Rosemount™ Wireless Permasense ET210
Corrosion Transmitter
■
Gain visibility to health of critical piping with a non-intrusive, easy to install corrosion monitoring system
■
Increase uptime by proactive maintenance on corroding piping, pairing with Data Manager for long
term tracking and actionable alerts
■
Backed by proven experience in wireless field instrumentation and expert technical support from
Emerson
Rosemount Wireless Permasense ET210 December 2020
Emerson's Wireless solution
IEC 62591 (WirelessHART®) … the industry standard
Self-organizing, adaptive mesh routing
■
Backed by Emerson’s proven experience in
Wireless field instrumentation and expert
technical support.
■
The self-organizing, self-healing network manages
multiple communication paths for any given
device. If an obstruction is introduced into the
network, data will continue to flow because the
device has other established paths.
Reliable wireless architecture
■
Standard IEEE 802.15.4 radios
■
2.4 GHz ISM band sliced into 15 radio-channels
■
Time Synchronized Channel Hopping
■
Direct sequence spread spectrum (DSSS)
technology delivers high reliability in challenging
radio environment
Emerson's Wireless
■
Seamless integration to all existing host systems
■
Native integration into DeltaV™ and Ovation™ is transparent and seamless
■
Gateways interface with existing host systems using industry standard protocols including OPC, Modbus® TCP/IP, Modbus
RTU, and EtherNet/IP
Layered security keeps your network safe
■
Ensures data transmissions are received only by the wireless Gateway.
■
Network devices implement industry standard Encryption, Authentication, Verification, Anti-Jamming, and Key Management.
■
Third party security verification including Achilles and FIPS197, with password strength monitoring, user-based log in,
password reset requirements, automatic lockout, password expiration requirements.
™
Contents
Emerson's Wireless solution...............................................................................................................................................................2
Rosemount Wireless Permasense ET210 Corrosion Transmitter........................................................................................................ 3
Ordering information........................................................................................................................................................................ 4
Specifications.................................................................................................................................................................................... 6
Product certifications........................................................................................................................................................................ 9
Dimensional drawing.......................................................................................................................................................................13
2 Emerson.com/Rosemount
December 2020 Rosemount Wireless Permasense ET210
Rosemount Wireless Permasense ET210 Corrosion Transmitter
Corrosion and erosion monitoring
■
Reliably detects thinning wall thickness in
piping through external coatings using an
ultrasonic sensor.
■
May be used on metal with continuous
service temperatures up to 248 °F (120 °C).
Reliable data in challenging environments
■
Data Manager application provides long
term pipe thickness status and trending,
allowing for proactive maintenance with
actionable alerts based on pipe condition.
■
Built-in thermocouple monitors pipe
surface temperature and allows
compensation in the thickness
measurement for the most reliable
measurement, even in high temperature
environments.
Mounting flexibility
■
Directly mount to process piping without
cutting pipes or changing pipe
configurations - allowing for a flexible
installation.
■
Magnetic design with a stabilization strap
means deployment is safe and easy in
challenging locations.
Reliable transmitter performance
■
Rugged and robust design of the
transmitter ensures reliable performance in
harsh environments.
■
WirelessHART® creates a self-forming and
self- managing wireless mesh, delivering
continuous wall thickness measurements of
the highest integrity and accuracy.
Emerson.com/Rosemount 3
Rosemount Wireless Permasense ET210 December 2020
Ordering information
Online Product Configurator
Many products are configurable online using our Product Configurator. Select the Configure button or visit our website to start.
With this tool's built-in logic and continuous validation, you can configure your products more quickly and accurately.
Specifications and options
See the Specifications and options section for more details on each configuration. Specification and selection of product materials,
options, or components must be made by the purchaser of the equipment. See the Material selection section for more information.
Optimizing lead time
The starred offerings (★) represent the most common options and should be selected for best delivery. The non-starred offerings
are subject to additional delivery lead time.
