Specication
Throat Size
Nominal Impedance
Power Rating**
Free Air Resonance
Usable Frequency Range
Recommended Crossover
Sensitivity***
Magnet Weight
Voice Coil Diameter
Re
Minimum Impedance
106.1dB (1W/1m across 1.2kHz-20kHz on
Mounting Information
Available in both screw-on and bolt-on formats
Overall Diameter
Mounting Holes Diameter (bolt on)
Mounting Holes B.C.D. (bolt on)
Mounting Thread (screw on)
Depth
Weight
Volume
3”, 76.2mm or 2.25” 57.2mm
Materials of Construction
Voice Coil Former
Diaphragm Material
Magnet Composition
1”, 25.4mm
8 or 16 ohms
80W (AES)
540Hz
1.2kHz-20kHz
18dB/oct @ 1.2kHz
axis on H290 horn)
34 oz.
2”, 50.8mm
6.1 ohms
7.6 ohms @ 3.7kHz
5.25”, 133.4mm
2X 1/4-20 or 3x M6
1 3/8” 18 UNEF ext.
2.2”, 55.9mm
5 lbs, 2.3kg
30.76 cu.in.
Polyimide
Titanium
Ferrite
PSD:2002 HF Drivers
PSD:2002 measured on Eminence H290 horn.
** Multiple units exceeded published power rating evaluated under AES noise sources and test standards while mounted on Eminence’s H290 or H290S horn in a non-temperature controlled environment.
*** The average on axis output across the entire usable frequency range when mounted to the H290 or H290S horn and applying 1W/1m into the nominal impedance, i.e. 2.83V/8Ω, 4V/16Ω. Eminence response curves are
measured under the following conditions: All speakers are tested at 1W/1m using a variety of test set-ups for the appropriate impedance | LMS using 0.25” supplied microphone (software calibrated) mounted 1m from wall/
bafe | 2ft x 2ft bafe is built into the wall with horn front mounted | Carver PM-120 amplier | 2700ft3 chamber with berglass on all six surfaces (three with custom-made wedges).
