ET 13P2
ET 19P2
INSTRUCTION MANUAL
Color Television
CCAAUUTTIIOONN
RRIISSKK OOFF EELLEECCTTRRIICC SSHHOOCCKK
DDOO NNOOTT OOPPEENN
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to constitute a risk electric shock.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and servicing instructions in the
literature accompanying the appliance.
WARNING
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE.
CAUTION
CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE MANUFACTURER COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
NOTE TO CATV SYSTEM INSTALLER
THIS REMINDER IS PROVIDED TO CALL THE CATV SYSTEM INSTALLER'S ATTENTION TO ARTICLE 820-40 OF THE NEC THAT PROVIDES GUIDELINES FOR PROPER
GROUNDING AND, IN PARTICULAR, SPECIFIES THAT THE CABLE GROUND SHALL
BE CONNECTED TO THE GROUNDING SYSTEM OF THE BUILDING, AS CLOSE TO
THE POINT OF CABLE ENTRY AS PRACTICAL.
CAUTION
The AC power cord provided with this product is polarized (one blade wider than the other).
To provide power to the TV, insert the AC plug into a standard 120V 60Hz polarized outlet.
NOTE
Never connect the plug to an electrical source other than one providing 120V 60Hz power. Use
only the attached power cord. If the polarized AC cord does not fit into a non-polarized outlet,
do not cut or file the blade. You are responsible for having the obsolete outlet replaced with a
polarized outlet.
If you feel a static discharge when touching the unit, and the unit does not function, simply
unplug the unit from the outlet. When you plug the unit back in, it should work normally.
Do not install power cords near any heating element or cooking appliances.
EMERSON RADIO
CORP.
9 Entin Road
P.O. Box 430
Parsippany. NY07054-0430
1-888-508-2627
Dear Customer :
Emerson Radio Corp. would like to thank you for choosing this color television receiver. It
incorporates a host of features designed to give you excellent performance for many years to
come.
We realize that you’re eager to turn it on and begin enjoying the high-quality pictures it delivers just as quickly as possible, but we ask you to take a few minutes to read the instructions
in the booklet to familiarize yourself with the receiver, its functions and some features which
may be new to you. If you follow the instructions, this unit should give you many years of
viewing pleasure.
If for any reason it does not, we want to hear about it. Please write to us at the address
above. Emerson always welcomes comments and suggestions on this or any of our other products.
On the other hand, when you discover the enjoyment, reliability and ease of use that is built
into it, we hope that you will tell your friends, and consider Emerson when you make your
next purchase of home entertainment equipment.
In addition to TV receivers, Emerson Radio Corp. produces a full line of audiovisual products
built to the same high design, engineering, and manufacturing standards as this unit.
Here are a few tips that will keep your TV receiver looking great and performing for years to
come.
• Avoid putting it in excessively hot locations. Damage to the cabinet or premature component failures can result.
• There are ventilation holes in the bottom and rear of the cabinet. Make sure that they
remain unobstructed. Do not place the receiver on top of a thick cloth.
• If you don’t plan to use the receiver for several days, it’s a good idea to unplug it from the
power outlet.
• Many common household cleaning agents, sprays, solvents, and polishes will cause permanent damage to the surface of the cabinet. The best cleaning agents are mild soap and a
damp cloth.
Again, thank you for choosing this Emerson product. We have employed advanced engineering
techniques in its design, and manufactured it in one of the world’s most up-to-date production
facilities. The result is a TV receiver that we know you will be as proud to own as we were to
create.
Very truly yours,
Emerson Radio Corp.
CONTENTS
Table of Contents
Important Safeguards 2
Chapter 1: Overview of Your Equipment 4
Your TV's Front Panel 4
Your TV's Back Panel
Your Remote Control
Installing your remote control batteries 6
Notes
Chapter 2: Connecting an Antenna or Cable to Your TV 7
Connecting an Antenna 7
Connecting a Cable System
Connecting Other Pieces of Equipment 9
Safety Note
Chapter 3: Operating Your TV 10
Turning your TV On 10
Programming Your TV's Channel Memory
Changing Channels 11
Changing the Volume
Changing The TV's Channel Memory 12
Adding/Deleting a channel to memory
Displaying the Current Channel 12
Adjusting Video Settings
Returning to the factory settings 14
Descriptions of video settings
4
5
6
8
9
10
11
12
13
14
Chapter 4: Using Timer Functions 15
Setting the Clock 15
Setting the Wake-up Timer
Setting the Off Timer 16
Canceling the Wake-up Timer or Off Timer
Setting the Sleep Timer 17
Chapter 5 : Additional Features 18
Changing the Language of the On-Screen Menus 18
Captioning 18
CC on Mute
Power Restore 19
Auto Tint(option)
Chapter 6 : Troubleshooting 21
Warranty 22
Table of Contents
15
16
19
20
1
2
Important Safeguards
SAFETY
IMPORTANT SAFEGUARDS
PLEASE READ ALL THESE INSTRUCTIONS REGARDING YOUR TELEVISION
EQUIPMENT AND RETAIN FOR FUTURE REFERENCE. FOLLOW ALL WARNINGS
AND INSTRUCTIONS MARKED ON THE TV RECEIVER.
