Emtec N200 User Manual

Home Multimedia Center
Movie Cube N200
User’s Manual
(Version 1.0.2)
Table of Contents
1. User Information ............................................................................................................................. 3
1.1 Cautions.................................................................................................................................3
2. Production Introduction ................................................................................................................. 5
2.1 Product Overview..................................................................................................................5
2.2 Package Contents..................................................................................................................6
2.3 Installation Procedure............................................................................................................7
2.4 Remote Control...................................................................................................................12
2.5 Front Panel..........................................................................................................................13
2.6 Side Panel............................................................................................................................13
2.7 Back Panel...........................................................................................................................14
1.1Setup Menu..........................................................................................................................15
3.2 Music Playback...................................................................................................................25
3.3 Photo Playback....................................................................................................................26
3.4 Movie Playback...................................................................................................................28
3.5 All Files...............................................................................................................................30
3.6 Net Radio.............................................................................................................................30
6.1 Specifications......................................................................................................................34
6.2 Frequently Asked Questions...............................................................................................35
6.3 Copyrights and Trademarks................................................................................................37
6.4 Warranty..............................................................................................................................38
6.5 GPL Statement....................................................................................................................38

1.User Information

1.1 Cautions
This player’s design and manufacture has your safety in mind. In order to safely and
effectively use this player, please read the following before usage.
1.1.1 Usage Cautions
User should not modify this player. If commercial hard disk is being used, the environmental
temperature should be within +5 ~ +35 .℃ ℃
1.1.2 Power
The player’s power voltage: DC 5V.
When using this player, please connect the supplied AC adapter or AC adapter cable to the
player’s power jack. When placing the adapter cable, make sure it can not get damaged or be
subject to pressure. To reduce the risk of electric shock, unplug the adapter first before
cleaning it. Never connect the adapter to the player in a humid or dusty area. Do not replace
the adapter or cable’s wire or connector.
1.1.3 Radio Interference
- If not properly shielded, almost all electronic devices will get radio interference. Under some
conditions, your player might get interference.
- The design of this player has followed the FCC/CE standard, and has followed the following
rules:
(1) This player may not cause harmful interference;
(2) This player could accept some interference received including interference that may cause
undesired operation.
1.1.4 Repair
If the player has a problem, you should take it to an appointed repair center and let the
specialists do the repair, never repair the player yourself, you might damage the player or
endanger yourself or your data.
1.1.5 Disposing of the Player
When you dispose of the player, be sure to dispose it appropriately. Some countries may
regulate disposal of electrical device, please consult with your local authority.
1.1.6 Others
When using this player, please do not let the player come into contact with water or other
liquid, if water is accidentally spilled on the player, please use a dry cloth to absorb the
spillage.
Electronic products are vulnerable, when using please avoid shaking or hitting the player, and
do not press the buttons too hard.
Do not let the player come into contact with water or other liquid.
Do not disassemble the player, repair the player or change the design of the player, any
damage done will not be included in the repair policy.
Do not press the buttons of the player too hard.
Avoid hitting the player with hard object, avoid shaking the player, and stay away from
magnetic fields.
During electrostatic discharge and the strong electromagnetic field, the product will
malfunction, then unplug the power cable and the product will return to normal
performance next time it is powered on.

