Eminence Alpha 3 A User guide

American Standard series

ALPHA 3-8

The Eminence Alpha 3-8 is a truly versatile compact full­range driver perfectly suited for tight fitting pro audio line
array and column array applications. With a program power
rating of 60 watts, this 3” driver utilizes an 8.3 oz ferrite
magnet in conjunction with an internal neodymium bucking
magnet for increased sensitivity and extends the response
out to 20kHz. The highly pressed cone sandwiches paper
with a layer of water-resistant polypropylene for increased
stiffness and lower distortion.

•

60 W Program Power

•

3.0” Nominal Diameter

•

8 Ω

ENCLOSUREAPPLICATION

4

4

Sealed Box

Vented Box

Scoop Loading

Horn Loading

Full Range

Midrange

Midbass

Woofer

Subwoofer

Bass Guitar

SPECIFICATION

Nominal Basket Diameter

Nominal Impedance*

Power Rating*

Program Power

Nominal Power

Resonance

Usable Frequency Range

Sensitivity*

Magnet Weight

Gap Height

Voice Coil Diameter

MATERIALS OF CONSTRUCTION

Copper voice coil

Polyimide former

Ferrite magnet

Vented / Flux source cap

Pressed steel basket

Paper/Poly sandwich cone

Poly cone edge

Poly dust cap

4

4

3.0”, 76 mm

118 Hz

150 Hz – 20.0 kHz

88.6 dB

0.10”, 2.5 mm

0.787”, 20 mm

THIELE & SMALL PARAMETERS

Fs

Re

Le

Qms

Qes

8 Ω

Qts

Vas

60 W

Vd

30 W

Cms

BL

Mms

EBP

8 oz.

Xmax

Sd

Xlim

FREQUENCY RESPONSE & IMPEDANCE CURVE

dBSPL

95

90

85

80

118 Hz

5.12 Ω

0.11 mH

7.94

0.53

0.50

0.03 cu.ft., 0.95 liters

6.9 cc

0.84 mm/N

3.93 T-M

2 grams

220

2.40 mm

28.6 cm2

4.0 mm

*

MOUNTING INFORMATION

Recommended Enclosure Volume

Sealed

Vented

Driver Volume Displaced

Major Diameter

Flat to Flat Diameter

Baffle Hole Diameter

Front Sealing Gasket

Rear Sealing Gasket

Mounting Holes Diameter

Mounting Holes B.C.D.

Depth

Net Weight

Shipping Weight

0.85–1.42 liters,

0.03–0.05 cu.ft.

1.42–1.98 liters,

0.05–0.07 cu.ft.

0.005 cu.ft., 0.13 liters

3.98’’, 101.1 mm

3.24”, 82.3 mm

3.04’’, 77.2 mm

Yes

Yes

0.16’’, 4.1 mm

3.63’’, 92.1 mm

1.76”, 44.6 mm

0.90 lbs , 0.41 kg

1.10 lbs , 0.50 kg

Ohm

80

70

60

50

40

30

75

70

65

60

55
