Emerson HD8118 User Manual

PERSONAL CD, CD-R/RW PLAYER

with 60 SECOND ANTI-SHOCK

and LIGHTWEIGHT

STEREO HEADPHONES

OWNER’S MANUAL

HD8118

Visit our web site at www.emersonradio.com

HD8118_022004.p65 20/2/2004, 11:3720

Thank you.........

For purchasing this Emerson Personal CD Player. The CD player has a 20
track programmable memory so you can listen to the songs on your favorite
CD's in any order you choose. Or you can use the Random playback feature
and let the player select the playback order for you. Use the 3-way Repeat
feature to repeat a single track, the entire disc, or a programmed sequence
of tracks, indefinitely. We've also included 60 second Electronic Anti-Skip
Protection which makes this player virtually skip-free during most active
uses.

Please read this instruction manual completely and carefully to make sure
you understand the proper operation of this product, and get the maximum
enjoyment out of all the features of this state-of-the-art CD player.

Once again, thanks for purchasing this Emerson product.
The serial number of your CD player can be found on the bottom cabinet.

We suggest that you record the serial number of your unit in the space
below for future reference.

Model Number: HD8118
Serial Number:

1

HD8118_022004.p65 20/2/2004, 11:371

IMPORTANT NOTES

!

WARNING: TO PREVENT FIRE OR SHOCK HAZARD,
DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.

Avoid installing the unit in locations described below:

• Places exposed to direct sunlight or
close to heat radiating appliances such
as electric heaters.

CLASS 1 LASER PRODUCT

• Dusty places.

• Places subject to constant
vibration.

• Humid or moist places.

CLASS 1 LASER PRODUCT

APPAREIL Á LASER DE CLASSE 1

PRODUCTO LASER DE CLASE 1

CAUTION

INVISIBLE LASER RADIATION

WHEN OPEN AND INTERLOCKS

DEFEATED.

AVOID EXPOSURE TO BEAM

This product contains a low power Laser Device.

CAUTION

THIS LASER COMPACT DISC PLAYER FUNCTIONS BY HELP OF INVISIBLE
LASER LIGHT AND IS EQUIPPED WITH SAFETY SWITCHES TO AVOID
EXPOSURE WHEN DOOR IS OPEN AND SAFETY INTERLOCKS ARE
DEFEATED. IT IS DANGEROUS TO DEFEAT OR BYPASS SAFETY SWITCHES.

DANGEROUS VOLTAGE
Uninsulated Dangerous Voltage, that may be of sufficient
magnitude to constitute a risk of electric shock to persons is
present within this product's enclosure.

ATTENTION
The Owner's Manual contains important operating and
maintenance instructions.
For your safety, it is necessary to refer to the manual.

This device complies with part 15 of the FCC rules. Operation is subject to the
condition that this device does not cause harmful interference.

2

HD8118_022004.p65 20/2/2004, 11:372

PREPARATION FOR USE

REMOVE THE TRANSIT CARD

This personal CD player is shipped with a dummy CD ‘transit card ‘ inside the CD
compartment. The purpose of this card is to prevent the laser from moving during
shipment of the product. This card must be removed before using the CD player.

Slide the OPEN switch to the right to unlock the CD door. Remove the ‘transit card’
from the player and discard it.

POWER SOURCES

This personal CD player is designed to operate on two “AA” batteries, not included.
Use a well known brand of Alkaline batteries for longest life and best performance.

This player can also be operated by with an optional AC/DC converter/adapter, not
included. If you decide to purchase an optional AC/DC adapter the specification
must be as follows:

Input: 120V 60Hz AC

Output: 4.5V DC, 500 mA.

Plug: 1.7 mm Female Type with Positive Center, UL Listed.

Positive (+)

You may also purchase a “Universal” type AC/DC adapter which allows you to
select the required output voltage and plug polarity, and normally includes multiple
plug sizes to fit most brands of equipment. Always look for the “UL” listing mark
when you purchase an adapter.

3

HD8118_022004.p65 20/2/2004, 11:373

Negative (–)

INSTALLING THE BATTERIES

OPE

N

+

Note: The battery compartment is located inside the CD compartment.

1.) Slide the OPEN switch to the right to open the CD door. If you have not already
done so, remove the dummy CD ‘transit card’ and discard it.

