Empertech KB-DA2250 User Manual

KB-DA2250
High Efficiency Power Amplifier
User Manual
Easy Installation
Easy Info Reading
Easy Access & Control
Easy Maintenance
Copyright
© 2011 Honeywell International Inc. All rights reserved. No part of this document may be reproduced in any form without the written permission
of the copyright owner.
Disclaimer
The contents of this document are subject to revision without notice due to continued progress in methodology, design, and manufacturing. Honeywell shall have no liability for any error or damage of any kind resulting from the use of this document.
Trademark List
All trademarks mentioned herein are the property of their respective owners. These are shown in the document Trademark Information.
This sign means to alert the user that there are non­insulated materials within the enclosure, which pose
threats of electrocution if mishandled.
This sign means to alert the user of important operation
and maintenance instructions.
Caution: To avoid electrocution, do not use polarized plug with an extension cord, receptacle, or other outlet unless the blades can be fully inserted to prevent blade exposure.
Caution: Do not block ventilation openings and stack other equipment on top.
i
Suggestions for Safety
For the installation, operation, and use of this product, please carefully read the following precautions.
Electrical Safety
The product installation and use must comply with local electrical safety regulations. Honeywell assumes no liability for user errors or misuse that result in a fire or an electrical
shock.
Transportation Safety
During transportation, do not violently shake the appliance or expose it to corrosive liquids.
Environmental Regulations
Do not install the appliance in an environment with extreme temperatures or excessive
amounts of dust.
The appliance should be placed away from direct sunlight in a well-ventilated, clean, and
stable environment without vibrations or shocks.
The required appliance power supply voltage is AC 220V (-15% ~ +10%) 5- ~ 60 Hz. If the
voltage is too high, too low, or fluctuates too drastically, it is recommended to install a stable AC power source.
The appliance is not waterproof. Do not expose the appliance to rain or moisture, and
avoid splashing it with water. Do not place any items filled with liquid on top of the product (such as a flower vase) to avoid damage.
Place the appliance away from sources of heat and ensure adequate ventilation space. Place the appliance on a level, stabilized surface or rack. Do not place other items on top of the appliance.
Safe Use Precautions
Install the equipment under the guidance of qualified technicians. Before using the appliance, make sure that the power cables are not damaged. The power
cables must clearly show quality and safety inspection labels.
The power plug and outlet prong configuration must match. If the plug outlet does not
match the prong configuration of the plug, the outlet must be replaced with one that matches the plug.
The appliance must have a sufficient power source and an independent grounding wire.
ii
Note that the equipment must be properly grounded. Otherwise, the equipment could fail
to work properly or be damaged.
When the power is turned on, high voltage runs through the power lines and the appliance.
Do not open the appliance to prevent an electric shock.
When installing the appliance, make sure the wires and cables are configured correctly to
avoid damage to the equipment.
When the power is turned on, do not touch power terminals with lightning safety logos to
prevent an electric shock.
When the power is turned on, do not physically alter the appliance to avoid damaging the
equipment.
Honeywell assumes no liability for appliance malfunctions. Please consult qualified
technicians for repairs.
Manual Labels and Information
Please note the product labels, product categories, power requirements, and other
information.
Read this manual thoroughly and use the equipment in accordance with the provided
instructions. This manual can be used as a reference for other components related to this product. For more specific information, contact Honeywell.
Keep this manual for future reference.
