Ethernet Extension Experts
Enable-IT 865 PTZ
56V PoE+ & Ethernet Extender
User Manual
All Rights Reserved 1997 - 2011 ENABLE-IT - Proprietary and Confidential
Page 2
Copyright © 1997-2011 Enable-IT, Inc. All rights reserved. No part of this documentation
may be reproduced in any form or by any means or use d to make any derivat ive work (such
as translation, transformation, or adaptation) without written perm ission from Enable-IT, Inc.
Enable-IT, Inc reserves the right to revise this documentation and to make changes in
content from time to time without obligation on the part of Enable-IT, Inc to provide
notification of such revision or change.
Enable-IT, Inc provides this documentation without warranty, term, or conditio n of any kind,
either implied or expressed, including, but not limit ed to, the implied warranties, terms or
conditions of merchantability, satisfactory quality, and fitness for a particular purpose.
Enable-IT, Inc may make improvements or changes in the product(s) and/or the
program(s) described in this documentation at any time.
If there is any software on removable media described in this doc umentation, it is furnished
under a license agreement included with the product as a separate document, in the hard
copy documentation. If you are unable to locate a copy, please cont act Enable-IT, Inc and a
copy will be provided to you.
UNITED STATES GOVERNMENT LEGEND
If you are a United States government agency, then this documentation and the software
described herein are provided to you subject to the following:
All technical data and computer software are c ommercial in nature and developed solely at
private expense. Software is delivered as "Commercial Computer Software" as defined in
DFARS 252.227-7014 (June 1995) or as a "commercial item" as def ined in FAR 2.101 (a)
and as such is provided with only such rights as are provided i n Enable-IT, Inc's standard
commercial license for the Software.
Technical data is provided with limited rights only as provided in DFAR 252.227-7015 (Nov
1995) or FAR 52.227-14 (June 1987), whichever is applic able. You agree not to remove or
deface any portion of any legend provided on any licensed program or documentation
contained in, or delivered to you in conjunction with, this User Guide.
Unless otherwise indicated, Enable-IT, Inc registered trademarks are registered in the
United States and may or may not be registered in other countries
Page 2 of 14 Ethernet Extension Experts
Page 3
CONTENTS
ABOUT THIS GUIDE 4
1
INTRODUCING THE ENABLE-IT 865 PTZ & EXTENDED ETHERNET KIT 5
About the 865 PTZ & Extended Ethernet Kit 5
Key Benefits 6
Summary of Features 6
Multi Use Applications 7
2 INSTALLING THE ENABLE-IT 865 PTZ & EXTENDED ETHERNET KIT 8
Site Plan – Installation Design Considerations 8
Unpacking the 865 PTZ Extended Ethernet Kit 9
Perform an out of the box Test 9
Performing the On-Site Installation 10
Mounting the 865 PTZ & Extended Ethernet Kit 10
Building the 865 PTZ Interlink wiring 10
Troubleshooting and Performance settings (Dip switch) 11
3 TECHNICAL SUPPORT
Online Technical Services 12
World Wide Web Site 12
Returning Products for Repair 12
4 ENABLE-IT INC. LIMITED WARRANTY 12
5 CONTACT US 14
Page 3 of 14 Ethernet Extension Experts
Page 4
ABOUT THIS GUIDE
This guide provides all the information needed to install and use the Enable-IT
865 PTZ & Extended Ethernet Kit. This guide is intend ed for use by technicians
who are responsible for installing and setting up network equipment.
Consequently, it is assumed that the installer has a basic working knowledge of
LANs (Local Area Networks) and voice telecom wiring.
If the information in the release notes that are shipped with your product differs
from the information in this guide, follow the instructions in the release notes.
Most user guides and release notes are available in Adobe Acrobat
Reader Portable Document Format (PDF) or HTML on the Enable-IT World Wide
Web site: http://www.ethernetextender.com/manuals/865_Manual.pdf
Page 4 of 14 Ethernet Extension Experts
