Emerson ES769 User Manual
MICRO AUDIO SYSTEM
With CD PLAYER
And DIGITAL TUNER
OWNER'S MANUAL
ES769
Visit our web site at www.emersonradio.com
ES769_drafts.P65 19/12/2003, 14:5624
BEFORE WE BEGIN
Thank you for purchasing this Emerson audio product. The Emerson
brand is your assurance of quality, performance and value.
Our engineers have included many useful and convenient features in this
product. Please be sure to read this Owner’s Manual completely to make
sure you are getting the maximum benefit from each feature.
This product was manufactured using the highest quality components and
standards of workmanship. It was tested by Emerson inspectors and found
to be in perfect working order before it left our factory. However, there is
always the chance that some problem may occur because of rough handling
during shipment to the retail store or to the final consumer.
If, after reading this Manual, you experience any problems with the operation
of this product, please refer to the instructions for obtaining service at the
end of this Manual. Emerson and Emerson retailers are committed to your
satisfaction.
Once again, thanks for purchasing this Emerson audio product.
For future reference, record the serial number in the space provided.
Model No: ES769
Serial No:
ES769_drafts.P65 19/12/2003, 14:532
2
FCC INFORMA TION
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reason able
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed a nd used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures :
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into a n outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions :
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
IMPORT ANT NOTES
ES769_drafts.P65 19/12/2003, 14:533
3
POWER SOURCE
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE
SLOT, AND INSERT FULLY.
ATTENTION:
POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRESLA LAME LA PLUS
LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISES ET
POUSSER JUSQU'AU FOND.
This unit is designed to operate only on normal 120V 60Hz AC house current. Operating this unit from any other power source may cause damage to unit and such damage
is not covered by your warranty.
This unit has a polarized AC plug with one wide blade and one narrow blade.
This plug will only fit into a matching polarized AC outlet. This is a safety feature to
reduce the possibility of electric shock. If this plug will not fit in your AC outlet, you
probably have an outdated non-polarized outlet. You should have your outdated outlet changed by a qualified licen sed electrician. Do not file the wide blade on the plug, or
use an adapter to make the plug fit into your outlet. This defeats the safety fe ature and
could expose you to electric shock.
ES769_drafts.P65 19/12/2003, 14:534
4
LOCATION OF CONTROLS AND INDICA TORS
CONTROLS IDENTIFICA TION
1
2
10
12
11
14
13
15
25
16
17 19 20 21
18
23
2224
3 4 56789
ES769_drafts.P65 19/12/2003, 14:535
5
1. CD COMPARTMENT
2. CD DOOR OPEN / CLOSE BUTTON
3. STANDBY INDICATOR
4. TUNING / SKIP/FAST SEARCH BUTTON
5. CD STOP BUTTON
6. CD PLAY/PAUSE BUTTON
7. VOLUME / BUTTON
8. MUTE BUTTON
9. EQ BUTTON
10. STANDBY BUTTON
11. CD BUTTON
12. TUNER /BAND BUTTON
13. PHONES JACK
14. AUX BUTTON
15. REMOTE SENSOR
16. MULTI FUNCTION LCD DISPLAY
17. MODE BUTTON
18. RESET BUTTON (AT BOTTOM CABINET)
19. RANDOM BUTTON
20. PROGRAM / MEMO BUTTON
21. REPEAT / MEMO-UP BUTTON
22. FM ANTENNA WIRE
23. AUX INPUT JACKS
24. SPEAKER TERMINALS
25. AC POWER CORD
26. SPEAKER BOX
27. SPEAKER WIRE
26
27
28. STANDBY Button
29. PLAY/PAUSE Button
30. TUNER/BAND Button
31. CD Function Button
32. AUX Function Button
33. ST/MO Button
34. EQ Button
35. RANDOM Button
36. MUTE Button
37. SLEEP Button
38. STOP Button
39. PRESET/REPEAT Button
40. VOL + & VOL - Buttons
41. MODE Button
42. SNOOZE Button
43. MEMORY Button
44. & Buttons
45. 0-9 Buttons
46. +10 Button
47. INTRO Button
48. TIMER Button
ES769_drafts.P65 19/12/2003, 14:536
REMOTE HANDSET
6
