Emotiva ERC-3 User Manual
Important Safety Precautions and Explanation of Symbols
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important
installation, operation, and service instructions in this manual.
!
The lightning ash with arrowhead symbol within an equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltages within the enclosure that may be of sucient magnitude to
constitute a risk of electrical shock to the user.
Please read this manual thoroughly before attempting to install, congure, or operate the Emotiva ERC-3.
After successful installation and conguration of the ERC-3, be sure to retain this manual in a safe place for
future reference.
Safety is a key component to a long lasting and trouble free installation. Please read and follow all
instructions and heed all warnings on the ERC-3 and in this manual. The vast majority of the subsequent
safety precautions are common sense. If you are not comfortable with the installation of audio/video
entertainment equipment, you should seek the services of a qualied installation professional or call us for
help.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT USE THE ERC3 NEAR WATER
OR IN WET LOCATIONS, DO NOT EXPOSE IT TO RAIN OR MOISTURE, DO NOT EXPOSE IT TO DRIPPING
!
OR SPLASHING FROM OTHER SOURCES, AND ENSURE THAT NO OBJECTS FILLED WITH LIQUIDS SUCH
AS VASES ARE PLACED ON IT. DOING SO MAY RESULT IN DAMAGE TO THE ERC3 AND THE RISK OF
ELECTRIC SHOCK, WHICH MAY RESULT IN BODILY INJURY OR DEATH.
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER FROM THE
ERC3. THERE ARE NO USERSERVICEABLE PARTS INSIDE THE ERC3. REFER ALL SERVICE TO QUALIFIED
SERVICE PERSONNEL.
Do not install the ERC-3 near or above any heat sources such as radiators, heating vents, or other apparatus
that produces heat. Do not block any ventilation openings or heat sinks. Avoid installing the ERC-3 directly
above other heat-producing equipment unless sucient ventilation or forced-air cooling is provided.
Do not install the ERC-3 in locations without proper ventilation. The ERC-3 should not be operated on a bed,
sofa, rug, or similar surface that may block vents. The ERC-3 should not be installed in an enclosed location
such as a bookcase, cabinet, or closed equipment rack unless sucient ventilation is provided.
Always install your ERC-3 according to the manufacturer’s instructions and only use attachments or
accessories specied by the manufacturer.
Do not install the ERC-3 on any stand, shelf, or other piece of furniture that is unable to support its weight.
If a cart is used to move the ERC-3, use caution to avoid injury from tip-over.
Connect the ERC-3 only to power sources of the correct voltage (as shown in this manual and on the ERC-3).
Protect power supply cables from being pinched, walked on, or otherwise damaged. Be especially careful
where the power cable enters the power outlet and the ERC-3 unit.
Only connect the ERC-3 to an electrical outlet or extension cord of appropriate type and rating.
DO NOT defeat the safety purpose of a grounding or polarized plug by removing ground pins or using unsafe
adapters. A polarized plug has two blades - one wider than the other. A grounding plug has a third ground
prong in addition to the two main conductors. The wide blade or third groundling prong is provided for your
safety. If the provided plug does not t your outlet, consult an electrician to replace your obsolete outlet. If
you replace the ERC-3 power cord, only use one of similar type and equal or greater current rating.
The power cable for the ERC-3 should be unplugged from the outlet during severe electrical storms, or when
unused for a long period of time.
Only replace the fuse(s) in the ERC-3 with a fuse(s) of proper value and voltage rating.
The ERC-3 should only be cleaned as directed in the manual. Avoid spraying liquids directly onto the ERC-3
and NEVER spray liquids into the vents or CD Loader mechanism. Care should be taken so that small objects
do not fall into the inside of the ERC-3.
You should seek service for your ERC-3 by qualied service personnel if any of the following occur:
!
1. The power-supply cord or the plug has been damaged.
2. Objects or liquid have fallen or spilled into the vents or CD Loader mechanism.
3. The ERC-3 has been exposed to rain.
4. The ERC-3 exhibits a marked change in performance.
5. The ERC-3 has been dropped, or its enclosure or chassis is damaged.
NOTE: TO COMPLETELY DISCONNECT THE ERC-3 FROM THE AC POWER MAINS, DISCONNECT THE
AC POWER CORD FROM THE AC RECEPTACLE.
NOTE: THE ERC-3 AC POWER CORD MUST REMAIN READILY ACCESSIBLE AT ALL TIMES.
WARNING: THE ERC-3 IS A CLASS 1 LASER PRODUCT. REMOVAL OF PROTECTIVE COVERS, UNATHORIZED
REPAIRS OR MODIFICATIONS, OR OPERATION NOT IN ACCORDANCE WITH THE PROCEDURES SET FORTH
!
IN THIS MANUAL, MAY EXPOSE THE USER TO HAZARDOUS LEVELS OF LASER RADIATION. DO NOT REMOVE
COVERS UNLESS INSTRUCTED TO DO SO BY AUTHORIZED PERSONNEL. DO NOT OPERATE THE UNIT WITH
COVERS REMOVED. REFER ALL REPAIRS TO QUALIFIED SERVICE PERSONNEL.
WARNING: NEVER FORCE FOREIGN OBJECTS INTO THE CD LOADER MECHANISM. NEVER INSERT CRACKED,
BROKEN, OR OTHERWISE DAMAGED DISCS INTO THE CD LOADER MECHANISM. DO NO INSERT DISCS
!