1
Read all of these instructions.
2
Save these instructions for later use.
3
Unplug this television equipment from
the wall outlet before cleaning. Do not
use liquid cleaners or aerosol cleaners.
Use a damp cloth for cleaning.
4
Do not use attachments not recommended by the television equipment manufacturer as they may result in the risk of
fire, electric shock or other personal
injury.
5
Do not use this television equipment
near water, for example, near a bathtub,
washbowl, kitchen sink, or laundry tub,
in a wet basement, or near a swimming
pool, or the like.
6
Do not place this television equipment on
an unstable cart, stand, or table. The
television equipment may fall, causing
serious injury to a child or adult, and
serious damage to the equipment. Use
only with a cart or stand recommended
by the manufacturer, or sold with the
television equipment. Wall or shelf
mounting should follow the manufacturer's instructions, and should use a
mounting kit approved by the manufacturer.
6A
An appliance and cart combination
should be moved with care. Quick stops,
excessive force, and uneven surfaces may
cause the appliance and cart combination to overturn.
7
Slots and openings in the cabinet and
the back or bottom are provided for ventilation and to ensure reliable operation
of the television equipment; and to protect it from overheating, these opening,
must not be blocked or covered. The
opening should never be blocked by placing the television equipment on a bed,
sofa, rug, or other similar surface. (This
equipment should never be placed near
or over a radiator or heat register.) This
television equipment should not be
placed in a built-in installation such as a
bookcase unless proper ventilation is
provided.
8
This television equipment should be
operated only from the type of power
source indicated on the marking label. If
you are not sure of the type of power
supplied to your home, consult your television dealer or local power company.
9
This television equipment is equipped
with a polarized alternating current line
plug (a plug having one blade wider than
the other). This plug will fit into the
power outlet only one way. This is a
safety feature. If you are unable to insert
the plug fully into the outlet, try reversing the plug. If the plug should still fail
to fit, contact your electrician to replace
your obsolete outlet. Do not defeat the
safety purpose of the polarized plug.
10
Do not allow anything to rest on the
power cord. Do not locate this television
equipment where the cord will be abused
by persons walking on it.
11
Follow all warnings and instructions
marked on the television equipment.
12
For added protection for this television
equipment during a lightning storm, or
when it is left unattended and unused
for long periods of time, unplug it from
the wall outlet and disconnect the antenna or cable system. This will prevent
damage to the equipment due to lightning and power-line surges.
3
Important Safeguards
13
An outside antenna system should not
be located in the vicinity of overhead
power lines or other electric light or
power circuits, or where it can fall into
such power lines or circuits. When
installing an outside antenna system,
extreme care should be taken to keep
from touching such power lines or circuits as contact with them might be
fatal.
14
Do not overload wall outlets and extension cords as this can result in fire or
electric shock.
15
Never push objects of any kind into this
television equipment through openings
as they may touch dangerous voltage
points or short-out parts that could
result in a fire or electric shock. Never
spill liquid of any kind on the television
equipment.
16
Do not attempt to service this television
equipment yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.
17
Unplug this television equipment from
the wall outlet and refer servicing to
qualified service personnel under the following conditions:
(a) When the power-supply cord or plug
is damaged or frayed.
(b) If liquid has been spilled, or objects
have fallen into the television equipment.
(c) If the television equipment has been
exposed to rain or water.
(d) If the television equipment does not
operate normally by following the
operating instructions. Adjust only
those controls that are covered by the
operating instructions as an improper
adjustment of other controls may
result in damage and will often
require extensive work by a qualified
technician to restore the TV receiver
to its normal operation.
(e) If the television equipment has been
dropped or the cabinet has been dam-
aged.
(f) When the television equipment
exhibits a distinct change in performance - this indicates a need for service.
18
When replacement parts are required, be
sure the service technician has used
replacement parts specified by the manufacturer that have the same characteristics as the original part. Unauthorized
substitutions may result in fire, electric
shock or other hazards.
19
Upon completion of any service or
repairs to this television equipment, ask
the service technician to perform safety
checks to determine that the television is
in a safe operating condition.
20
If an outside antenna or cable system is
connected to the television receiver, be
sure the antenna or cable system is
grounded so as to provided some protection against voltage surges and built-up
static charges.
