Emtec N120 User Manual
Home Multimedia Center
Movie Cube N120
User’s Manual
(Version 1.0.0)
Table of Contents
1. Introduction .......................................................................................................................... 3
1.1 Preface ............................................................................................................... 3
1.2 Packing List ...................................................................................................... 3
1.3 Caution .............................................................................................................. 3
1.4 Connection ........................................................................................................ 5
1.5 First Time Usage ............................................................................................... 7
2. About the Player .................................................................................................................. 8
2.1 Remote Control ................................................................................................. 8
2.2 Front Panel ........................................................................................................ 9
2.3 Rear Panel ......................................................................................................... 9
2.4 Side Panel ........................................................................................................ 10
3. Setup Menu ......................................................................................................................... 11
3.1 General Setup .................................................................................................. 11
3.2 Video Setup ..................................................................................................... 12
3.3 Audio Setup ..................................................................................................... 12
3.4 Photo Setup ..................................................................................................... 13
3.5 Firmware Version ............................................................................................ 13
4. Media Playback .................................................................................................................. 14
4.1 Video List ........................................................................................................ 14
4.2 Music List ....................................................................................................... 15
4.3 Photo List ........................................................................................................ 16
4.4 Slide Show ...................................................................................................... 17
4.5 File List ........................................................................................................... 17
4.6 DVD Playback ................................................................................................ 17
5. Upgrading the Firmware ................................................................................................... 19
6. Appendixes......................................................................................................................... 20
6.1 Specifications .................................................................................................. 20
6.2 Frequently Asked Questions ........................................................................... 20
6.3 Copyrights and Trademarks ............................................................................ 21
6.4 Warranty .......................................................................................................... 21
2 / 21
1. Introduction
Video Playback
-
supports AVI, VOB, MPG, DAT, MP4 files with corresponding codec:
MPEG-1, MPEG-2, MPEG-4 ASP, XviD (resolution up to D1 quality).
Music Playback
-
supports MP3, WMA (DRM, Pro and Advanced Profile not supported)
Photo Playback
-
supports JPG/JPEG files.
- supports slide show mode.
USB HOST
-
direct playback files from U disk and external USB HDD.
Card Reader
-
supports memory cards: SD/MMC/MS.
Part
Quantity
Player
1
A/V cable
1
Remote Control
1
AC/DC adaptor
1
CD (with User Manual)
1
Scart in adapter
1
QIG
1
1.1 Preface
Dear Customer,
Thank you very much for purchasing the product. In the digital era, this product is a great home
entertainment partner. With the outstanding design, you can enjoy movies and music, and view
photos of precious moments. This product can directly playback files from U disk and portable
HDD with its high-speed USB 2.0. It also can recognize files which stored on memory card.
This player has the following functionality:
We hope that this product will bring you a lot of enjoyment. We are committed to apply
multimedia technology in your work, entertainment, family, daily life, car and everywhere!
Welcome to us. Thank you again for choosing our product.
1.2 Packing List
Note:
The actual contents in the package might be different from the packing list in this manual.
1.3 Caution
This player’s design and manufacture has your safety in mind. In order to safely and effectively
use this player, please read the following before usage.
3 / 21
1.3.1 Usage cautions
User should not modify this player. The environmental temperature should be within +5℃ ~
+35℃.
1.3.2 Power
The player’s power voltage: DC 5V.
When using this player, please connect the supplied AC adapter or AC adapter cable to the
player’s power jack. When placing the adapter cable, make sure it can not get damaged or be
subject to pressure. To reduce the risk of electric shock, unplug the adapter first before
cleaning it. Never connect the adapter to the player in a humid or dusty area. Do not replace
the adapter or cable’s wire or connector.
1.3.3 Radio interference/compatibility
- If not properly shielded, almost all electronic devices will get radio interference. Under some
conditions, your player might get interference.
- The design of this player has followed the FCC/CE standard, and has followed the following
rules:
(1) This player may not cause harmful interference;
(2) This player could accept some interference received including interference that may
cause undesired operation.
1.3.4 Repair
If the player has a problem, you should take it to an appointed repair center and let the
specialists do the repair, never repair the player yourself, you might damage the player or
endanger yourself or your data.
1.3.5 Disposing of the player
When you dispose of the player, be sure to dispose it appropriately. Some countries may
regulate disposal of electrical device, please consult with your local authority.
1.3.6 Others
When using this player, please do not let the player come into contact with water or other liquid,
if water is accidentally spilled on the player, please use a dry cloth to absorb the spillage.
Electronic products are vulnerable, when using please avoid shaking or hitting the player, and
do not press the buttons too hard.
Do not let the player come into contact with water or other liquid.
Do not disassemble the player, repair the player or change the design of the player, any
damage done will not be included in the repair policy.
Do not press the buttons of the player too hard.
Avoid hitting the player with hard object, avoid shaking the player, and stay away from
magnetic fields.
During electrostatic discharge and the strong electromagnetic field, the product will
malfunction, then unplug the power cable and the product will return to normal
performance next time it is powered on.
4 / 21
1.4 Connection
1.4.1 USB Mass Storage Device (like USB Pen Drive, MP3, USB HDD, etc.) Connection
(1) Make sure the player is powered on;
(2) Plug in the USB Pen Drive or USB HDD or other USB device to the USB HOST port of this
player.
1.4.2 Memory card connection
Memory card can be used by inserting to the card slot.
(1) Make sure the player is powered on;
(2) Insert your memory card (SD/MMC/MS) to the card slot of this player properly.
5 / 21
1.4.3 TV connection
1.4.3.1 A/V OUT
(1) Follow the picture and plug in the connector to the player’s A/V OUT jack;
(2) Follow the picture and plug in the 3 color connector to the TV’s A/V IN jack.
(3) Select the appropriate input source.
In this way, you can enjoy the content in the player on TV or other display devices.
1.4.3.2 HDMI OUT
(1) Follow the picture and plug one connector on your HDMI cable to the player’s HDMI jack;
(2) Follow the picture and plug the other connector on your HDMI cable to the TV’s HDMI jack.
(not supplied)
(3) Select the appropriate input source.
In this way, you can have the highest quality video and audio via a single cable.
1.4.4 Power connection
(1) Follow the picture and connect the AC adaptor to the player’s DC IN jack;
(2) Follow the picture and plug in the AC adaptor to the power outlet.
6 / 21
1.5 First Time Usage
1. Power on
Plug in the power cord to DC IN jack on the player, and the POWER indicator on the front panel will
turn blue.
2. Power off
In playback and other interface, press the POWER button on the remote control, the player will
enter standby mode, and the POWER indicator will turn red.
3. Language control
The system language of this player can be set to English or other languages. In setup menu,
the selected language will take effect immediately.
7 / 21
