Emtec Portable HDD USB 3.0 Wi-Fi, P600 User Manual
USER GUIDE
FOR iPhone/iPad
Compatibility: Apple iOS 5.1 or higher
2
1. Overview .......................................................................................................................................... 4
2. Install and Set Up ............................................................................................................................. 4
2.1. Download Emtec Connect App .................................................................................................... 4
2.2. Connect your Wi-Fi HDD to your iPhone/iPad (no Internet connection required) ..................... 4
2.3. Charge your Wi-Fi HDD ................................................................................................................ 5
3. Main interface ................................................................................................................................. 6
3.1. Home page .................................................................................................................................. 6
3.2. Access to the files of Wi-Fi HDD/ iPhone/iPad ............................................................................ 7
3.3. Videos/ Photos/ Music/ Documents Gallery ............................................................................... 8
3.4. Play movie/ video ........................................................................................................................ 9
3.5. Listen to music ............................................................................................................................. 9
3.6. View pictures ............................................................................................................................. 11
3.7. View documents ........................................................................................................................ 12
3.8. Download/upload files .............................................................................................................. 13
3.9. Share files .................................................................................................................................. 14
4. Settings .......................................................................................................................................... 15
4.1. Emtec Connect settings ............................................................................................................. 15
4.1.1. Wi-Fi settings ......................................................................................................................... 16
4.1.2. LAN setting ............................................................................................................................ 18
4.1.3. Internet settings/ Router function ........................................................................................ 20
4.1.4. System settings ...................................................................................................................... 22
4.1.5. Cache ..................................................................................................................................... 26
4.1.6. Language ............................................................................................................................... 26
4.1.7. About ..................................................................................................................................... 27
4.1.8. Log out ................................................................................................................................... 27
3
WARNING!
To avoid damage or malfunction:
Do not expose the product to excessive heat caused by heating equipment or direct sunlight.
Do not drop the product or allow objects to fall on your device.
Do not allow the product to be submerged in water. Do not expose device to water, as water
entering the set may cause major damage.
Avoid damp environments.
Protect the device against electromagnetic sources.
Back up your files. Ensure that you retain the original files you have downloaded to your
device. EMTEC is not responsible for any loss of data if the product becomes damaged or not
readable / legible.
Do not use any cleaning agents containing alcohol, ammonia, benzene, or abrasives as these
may harm the product.
About operating and storage temperatures:
Best operating conditions: 41° to 104°F (5°C à 40°).
Technical Support:
Online assistance:
support@emtec-international.com
https://twitter.com/EMTEC_Support
4
1. Overview
1. Battery level LED
Red: Low battery
Flashing Green: Charging
Solid Green: Drive On
Off: Battery full or Drive Off
2. HDD read/write LED
White: Stand-by
Flashing White: Read/Write
(LED is blue when the device is connected at
a USB3.0 port)
3. Wi-Fi LED
Blue: Wi-Fi ready
4. Internet LED
Green: connected to Internet
5. Power Button
Press and hold for 2 seconds to power
on/turn off the device.
On: Wi-Fi HDD mode.
Off: Synchronization mode (The HDD works
as a standard portable HDD).
6. USB 3.0 Port
7. Reset
8. Ethernet port (RJ45)
2. Install and Set Up
2.1. Download Emtec Connect App
Download “Emtec Connect” application on the App Store.
2.2. Connect your Wi-Fi HDD to your iPhone/iPad (no Internet connection required)
1. Turn-on your Wi-Fi HDD P600. Once the Wi-Fi blue LED stops flashing, the Wi-Fi function is ready.
2. Go to Wi-Fi settings on your iPhone/iPad and activate your Wi-Fi connection. Then choose the
name of your Wi-Fi HDD in the network list.
5
3. Enter the password (default: EMTEC4567).
Note: Your iPhone/iPad will remember the password and you will not need to enter it again a
second time.
4. When the connection is established, open Emtec Connect app to enjoy your files.
2.3. Charge your Wi-Fi HDD
Connect the included USB 3.0 cable into any available USB port on your computer. The battery LED
will start flashing while it is charging and will turn off once it is fully charged. You may use any Power
Adapter (not included) with 5V/2.1A charging current to charge the product.
Note: In Wi-Fi HDD mode, Wi-Fi function works when the battery is charging. Just turn on the Wi-Fi
HDD before you start charging.
6
3. Main interface
3.1. Home page
Note: Once your iPhone/iPad is connected with your Wi-Fi HDD, the “Online” pictogram will be
green.
Video Gallery:
Allows you to see all the videos available on the Wi-Fi HDD and your iPhone/iPad.
Photos Gallery:
Allows you to see all the photos available on the Wi-Fi HDD and your iPhone/iPad.
Music Gallery:
Allows you to see all the music available on the Wi-Fi HDD and your iPhone/iPad.
Documents Gallery:
Allows you to see all the documents available on the Wi-Fi HDD and your iPhone/iPad.
System menu:
Access to all the settings of your Wi-Fi HDD.
7
Explorer menu:
Allows you to manage and upload/download files (copy/paste, new folder…) from your iPhone/iPad
to your Wi-Fi HDD or from your Wi-Fi HDD to your iPhone/iPad.
Note: From the homepage, you can directly see the different files (compatible directly with the app)
you have in "Videos", "Photos" and "Music" by sliding your finger on the thumbnail.
3.2. Access to the files of Wi-Fi HDD/ iPhone/iPad
Emtec Connect / “iPhone”/”iPad” access:
Select file location by clicking on “EmtecConnect" (your Wi-Fi HDD) or "iPhone"/”iPad”.
8
3.3. Videos/ Photos/ Music/ Documents Gallery
All files:
Show all the files available (Videos/ Photos/ Music/ Documents) on your Wi-Fi HDD or iPhone/iPad.
Top 25:
Show the 25 Videos/ Photos/ Music/ Documents you look at most often.
My Favorites:
Shows your favorite Videos/ Photos/ Music/ Documents.
Favorite icon:
Click on the Favorite icon to add the file in “My Favorites” section.
DLNS/ Digital Media Sharing:
Click on the TV icon to display on your TV.
9
3.4. Play movie/ video
Note: Compatible fles: MP4, MOV, M4V. Other formats will be opened in a third party app available
on your iPhone/iPad. If no movie player is available on your iPhone/iPad, you can download one on
the App Store. Many movie players are available for free.
To play a video, you can go in the “Videos” gallery or in Explorer.
Just click and hold on the video you want to play and choose the movie player you desire to see the
video with.
3.5. Listen to music
To listen to music, you can go in the “Music” gallery or in Explorer.
Note: Compatible files: AAC, MP3, M4A, AIFF, WAV. Other files will be opened in a third party app
available on your iPhone/iPad. If no music player is available on your iPhone/iPad, you can download
one on the App Store. Many music players are available for free.
Simply locate the music file that you would like to play. Click on the file and your music will
automatically play.
