EM10
Be sure to read this manual before use.
Safety Precautions
Requests regarding Handling
Product Handling
Instruction Manual
Version 1.11 Mar. 06, 2015
Mobile Payment Device for Business
- 02 -
◆
Introduction 03
◆
Safety Precautions (follow strictly) 04
◆
Requests regarding Handling 09
◆
Waterproofing, Dust-proofing, and Antibacterial Capabilities 12
◆
Product Handling 13
●
Product characteristics 13
●
Product checks 13
●
Part names 14
EM10 main unit 14
Cradle 16
Snap-on 17
●
Attaching/detaching the battery 18
●
Reading cards 19
◆
Product Use 20
●
Connecting power and charging the device 20
Connecting power and charging the device using the cradle 20
Connecting power and charging the device using the snap-on 21
●
Turning on the power 22
●
Turning off the power 22
◆
Troubleshooting 23
●
Before wondering if the product is broken 23
●
When a problem arises 23
◆
EM10 Specifications 24
CONTENTS
EM10
- 03 -
Introduction
Thank you very much for purchasing the EM10 (referred to below as
“the device” or “the main unit”).
This handbook describes the basic handling of this device.
Prior to use, be sure to carefully read the “Safety Precautions”, “Re-
quests regarding Handling”, and “Product Handling”, and handle the
product safely and correctly.
After reading this manual, store it safely so that you can subsequently
refer to it when necessary.
Note that the following components are described in this manual.
The device or main unit: EM10 main unit only
The product: EM10, AC adapter power cable, snap-on,
cradle, and all other packed articles
Battery: EM10 battery
Note: Reproduction of this manual in whole or in part without permission is pro-
hibited.
- 04 -
Safety Precautions (follow strictly)
Be sure to read the “Safety Precautions” carefully before use, and to use the
product safely and correctly.
●
The cautionary points which appear here serve to prevent injury to users
and other individuals, and damage to property. Be sure to follow these points
strictly.
●
The following indication classes represent different levels of injury/damage
which can occur if the accompanying caution is not followed. Be sure to un-
derstand the cautions as you read this manual.
Cautionary points common to the device, battery, AC adapter,
snap-on and cradle
Danger
Indicates content for which, if the indication is
ignored and the product is misused, imminent
dangers which may cause death or serious
injury are expected.
Warning
Indicates content for which, if the indication is
ignored and the product is misused, the possibility of death or serious injury is expected.
Caution
Indicates content for which, if the indication
is ignored and the product is misused, the
possibility of minor injury, or the possibility of
physical damage, is expected.
Examples of pictorial indicators
Indicates that an action is prohibited.
Indicates content which mandates or commands an action (which
absolutely must be executed).
Do not use, store, or leave the battery in locations which reach high
temperatures (for example, in or near flames, near heating appli-
ances, inside heated tables, in locations exposed to direct sunlight
is strong, or in cars in extremely hot surroundings). (This includes
placing the battery in a pocket on one’s clothing or otherwise placing
the battery close to one’s body.) Doing so may cause burst, catch fire,
etc., resulting in fire, injury, etc.
Be absolutely sure to observe the following points. Failure to do so
may cause fire, electric shock, accidents, or product failure.
◆
Be sure to use only designated batteries.
◆
Be sure to charge the battery using the device.
Turn off the device when in the vicinity of electronic devices which
handle high-precision controls, weak signals, etc. It may exert effects
in which for example the electronic equipment malfunctions. Examples
of electronic equipment near which to exercise caution: hearing aids,
pacemakers, other medical electrical equipment, fire alarms, automatic
doors, other automatic control devices, etc. Individuals who use pace-
makers and other medical electrical equipment should check with the
manufacturers of the medical electrical equipment in question regard-
ing the effects of electromagnetic waves on the equipment.
Be careful not to touch the high-temperature parts of this product.
Touching these parts may cause burns.
Do not disassemble, modify, or short-circuit the product. Doing so
may cause burst, catch fire, etc., resulting in fire, injury, etc.
Use with the device only AC adapters, power cables, and batteries
that have been designated by our company. Using products other than
those which have been designated may cause the battery to leak
fluid, heat up, burst, or catch fire.
Do not drop pieces of metal, or water or other liquids, into the device
or into the crevices on the device. Doing so may cause fire, electric
shock, or product failure.
Do not impart strong shocks on the device or throw the device. Doing
so may cause the battery to leak fluid, heat up, burst, or catch fire, or
may cause device failure or fire.