Section 810 of the National Electrical
Code, ANSI/NFPA N0.70-1984, provides
information with respect to proper
grounding of the mast and supporting
structure, grounding of the lead-in wire
to an antenna discharge unit, size of
grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the
grounding electrode.
4
Chapter 1 :
Overview of Your Equipment
CHAPTER
1
Overview of Your Equipment
Your TV comes with a remote control. The section below summarizes the buttons,
controls, and terminals that you will use with your TV.
Your TV's Front Panel
1 POWER
Use this button to turn your TV on or off.
2 ▼CH▲
Use these buttons to change channels on your TV, or to select items in the menu
system.
3 CVOLB
Use these buttons to change your TV's volume, to activate selections in the menu
system, or to change audio and video settings.
4 MENU
Use this button to turn the TV's menu system on and off.
5 Remote control receiver
This receiver receives a signal from your remote control. Do not block it.
Your TV's Back Panel
1 Antenna terminal
Use this terminal to attach an antenna or cable
system to your TV.
5
Chapter 1 :
Overview of Your Equipment
Your Remote Control
1. POWER
Use this button to turn your TV on or off.
2. MUTE
Use to turn the TV’s sound on and off.
3. ▼CH▲
Use these buttons to change channels on
your TV, or select items in the menu system.
4. CVOLB
Use these buttons to change your TV's volume, to activate selections in the menu system, or to change audio and video settings.
5. MENU
Use this button to turn the TV's menu system on and off.
6. DISPLAY
Use this button to display the channel
number and status.
7. INPUT
Use this button to select the TV’s signal source.
8. VIDEO
Use this button to display video adjustment
items.
9. 0-9
Use these buttons to change channels.
10. SLEEP
Use this button to program the TV to turn off
after a certain time.
11. PREVIOUS
Use this button to return to the previous
channel you were watching.
MUTE
POWER
C H
C H
VOL
MENU
DISPLAY
1
2
3
4
3
6
9
10
1
4
5
8
7
11
2
3
4
5
6
7
8
0
9
SLEEP PREVIOUS
R-38T01
INPUT VIDEO
VOL
6
Chapter 1 :
Overview of Your Equipment
Installing your remote control batteries
1
Open the battery compartment on the back of the remote control.
2
Install two AAA-size batteries (not included) as shown. Make sure the “+” and “-”
terminals are oriented correctly.
3
Replace the cover.
Notes
Do not mix different types of batteries, or mix an old and a new battery.
Remove and replace weak batteries. Weak batteries can leak and damage your con-
troller. Dispose of batteries properly; never throw them into a fire.
Point your remote at the receiver on the center of the front of the TV. Make sure the
receiver is not blocked.
The remote control can operate up to 30 feet away from the TV, if you are directly
facing the front of the TV. Operating distance diminishes as you move to the sides of
the TV.
CHAPTER
2
7
Chapter 2 :
Connecting an Antenna or Cable to Your TV
Connecting an Antenna or Cable to Your TV
Your TV will provide you with the best performance if you connect it to an external
antenna or cable system. Follow the directions below make this connection. Please
note that you will normally only have to make one of the connections shown below,
not all of them.
All connections will be made to the antenna terminal on the back of your TV. The
antenna terminal is a silver metal post partially surrounded by two plastic tabs. For
help in locating the antenna terminal, see “Your TV's Back Panel” on page 4.
Connecting an Antenna
If your antenna ends in a single coaxial lead,
simply press or screw the cable onto the
antenna terminal on the back of your TV.
If your antenna ends in a pair of 300 ohm twin leads
, you must use a
300-ohm/75-ohm adapter(available at your local electronics store). Place the leads
underneath the screws on the adapter, tighten the screws, then press the adapter onto
the antenna terminal on the back of the TV.
8
Chapter 2 :
Connecting an Antenna or Cable to Your TV
Antennas with two sets of leads
You might have two sets of leads from your antenna system, especially if you have
one antenna for VHF signals and one antenna for UHF signals.
If your antenna system has both a coaxial lead and twin 300-ohm leads
,
you
must obtain a combiner (available at your local electronics store). Press or screw the
coaxial lead onto the combiner; place the twin leads underneath the screws on the
combiner and tighten the screws. Press the cable from combiner onto the antenna terminal on the back of your TV.
If your antenna system has two sets of twin 300-ohm leads,
you must
obtain a combiner (available at your local electronics store). Place one set of twin
leads underneath the screws on the combiner and tighten the screws. Do the same
with the other set of twin leads. Press the cable from the combiner onto antenna terminal on the back of your TV.
Connecting a cable system
If your cable set-up is not described below, please contact your cable company for
more information.
If your cable system does not
require the use of a cable box
,simply
press or screw the incoming cable onto the
antenna terminal on the back your TV.
