Owner’s Manual
Owner’s Manual
© 2006 E-MU Systems
All Rights Reserved
E-MU World Headquarters
E-MU Systems
1500 Green Hills Road
Scotts Valley, CA 95066
USA
Asia Pacic Africa, Middle East
Creative Technology Ltd
31 International Business Park
Creative Resource, Singapore 609921
SINGAPORE
Europe
Creative Labs (Ireland) Ltd
Ballycoolin Business Park
Blanchardstown, Dublin 15
IRELAND
Japan
Creative Media K. K.
Kanda Eight Bldg., 3F
4-6-7 Soto-Kanda
Chiyoda-ku, Tokyo 101-0021
JAPAN
E-MU® Xmidi 2x2
32 MIDI Channels • Plug-and-Play
Bus-powered • Ultra-fast MIDI Response
Thank you for purchasing the E-MU Xmidi 2x2
USB MIDI interface. The Xmidi 2x2 connects to
your computer via USB and provides two MIDI
input and output ports.
Package Contents
E-MU Xmidi 2x2
•
USB Cable (2-meters)
•
Carrying Pouch
•
Owner’s Manual
•
E-MU Software/Manual CD-ROM with:
•
Windows XP and x64 drivers
–
Owner’s Manual PDF
–
System Requirements
PC
Microsoft® Windows® XP SP2 or greater
•
or Windows XP x64
Intel® or AMD® processor – 600MHz or
•
faster
128MB RAM
•
1 Available USB port
•
CD-ROM or DVD-ROM drive
•
Mac
Apple® Mac® OS X 10.3.9 or greater
•
450MHz G4 processor or faster
•
128MB RAM
•
1 Available USB port
•
CD-ROM or DVD-ROM drive (for manual)
•
Setting up the Xmidi 2x2
Connect the Xmidi 2x2 to your computer using
the supplied USB cable. If you use a hub, it must
be powered.
When properly connected, the Xmidi 2x2
Power LED illuminates when your computer is
on and awake. Windows users MUST install the
Xmidi 2x2 drivers from the included CD.
Windows XP Drivers
To install your E-MU Xmidi 2x2 interface on
Windows XP:
Connect the Xmidi 2x2 to your computer
1.
using the provided USB cable.
Insert the CD labelled “Software/Manual
2.
Installation.”
When the “Welcome to E-MU Software
3.
Setup” dialog box appears, follow the onscreen instructions.
If you encounter the “Windows Logo-
4.
Testing” warning screen, click Continue
Anyway.
When prompted, restart your computer.
5.
Your Xmidi 2x2 is now ready to use.
Mac OS X Drivers
You don’t need to install any drivers for Mac
OS X. Simply connect the Xmidi 2x2 to your
computer using the provided USB cable.
The Xmidi 2x2 will appear as a MIDI Device with
two pairs of in and out ports in your Audio MIDI
Setup utility. Create and connect the appropriate
devices in the Audio MIDI Setup Utility.
Using the Xmidi 2x2
MIDI 1
Out
Out
Power
In
In
1
2
The Xmidi 2x2 has two pairs of MIDI In and
Out Ports. The rst set is located on the front,
and the second on the back.
4
1
MIDI 1 In & Out Connectors
1.
Connect a MIDI device’s input and/or output to these 5-pin DIN connectors.
MIDI Activity LEDs
2.
These LEDs Illuminate when activity occurs
on the corresponding inputs or outputs.
Power LED
3.
This LED Illuminates when the Xmidi 2x2 is
receiving power via USB.
MIDI 2 In & Out Connectors
4.
Connect a second MIDI device’s input and/
or output to these 5-pin DIN connectors.
USB Connector
5.
Plug the provided USB Cable into this
connector and your computer.
2
5
3
Applications
The Xmidi 2x2 works with any application that
requires/utilizes MIDI.
Windows XP
In software such as E-MU Proteus X, Steinberg
Cubase, or Cakewalk Sonar, the Xmidi 2x2 In
and Out ports will appear as:
E-MU XMidi 2X2 Midi In 1
•
E-MU XMidi 2X2 Midi In 2
•
Mac OS X
In most audio applications, the Xmidi ports
should appear as the name of whatever device
you attached to them in the Audio MIDI Setup
utility.
Uninstalling
Windows XP users should make sure the
device is unplugged from the computer before
running the uninstaller.
Specications
2 MIDI in / 2 MIDI out
•
USB 1.1
•
USB bus-powered
•
Ultra-fast MIDI response
•
Active-Sensing messages ltered
•
MME, DirectMusic, and CoreMIDI support
•
Multiple device support
•
The use of the WEEE symbol indicates that this product may not be treated as household waste. By ensuring
this product is disposed of correctly, you will help protect the environment. For more detailed information
about the recycling of this product, please contact your local authority, your household waste disposal service
provider or the shop where you purchased the product.
Ce WEEE symbole indique que ce produit ne peut pas être traité comme un déchet ménager. En veillant à vous
débarrasser correctement de ce produit, vous participerez activement à la protection de l’environnement.
Pour de plus amples détails sur le recyclage de ce produit, consultez les autorités compétentes locales, votre
centre de traitement des déchets ou votre revendeur.
Das WEEE-Symbol weist Sie darauf hin, dass dieses Produkt nicht als Hausmüll behandelt werden darf. Indem Sie eine korrekte
Ent-sorgung des Produkts sicherstellen, tragen Sie zum Umweltschutz bei. Nähere Informationen über das Recycling dieses Produkts
er-halten Sie bei der zuständigen Verwaltungsbehörde, der Müllabfuhr oder dem Geschäft, in dem Sie das Produkt gekauft haben.
O usu deste símbolo indica que este produto não pode ser tratado como lixo comum. Dispensando este produto corretamente
ajudará a proteção do meio ambiente. Para maiores informaçõs sobre reciclagem deste producto, entre em contato com as autoridades locais, or seu fornecedor de serviços de lixo ou a loja onde você adquiriu o produto.
El uso del símbolo WEEE indica que este producto no debe ser tratado como basura ordinaria. Al asegurarse de que este producto
sea eliminado correctamente estará ayudando a la protección del medio ambiente. Para más información acerca del reciclaje de este
producto, contacte con la autoridad de reciclaje local, su servicio de recogida de basuras o con el comercio en el que haya adquirido
este producto.
WARNING: The cord(s) included with this product may contain chemicals known to the State of California to cause cancer and birth
defects or other reproductive harm. Wash hands after handling.
