Page 1
(Continued)
Action: Avoid these if possible, or choose another place to
operate RC Stunt Car.
Problem: Loss of control.
Cause: Another radio control vehicle using the same frequency
is operated near your vehicle. Please Note: do not use two RC
Stunt Car’s near each other. Out of sight or the control range
of distance. (1 to 25 feet.)
Action: Move to another place where radio frequency
interference from another device or vehicle is not present.
Care of Unit:
RC Stunt Car can be wiped clean with any household multipurpose cleaner and disinfectant. We recommend Simple
Green, which is a non toxic biodegradable all-purpose cleaner.
Do not submerge the unit, as it will damage the contents and
the electrical components.
Do not use abrasive cleaners, as they will scratch the surface
of the unit.
For Technical Support:
Call our Technical Service Department
Monday through Friday, 9 a.m. to 5 p.m. (EST)
1-800-832-8697
RC Stunt Car #3092
USER’S GUIDE
50 Broadway
Hawthorne, NY 10532
Tel. 914.747.3070 / Fax 914.747.3480
Toll Free 800.832.8697
www.enablingdevices.com
Page 2
Perform stunts, 360-degree axle spins, and incredible wheelies
when you activate our easy-to-use controller. Bright multicolor
flashing lights and sound effects add to the excitement. Enjoy
hours of fast-paced action. Great for increasing visual attention.
Car size: 5"L x 5"W x 4½"H; Remote size: 5"L x 5"W x 2½"H. Car
requires 4 AA Batteries; Remote requires 2 AA Batteries. Weight:
1½ lbs.
Operation:
1. The RC Stunt Car requires 4 AA batteries (Not included).
Use alkaline batteries only (e.g. Duracell or Energizer
brand). Do not use rechargeable batteries or any other type
of batteries because they supply lower voltage and the unit
will not perform properly. Never mix old and new batteries
together or different brands or types together.
2. To install the batteries in the car, first turn the car over. Next
remove the screw holding the battery compartment door and
lift the cover off. Install 4 AA batteries following proper (+) &
(-) battery placement. Replace cover and screw. Turn the
car’s ON/OFF switch located on the bottom of the car to ON.
3. To install the battery for the big button remote control, turn
the remote over and locate the small screw on the battery
cover door. Using a Phillips head screwdriver open the
compartment and install 2 AA batteries paying close
attention to proper battery polarity. Replace the battery
compartment cover and secure with the screw. Set the
On/Off toggle switch to On.
4. This big button controller allows the user to move RC Stunt
Car forward, reverse, left or right. (Please Note: The front
wheels spin left or right like a propeller, they do not turn like
a normal car. Push the green button in the middle of the
controller and you will hear car sound effects and music.
5. Slight pressure on the control button in any of the four
directions will drive RC Stunt Car in that direction. Once you
release pressure on the button RC Stunt Car will stop.
6. When you are finished using RC Stunt Car turn the On/Off
switch on the car and controller to Off, this will help conserve
battery power. If RC Stunt Car is not going to be used for a
long period of time, e.g. one month or longer, we
recommend removing the batteries from the car and
controller during storage to prevent battery drain or leakage,
which can cause damage to RC Stunt Car and big button
controller.
Troubleshooting:
Problem: RC Stunt Car is not running.
Action: Make sure batteries in the car and the controller are
fresh and installed following proper (+) & (-) battery placement.
Problem: RC Stunt Car is running intermittently.
Action: Replace batteries in the big button remote control and
car. Weak batteries will severely limit the normal transmitting
range of your remote control.
Problem: RC Stunt Car does not react, or reacts poorly to
operation by controller.
Cause: High-frequency interference occurred near to highvoltage lines, transformers and some types of building.
(Continued on back page)
Rev: 8/29/17