CONTAMINATED WITH EXCESSIVE DIRT OR STICKY MATERIALS INTO THE CD LOADER MECHANISM. DOING
SO MAY RESULT IN MALFUNCTION OR PERMANENT DAMAGE (WHICH MAY NOT BE COVERED BY YOUR
WARRANTY).
CAUTION
CAUTION: TO REDUCE THE RISK
OF ELECTRICAL SHOCK, DO
NOT REMOVE COVER. NO USER
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
ERC-3
Dierential Reference™ CD Player and Digital Transport
Contents
Important Safety Precautions and Explanation of Symbols
Introduction .......................................................................................................................2
About This Manual ........................................................................................................... 3
Features ...............................................................................................................................4
Unpacking ...........................................................................................................................5
Supported Formats ..........................................................................................................6
Connections .......................................................................................................................7
ERC-3 Front Panel ............................................................................................................. 8
ERC-3 Rear Panel ............................................................................................................ 10
ERC-3 Remote Control ................................................................................................. 12
Basic Operation .............................................................................................................. 15
Changing Remote Control Batteries....................................................................... 16
Specications .................................................................................................................. 17
Care and Maintenance ................................................................................................ 18
Troubleshooting ............................................................................................................ 19
Emotiva Audio Corporation Five-Year Limited Warranty ................................ 20
FCC Compliance ............................................................................................................. 22
Important User Information ...................................................................................... 22
Notes .................................................................................................................................. 23
ERC-3
Introduction
Thank you for choosing the Emotiva ERC-3 Dierential Reference™ CD Player and
Digital Transport. The ERC-3 combines a high-quality digital CD transport and a superb
balanced DAC (digital-to-analog converter) in one convenient and attractive package. The
advanced engineering, quality construction, and powerful laser engine in the ERC-3 ensure true
audiophile performance; whether you use the ERC-3 as a transport or as a complete audio source
component.
On the outside, a solid-aluminum face plate and new blackout trim contribute to the ERC-3’s
modern “Gen2” design aesthetic and the reinforced and isolated steel chassis delivers rugged
reliability and prevents any external inuences from interfering with your listening experience.
The precision tray-loading disc mechanism handles your discs gently and carefully, and is
automatically lit by soft blue illumination so you can see to load and unload discs in a darkened
room. Control is provided via either the full function solid metal remote control or the front panel
transport buttons.
Inside, extra shielding and mass loading provides even more protection against interference,
vibration, and jitter. A well ltered multi-stage supply powers the digital circuitry and analog
circuitry and the new upgraded DAC, allowing the ERC-3 to deliver truly phenomenal audio
quality.
Whether you use the ERC-3 as a precision bit-perfect digital CD transport, or connect the analog
output of its advanced DAC to your preamp, we’re certain the ERC-3 will elevate your CD listening
experience to the next level.
The Emotiva Team.
Page 2
ERC-3
About This Manual
This manual will provide you with all the information you need to get great sound, and many
years of reliable service, from your ERC-3. The manual also includes a brief summary of the
features oered by the ERC-3 and describes how the controls work and how to perform common
operations.
You may wish to record serial numbers or other purchase information on the Notes page at the
back of this manual.
Page 3
ERC-3
Features
The Emotiva ERC-3 Dierential Reference™ CD Player and Digital Transport is a two-channel audio
CD player that combines rugged reliability, bit-perfect digital performance, and superb sound
quality in a single attractive and convenient source component. Here are just some of the exciting
features oered by the ERC-3:
• Excellent technical performance and true audiophile sound quality.
• A dedicated CD player that plays all standard Red Book stereo audio CDs
(the ERC-3 can also play MP3 CDs and the Red Book audio CD layer of Hybrid SACDs).
• Supports HDCD encoded discs.
• Analog Devices AD1955 High-Performance Multi-bit Delta-Sigma DAC.
• Multiple isolated and well ltered linear power supplies for analog and digital circuitry.
• Full assortment of digital outputs (Toslink optical S/PDIF, coax S/PDIF, and AES/EBU).
• Both balanced and unbalanced analog audio outputs.
• Machined, gold plated audiophile quality RCA unbalanced output connectors.
• Machined, gold plated coaxial digital S/PDIF output connector.
• Reinforced steel chassis for rugged reliability and isolation from vibration.
• Additional internal shielding and mass loading to minimize interference and vibration.
• High-reliability tray loading mechanism handles discs consistently and reliably.
• Solid machined aluminum face plate and new “Gen2” black trim.
• High visibility blue alphanumeric VFD status display.
• Front panel transport controls with blue halo illumination.
• Full function solid machined aluminum remote control.
• Motorized CD loading tray (which automatically illuminates when you open it).
• User selectable universal line voltage operation (115 VAC /230 VAC +/- 15%).
• Trigger input and output.
• Standard IEC power receptacle (accepts all standard IEC power cables).
Page 4
ERC-3
Unpacking
Your ERC-3 was carefully packed and should reach you in perfect condition. If you notice any
shipping damage or other issues when you unpack it, please contact Emotiva immediately.
Gently remove your ERC-3 and its remote control from the packing carton, and remove all
wrappings and shipping material.
It is important to save the box and all packing materials in case your ERC-3 ever needs to be
moved or shipped back to the factory for service.
We truly value customer feedback and would like to hear from you.
Box Contents
• ERC-3 unit
• Remote control
• Power cable
• Trigger cable
Page 5