9
Chapter 2 :
Connecting an Antenna or Cable to Your TV
If your cable system requires you to use a converter box for all
channels,
connect the incoming cable to the IN terminal on the converter box.
Connect another cable between the OUT terminal on the converter box and the
antenna terminal on the TV. You will need to keep your TV tuned to channel 3 or 4
and change channels using the converter box.
If your cable system only requires you to use a converter box for
some channels (i. e. pay-TV channels),
follow these steps: Find the primary
incoming coaxial cable. Plug this cable into a splitter (available at your local electronics
store). Connect one coaxial cable between one OUT terminal on the splitter and the IN
terminal on the converter box. Connect another coaxial cable between the other OUT
terminal on the splitter and the B-IN terminal on an A/B switch (available at your local
electronics store.) Connect a third coaxial cable between the OUT terminal on the converter box and the A-IN terminal on the A/B switch. Finally, connect a coaxial cable
between the OUT terminal on the A/B switch and the antenna terminal on the back of
your TV.
When the A/B switch is in the A position, you need to change channels on the con-
verter box (and your TV should be tuned to channel 3 or 4); when the A/B switch is
in the B position you can change channels on the TV.
Connecting Other Pieces of Equipment
You may want to connect a VCR, laser disc player, satellite receiver, or another type
of equipment to your TV. We recommend that you follow the instructions included
with the piece of equipment you wish to connect.
Safety Note
If you plan on being away from your home for an extended period of time, or if a
thunderstorm is approaching, you should unplug your television, and you may wish to
disconnect your TV from a rooftop or satellite antenna. You do not need to disconnect
your TV from a cable system.
Converter Box
IN
OUT
IN OUT
Converter Box
OUT OUT
IN
OUT
IN IN
B
A
10
Chapter 3:
Operating Your TV
CHAPTER
3
Operating Your TV
Once you have connected your TV to an antenna or cable system, plugged the TV in,
and put batteries in the remote, you are ready to use the TV. The first thing you
should do is program your TV so it memorizes all of available channels.
Turning Your TV On
1
To turn your TV, press the POWER button on the remote control. You can also use the POWER button on the front panel.
Make sure your TV is plugged in before you try to turn it on.
Programming Your TV's Channel Memory
Your TV's memory determines the channels that are available using the
▼CH▲
buttons. If a channel is not in memory, you can tune to it with the number buttons, but
not with the
▼CH▲
buttons. Follow these steps to program your TV's memory:
1
With the TV on, press the MENU button twice, then “Set-Up” menu will appear.
2
Use the
▼CH▲
buttons to select “Reception”, then use the
CVOLB
button to
select ‘Air’ or ‘Cable’. If you connected an antenna to your TV, select ‘Air’; If you
connected a cable system, select ‘Cable’.
3
Use the
▼CH▲
buttons to select “Memorize Channels”, then use the
CVOLB
button to enter the “Memorize Channels” process. Again press the
CVOLB
but-
ton to begin.
4
Press the MENU button to return to Set-Up menu.
5
Press the MENU button three times to return to normal TV viewing.
Your TV's channel memory will not be affected by a power outage. You will not need
to re-program the memory unless you change the type of cable or antenna connected
to your TV.
Select
Set-Up
Language : English
Reception : Air
Memorize Channels
Add/Delete Channels
Adjust Next
1
Select
Set-Up
Language : English
Reception : Air
Memorize Channels
Add/Delete Channels
Adjust Next
3-1
Select
Set-Up
Language : English
Reception : Air
Memorize Channels
Add/Delete Channels
Adjust Next
2
Memorize Channels
Air 11
Memorizing all air channels.
Please stand by.
Press MENU to cancel and
returu to Set-up menu.
3-2
5
Select
Set-Up
Language : English
Reception : Air
Memorize Channels
Add/Delete Channels
Adjust Next
4
11
Chapter 3:
Operating Your TV
Changing Channels
You can change channels in three ways:
1
The
▼CH▲
buttons will take you through all memorized
channels, one by one. The
▼CH▲
buttons will not access
channels that have not been programmed into the TV's
memory. For more information about programming channels into memory, see the section “Programming your TV's
Channel Memory” on the previous page.
2
The number buttons (0-9) will take you to any channel,
even if it has not been memorized. To change to a channel,
enter its number; the TV will tune to the new channel
when you enter the second digit of the channel.
3
The PREVIOUS button will take you instantly to the last
channel you were watching.
Changing the Volume
1
To change the volume of the TV set, use the
CVOLB
buttons on the remote or on the front panel.
2
To quickly turn off the sound, press the MUTE button on
the remote. The ‘MUTE’ will appear on screen, colored
green. To return the volume to its previous level, press
MUTE again.
