Emerson HD7998 User Manual
Personal CD Player
with Lightweight
Stereo Headphones
OWNER’S MANUAL
HD7998
Visit our web site at www.emersonradio.com
HD7998_B081105.p65 11/8/2005, 15:0519
Thank you.........
For purchasing this Emerson Personal CD Player. The CD player has a 20
track programmable memory so you can listen to the songs on your favorite
CD's in any order you choose. Or you can use the Shuffle playback feature
and let the player select the playback order for you.
Use the 3-way Repeat feature to repeat a single track, the entire disc, or a
programmed sequence of tracks, indefinitely.
Please read this instruction manual completely and carefully to make sure
you understand the proper operation of this product, and get the maximum
enjoyment out of all the features of this state-of-the-art CD player.
Once again, thanks for purchasing this Emerson product.
HD7998_B081105.p65 11/8/2005, 15:051
1
IMPORTANT NOTES
!
WARNING: TO PREVENT FIRE OR SHOCK HAZARD,
DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
Avoid installing the unit in locations described below:
• Places exposed to direct sunlight or
close to heat radiating appliances such
as electric heaters.
CLASS 1 LASER PRODUCT
• Dusty places.
• Places subject to constant
vibration.
• Humid or moist places.
CLASS 1 LASER PRODUCT
APPAREIL Á LASER DE CLASSE 1
PRODUCTO LASER DE CLASE 1
CAUTION
INVISIBLE LASER RADIATION
WHEN OPEN AND INTERLOCKS
DEFEATED.
AVOID EXPOSURE TO BEAM
This product contains a low power Laser Device.
CAUTION
THIS LASER COMPACT DISC PLAYER FUNCTIONS BY HELP OF INVISIBLE
LASER LIGHT AND IS EQUIPPED WITH SAFETY SWITCHES TO AVOID
EXPOSURE WHEN DOOR IS OPEN AND SAFETY INTERLOCKS ARE
DEFEATED. IT IS DANGEROUS TO DEFEAT OR BYPASS SAFETY SWITCHES.
DANGEROUS VOLTAGE
Uninsulated Dangerous Voltage, that may be of sufficient
magnitude to constitute a risk of electric shock to persons is
present within this product's enclosure.
ATTENTION
The Owner's Manual contains important operating and
maintenance instructions.
For your safety, it is necessary to refer to the manual.
This device complies with part 15 of the FCC rules. Operation is subject to the
condition that this device does not cause harmful interference.
2
HD7998_B081105.p65 11/8/2005, 15:052
PREPARATION FOR USE
Remove The Transit Card
This personal CD player is shipped with a dummy CD ‘transit card ‘ inside the CD
compartment. The purpose of this card is to prevent the laser from moving during
shipment of the product. This card must be removed before using the CD player.
Slide the Open “ ” switch to the right to unlock the CD door. Remove the ‘transit
card’ from the player and discard it.
Power Sources
This personal CD player is designed to operate on two “AA” batteries, not included.
Use a well known brand of Alkaline batteries for longest life and best performance.
This player can also be operated by with an optional AC/DC converter/adapter, not
included. If you decide to purchase an optional AC/DC adapter the specification
must be as follows:
Input: 120V 60Hz AC
Output: 4.5V DC, 500mA.
Plug: Female Type with Positive Center, UL Listed.
Positive (+)
You may also purchase a “Universal” type AC/DC adapter which allows you to
select the required output voltage and plug polarity, and normally includes multiple
plug sizes to fit most brands of equipment.
Always look for the “UL” listing mark when you purchase an adapter.
Negative (–)
3
HD7998_B081105.p65 11/8/2005, 15:053
Connecting The Optional AC/DC Adapter (Not Included)
DC 4.5V Input Jack.
To 120V/60Hz AC Outlet.
1.) Connect the small female plug of the optional AC adapter to the “DC 4.5V”
jack on the right side of the CD player.
2.) Connect the adapter housing to your 120V 60Hz AC outlet.
20 TRACK PROGRAMMABLE CD PLAYER
Optional AC/DC Adapter
NOTES:
• Never connect or disconnect the adapter from the AC outlet while your hands
are wet.
• The housing of the AC adapter may become warm during operation. This is
normal.
• The female plug of the AC adapter must be completely disconnected from the
CD player in order to operate the player on batteries.
4
HD7998_B081105.p65 11/8/2005, 15:054
Installing The Batteries
NOTE: The battery compartment is located inside the CD compartment.
1.) Slide the Open “ ” switch to the right to open the CD door. If you have not
already done so, remove the dummy CD ‘transit card’ and discard it.
2.) Press on the locking tab on the battery
door in the direction of the “arrow” and
lift it up.
3.) Insert two “AA” alkaline batteries in
the battery compartment. Be sure to
observe the polarity markings
engraved in the battery compartment.
If the batteries are inserted incorrectly
the unit will not work.
4.) Close the battery door, and press the door down make sure fully locked again.
5.) Close the CD door.
Replacing The Batteries
When the battery symbol flashes
in the display the batteries are becoming
weak and should be replaced.
Always replace both batteries at the same time with new fresh alkaline batteries.
Do not mix old and new batteries or different types of batteries together.
If the display remains blank when you press the PLAY/PAUSE button, the
batteries are completely dead.
Replace them immediately. If dead batteries are left inside the battery compartment
for a long period of time they may leak and cause damage to the unit, and such
damage or corrosion from leaking batteries is not covered by your warranty.
5
HD7998_B081105.p65 11/8/2005, 15:055
