EMS FirePoint System 5000 User Manual

SYSTEM 5000

USER MANUAL

EMS SYSTEM 5000

USER MANUAL, ISSUE 2.4 – 19/11/09

3

Table of Contents

Section Page No

1 Introduction: - ............................................................................................... 4

1.1 Procedure:

....................................................................................................... 4

1.2 Warnings and Cautions:..............................................................................................................................4

2 User Control Levels:...................................................................................... 4

3 User Passwords: ........................................................................................... 5

4 Controls and Displays: -................................................................................ 5

4.1 Controls Layout:

................................................................................................ 5

5 Table of the Functions of the panel’s LED Indicators: - ................................ 6

6 Control Keyswitch:........................................................................................ 7

6.1 OFF (Normal) Position Functionality: (Access Level 1)

................................................. 7

6.2 ON Position Functionality: (Access Level 2) ...........................................................................................8

6.3 ISOLATED Position Functionality: .............................................................................................................9

7 User Option Functions: ............................................................................... 10

8 Alphanumeric Display Indicators: -............................................................. 12

8.1 Non-Alarm Conditions:

.......................................................................................12

8.15 Fire Event: .................................................................................................................................................12

8.2 Fire (Networked Device): .........................................................................................................................13

8.25 Pre-Alarm: .................................................................................................................................................13

8.3 Tamper: …………………………………………………………………………………………………………….13

8.35 Fault Event:

.............................................................................................................................. 13

8.4 Fault : BT: MN: ..........................................................................................................................................14

8.45 Fault : BT: ................................................................................................................................................14

8.5 Fault : PR: ....................................................................................................................................................14

8.55 Fault : RI: ..................................................................................................................................................15

8.6 Fault : OL:....................................................................................................................................................15

9 Step by Step Guidance:............................................................................... 16

9.1 Weekly Test Recommendations.

...........................................................................16

9.3 Enabling/Disabling Devices:.....................................................................................................................17

9.4 Enabling/Disabling Zones:........................................................................................................................18

9.5 Enabling/Disabling Brigade Relay: .........................................................................................................19

9.6 Printer Options: ………………………………………………………………………………………………………………………….19

9.7 Viewing the Event Log:

.............................................................................................................. 20

9.8 Enabling/Disabling Networked Devices:................................................................................................21

9.9 Selecting Verify Delay Operation: ..........................................................................................................22

10 Routine Tests: - ........................................................................................ 23

10.1 Daily:

...........................................................................................................23

10.2 Weekly: ......................................................................................................................................................23

10.3 Quarterly: ..................................................................................................................................................23

10.4 Annually:....................................................................................................................................................23

10.5 Periodic Cleaning:

................................................................................................................................23

11 Logbook: -................................................................................................. 24

EMS SYSTEM 5000

USER MANUAL, ISSUE 2.4 – 19/11/09

4

1 Introduction: -

This manual contains all of the information required for the use and operation of the EMS
System 5000. This manual is also written in a format that presumes that the system has
been correctly installed and commissioned. When using the system it is important to
follow this user manual at all times. Any questions on the system should be put to the
Installer/Maintainer.

1.1 Procedure:

In accordance with BS5839 Part 1:2002, written procedures must be established in
dealing with alarms for: -

Fire, Fault Warnings and the Disablement of any part of the System.

A responsible person should be appointed who ensures that all users are instructed in
the proper use of the system and are familiar with all associated procedures. The
nominated person shall also be responsible for liaising with the maintenance company,
on all matters relating to the maintenance of the system. One of the associated
procedures is to maintain an up to date logbook.

The logbook should include properly recorded events including all real and false alarms.
Also any testing or even temporary disablements should be noted. Infact, any events
affecting the system should be recorded. It should always be kept in a safe place near
the system, only with access by authorised personnel. A sample logbook sheet is
displayed in Section 11.

1.2 Warnings and Cautions:

These instructions contain the procedures to follow in order to operate the System 5000
control panel correctly. It is assumed that the user has been suitably trained and is
familiar with the relevant regulations.

All equipment is to be operated in accordance with the appropriate standards applicable.

The material and instructions covered in this manual have been carefully checked for
accuracy and are presumed to be correct. However the manufacturer assumes no
responsibility for inaccuracies and reserves the right to modify and revise this document
without notice.

2 User Control Levels:

System 5000 has three different access levels. They are Levels 1, 2 & 3.