1
2
3
1
2
12
Chapter 3:
Operating Your TV
Changing the TV's Channel Memory
Your TV's memory determines the channels that are available using the
▼CH▲
buttons. You can add channels to this memory or remove them from memory. If a channel is removed from memory, you can tune to it with the number buttons, but you
cannot tune to it with the
▼CH▲
buttons.
If there are just one channel memorized, then the Add/Delete Channels function will
search the whole channels. But if there are two or more channel memorized, then the
Add/Delete Channels function will search the memorized channels only.
Adding/Deleting a channel to memory
1
Use the number buttons to tune to the channel.
2
Press the MENU button twice, then “Set-Up” menu will display.
3
Use the
▼CH▲
buttons to select “Add/Delete Channels”, then use the
CVOLB
button to enter the “Add/Delete Channels” process.
4
If the channel is not in memory, then use the
CVOLB
button to add the channel
from memory.
5
If the channel is in memory, then use the
CVOLB
button to delete the channel
from memory.
6
If you are going to delete other channel, then press the
▼CH▲
buttons until
desired channel is selected. And press the
CVOLB
button to delete the channel.
7
Wait 10 seconds, or press the MENU button four times to exit.
Displaying the Current Channel
1
To quickly see the current channel number and status, press DISPLAY
button on the remote control.
The current channel number and status will be displayed.
11
1
Select
Set-Up
Language : English
Reception : Air
Memorize Channels
Add/Delete Channels
Adjust Next
3
Select
Set-Up
Language : English
Reception : Air
Memorize Channels
Add/Delete Channels
Adjust Next
2
Add/Delete Channels
Air 11
This channel is not in memory.
Press VOL to add.
Press CH for other channels.
Press MENU to return
to Set-up menu.
4
Add/Delete Channels
Air 11
This channel is in memory.
Press VOL to delete.
Press CH for other channels.
Press MENU to return
to Set-up menu.
6
Add/Delete Channels
Air 11
This channel is in memory.
Press VOL to delete.
Press CH for other channels.
Press MENU to return
to Set-up menu.
5
13
Chapter 3:
Operating Your TV
Adjusting Video Settings
You may wish to adjust the video settings (e. g. contrast or color) to obtain the most
pleasing picture. To do so, follow these directions:
1
With the TV on, press the MENU button. then “Video” menu will appear.
2
The “Settings” item will be selected. Use the
CVOLB
buttons to turn Settings to
Preset or Custom.
3
Use the
▼CH▲
buttons to select the video setting you wish to adjust.
Descriptions of the video settings are on the next page.
4
Use the
CVOLB
buttons to adjust the video setting to the level you prefer.
5
Use the
▼CH▲
buttons to select another video setting to adjust.
6
When you are finished, press the MENU button until menu OSD will be disappeared.
Select
Video
Settings : Custom
Contrast :
Brightness
Sharpness
Color
Tint
Adjust Next
1
Select
Video
Settings : Preset
Contrast :
Brightness
Sharpness
Color
Tint
Adjust Next
3
Select
Video
Settings : Preset
Contrast :
Brightness
Sharpness
Color
Tint
Adjust Next
2
Contrast
4
6
Brightness
5
14
Chapter 3:
Operating Your TV
Returning to the factory settings
If you would like to return to the original video settings, as they were calibrated at the
factory, follow these steps :
1
With the TV on, press the MENU button. then “Video” menu will appear.
2
Press the
CVOLB
buttons to set the “Settings” to ‘Preset’.
The TV will remember the ‘Custom’ settings you had previously chosen. When you
set “Settings” to ‘Custom’ again, your previous custom settings will be restored.
Descriptions of video settings
The contrast setting controls the relation between the light and black areas of the
screen. If the light areas are too bright and are losing details, press the CVOL button; if the picture is gray and lacks contrast, press the VOLBbutton.
The brightness settings controls the overall amount of light in the picture. If the picture is too bright, press the
C
VOL button; if the picture is too dark, press the VOL
B
button.
Sharpness controls how the TV displays edges of objects on-screen. If the TV shows
multiple vertical lines at the edges of an object, press the
C
VOL button; if the verti-
cal edges of on-screen objects are fuzzy, press the VOL Bbutton.
The color setting controls the intensity of color. If the color is over-saturated, press the
VOL
B
button; if the color is washed out, press the VOL Bbutton.
The tint setting controls the relationship of red and green in a picture. Tint is especially noticeable in flesh tones. If flesh tones seem too red or purple, press the VOL
B
button; if flesh tones are too green, press the VOLBbutton.
Select
Video
Settings : Custom
Contrast :
Brightness
Sharpness
Color
Tint
Adjust Next
1
Select
Video
Settings : Preset
Contrast :
Brightness
Sharpness
Color
Tint
Adjust Next
2
15
Chapter 4:
Using Timer Functions
Using Timer Functions
Your TV has a built in-clock, and you can set the TV to turn on and off at times that
you select. You can also set your TV to turn off after counting down a certain amount
of time.