iii
Contents
Suggestions for Safety ................................................................................................ i
Electrical Safety .............................................................................................................. i
Transportation Safety ..................................................................................................... i
Environmental Regulations ............................................................................................. i
Safe Use Precautions ..................................................................................................... i
Manual Labels and Information ...................................................................................... ii
Contents ...................................................................................................................... iii
Preface ......................................................................................................................... 1
Introduction ........................................................................................................................ 1
Audience ............................................................................................................................ 1
How to Use This Manual ..................................................................................................... 2
1 Introduction ........................................................................................................ 3
Features ............................................................................................................................. 3
Functions ............................................................................................................................ 3
Power Supply Protection ............................................................................................... 3
Overheating Protection ................................ ................................................................ .. 4
Overload and Short Circuit Protection ............................................................................ 4
Fault Detection and Fault Logs ................................................................ ...................... 4
2 Interfaces ............................................................................................................ 4
Front Panel ......................................................................................................................... 4
Rear Panel ......................................................................................................................... 5
3 Installation .......................................................................................................... 7
Preparing for Installation ..................................................................................................... 7
Tools ............................................................................................................................. 7
Materials ........................................................................................................................ 7
Cables and Wires .......................................................................................................... 7
Package Inspection ....................................................................................................... 8
Connecting the Cables ....................................................................................................... 8
iv
Grounding Cable ........................................................................................................... 8
Audio Input Cable .......................................................................................................... 9
Output Cable ................................ ................................................................ ............... 10
Completing Installation and Commissioning...................................................................... 11
Precautions ...................................................................................................................... 12
4 Technical Specifications .................................................................................. 13
5 Packing List ...................................................................................................... 14
1
Preface
Thank you for purchasing the KB-DA2250 High Efficiency Power Amplifier. Please read this manual carefully before using the KB-DA2250 High Efficiency Power Amplifier to ensure proper use of the system.
Introduction
This manual describes the KB-DA2250 High Efficiency Power Amplifier features, functions, applications, user interfaces, technical specifications, and installation procedures. This manual includes the following sections:
Chapter 1: Introduction
Introduction of the KB-DA2250 High Efficiency Power Amplifier features, functions, and applications
Chapter 2: Package Contents
Package content details of the KB-DA2250 High Efficiency Power Amplifier
Chapter 3: User Interface
KB-DA2250 High Efficiency Power Amplifier front and rear panel controls, indicator lights, and cable connection ports
Chapter 4: Installation
KB-DA2250 High Efficiency Power Amplifier installation preparation instructions, hardware installation procedures, and other related information
Chapter 5: Technical Specifications
KB-DA2250 High Efficiency Power Amplifier technical specifications
Audience
This manual is primarily intended for personnel who require information regarding the installation, operation, and maintenance of the KB-DA2250 High Efficiency Power Amplifier.
2
How to Use This Manual
Pictures in this manual are for reference only. Please see the actual items
depicted for details.
This product is subject to change when upgraded and will be done so without
notice.
Users should read this manual carefully before using the KB-DA2250 High
Efficiency Power Amplifier, and pay close attention to all warnings and instructions.
Keep this manual for later use and reference. This manual has been reviewed to ensure its accuracy. If there is any
uncertainty or disputes regarding the manual contents, please contact Honeywell.
Honeywell does not take any responsibility for consequences caused by the
misunderstanding of this manual or for incorrect product operation or use.
3
1 Introduction
This chapter introduces the KB-DA2250 High Efficiency Power Amplifier features and functions. The KB-DA2250 High Efficiency Power Amplifier is referred to as “DA” throughout the remainder of this manual.
The DA amplifies audio signal power it receives from audio input devices to maintain clarity and volume when broadcast over many speakers.
Features
The DA includes the following features:
A CLASS-D power amplifier with high efficiency and energy conservation Contains two independent channels The rated output power of each channel is 250W Each channel has 100V or 70V of output Supports balanced or unbalanced audio input Heat radiation through forced air-cooling mode Able to automatically limit output voltage
Functions
The DA includes the following main functions:
Power Supply Protection Temperature Regulation Overload and Short Circuit Protection Fault Detection and Fault Logs
Power Supply Protection
If a power supply fault occurs, the DA automatically disconnects the main power supply.
4
Overheating Protection
When the DA internal temperature reaches 45°C, the cooling fan turns on. At temperatures below 40°C, the fan turns off.
If the temperature surpasses 75°C, the power supply is disconnected and a fault is signaled to prevent overheating. When the temperature returns to safe levels under 70°C, the DA resumes functioning.
Each output channel is protected against such overheating and can signal a fault if temperatures become too high.
Overload and Short Circuit Protection
When the DA power supply detects a circuit overload or if a short circuit occurs, the DA automatically disconnects the power. The DA remains protected and signals a fault until the problem is fixed.
The DA is capable of detecting faults for each individual channel.
Fault Detection and Fault Logs
The main power supply of the DA can detect power failures and overheating to protect it from short circuits and circuit overloads. When the DA detects a failure, a fault is signaled until the problem is fixed.
The current state of the DA is shown on the front panel, and if a fault is signaled it is displayed.