Required model components
Model
Code
ET210 Rosemount Wireless Permasense Corrosion Transmitter ★
Transmitter output
Code
X Wireless ★
Measurement type
Code
1 Insight ★
Product certifications
Code
Description
Description
Description
Description
NA No approval ★
I1 ATEX Intrinsic Safety ★
I5 USA Intrinsically Safe ★
I6 Canada Intrinsically Safe ★
I7 IECEx Intrinsic Safety ★
4 Emerson.com/Rosemount
December 2020 Rosemount Wireless Permasense ET210
Code Description
I2 Brazil Intrinsic Safety ★
I3 China Intrinsic Safety ★
I4 Japan Intrinsic Safety ★
IM EAC Intrinsic Safety ★
IP Korea Intrinsic Safety ★
Wireless update rate, operating frequency and protocol
Code Description
WA3 User configurable update rate, 2.4 GHz, WirelessHART
®
★
Omni-directional wireless antenna and SmartPower™ solutions
Code Description
WP6 Internal antenna, compatible with Corrosion Power Module (Standard Power Module included) ★
Spare parts and accessories
Part number
BP20E-5100-0001 BP20E Power Module, SGSus-c ★
BP20E-5100-0002 BP20E Power Module, ATEX, IECEx ★
BP20E-5100-0003 BP20E Power Module, EAC EX
BP20E-5100-0004 BP20E Power Module, Japan
BP20E-5100-0005 BP20E Power Module, Brazil
BP20E-5100-0006 BP20E Power Module, Korea
BP20E-5100-0007 BP20E Power Module, China
IK220-2000-0101 Commissioning kit (SGSus-c)
IK220-2000-0102 Commissioning kit (ATEX, IECEx, IA)
IK220-2000-0103 Commissioning kit (EAC)
IK220-2000-0104 Commissioning kit (CML)
IK220-2000-0105 Commissioning Kit (Brazil)
IK220-2000-0107 Commissioning Kit (China)
Description
Emerson.com/Rosemount 5
Rosemount Wireless Permasense ET210 December 2020
Specifications
Functional specifications
Output
IEC 62591 (WirelessHART®) 2.4 GHz
Humidity limits
0-100 percent relative humidity
Transmit rate
Every 12 hours by default
Radio frequency power output from antenna
Internal (WP option) antenna: Less than 10 mW (10 dBm) EIRP
Accuracy
Thickness
Reference Accuracy: ±0.3 mm
Reference Repeatability: ±0.1 mm
(1)
Surface temperature
Accuracy: 18 °F (10 °C)
Repeatability: within 4 °F (2 °C)
Physical specifications
Application requirements
Pipe diameter: minimum 4 in.(100 mm)
Wall thickness
Compatible pipe materials:
External coating thickness:
Compatible external coating materials:
Minimum
Maximum
Carbon steel
Duplex stainless steel
Super duplex stainless steel
Maximum .040-in. (1 mm)
Common coatings, including zinc coatings, etc.
Consult factory for special coating compatibility
(2)
: 0.16-in. (4 mm)
(3)
: 3.94-in. (100 mm)
(1) Reference accuracy is stated across the range of measurable wall thicknesses on calibrated test blocks with ultrasonic velocity within 2 percent actual velocity,
measured at 68 °F (20 °C). Meeting reference thickness accuracy across the operating temperature range requires velocity is known across the temperature range
to within 2 percent.
(2) Where the inner surface of the measured pipe/vessel wall is non-uniform or rough, the minimum measurable metal thickness is ¼-in. (6 mm).
(3) For wall thickness greater than 2-in. (50 mm), parameter adjustment at installation is required.
6 Emerson.com/Rosemount
December 2020 Rosemount Wireless Permasense ET210
Material selection
Emerson provides a variety of Rosemount products with various product options and configurations including materials of
construction that can be expected to perform well in a wide range of applications. The Rosemount product information presented
is intended as a guide for the purchaser to make an appropriate selection for the application. It is the purchaser’s sole responsibility
to make a careful analysis of all process parameters (such as all chemical components, temperature, pressure, flow rate, abrasives,
contaminants, etc.), when specifying product materials, options, and components for the particular application. Emerson is not in a
position to evaluate or guarantee the compatibility of the process fluid or other process parameters with the product options,
configuration, or materials of construction selected.
Electrical connections/power module
■
Replaceable, non-rechargeable, Intrinsically Safe lithium-thionyl chloride power module
■
Nine-year power module life at reference conditions with BP20E module
(4)
Field Communicator connections
Commission the ET210 using CC21 with BP20E not installed
Materials of construction
Transmitter housing:
Power module housing:
PBT/PC
PBT/PC
Sensor type
Single electro-magnetic acoustic transducer (no couplant required)
Mounting
Transmitters are directly attached to process piping a magnetic foot. A 3 ft. (.91 m) strap is included to secure the sensor to the
pipe.
Weight
Rosemount ET210 with BP20E power module:
Rosemount ET210 without BP20E power module:
1.8 lb. (805 g)
1 lb. (450 g)
Enclosure ratings
(5)
IP67
Performance specifications
Temperature limits
Ambient limit:
Storage limit:
Application continuous temperature: up to 248 °F (up to 120 °C)
–40 to 185 °F (–40 to 75 °C)
–58 to 185 °F (–50 to 75 °C)
Electro Magnetic Compatibility (EMC)
Meets all relevant requirements of EN 61326-1: 2013
(4) Reference conditions are 68 °F (20 °C), transmit rate of 12 hours, and routing data for three additional network devices.