Setting the Clock
1
With the TV turned on, press the MENU button until “Time” menu will be displayed.
2
The “Set Clock” item will be selected. Press the
CVOLB
buttons to set the clock.
If you hold down either CVOL or VOLBbutton, the corresponding numbers will
change more quickly.
3
When the clock is set correctly, use the
▼CH▲
buttons to select another “Time”
function, or press the MENU button until menu OSD will be disappeared.
Settings the Wake-up timer
If you enter a time in the “Wake-up time” setting, your TV will automatically turn on
at that time. Follow these instructions to set the “Wake-up time”.
After Wake-up Timer turned on the TV set, if user do not input the user
control (e.g. remote CH or VOL key) within 15 minutes, the TV set will
turn off automatically. If user input the user control within 15 minutes,
the TV set will turn on continuously.
It is safety feature for prevent from any kind of problem without human
control.
1
With the TV turned on, press the MENU button until “Time” menu will be displayed.
2
Use the
▼CH▲
buttons to select “Wake-up time” item.
3
If you hold down either CVOL or VOLBbutton, the corresponding numbers will
change more quickly.
4
When the setting is correct, use the
▼CH▲
buttons to select another “Time” func-
tion, or press the MENU button until menu OSD will be disappeared.
CHAPTER
4
Select
Time
Set Clock : :
Wake-up time : :
Off time : :
Sleep timer : 0 min
Adjust Next
1
Select
Time
Set Clock : 12 : 00 AM
Wake-up time : :
Off time : :
Sleep timer : 0 min
Adjust Next
3
Select
Time
Set Clock : 12 : 00 AM
Wake-up time : :
Off time : :
Sleep timer : 0 min
Adjust Next
2
Select
Time
Set Clock : 12 : 00 AM
Wake-up time : :
Off time : :
Sleep timer : 0 min
Adjust Next
1
Select
Time
Set Clock : 1 2 : 00 AM
Wake-up time : 06 : 30 AM
Off time : :
Sleep timer : 0 min
Adjust Next
3
Select
Time
Set Clock : 12 : 00 AM
Wake-up time : :
Off time : :
Sleep timer : 0 min
Adjust Next
2
16
Chapter 4:
Using Timer Functions
Setting the Off Timer
If you enter a time in the “Off time” setting, your TV will automatically turn off at
that time. Follow these instructions to set the “Off time”.
1
With the TV turned on, press the MENU button until “Time” menu will be displayed.
2
Use the
▼CH▲
buttons to select “Off time” item.
3
If you hold down either CVOL or VOL Bbutton, the corresponding numbers will
change more quickly.
4
When the setting is correct, use the
▼CH▲
buttons to select another “Time” func-
tion, or press the MENU button until menu OSD will be disappeared.
Canceling the Wake-up Timer or Off Timer
If you would like to cancel the Wake-up Timer or the Off Timer, Press the CVOL
B
buttons until the timer settings return to “- -:- -”.
The Wake-up Timer and Off Timer will not function correctly unless the clock has
been set.
Select
Time
Set Clock : 12 : 00 AM
Wake-up time : 06 : 30 AM
Off time : :
Sleep timer : 0 min
Adjust Next
1
Select
Time
Set Clock : 1 2 : 00 AM
Wake-up time : 06 : 30 AM
Off time : 1 1 : 30 PM
Sleep timer : 0 min
Adjust Next
3
Select
Time
Set Clock : 1 2 : 00 AM
Wake-up time : 06 : 30 AM
Off time : :
Sleep timer : 0 min
Adjust Next
2
17
Chapter 4:
Using Timer Functions
Setting the Sleep Timer
The sleep timer allows you to set an amount of time from 15 minutes to 120 minutes.
TV will count down the amount of time you set, then turn itself off.
To set the sleep timer:
1
With the TV turned on, press the MENU button until “Time” menu will be displayed.
2
Use the
▼CH▲
buttons to select “Sleep timer” item.
3
Use the CVOLBbuttons to set the sleep time. Each time you press VOL, you step
between the available sleep times : 15min, 30min, 45min, 60min, 90min, or
120min.
4
When the setting is correct, use the
▼CH▲
buttons to select another “Time” func-
tion, or press the MENU button until menu OSD will be disappeared.
5
You can also set the “Sleep Timer” during normal TV viewing, simply by pressing
the SLEEP button on the remote control. This button steps through the available
sleep times(see step 3), one by one.
To cancel the Sleep timer, turn the TV off, or set the sleep time to “0” using one of
the methods described above.