2 Interfaces
Front Panel
5
Table 1 Front Panel
NO
Name
Description
1
POWER
Power indicator light. The light is green when the DA is working normally.
2
Power switch
Turns the power on or off
3
CH1
PROTECT
DA protection indicator light. When the DA overheats, experiences over-current, over-voltage, or under-voltage, the DA automatically protects the equipment. In this case, the light turns yellow.
4
CLIP
Peak clipping indicator light. When the input signal exceeds the rated peak value, the indicator light turns red.
5
SIGNAL
Signal indicator light. This light turns green and fluctuates depending upon the signal intensity. If the light is off, there is no input signal.
6
VOLUME
To increasing or reducing the volume level.
7
CH2
PROTECT
DA protection indicator light. When the DA overheats, experiences over-current, over-voltage, or under-voltage, the DA automatically protects the equipment. In this case, the light turns yellow.
8
CLIP
Peak clipping indicator light. When the input signal exceeds the rated peak value, the indicator light turns red.
9
SIGNAL
Signal indicator light. This light turns green and fluctuates depending upon the signal intensity. If the light is off, there is no input signal.
10
VOLUME
To increasing or reducing the volume level.
Rear Panel
Table 2 Rear Panel
NO
Name
Description
1
RJ45 Ethernet port
Connects to an external audio input device See Table 4 for port PIN descriptions.
2
Cooling fan
6
NO
Name
Description
3
Audio input and control ports
FAULT
A
If a DA fault occurs, it is protected, or it is self-tested, ports A and B experience a short circuit.
B
CH1 +
Balanced positive input
-
Balanced negative input
G
Grounding (Connect to the “-“ port if the input is an unbalanced input connection.)
CH2 +
Balanced positive input
-
Balanced negative input
G
Grounding (Connect to the “-“ port if the input is an unbalanced input connection.)
4
Audio output ports CH1 100V
100V high impedance audio output
70V
70V high impedance audio output
COM
Common
CH2 100V
100V high impedance audio output
70V
70V high impedance audio output
COM
Common
5
Cooling fan
6
Main power supply power port
Supplies electricity to the main power supply
7
Fuse
T10AL250V
8
Grounding terminal
Connects the grounding wire
Table 3 RJ45 Port
PIN
Description
Figure
1
Balanced positive input of CH2
2
Balanced negative input of CH2
3
DA fault information output When the DA is working properly, the output voltage is VCC
(12V-24V).
When the DA faults, is protected, or undergoes self-testing,
the output voltage is GND (0V).
4
Balanced positive input of CH1
5
Balanced negative input of CH1
6
GND (0V)
7
VCC (12V-24V, powered by an external device)
8
Self-test port When the DA output voltage is VCC (12V-24V), the DA is
being self-tested.
When the DA has no input voltage, the DA is working
normally.
7
3 Installation
This chapter describes how to install the DA hardware in step-by-step instructions.
Preparing for Installation
Make sure the following are prepared prior to DA installation:
Tools Materials Cables and Wires Package Inspection
Tools
For the installation of the DA, prepare the following tools:
Anti-static wrist strap Anti-static gloves Cutting pliers Wire cutters Electrical cable crimping pliers
Materials
For the installation of the DA, prepare the following materials:
Insulation tape Wire buckles Wire labels
Cables and Wires
For the installation of the DA, prepare the following cables:
Backup power cable
The backup power cable and main power cable are required to have matching specifications.
8
Audio output cable
The cable should be unshielded.
Notice:
The use of a high-grade, high transmission capacity speaker cable is strongly recommended.
The longer the cable, the thicker it should be to retain transmitted audio quality. Select the appropriate audio cable according to the installation situation and environment.
Package Inspection
Check the packaging and make sure all items specified on the Package Contents list are intact (see Chapter 2). If an item is missing, please contact the appropriate vendor.
Connecting the Cables
These cables include the grounding cable, main and backup power cables, audio input cable and audio output cable.
Notice:
When connecting cables, make sure the DA power switch is turned off. Plug the cables into the correct ports and tighten the cable terminal screws. Power and data wires must be separated and not be wrapped in the same
cable’s insulation. Keeping the power and data cables separate helps to avoid signal interference.
Grounding Cable
The grounding cable connects to the DA grounding cable port.