(5) When mated to the power module.
Emerson.com/Rosemount 7
Rosemount Wireless Permasense ET210 December 2020
Wireless output specifications
Range
Up to 160 ft. (50 m) line of sight
8 Emerson.com/Rosemount
December 2020 Rosemount Wireless Permasense ET210
Product certifications
Rev 0.1
European Directive information
A copy of the EU Declaration of Conformity can be found at the end of the Quick Start Guide. The most recent revision of the EU
Declaration of Conformity can be found at Emerson.com/Rosemount.
Telecommunications compliance
All wireless devices require certification to ensure they adhere to regulations regarding the use of the RF spectrum. Nearly every
country requires this type of product certification.
Emerson is working with governmental agencies around the world to supply fully compliant products and remove the risk of
violating country directives or laws governing wireless device usage.
FCC and IC
This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: This device may not cause
harmful interference; this device must accept any interference received, including interference that may cause undesired
operation. This device must be installed to ensure a minimum antenna separation distance of 20 cm from all persons.
Ordinary location certification
As standard, the device has been examined and tested to determine that the design meets the basic electrical, mechanical, and fire
protection requirements by a nationally recognized test laboratory (NRTL) as accredited by the Federal Occupational Safety and
Health Administration (OSHA).
North America
The US National Electrical Code® (NEC) and the Canadian Electrical Code (CEC) permit the use of Division marked equipment in
Zones and Zone marked equipment in Divisions. The markings must be suitable for the area classification, gas, and temperature
class. This information is clearly defined in the respective codes.
USA
I5 USA Intrinsically Safe (IS)
Certificate:
Standards:
Markings:
Emerson.com/Rosemount 9
SGSNA/17/SUW/00281
UL 913 - 8th Edition, Revision Dec 6 2013
CLASS I, DIV 1, GP ABCD, T4, Tamb = -50 °C to +75 °C, IP67
Rosemount Wireless Permasense ET210
Canada
I6 Canada Intrinsically Safe (IS)
December 2020
Certificate:
Standards:
Markings:
SGSNA/17/SUW/00281
CAN/CSA C22.2 No. 157-92 (R2012) +UPD1 +UPD2
CLASS I, DIV 1, GP ABCD, T4, T
= -50 °C to +75 °C, IP67
amb
Europe
I1 ATEX Intrinsically Safe (IS)
Certificate:
Standards:
Markings:
Specific Conditons For Safe Use (X):
1. The plastic mounting foot may present a potential electrostatic ignition risk and must not the rubbed or cleaned with a dry
cloth.
2. When fitted with the appropriate high-temperature mounting foot, the equipment may be attached to process pipework at
a temperature of up to 120 °C.
3. The enclosure may present a potential electrostatic ignition hazard and must not be rubbed or cleaned with a dry cloth.
Baseefa15ATEX0146X Issue 3
EN IEC 60079-0:2018
EN 60079-11: 2012
II 1 G, Ex ia IIC T4 Ga, T
amb
= -50 °C to +75 °C, IP67
International
I7 IECEx Intrinsically Safety (IS)
Certificate:
Standards:
Markings:
Specific Conditons For Safe Use (X):
1. The plastic mounting foot may present a potential electrostatic ignition risk and must not the rubbed or cleaned with a dry
cloth.
2. When fitted with the appropriate high-temperature mounting foot, the equipment may be attached to process pipework at
a temperature of up to 120 °C.
3. The enclosure may present a potential electrostatic ignition hazard and must not be rubbed or cleaned with a dry cloth.
10 Emerson.com/Rosemount
BAS 15.0098X Issue 5
IEC 60079-0:2017 Edition 7.0, IEC 60079-11: 2011 Edition 6.0
Ex ia IIC T4 Ga, T
= -50 °C to +75 °C, IP67
amb
December 2020
Brazil
I2 INMETRO Intrinsically Safe (IS)
Rosemount Wireless Permasense ET210
Certificate:
Standards:
Markings:
UL-BR 19.1701X
ABNT NBR IEC 60079-0:2013
ABNT NBR IEC 60079-11:2013
Ex ia IIC T4 Ga (-50 °C ≤ T
≤ +75 °C)
amb
Specific Conditions for Safe Use (X):
1. The plastic mounting foot may present a potential electrostatic ignition risk and must not be rubbed or cleaned with a dry
cloth.
2. When fitted with the appropriate high-temperature mounting foot, the equipment may be attached to process pipework at
a temperature of up to 120 °C.