Select
Time
Set Clock : 1 2 : 00 AM
Wake-up time : 06 : 30 AM
Off time : 1 1 : 30 PM
Sleep timer : 0 min
Adjust Next
1
Select
Time
Set Clock : 1 2 : 00 AM
Wake-up time : 06 : 30 AM
Off time : 1 1 : 30 PM
Sleep timer : 60 min
Adjust Next
3
Select
Time
Set Clock : 1 2 : 00 AM
Wake-up time : 06 : 30 AM
Off time : 1 1 : 30 PM
Sleep timer : 0 min
Adjust Next
2
18
Chapter 5 :
Additional Features
CHAPTER
5
Additional Features
This section contains descriptions of the more advanced features of your TV.
Changing the Language of the On-screen Menus
You can choose to display the on-screen menus in English, Spanish, French.
To change the on-screen language:
1
With the TV on, press the MENU button twice, then “Set-Up” menu will appear.
2
The “Language” item will be selected. Press the CVOLBbuttons to select the language you want to use: English, Spanish, French.
3
To return normal TV viewing, press the MENU button until menu OSD will be
disappeared.
Captioning
Many TV shows contains “closed captions”. These captions are hidden words that can
be displayed on your TV screen. There are two types of these words : “captions” usually follow the action on-screen, providing a written version of the dialogue, narration, and sound effects ; “text” is not usually related to the action on-screen, often
providing information such as news or weather. A TV program might be providing
more than one set of captions or one set of text.
To set your TV to display captions or text.
1
With the TV turned on, press the MENU button until “Special” menu will be displayed.
2
The “Closed Caption” item be selected. To turn captioning on, use the CVOL
B
buttons to select Captions (C1 or C2) or Text (T1 or T2).
At the time these instructions were written, only C1 is normally available, but feel
free to try the other selections.
3
Wait 10 seconds, or press the MENU button to return to normal TV viewing.
Your setting will remain intact until you change it.
Select
Set-Up
Language : English
Reception : Air
Memorize Channels
Add/Delete Channels
Adjust Next
1
Choix
Installer
Langue : Francais
Reception : Air
Memoriser Chaines
Ajouter/Supprimer Chaines
Regler Suivant
2-2
Escoger
Config
Idioma : Español
Recepcion : Aire
Memorizar canales
Añadir/Borrar canales
Ajustar Otro
2-1
Select
Special
Closed Caption : OFF
CC on Mute : OFF
Power Restore : OFF
Auto Tint : OFF
Adjust Exit
1
Select
Special
Closed Caption : T 1
CC on Mute : OFF
Power Restore : OFF
Auto Tint : OFF
Adjust Exit
2-2
Select
Special
Closed Caption : C 1
CC on Mute : OFF
Power Restore : OFF
Auto Tint : OFF
Adjust Exit
2-1
19
Chapter 5 :
Additional Features
CC on Mute
When the sound is muted, user can select the caption display. It will display the caption content instead of sound mute.
1
With the TV turned on, press the MENU button until “Special” menu will be displayed.
2
Use the
▼CH▲
buttons to select “CC on Mute” item.
3
Use the CVOLBbuttons to select “C1” or “C2”.
Power Restore
User can select the On/Off status when the power cord put into the wall outlet. If
user have a cable box with AC outlet, then user can connect the TV power cord to the
AC outlet and control the TV without TV remote control. This function is rarely used
for home use, so special care is needed while using.
1
With the TV turned on, press the MENU button until ‘Special” menu will be displayed.
2
Use the
▼CH▲
buttons select ‘Power Restore” item.
3
Use the CVOLBbuttons to select “On” or “Off”.
Select
Special
Closed Caption : C 1
CC on Mute : OFF
Power Restore : OFF
Auto Tint : OFF
Adjust Exit
1
Select
Special
Closed Caption : C 1
CC on Mute : C 2
Power Restore : OFF
Auto Tint : OFF
Adjust Exit
3-2
Select
Special
Closed Caption : C 1
CC on Mute : C 1
Power Restore : OFF
Auto Tint : OFF
Adjust Exit
3-1
Select
Special
Closed Caption : C 1
CC on Mute : OFF
Power Restore : OFF
Auto Tint : OFF
Adjust Exit
2
Select
Special
Closed Caption : C 1
CC on Mute : C 1
Power Restore : OFF
Auto Tint : OFF
Adjust Exit
1
Select
Special
Closed Caption : C 1
OC on Mute : OFF
Power Restore : On
Auto Tint : OFF
Adjust Exit
3
Select
Special
Closed Caption : C 1
OC on Mute : C 1
Power Restore : OFF
Auto Tint : OFF
Adjust Exit
2
20
Chapter 5 :
Additional Features
Auto Tint(option)
This is function for fresh tone compensation.