Notice:
9
Do not connect the grounding output cable with the grounding input cable as this action causes a short circuit to occur.
Audio Input Cable
user can select the input method according to the equipment storage environment.
Use RJ45 Port:
The See Table 3 for the pin descriptions.
Note:
Do not use the RJ45 port and terminal blocks at same time. Instead, plug the CAT5 cable into the RJ45 port.
Use Terminal blocks:
Notice:
If the audio input cable is supplied by the installation personnel, the cable must be shielded.
DA has a balanced input connection. A balanced connection is recommended to reduce AC power interference, especially when using a long cable. For short cables that have an unbalanced connection, the signal impedance should be less than 600 ohms.
The following steps describe connecting a balanced input connection:
1. Pull the input cable through the terminal protection cover, as shown in Figure 1.
Figure 1 Pulling the input cable through the terminal protection cover
10
2. Strip 7 mm of the input cable and connect it to the input terminal, and then tighten the screws to secure the wires, as shown in Figure 2. See Table 2 for port descriptions.
Figure 2 Connecting the input cables to the input terminal
3. Connect the input terminals to their corresponding input ports, as shown in Figu
Figure 3 Connecting the input terminals
Output Cable
1. Pull the output cable through the terminal protection cover, as shown in Figure 1.
2. Strip 7 mm of insulation off the output cable, and connect it to the output terminal, as shown in 04.
11
Figure 4 Output connection terminal
3. Connect the prepared output terminal to the DA output port.
4. Attach the terminal protection cover, and tighten the screws as show in figure 5
Figure 5 Attaching the terminal protection cover
Completing Installation and Commissioning
Once the DA hardware and cables are installed, complete the following commissioning procedures:
1. Set the audio volume to a minimum level.
2. Press the DA front panel power button. The POWER indicator light comes on to show the DA is now turned on and working properly.
3. Optimize the audio volume to an appropriate level. A sound plays through the DA speaker to indicate the DA is working properly.
12
Notice:
If either the CH1 or CH2 PROTECT indicator light is yellow, there is no output signal. Carefully check the cable connections. More information can be found in the “Connecting the Cables” section.
Precautions
When using the DA, pay particular attention to the following issues.
Notice:
Make sure all cables are connected properly before turning on the DA. Refer to the “Connecting the Cables” section for more information.
Pay particular attention to which audio input source is selected and configure the output signal level appropriately, as this can save electricity.
Do not connect the grounding output cable with the grounding input cable as this causes a short circuit to occur.
Warning!
Do not alter the circuit board or schematic diagram. When the CLIP indicator light is flashing red, immediately reduce the audio
volume. If peak clipping occurs for too long, the DA could be damaged. If the audio signal or peak clipping signal is too high, the speakers could be
damaged.
13
4 Technical Specifications
Parameter
Value
Nominal output power
2X250W
Main power supply voltage
~ 220V-240V 50/60Hz
Power consumption
< 720W
Main power supply protection
T10AL 250V
Speaker output voltage
100V / 70V
Frequency response
7018KHz +1dB ~ -3dB
Input sensitivity
1.414V
RMS
Input impedance
20K ohm
Signal to noise ratio
90dB
Non-linear distortion
0.1% (at 1/3 rated power, 1kHz)
Indicator lights
1 power indicator light 2 signal lights 2 peak clipping lights 2 equipment protection lights
Number of channels
2
Operating conditions
95% humidity, 0°C ~+40°C (0~104°F) (no condensation)
Storage temperature
-10°C ~+55°C (14°F~131°F)
Cooling method
Air cooling
Product dimensions (width × height × depth)
400×88×483 mm
Package dimensions (width × height × depth)
489×186×568 mm
Net weight
12kg
Gross weight
14.5kg
14
5 Packing List
Name
Quantities
KB-DA2250 High Efficiency Power Amplifier
1 Audio input connector
1
Audio output connector
1
Safety shield
1
Screws
2
AC power cable
1
Product manual
1
Life Safety A/V (Guangzhou) Co.,Ltd
No. 257 Junye Road Guangzhou GETDD East 510530, China Phone: +86 20 2839 9600 Fax: +86 20 2839 8706 Website: www.empertech.com
Manual_KB-D Series_EN1.0 Sep. 2011
Subject to change without notice
© 2011 Honeywell International, Inc.
Loading...
