EMS SBR-FX/RMD, SBR FX-15000/RMD, SBR FX-40000/RMD User Manual

SafetyBUS p Fiberoptic Router

SBR-FX/RMD

User Manual

EMS

THOMAS WÜNSCHE

Sonnenhang 3
D-85304 Ilmmünster
Tel [phone]
Fax [phone]

Documentation for SafetyBUS p Fiberoptic Router
SBR-FX/RMD

Document version: V1.5
Documentation date: April 17th, 2008

No part of this document or the software described herein
may be reproduced in any form without prior written
agreement from EMS Dr. Thomas Wünsche.

For technical assistance please contact:

EMS Dr. Thomas Wünsche
Sonnenhang 3

D-85304 Ilmmünster

Tel. [phone]
Fax [phone]
Email: [e-mail]

Our products are continuously improved. Due to this fact
specifications may be changed at any time and without
announcement.

WARNING: SBR-FX/RMD hardware and software may

not be used in applications where damage
to life, health or private property may result
from failures in or caused by these compo­nents.

User Manual SBR-FX/RMD

ii EMS Dr. Thomas Wünsche

Content

1 Overview ........................1

1.1 Attributes ......................1

1.2 General Description ................1

1.3 Ordering Information ................2

2 Hardware ........................3

3 Software ........................5

3.1 General Configuration ...............5

3.2 SafetyBUS p Startup Configuration.........8

4 Electrical Characteristics ..............11

4.1 Absolute Limiting Values .............11

4.2 Nominal Values ..................12

5 Operating Instructions ................13

5.1 Connection Scheme................13

5.2 Router Correction Time and Cascading......14

5.3 ESD Precaution ..................15

SBR-FX/RMD User Manual

EMS Dr. Thomas Wünsche iii

THIS PAGE INTENTIONALLY LEFT BLANK

User Manual SBR-FX/RMD

iv EMS Dr. Thomas Wünsche

1 Overview

1.1 Attributes

•

Optical fiber based Ethernet/CAN router
for the connection of SafetyBUS p sub­networks

•

Powerful 32 bit microcontroller Sam­sung S3C4510B with CAN controller
SJA1000

•

Abolition of the extension/datarate re­strictions between two CAN bus
segments

•

Optical fiber extensions up to 15/40 km
possible (2 different device types)

•

Automatic detection of the used
baudrate

1.2 General Description

The rail mountable router SBR-FX/RMD trans­mits data between SafetyBUS p networks
using optical fiber. To achieve the connection
two devices are linked back-to-back, the trans­mission protocol used on the optical fiber is
the UDP/IP protocol. The use of UDP/IP abo­lishes the length/datarate restrictions between
two CAN bus segments. Depending on the
type of the device, extensions up to 15km or
40km are possible.

SBR-FX/RMD automatically detects the baud
rate on the controlling side. The I/O side can
be run with the baudrate detected on the con­trolling side or an independently customized
baudrate.

SBR-FX/RMD User Manual

EMS Dr. Thomas Wünsche 1

1.3 Ordering Information

12-20-500-20 SBR FX-15000/RMD

SafetyBUS p Fiberoptic
Router, rail mountable, range
up to 15km

12-20-501-20 SBR FX-40000/RMD

SafetyBUS p Fiberoptic
Router, rail mountable, range
up to 40km