3. Enclosures may present a potential electrostatic charging ignition hazard and must not be rubbed or cleaned with a dry
cloth.
China
I3 China NEPSI Intrinsic Safety
Certificate:
Standards:
Markings:
GYJ18.1089X
GB3836.1-2010, GB3836.4-2010, GB3836.20-2010
Ex ia IIC T4 Ga
Specific Condition For Safe Use (X):
See certificate for specific conditions of safe use.
EAC - Kazakhstan and Russia
IM (EAC) Intrinsic Safety
Certificate:
Standards:
Markings:
Specific Condition For Safe Use (X)
See certificate for specific conditions of safe use.
Emerson.com/Rosemount 11
C-GB.МЮ62.В.05220
ТР ТС 012/2011
0Ex ia IIC T4 Ga X
Rosemount Wireless Permasense ET210
India
India (PESO) Intrinsic Safety
December 2020
Certificate:
Markings:
A/P/HQ/MH/104/6455 (P474307)
Ex ia IIC T4 Ga
Specific Condition For Safe Use (X):
See certificate for specific conditions of safe use.
Japan
I4 CML Intrinsically Safe (IS)
Certificate:
Standards:
Markings:
Specific Conditions for Safe Use (X):
1. The plastic enclosure and mounting foot may present a potential electrostatic ignition risk and must not be rubbed or
cleaned with a dry cloth.
2. When fitted with the appropriate high-temperature mounting foot, the equipment may be attached to process pipework at
a temperature of up to 120 °C.
CML 19JPN2339X
JNIOSH-TR-46-1:2015
JNIOSH-TR-46-6:2015
Ex ia IIC T4 Ga
3. Enclosures may present a potential electrostatic charging ignition hazard and must not be rubbed or cleaned with a dry
cloth.
4. The CC21 Commissioning Cable must only be used in a non-hazardous area – it provides an interface between unspecified
non-hazardous area equipment and a Mesh Sensor. It must not be used to provide power whilst located in a hazardous area.
Korea
IP Korea (KCS) Intrinsic Safety
Certificate:
Markings:
Specific Condition For Safe Use (X):
See certificate for specific conditions of safe use
17-KA4BO-0663X (when supplied from UK)
20-KA4BO-0505X (when supplied from Singapore)
Ex ia IIC T4
12 Emerson.com/Rosemount
December 2020
Dimensional drawing
Rosemount Wireless Permasense ET210
Dimensions are in inches (millimeters).
Emerson.com/Rosemount 13
Rosemount Wireless Permasense ET210 December 2020
14 Emerson.com/Rosemount
December 2020 Rosemount Wireless Permasense ET210
Emerson.com/Rosemount 15
00813-0100-4211
Rev. BA
December 2020
Emerson Automation Solutions
6021 Innovation Blvd.
Shakopee, MN 55379, USA
+1 800 999 9307 or +1 952 906 8888
+1 952 949 7001
RFQ.RMD-RCC@Emerson.com
Latin America Regional Office
Emerson Automation Solutions
1300 Concord Terrace, Suite 400
Sunrise, FL 33323, USA
+1 954 846 5030
+1 954 846 5121
RFQ.RMD-RCC@Emerson.com
Asia Pacific Regional Office
Emerson Automation Solutions
1 Pandan Crescent
Singapore 128461
+65 6777 8211
+65 6777 0947
Enquiries@AP.Emerson.com
North America Regional Office
Emerson Automation Solutions
8200 Market Blvd.
Chanhassen, MN 55317, USA
+1 800 999 9307 or +1 952 906 8888
+1 952 949 7001
RMT-NA.RCCRFQ@Emerson.com
Europe Regional Office
Emerson Automation Solutions Europe
GmbH
Neuhofstrasse 19a P.O. Box 1046
CH 6340 Baar
Switzerland
+41 (0) 41 768 6111
+41 (0) 41 768 6300
RFQ.RMD-RCC@Emerson.com
Middle East and Africa Regional Office
Emerson Automation Solutions
Emerson FZE P.O. Box 17033
Jebel Ali Free Zone - South 2
Dubai, United Arab Emirates
+971 4 8118100
+971 4 8865465
RFQ.RMTMEA@Emerson.com
Linkedin.com/company/Emerson-Automation-Solutions
Twitter.com/Rosemount_News
Facebook.com/Rosemount
Youtube.com/user/RosemountMeasurement
©
2020 Emerson. All rights reserved.
Emerson Terms and Conditions of Sale are available upon request. The Emerson logo is a
trademark and service mark of Emerson Electric Co. Rosemount is a mark of one of the
Emerson family of companies. All other marks are the property of their respective owners.
Loading...
