablingdevices.com
50 Broadway
Hawthorne, NY 10532
Tel. 914.747.3070 / Fax 914.747.3480
Toll Free 800.832.8697
www.enablingdevices.com
The Mini-Gumball switch is versatile and durable. It has a 1¼ inch
activation surface. This switch is small enough to be easily mounted
anywhere. Base has three holes for easy mounting. It provides tactile
and audible feedback. Mounting plate is removable. Size: 2"Base x
½"H. Weight: 1 oz.
Operation:
Operation:
Operation:Operation:
1. The Mini Gum Ball Switch does
not
not
require any batteries to
notnot
operate. The base is removable if desired. To remove the base
turn the switch over and unscrew the two Phillips Head screws.
Next pull the base ring off the switch. After the base has been
removed you can place the included piece of non skid rubber, to
give the switch a firm grip on smooth surfaces.
2. Plug the Mini Gum Ball Switch into the jack on your switchadapted toy/device.
4. If it is necessary for you to use an adapter, make sure that you use
a MONO adapter, not a STEREO adapter.
5. Make sure that the connection between the Mini Gum Ball Switch
and your toy/device is tight. There should be no gaps.
6. Simply press anywhere on the Mini Gum Ball Switch’s colored top
to activate your toy/device.
7. The toy/device will only remain activated while the Mini Gum Ball
Switch continues to be actuated. Once you release the switch, the
toy/device will turn off.
Troubleshooting:
Troubleshooting:
Troubleshooting:Troubleshooting:
Problem:
Problem: The Mini Gum Ball Switch does not activate your
Problem: Problem:
toy/device.
Action #1:
Action #1: Make sure that the connection between the Mini Gum Ball
Action #1: Action #1:
Switch and your toy/device is tight. There should be
no
no
gaps. This is a
no no
common error and an easy fix.
Action #2:
Action #2: Try a different switch with your toy/device to rule out the
Action #2: Action #2:
toy/device as the source of the problem.
Action #3:
Action #3: Try a different adapter (if applicable) to rule this out as the
Action #3: Action #3:
source of the problem.
Care of Unit:
Care of Unit:
Care of Unit:Care of Unit:
The Gum Ball Switch can be wiped clean with any household multipurpose cleaner and disinfectant. We recommend Simple Green,
which is a non toxic biodegradable all-purpose cleaner.
Do not submerge
Do not submerge the unit, as it will damage the contents and the
Do not submergeDo not submerge
electrical components.
Do not use abrasive cleaners,
Do not use abrasive cleaners, as they will scratch the surface of the
Do not use abrasive cleaners,Do not use abrasive cleaners,
unit.
Rev
Rev 2222/14
/14/1
/14/14
/17777
/1/1
Rev Rev