Do not insert the product into a microwave oven, high-pressure ves-
sel, etc. Doing so may cause the battery to leak fluid, heat up, burst,
or catch fire, or may cause the device to heat up, catch fire or be
destroyed.
Avoid using the device in locations with extremely high humidity, loca-
tions exposed to moisture, etc. Failure to do so may cause fire, elec-
tric shock, or product failure. For information regarding waterproofing,
see “Waterproofing, Dust-proofing, and Antibacterial Capabilities”.
Do not connect or disconnect the AC adapter etc. with wet hands.
Doing so may cause electric shock.
In the following cases, turn off the power and unplug the AC adapter
from the outlet. Continued use in this abnormal state may cause acci-
dents or fire.
◆
When performing repair and maintenance, handling errors, etc.
◆
When the device gives off a peculiar odor, releases smoke, or emits
an abnormal sound.
◆
When pieces of metal, or water or other liquids, have gotten into
the device or into the crevices on the device.
Indicates “disassembly prohibited”.
Indicates to “unplug the power plug from the outlet”.
Danger
Warning
EM10
- 05 -
Handling the device’s battery
Handling the device’s AC adapter
Do not heat up the battery, throw it into flames, etc. Doing so may
cause the battery to burst, catch fire, etc., resulting in fire, injury, etc.
Be sure to use only AC adapters designated by our company. Failure
to do so may cause electric shock, fire, or product failure.
Be absolutely sure not to do the following. Doing so may cause fire,
electric shock, accidents, or product failure.
◆
Do not place other objects on top of the product.
◆
Do not strike or otherwise impart shocks to the product.
◆
Do not place the product in unstable locations.
◆
Do not place other objects on top of the AC adapter, power cable,
etc., and do not twist or forcefully pull the cables.
Do not get the battery wet. Doing so may cause the battery to heat
up, emit smoke, or rust.
If during use, charging, or storage, the battery exhibits changes in odor,
temperature, color, or shape, replace the battery. Continued use of the
battery may cause the battery to leak fluid, heat up, burst, or catch fire.
Under no circumstances should the battery be disassembled, modi-
fied, or short-circuited. Doing so may cause the battery to burst, catch
fire, etc., resulting in fire, injury, etc.
Be absolutely sure not to short-circuit the charging terminals. Doing
so may cause device failure or personal injury.
When connecting the battery to the device, if the connection cannot
be made satisfactorily, do not try to remedy the situation using ex-
cessive force. Doing so may cause the battery to leak fluid, heat up,
burst, or catch fire.
Do not use the power cord of an AC adapter if it becomes damaged.
Doing so may cause fire or electric shock.
If the fluid from inside the battery adheres to skin or clothing, immediately
wash the fluid off with pure water, as there is a risk of injury to the skin.
Do not store in a location where there is moisture or large amounts
of dust, or in locations where the temperature becomes very high or
very low. Doing so may cause product failure.
Do not use or store the battery in locations where direct sunlight is strong,
high-temperature locations such as cars in extremely hot surroundings,
etc. Doing so may cause the battery to leak fluid or heat up, which can
cause degradation in the performance or lifespan of the battery.
Be sure to use the designated power supply voltage with the AC
adapter. Failure to do so may cause fire, electric shock, accidents, or
product failure.
Store the product beyond the reach of infants.
If the battery leaks or emits a peculiar odor, immediately move it
away from any source of fire. Failure to do so may cause the leaked
solution becoming ignited and catching on fire or bursting.
Danger
Warning
Warning
Caution
Caution
Turn off the device when in an area in which mobile phone use is
prohibited, such as airplanes and hospitals.
It may exert an effect on electronic equipment, medical electrical
equipment, etc. When using the device in medical institutions, follow
the instructions of the respective institutions.
Remove any dust which has adhered to the power plug portion of the
AC adapter, power cable, etc. Failure to do so may cause fire.
If water, pet urine, or other liquids get inside the product, this may
cause heat generation, electric shock, product failure, etc. For infor-
mation regarding waterproofing, see “Waterproofing, Dust-proofing,
and Antibacterial Capabilities”.
If water or some other liquid should get into the AC adapter, power
cable, etc., unplug the power cord immediately. Failure to do so may
cause electric shock, smoke, or fire.
If the fluid from inside the battery gets into the eyes, cleanse the
eyes with pure water without rubbing, and immediately seek medical
treatment. Failure to do so may cause a loss of vision.
Do not use or store the battery in a high-temperature area such as
near a flame or near a heater. Doing so may cause the battery to leak
fluid, heat up, burst, or catch fire.