2.) Press the battery door locking tab in the direction of the ‘Arrow’ to open the
battery door. Lift the door upward as shown.

3.) Insert two alkaline “AA” batteries in the battery compartment. Be sure to observe
the polarity markings engraved in the battery compartment. If the batteries are
inserted incorrectly the unit will not work.

4.) Fold the battery removal ribbon over the top of the batteries, close the battery
door, and push the battery door downward until you hear a ‘click’ sound to
lock the door again.

5.) Close the CD door.

REPLACING THE BATTERIES

When the battery symbol appears in the display the batteries are becoming
weak and should be replaced. Always replace both batteries at the same time with

new fresh alkaline batteries. Do not mix old and new batteries or different types of
batteries together.

If the display remains blank when you press the PLAY/PAUSE button, the batteries
are completely dead. Replace them immediately. If dead batteries are left inside
the battery compartment for a long period of time they may leak and cause damage
to the unit, and such damage or corrosion from leaking batteries is not covered by
your warranty.

4

HD8118_022004.p65 20/2/2004, 11:374

CONNECTING THE OPTIONAL AC ADAPTER (NOT INCLUDED)

DC 4.5V INPUT JACK

TO 120V/60Hz AC OUTLET

OPTIONAL AC/DC ADAPTER

1.) Connect the small female plug of the optional AC adapter to the “DC IN 4.5 V”
jack on the right side of the CD player.

2.) Connect the adapter housing to your 120V 60Hz AC outlet.

Notes:

• Never connect or disconnect the adapter from the AC outlet while your hands
are wet.

• The housing of the AC adapter may become warm during operation. This is
normal.

• The female plug of the AC adapter must be completely disconnected from the
CD player in order to operate the player on batteries.

Follow these precautions when using batteries in this device:

1. Use only the size and type of batteries specified.

2. Be sure to follow the correct polarity when installing the batteries as indicated in the battery
compartment. Reversed batteries may cause damage to the device.

3. Do not mix different types of batteries together (e.g. Alkaline and Carbon-Zinc) or old batteries
with fresh ones.

4. If the device is not to be used for a long period of time, remove the batteries to prevent
damage or injury from possible battery leakage.

5. Do not try to recharge batteries not intended to be recharged; they can overheat and rupture
(Follow battery manufacturer’s directions.)

BATTERY PRECAUTIONS

5

HD8118_022004.p65 20/2/2004, 11:375

CONNECTING THE STEREO HEADPHONES

Connect the plug of the supplied stereo headphones to the green-colored
headphone jack on the left side of the cabinet.

NOTE: Make sure the headphone plug is inserted into the headphone jack as
far as it will go. If the plug is not fully inserted, you may only hear sound from
one side of the headphones.

IMPORTANT!

Always set the VOLUME control to a low level before you put the headphones on
and begin playing a CD. Then start playback and gradually increase the volume to
a comfortable listening level. Do not play the CD at loud volume levels that might
prevent you from hearing warning sounds such as car horns, etc.

6

HD8118_022004.p65 20/2/2004, 11:376

LOCATION OF CONTROLS AND INDICATORS

4

51011169

12

1312

3

15

7

14

1.) OPEN Switch – Slide to the right to unlock and open the CD door..

2.) VOLUME Control – Raises or lowers the volume.

3.) PHONES Jack – Connect stereo headphones, included, to this jack.

6
8

4.) HOLD (Bottom Cabinet) Switch.

5.) PROG (Program) Button

6.) PLAY/PAUSE Button.

7.) SKIP REV Button.

8.) SKIP FWD Button.

9.) LCD Display – Shows Track number, Playing time, Anti-Skip status, Program,
Repeat, Shuffle, and Intro modes.

10.) MODE Button – Selects the playback mode: Repeat 1/All, Shuffle, or Intro.

11.) ESP Button

12.) STOP Button.

13.) DC IN 4.5V Input Jack – Connect an AC adapter (not included) to this jack to
use 120V 60Hz house current.

14.) CD Door.

15.) BASS BOOST ON/OFF Switch.

16.) Battery Compartment (Inside CD Compartment).

7

HD8118_022004.p65 20/2/2004, 11:377

LCD DISPLAY INDICA TORS

10

43265

7

918

1.) Track Number Display.

2.) PROG (Program) Indicator – Appears when programming tracks or

playing programmed tracks.

3.) SHUFF (Shuffle) Indicator – Appears when Random playback mode

is selected.

