ALPHA 10
Nominal Basket Diameter
Impedance
Power Rating
Resonance
Usable Frequency Range
Sensitivity
Magnet Weight
Gap Height
Voice Coil Diameter
Mounting Information
Recommended Enclosure Volume
(vented)
Overall Diameter
Baffle Hole Diameter
Front Sealing Gasket
Rear Sealing Gasket
Mounting Holes Diameter
Mounting Holes B.C.D.
Depth
Shipping Weight
Thiele-Small Parameters
Resonant Frequency (fs)
Impedance (Re)
Coil Inductance (Le)
Electromagnetic Q (Qes)
Mechanical Q (Qms)
Total Q (Qts)
Compliance Equivalent Volume (Vas)
Peak Diaphragm Displacement Volume (Vd)
Mechanical Compliance of Suspension (Cms)
BL Product (BL)
Diaphragm Mass inc. Airload (Mms)
Equiv. Resistance of Mechanical
Suspension Loss (Rms)
Efficiency Bandwidth Product (EBP)
Voice Coil Overhang (Xmax)
Surface Area of Cone (Sd)
Impedance at Resonance (Zmax)
Maximum Linear Excursion (Xmech)
10", 254mm
8 ohms
150Wrms
50Hz
45Hz - 5kHz
see guide on web
20oz.
0.25", 6.35mm
1.5", 38.1mm
42 - 71 liters
1.5 - 2.5 cu. ft.
10.11", 256.8mm
9.13", 231.8mm
fitted as standard
fitted as standard
0.225", 5.7mm
9.6", 243.8mm
3.90", 99mm
5.8lbs., 2.6 kg.
50Hz
5.31 ohms
0.66mH
0.66
5.21
0.59
82.2 liters
2.9 cu. ft.
113cc
0.46mm/N
7.5 T-M
22 grams
1.33N*sec/M
75
3.2mm
355.4cm
2
47 ohms
18.29mm
_______________
Application Notes
Ideal for two-way sound
reinforcement systems,
keyboard, and guitar
combos.
__________________
Materials of Construction
● Kapton coil former for increased rigidity and
thermal protection
● Polyamide-imide coated two-layer, 31ga., copper
voice coil for improved power handling and
durability.
● Ferrite Magnet
● Vented core for increased power handling
● Premium pressed steel basket for maximum
strength
● Paper cone
● Cloth cone edge
● Solid composition paper dust cap
Eminence Speakers LLC
P. O. Box 360
Eminence, Kentucky 40019
USA
502.845.5622 phone
502.845.5653 fax
[email protected]
www.eminence.com
FORM 96118