Do not drive nails into the battery, strike the battery with a hammer,
step on the battery, etc. Doing so may cause the battery to leak fluid,
heat up, burst, or catch fire.
Be sure to use only batteries designated by our company. Failure to
do so may cause fire, electric shock, accidents, or product failure.
Do not directly solder the battery terminals. Doing so may cause the
battery to leak fluid, heat up, burst, or catch fire.
Be sure to use this device to charge the battery used with this device.
Using devices other than this one to charge the battery may cause the
battery to leak fluid, heat up, burst, or catch fire.
Do not use an AC adapter, power cable, etc. that has become dam-
aged. Doing so may cause fire.
- 06 -
Usage Location Material Surface Treatment
Main unit
Front panel:
Touch panel
Glass -
Exterior case:
Front case
PC resin Hard coat
(containing antibacterial
agent)
Exterior case:
Rear case
PC resin Hard coat
(containing antibacterial
agent)
Exterior case:
Batt cover
PC resin Hard coat
(containing antibacterial
agent)
Exterior case:
Batt deco
PC resin Hard coat
(containing antibacterial
agent)
Exterior case:
Rear deco
PC resin Hard coat
(containing antibacterial
agent)
Exterior case:
Rear cam case
PC resin
(containing antibacterial agent)
-
Cap:
GPS ANT cap
PC resin
(containing antibacterial agent)
-
Battery: knob:
Batt knob (left)
PC resin
(containing antibacterial agent)
-
Battery: knob:
Batt knob (right)
PC resin
(containing antibacterial agent)
-
Side key:
Power button
PC resin
(containing antibacterial agent)
-
Side key:
Volume button
PC resin
(containing antibacterial agent)
-
Panel:
Rear cam window
PMMA -
Panel:
Flash window
PMMA -
Sheet:
Screw covers (4)
PC sheet material Antibacterial agent+
Hard coat
Contact terminal Phosphor bronze Gold plating
Contact terminal
holder
PPA resin
(containing glass)
-
In addition to these points, observe the warnings and cautions appearing in the
respective sections.
Do not get the AC adapter wet. If water, pet urine, or other liquids
get inside it, this may cause heat generation, electric shock, product
failure, etc.
Do not under any circumstances use the AC adapter in high-humidity
locations such as bathing areas. Doing so may cause electric shock,
product failure, etc.
If water, pet urine, or other liquids get inside, unplug the power cord
immediately. Failure to do so may cause electric shock, smoke, or fire.
Do not touch the AC adapter, power cord, or outlet with wet hands.
Doing so may cause electric shock.
Wipe off any dust etc. which has adhered to the power plug portion of
the AC adapter. Failure to do so may cause fire or electric shock.
Do not disassemble or modify the AC adapter. Doing so may cause
electric shock, fire, or product failure.
Do not place heavy objects on top of the AC adapter, twist or forcefully
pull the cables, etc. Doing so may cause fire, electric shock, acci-
dents, or product failure.
Be sure to use the designated power supply voltage with the AC
adapter. Failure to do so may cause fire, electric shock, accidents, or
product failure.
During cleaning, be sure to unplug the AC adapter from the outlet.
Failure to do so may cause electric shock.
When unplugging the power cord, be sure to hold the plug. Pulling the
cord may damage it and cause electric shock, fire, etc.
Caution
Handling the product near medical electrical equipment
If you have an implanted pacemaker, carry and use the product at a
distance of at least 22 cm from the site at which the pacemaker is
implanted. The electromagnetic waves may exert effects in which for
example the pacemaker malfunctions.
Turn off the power when in congested areas such as crowded trains,
as there is a chance that individuals using pacemakers may be in the
vicinity. The electromagnetic waves may exert effects in which for
example the pacemaker malfunctions.
If, during home convalescence or the like, medical electrical devices
other than implanted pacemakers is used in a location other than a
medical institution, check with the manufacturers of the individual
medical electrical devices regarding the effects of electromagnetic
waves.
Warning
Observe the following points when using the product in a medical
institution.
◆
Do not take the product into an operating room, an intensive care
unit (ICU), or a coronary care unit (CCU).
◆
Turn off the device when in a hospital ward.
◆
Turn off the device even when in a lobby etc. if there is medical
electrical equipment in the vicinity.
◆
If a medical institution designates specific locations where using
the product is prohibited, bringing the product in is prohibited, etc.,
follow the instructions of the institution.
Material List
Loading...