4.) INTRO Indicator – Appears when Intro playback mode is selected.

5.) HOLD Indicator – Appears when HOLD switch is set to ‘On’ position.

6.) (Repeat 1) /ALL Indicators – Appears when the Repeat playback

mode is selected.

7.) Battery Status Indicator – Appears when battery level becomes low.

8.) Elapsed Time (Seconds) Display.

9.) Elapsed Time (Minutes) Display.

10.) ANTI-SHOCK Indicator – Indicates ESP Protection is activated.

8

HD8118_022004.p65 20/2/2004, 11:378

OPERATING INSTRUCTIONS

(Off)

SPECIAL FUNCTIONS

HOLD Switch

The HOLD switch on the bottom of the cabinet must be in the ‘Off’ (left) position to
start the CD player. If you plan to carry the CD player in a handbag, briefcase,
school bag, back pack, etc, slide the HOLD switch to the ‘On’ (right) position.
While the HOLD switch is ‘On’ all of the controls on the CD door are disabled. This
prevents the player from starting accidentally by something pressing against the

PLAY/PAUSE button.

HOLD

After you begin CD playback you may also slide the HOLD switch to the ‘On’ (right)
position to disable all the controls on the CD door. You can then place the player in
a handbag, backpack, etc, and do not have to worry that the player will be
accidentally turned off by something pressing against the STOP button or Track
Skip buttons.

BASS BOOST Switch

During CD playback you may slide the BASS BOOST switch to the ‘ON’ position
to activate the Bass Boost function as desired.

9

HD8118_022004.p65 20/2/2004, 11:379

Electronic Skip Protection (ESP)

This CD player includes an Electronic Skip Protection circuit that continuously
stores 60 seconds of CD music in an electronic memory. If the player is bumped
or shaken you will not hear any skipping because the player is reading from the
memory, not directly from the disc. Of course if the shaking continues for more
than 60 seconds, the ESP memory will be depleted and the player may then skip
or stop if the shaking continues.

ESP memory function is automatically activated during playback. The display will
show the ESP meter and begin to fill up with bars. Each bar represents

approximately 12 seconds of music in the memory. When all 5 bars appear
the memory contains 60 seconds of music. If the player is bumped or shaken one
or more of the bars may disappear as the memory is depleted . When the
shaking stops the memory will fill up again.
To deactivate the ESP function, press the ESP button and the ESP meter will

disappear in the display.

Notes:

• The ESP circuit draws additional current from the batteries. To extend the

battery life leave the ESP circuit ‘Off’ when the unit is used in a stable location
not subject to bumps and shakes.

• When the ESP circuit is switched ‘On’ or ‘Off’ the sound will be

interrupted for 2 to 5 seconds. This is normal and not an indication
of any problem with the player.

10

HD8118_022004.p65 20/2/2004, 11:3710

NORMAL CD PLAYBACK

OPEN

• Make sure you have installed the batteries.

• Make sure the HOLD switch is set to the ‘Off’ (left) position.

• Make sure to set the VOLUME control to a low setting before you put on

the headphones.

IMPORTANT:

This CD player can play normal CDs plus CD Recordable (CD-R) and CD
Rewriteable (CD-RW) discs. However the playability of CD-R and CD-RW discs
may be affected by the type of software that was used in ‘ripping’ the tracks from
the original discs and ‘burning’ the tracks onto the blank media. Playability may
also be affected by the quality and condition of the blank media you use for
recording. 100% compatibility cannot be guaranteed. This is not an indication of
any problems with your player.

1.) Slide the CD door OPEN switch to the right to unlock

and open the CD door.

2.) Place your CD on the center spindle with the printed

label side facing up. Press downward on the disc
near the center hole until the disc is fully seated on
the spindle.

3.) Close the CD door and connect the headphones to

the headphone jack (green color) by pushing the
headphone plug the into headphone jack until a ‘click’
sound is heard.

4.) Press the PLAY/PAUSE button to begin playback. The

display will briefly show “60 SEC”, then “ – – “ flashes
while the player reads the disc. The total tracks and playing time will appear
briefly in the display and then the playback will begin on track 1. The display
will show the elapsed playing time of the track being played.

5.) Adjust the VOLUME, and BASS BOOST controls as desired.

11

HD8118_022004.p65 20/2/2004, 11:3711
