Movie Cube
User’s Guide to Wireless Function
Table of Contents
1. WLAN USB Adapter Connection............................................................3
2. Wireless Setup.........................................................................................4
2.1 Infrastructure (AP)...........................................................................5
2.2 Peer to Peer (Ad Hoc).....................................................................7
2.3 Settings for PC................................................................................8
3. Getting Started.......................................................................................13
3.1 Browsing Content via WLAN.........................................................13
3.2 Network Copy ...............................................................................13
3.3 NAS function.................................................................................13
4. Troubleshooting.....................................................................................14
2 / 14
Notice:
To ensure the functionality of the Wifi USB dongle on EMTEC Movie Cube, you have to
check if your firmware is v2.0.7 or higher. If this is not the case then please download
the latest firmware upgrade from
www.emtec-international.com
1. WLAN USB Adapter Connection
A) Make sure the player is powered on;
B) Plug the Wireless LAN USB Adapter to one of the USB HOST ports of the player.
3 / 14
2. Wireless Setup
Select to set the WLAN (Wireless Local Area Network) Settings.
Make sure your network has a wireless router or an AP (Access
Point), or at least your PC should be equipped with a wireless
Please share the folders which you wish to browse on your PC,
Select Setup from the Guide menu or select on the remote control to enter the Setup
Menu. Press and on the remote control to select the Network tab from the menu bar.
Wireless Setup
Before using the wireless functions, please check following items:
1) Connect the WLAN USB Adapter to one of the USB HOST ports;
2)
network adapter/card;
3) Please turn off your PC’s firewall;
4)
and make sure that ‘Everyone’ has the right to access;
5) Make sure your player is in the effective range of the WLAN.
• Selecting a connection profile
This player can store up to three wireless network connections. Press ENTER to go to
next step, press RETURN to cancel, and press PLAY to connect.
4 / 14
• Get Connection Mode
Choose between Infrastructure (AP) and Peer to Peer (Ad Hoc). Press ENTER to go to
next step, and press RETURN to cancel.
2.1 Infrastructure (AP)
Infrastructure mode is used to connect computers with wireless network adapters, also
known as wireless clients, to an existing wired network with the help from wireless router
or access point.
• Get SSID Name
Press ENTER to go to next step, press RETURN to cancel, and press SELECT to refresh
the SSID list.
Note: In the Security list, WEP (Wired Equivalent Privacy) and WPA (Wi-Fi Protected
Access) means the network is encrypted, i.e. an encryption key is needed to access the
network. NONE means it is an open system network.
5 / 14