1
With the TV turned on, press the MENU button until “Special” menu will be displayed.
2
Use the
▼CH▲
buttons to select “Auto Tint” item.
3
Use the CVOLBbuttons to select “On” or “Off”.
Select
Special
Closed Caption : C 1
CC on Mute : C 1
Power Restore : On
Auto Tint : OFF
Adjust Exit
1
Select
Special
Closed Caption : C 1
OC on Mute : C 1
Power Restore : On
Auto Tint : On
Adjust Exit
3
Select
Special
Closed Caption : C 1
OC on Mute : C 1
Power Restore : On
Auto Tint : OFF
Adjust Exit
2
Troubleshooting
Your Emerson television is designed to give you trouble-free performance for many
years. If you have a problem with your TV, try the solutions listed below.
If the suggestions listed below do not solve your problem, contact your Emerson Radio
Corp. dealer or an authorized Emerson service center. You can also call Emerson
directly at 1-888-508-2627.
There is no picture or sound, or the TV won't turn on.
¥ Make sure the TV is plugged in.
¥ Make sure the MUTE is not set.
¥ Make sure the power is on.
¥ If there is neither picture or sound, unplug the TV for 30 seconds, then plug it in
and try again.
There is no picture or sound on some UHF channels.
¥ Try another station. If the other stations are OK, it may be a station problem.
¥ Check that the antenna is connected, is in good working order, has no broken wires,
and is adjusted correctly.
¥ See if anything is interfering with the antenna signal.
¥ Make sure the AIR/CABLE setting is correct.
The sound is OK, but the picture is poor.
¥ Try another station. If the other stations are OK, it may be a station problem.
¥ Check that the antenna is connected and is in good working order, has no broken
wires, and is adjusted correctly.
The picture is OK, but the sound is poor.
¥ Try another station. If the other stations are OK, it may be a station problem.
¥ Check that the antenna is connected, is in good working order, has no broken wires,
and adjusted correctly.
There is poor reception on some channels.
¥ Try another station. If the other stations are OK, it may be a station problem.
¥ Check that the antenna is connected, is in good working order, has no broken wires,
and is adjusted correctly.
You cannot tune to a cable channel.
¥ Make sure the AIR/CABLE setting is correct.
¥ The channel may not be programmed into memory.
The picture rolls, slants, shows lines, is grainy, has poor color, or has
ghosts.
¥ Try another station. If the other station are OK, it may be a station problem.
¥ Check that the antenna is connected, is in good working order, has no broken wires,
and is adjusted correctly.
¥ See of anything is interfering with the antenna signal.
The remote control does not work.
¥ Make sure the TV is plugged in.
¥ Make sure there are fresh batteries in the remote control.
¥ Make sure there is nothing blocking the remote control signal.
21
Chapter 6 :
Troubleshooting
CHAPTER
6
22
Warranty
WARRANTY
Warranty
Emerson Radio Corp.
warrants each new electronic product manufactured by it
to be free from defective material and workmanship and agrees to remedy any such
defect or to furnish a new part (at the Company’s option) in exchange for any part of
any unit of its manufacture which under normal installation, use, and service disclosed such defect, provided the unit is delivered by the owner to us or to our authorized distributor from whom purchased or authorized service station, intact, for our
examination with all transportation charges prepaid to our factory. To establish and
receive warranty service at our factory or authorized service facilities, proof of purchase/dated sales invoice is required
Return authorization must be obtained before any merchandise is returned to the factory.
This warranty does not extend to any of our electronic products which have been subjected to misuse, neglect, accident, incorrect wiring not our own, improper installation,
unauthorized modification, or to use in violation of instructions furnished by us, nor
units which have been repaired or altered outside of our factory, nor to cases where
the serial number thereof has been removed, defaced, or changed.
This warranty is in lieu of all warranties expressed or implied and no representative
or person is authorized to assume for us any other liability in connection with the
sake of our electronic products.
Over-the-counter exchange for units that are initially defective
“Initially defective” is described as when the dealer opens the unit and finds that it is
inoperative or a customer opens a new unit and finds that it is inoperable. This unit
may be returned to the factory by the dealer for exchange. Under no circumstances
will the customer be permitted to return the defective unit directly to the factory.
Exchange must be directly with the dealer.
Model Parts Labor Picture Tube
ET-13P2 90 days 90 days 2 years
ET-19P2 90 days 90 days 2 years
This instrument is listed by Underwriter’s
Laboratories, Inc. It is designed and
manufactured to meet rigid U.L. safety
standards against X-radiation, fire, casualty
and electrical hazards.
EMERSON RADIO CORP.
9 Entin Road
P.O. Box 430
Parsippany. NY07054-0430
1-888-508-2627
For more information about this or other Emerson products, please call 1-888-508-2627.
Loading...
