Empava EMPV-36GC881, EMPV-36GC901, EMPV-30GC0A5, EMPV-36GC202, EMPV-36GC888 User Manual
...
INSTRUCTION MANUAL
GAS COOKTOP
Appliance Class: 3
Empava Item #:
30 " :EMPV-30GC0A2 EMPV-30GC0A5
36" : EMPV-36GC202 EMPV-36GC881 EMPV-36GC888 EMPV-36GC901
Distributed by:
Empava Appliances Inc.
15253 Don Julian Rd, City of Industry, CA 91745 USA
www.empava.com
The instructions shall be marked with directions to the installer to leave them with
the appliance and to the consumer to retain them for future reference.
WARNING:
This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
If the supply cord is damaged, it must be replaced by the manufacturer. its service agent or
similarly qualified persons in order to avoid a hazard.
WARNING:
If the information in these instructions is not followed exactly, a fire or explosion may result
causing property damage, personal injury or death.
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
1
Contents
Cooktop Description
Important Information
Operation
Maintenance and Cleaning
Troubleshooting
Instructions for the Installer
Important safety requirements
Installation
This appliance shall be installed in accordance with the regulations in force and only used in a well-
ventilated space.
Read the instructions before installing or using this appliance.
The installation must conform with local codes or, in the absence of local codes, with the National Fuel
Gas Code, ANSI Z223.1/NFPA 54 or, in Canada, the Natural Gas and Propane Installation Code, CSA
B149.1.
The appliance, when installed, must be electrically grounded in accordance with local codes or, in the
absence of local codes, with the National Electrical Code, NFPA 70 or the Canadian Electric Code, CSA
C22.1‐02.
2
Cooktop Description
EMPV-30GC0A2
Total h eat inp ut: 37600Btu/hr
Figure 1
Figure 2
1.burner 6—6000Btu/hr in 2.56"
2.burner 7—10200Btu/hr in 3.74"
3.burner 8—13600Btu/hr in 5.20"
4.burner 9—6000Btu/hr in 2.56"
Total h eat inp ut: 37600Btu/hr
5.Burner 10—3400Btu/hr in 1.77”
Operating Instructions:
Knob 1 is for burn er 10
Knob 2 is for burn er 9
Knob 3 is for burn er 8
Knob 4 is for burn er 7
Operating Instructions:
Knob 1 is for burn er 10
Knob 2 is for burn er 9
Knob 3 is for burn er 8
Knob 4 is for burn er 7
1.burner 6—6000Btu/hr in 2.56"
2.burner 7—10200Btu/hr in 3.74"
3.burner 8—13600Btu/hr in 5.20"
4.burner 9—6000Btu/hr in 2.56"
5.Burner 10—3400Btu/hr in 1.77”
Figure 3
Operating Instructions:
Knob 1 is for burner 10
Knob 2 is for burn er 9
Knob 3 is for burn er 8
Knob 4 is for burn er 7
Knob 5 is for burn er 6
1.burner 6—10200Btu/hr in 3.74"
2..burner 7— 6000Btu/hr in 2.56"
3.burner 8—13600Btu/hr in 5.20"
4.burner 9—6000Btu/hr in 2.56"
5..burner 10—3400Btu/h r in 1.77”
Total h eat inp ut: 37600Btu/hr
EMPV-36GC881
5..burner 10—3400Btu/hr in 1.77”
Total h eat inp ut: 37600Btu/hr
Figure 4
3
Operating Instructions:
Knob 1 is for burner 10
Knob 2 is f or burner 9
Knob 3 is f or burner 8
Knob 4 is f or burner 7
1.burner 6—10200Btu/hr in 3.74"
2..burner 7— 6000Btu/hr in 2.56"
3.burner 8—13600Btu/hr in 5.20"
4.burner 9—6000Btu/hr in 2.56"
Operating Instructions:
Knob 1 is for burner 10
Knob 2 is f or burner 9
Knob 3 is f or burner 8
Knob 4 is f or burner 7
Knob 5 is f or burner 6
Figure 5
1.burner 6—10200Btu/hr in 3.74"
2..burner 7— 6000Btu/hr in 2.56"
3.burner 8—13600Btu/hr in 5.20"
4.burner 9—6000Btu/hr in 2.56"
5..burner 10—3400Btu/h r in 1.77”
Total h eat inp ut: 37600Btu/hr
EMPV-36GC901
Figure 6
Operating Instructions:
Knob 1 is for burner 10
Knob 2 is f or burner 9
Knob 3 is f or burner 8
Knob 4 is f or burner 7
Knob 5 is f or burner 6
1.burner 6—10200Btu/hr in 3.74"
2.burner 7—6000Btu/hr in 2.56"
3.burner 8—6000Btu/hr in 2.56"
4.burner 9—3400Btu/hr in 1.77”
5.Burner 10—13600Btu/h r in 5.20"
Total h eat inp ut: 37600Btu/hr
4
Important Information
Read the instructions before installing or using this appliance.
Children should be supervised to ensure that they do not play with the appliance.
These instructions are only valid if the country symbol appears on the appliance. If the symbol does not
appear on the appliance, it is necessary to refer to the technical instructions which will provide the