At User Level 1, all of the displays are completely functional, however the panel’s control
buttons and menu access features are inhibited.

At User Level 2, (Standard user access level via control keyswitch); all panel controls are
functional and the control panel’s menu is accessible. The requirement of the Engineers
PIN at the Engineers Config Menu, allows access to Level 3.

At User Level 3, all the panel’s controls are functional and the control panel’s menu is
fully accessible making full system configuration possible. User Level 3 is reached by
entering the Engineers PIN from Level 2. (Engineers Config Menu). User Level 3 is
intended for use by the System Installer/Maintenance Contractor.

EMS SYSTEM 5000

USER MANUAL, ISSUE 2.4 – 19/11/09

5

3 User Passwords:

It is possible for the system to be programmed to allow a PIN number rather than the
control keyswitch to change from Access Level 1 to Level 2.

The system is not programmed, as standard with this feature as the control keyswitch is
normally used, however up to 99 User PINS can be assigned/changed at User Level 3 by
the Installer/Maintenance Contractor if required.

4 Controls and Displays: -

4.1 Controls Layout:

The System 5000 control panel provides status information via the Display, Zone Lamps
and Status Lamps. The display and control of the panel’s functions is achieved through
two control panel sections. Figure 1, shows the display area which includes Fire Zone

Lamps, the Display itself and the “∆” and “∇” Scroll Buttons.

Figure 1 - Zone Lamps and Display (model shown 5096)

The System 5000 Panel is controlled by the use of the Control Keyswitch, a Numeric
Keypad and 3 Control Buttons. Fig 2 shows the Panel Controls and Indicator Lamps.

Figure 2

NOTE: The Status Lamps/Buttons & Control Keyswitch/Buttons operation is identical, for
all styles of control panel.

Zone Lamps

Scroll Buttons

Front Panel Lock

20 Character 4

-

Line Display

EMS SYSTEM 5000

USER MANUAL, ISSUE 2.4 – 19/11/09

6

5 Table of the Functions of the panel’s LED Indicators: -

LED Indicator Led Colour(s)

Control Panel Function

POWER

Indicates a good AC power supply.

ZONE FAULT

Illuminates, should one of the
detection devices, develop a fault
condition.

GENERAL FAULT

Illuminates, should a fault condition
occur within a Control Panel or device.

ARE / BRIGADE FAULT

Illuminates should a communication
fault occur between the Alarm Routing
equipment and the Control Panel.

EARTH FAULT

Illuminates should an earth fault
condition occur on the system.

ARE / BRIGADE

DISABLED

Illuminates when communication with
the Alarm Routing Equipment is
disabled

TEST MODE

Illuminates whilst a device or
detection zone is in “TEST MODE”.

SOUNDER & OUTPUTS

DISABLED

Illuminates when an individual
Sounder/Output device or sounder
zone is disabled.

FIRE

Illuminates when any device is in Fire
Alarm condition along with the fire
zonal LED.

SOUNDER FAULT

Illuminates should a Sounder Based
Device indicates a fault condition.

SYSTEM FAULT

Illuminates should a fault become
present with the control panel itself.

DETECTOR/ZONE

DISABLED

Illuminates when a Detection Device
or Zone is disabled.

Fig 3

EMS SYSTEM 5000

USER MANUAL, ISSUE 2.4 – 19/11/09

7

6 Control Keyswitch:

The Control Keyswitch has three different positions. They are “OFF”, “ON” and
ISOLATED”.

Each of their functions are explained on the following page: -

6.1 OFF (Normal) Position Functionality: (Access Level 1)

With the control keyswitch in the “OFF” position,
the panel is at Access Level 1. The key is
removable in this position and it is recommended
that the panel is left in this position with the
key removed. The following control options are
available: -

Scroll Buttons

Operational when multiple events are
displayed to enable each event to be viewed.

Reset/Led
Test

Operates Status lamp test when system has
no events shown.

Silence Alarms

No operation.

Sound Alarms

No operation.

View Tests

2nd Feature
of key

Displays any device/zone currently in test.
This will automatically timeout and return to
the Front Screen if left in this mode.

View
Disablements

2nd Feature
of key

Displays any device/zone currently disabled.
This will automatically timeout and return to
the front screen if left in this mode.

View Faults

2nd Feature
of key

Displays any device currently in fault
condition. This will automatically timeout and
return to the front screen if left in this mode.