2. Production Introduction

2.1 Product Overview
Thank you very much for purchasing the product. We hope you will enjoy using it as a great
home entertainment partner. This player has the following functionality.
Network Feature
•
A/V streaming/transmission via Ethernet (10M/100M) & Wi-Fi (802.11b/g/n)
•
A/V streaming via UPnP Media Server
•
Internet radio(MMS)
USB 2.0 Support
•
USB HOST port x 2 (for USB storage devices)
Card Reader
•
Support SD/MMC/MS/MS Pro
Navigation Options Include
•
Search: search by genre, album, date, folder, recent, playlist and artist.
•
Media Library: lets you view all your media files in one menu regardless of its location in
folders or drivers. You can filter by categories such as genre, artist, album and so on.
Photo Viewing
•
You can view photos in slide show mode with background music.
•
Zoom in/out, Rotate
Movie Playback
•
Fast forward/rewind
•
View subtitle
Music Playback
•
Fast forward/rewind
•
Shuffle
•
Repeat
Note: All the information contained in this manual was correct at the time of publication.
However, as our engineers are always updating and improving the product, your device’s
software may have a slightly different appearance or modified functionality than presented in
this manual.
2.2 Package Contents
Part Quantity
Player 1 A/V cable 1 Remote Control 1 AC/DC adaptor 1 Quick Installation Guide 1 Driver CD (with User Manual) 1 SCART in adapter 1
Note:
The actual contents in the package might be different from the packing list in this manual.
2.3 Installation Procedure
The Movie cube installation procedure is outlined below:
Step 1 - Connecting the Power Supply
(1) Follow the picture and connect the AC adaptor to the player’s DC IN jack;
(2) Follow the picture and plug in the AC adaptor to the power outlet.
Step 2 - Connecting to a TV
The below connection method can help you to enjoy the high quality movie, music and photo.
The standard connection uses the AV cable.
The best connection uses the HDMI cable.
Note: HDMI and Toslink (Optical) cables are sold separately.
1. A/V OUT (Standard Definition)
(1) Follow the picture and plug in the 3 color connector to the player’s A/V OUT jack;
(2) Follow the picture and plug in the 3 color connector to the TV’s A/V IN jack.
(3) Select the appropriate TV input source.
In this way, you can enjoy the content in the player on TV or other display devices.
2. Y/Pb/Pr Component OUT
(1) Follow the picture and plug in the 3 color connector to the player’s Y/Pb/Pr jack;
(2) Follow the picture and plug in the 3 color connector to the TV’s Y/Pb/Pr jack.
Y/Pb/Pr cable connection only output video, you will need AV cable or S/PDIF cable (optical)
for audio output.
Follow the Audio Connection method as below:
First method: Use the audio output from the A/V OUT jack;
Second method: Use the audio output from the S/PDIF optical jack.
In this way, you can also enjoy videos, music, and photos in the player on TV.
3. HDMI OUT (High Definition)
The HDMI connection can provides video quality resolution up to 1080p.
(1) Follow the picture and plug one connector on your HDMI cable to the player’s HDMI jack;
(2) Follow the picture and plug the other connector on your HDMI cable to the TV’s HDMI
jack.
(3) Select the appropriate TV input source.
Note: The HDMI cable is an optional accessory sold separately.
In this way, you can have the highest quality video and audio via a single cable.
4. Connecting to a Digital Amplifier
(1) Follow the picture and plug in the Toslink connector of your optical fiber to the player’s
S/PDIF Optical jack;
(2) Follow the picture and plug in the other connector of your optical fiber to the digital audio
device (digital amplifier or decoder).
(3) Select the appropriate TV input source.
Note: Optical fiber is an optional accessory sold separately.
Step 3 - Connecting a USB Device or Memory Card to the Movie Cube
1. Connecting a USB Device
(1) Make sure the player is powered on;
(2) Plug in the USB stick or USB HDD etc. to the USB HOST port of this player.
In this way, you can browse contents on the USB device.
2. Connecting a Memory Card
Memory card can be used by inserting to the card slot
(1) Follow the picture to insert the memory card to the card slot properly;
(2) Insert the card by following the arrow pointer in the picture.
In this way, you can browse contents on the memory card.
Removing a USB Device or Memory Card
In order to prevent data loss, it is highly recommended you press EJECT button on the
remote control before remove a USB device or Memory Card.
To remove a USB Device or Memory Card
1. Press EJECT button on the remote control
2. Select the USB device you want to remove
3. Press ENTER button on the remote control to remove USB device or Memory card.
Step 4 - Connecting to a Network
1. Connecting to a LAN
To connect to a LAN (Local Area Network) you require a cat5, cat5e or cat6 network cable
(not supplied).
(1) Connect one of the crystal plugs on the cable to the player’s RJ45 LAN socket;
(2) Connect the other crystal plug on the cable to a RJ45 LAN port on your router, switch, or
hub devices.
2. Connecting to a WLAN
(1) Make sure the player is powered on;
(2) Plug the Wireless LAN USB Adapter (i.e. Wi-Fi USB Dongle) to the USB HOST port of the
player.
Note: The Wi-Fi Dongle is an optional accessory sold separately.
2.4 Remote Control
1. POWER OFF 2. HOME
3. OPTION 4. VOL+
5. UP 6. LEFT
7. ENTER 8. VOL-
9. DOWN 10. FR
11. PLAY/PAUSE 12. SEARCH
13. STOP 14. EJECT
15. TV SYS. 16. FF
17. PREV 18. RIGHT
19. NEXT 20. RETURN
21. MUTE
No. Button Function
1 POWER OFF Press to power off the player. 2 HOME Press to enter the home screen. 3 OPTION Press to display or hide the information bar during playback. 4 VOL+ Press to increase the volume. 5 UP Navigational button. Press the arrow buttons to select menu
options.
6 LEFT Navigational button. Press the arrow buttons to select menu
options. 7 ENTER Press ENTER button to confirm. 8 VOL- Press to decrease the volume. 9 DOWN Navigational button. Press the arrow buttons to select menu
options
10 FR Press to fast rewind the current playback. Press repeatedly to
select speeds.
11 PLAY/PAUSE Press to begin playback and pause the current playback. 12 SEARCH Filter the current folder to locate the specific media file. Does
not search subfolder;
Press to jump to a specific point on a title. Specify the point
using Title, Chapter and Time.
13 STOP Press to stop playback. 14 EJECT Press to safely remove the USB device. 15 TV SYS. Press to switch between NTSC, PAL, 480P, 576P, 720P, 1080I,
and 1080P.
16 FF Press to fast forward the current playback. Press repeatedly to
select speeds.
17 PREV Press to view the previous file / page up. 18 RIGHT Navigational button. Press the arrow buttons to select menu
options.
19 NEXT Press to view the next file / page down. 20 RETURN Press to return to the previous screen while navigating menus. 21 MUTE Press to mute audio output, and press again to resume.
2.5 Front Panel
1.
IR receiver 2. USB indicator 3. Power indicator
2.6 Side Panel
1.
USB HOST port 2. Memory Card slot 3. Power button