View Fires

2nd Feature
of key

Returns to view fire events if any of the other
view options used. This will automatically
timeout and return to the front screen if left
in this mode.

Status Lamps,
(see fig 2)

N/A Indicates the systems current status

System Menus N/A No Operation

OFF

position

ISOLATED

OFF ON

EMS SYSTEM 5000

USER MANUAL, ISSUE 2.4 – 19/11/09

8

6.2 ON Position Functionality: (Access Level 2)

The Control Panel requires the control keyswitch
turned to the “ON” Position, enabling Access Level 2: -

The key may not be removed when in this position.

Scroll Buttons

Operational when multiple events are
displayed to enable each event to be viewed.

Reset/Led
Test

This button has two functions. It is firstly
used to reset a Fire/Fault Event, after the
“Silence Alarm” button has been pressed and
the Fire/Fault condition has been cleared. It
is secondly used to test all of the Systems
Status Lamps. This is achieved by pressing
the button when the Systems Status is
normal, i.e. no events displayed.

Silence Alarms

This button Silences the System’s Sounders
and internal buzzers. The panel will give an
intermittent beep every 10 – 15 seconds until
the condition is reset and will display Silence
Alarms when pressed.

Sound Alarms

This key is used for activating the System’s
Sounders. The display will show Alarms
Sounded when pressed.

View Tests

2nd
Feature

of key

Displays any device/zone currently in test.
This will automatically timeout and return to
the front screen if left in this mode.

View
Disablements

2nd
Feature

of key

Displays any device/zone currently disabled.
This will automatically timeout and return to
the front screen if left in this mode.

View Faults

2nd
Feature

of key

Displays any device currently in fault
condition. This will automatically timeout and
return to the front screen if left in this mode.

View Fires

2nd
Feature
of key

Returns to view fire events if any of the other
view options used. This will automatically
timeout and return to the front screen if left
in this mode.

Status Lamps,
(see fig 2)

N/A

Indicates the systems current status.

System Menus

N/A

Options and further Fire system Options
Menus are now accessible by pressing the “0”
Key. Details are shown in Section 7.

ISOLATED

OFF ON

ON position

EMS SYSTEM 5000

USER MANUAL, ISSUE 2.4 – 19/11/09

9

6.3 ISOLATED Position Functionality:

The Control Panel requires the control keyswitch turned to the
ISOLATED position. Access Level 2 is accessible with the same
Features as detailed previously and all control buttons are operational.
Plant Shutdown equipment can be disabled through this function as a
pre selected Sounder Group can be disabled. This is normally used for
isolating Plant Equipment whilst carrying out weekly tests. However,
this is a programmable feature and can be configured by the installer/
maintenance contractor if required.

Scroll Buttons

Operational when multiple events are
displayed to enable each event to be
viewed.

Reset/Led
Test

This button has two functions. It is firstly
used to reset a Fire/Fault Event, after the
“Silence Alarm” button has been pressed
and the Fire/Fault Condition has been
cleared. It is secondly used to test all of the
Systems Status Lamps. This is achieved by
pressing the button when the Systems
Status is normal, i.e. no events displayed.

Silence Alarms

This button Silences the System’s Sounders
and internal buzzers. The panel will give an
intermittent beep every 10 – 15 seconds
until the condition is reset and will display
Silence Alarms when pressed.

Sound Alarms

This key is used for activating the System’s
Sounders. The display will show Alarms
Sounded when pressed.

View Tests

2nd Feature
of key

Displays any device/zone currently in test.
This will automatically timeout and return
to the front screen if left in this mode.

View
Disablements

2nd Feature

of key

Displays any device/zone currently
disabled. This will automatically timeout
and return to the front screen if left in this
mode.

View Faults

2nd Feature

of key

Displays any device currently in fault
condition. This will automatically timeout
and return to the front screen if left in this
mode.

View Fires

2nd Feature

of key

Returns to view fire events if any of the
other view options used. This will
automatically timeout and return to the
Front screen if left in this mode.

Status Lamps,
(see fig 2)

N/A Indicates the systems current status

System Menus N/A Options and further Fire system Options

Menus are now accessible by pressing the
“0” Key. Details are shown in Section 7.

Isolated Lamp

ISOLATED

Sounder group disabled by key position.
This is a programmable feature normally
used for isolating plant equipment on a
weekly test and is configured by the
Installer/Maintenance contractor.
