Emerson EMP588-4 User Manual

Touch Screen

User Guide

EMP588-4

IN THE BOX

music

ebook

video

record

photos

browser

USB 2.0 Cable

(for battery charging

and high speed data transfer)

Quick Start and Media Transfer

4 GB

music

video

photos

settings

MP3 Music and Video Player

record

ebook

EMP588-4

CD Quick Start Guide

Stereo Headphones

browser

settings

1

FCC INFORMATION

FCC Part 15

This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the Federal Communications
Commission (FCC) rules. These requirements are intended to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:

● Re-orient or relocate the receiving antenna.

● Increase the separation between the equipment and receiver.

● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

● Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications to this equipment not expressly approved by the party responsible for compliance could void the user’s authority to operate the

equipment.

2

INTRODUCTION

Congratulations on purchasing the Emerson MP3 Music & Video Player.
This manual contains important safety information and correct operation instructions.
Before using the player, read this manual thoroughly and keep it for future reference.

Copyright Information

Trademarks and trade names used in this instruction manual are owned by their respective
companies or organizations.

Unauthorized duplication of any recordings whether downloaded from the internet or made from audio
CDs is a violation of copyright laws and international treaties.

The making of unauthorized copies of copy-protected material, may be an infringement of copyrights
and constitute a criminal offence. This equipment should not be used for such purposes.

3

IMPORTANT SAFETY PRECAUTIONS

Always follow these basic safety precautions when using your player. This will reduce the risk of product damage and personal injury.

Do not disassemble, repair or modify the player by yourself. Refer servicing to qualified personnel.
This device contains a built- in battery, do not dispose of in fire.
In the event that the battery is leaking, do not handle the device with your bare hands. Contact the service center for help since the liquid may
remain in the player. If your body or clothes had contact with the battery liquid, wash it off thoroughly with water. Also, if some liquid gets into
your eyes, do not rub your eyes but immediately wash them with clean water, and consult a doctor.
Keep the player away from direct sunlight and any direct heat source.
Do not expose the unit to rain or moisture.
Do not use the player in dry environments to avoid static.
Never apply heavy impact on the player, or place it on a magnet.
Route the USB cable so that people and pets are not likely to trip over it.
Disconnect the USB cable from the computer when you do not use the player for a long time.
Clean only with a dry cloth. Make sure the player is turned off before cleaning. Do not use a liquid cleanser.
Be sure to back up your files to avoid data loss.

Precautions in using the headphones

Do not use the headphones while driving an automobile or riding a bicycle. It is dangerous, and against the
law. To avoid an accident, do not turn up the volume of the headphones too high while walking.
It is not recommended that you use the headphones at a high volume for an extended time, as this may
cause hearing damage.

4

FEATURES

 2.8” Touch screen



4 GB internal memory
Mini SD card slot (add up to 8 GB additional memory, mini SD card not included)



Built-in stereo speaker



 USB 2.0 high speed connection
 Stores and plays music, video, and pictures
 Text reading (txt format)

 Digital voice recording (built-in microphone)
 Folder navigation
 Li-ion rechargeable battery
 Supports MP3 / WMA / WAV music formats
 MPEG - 4 (AVI) movie / video files
 JPEG format picture browsing

5

LOCATIONS OF CONTROLS

1.

Headphone jack

2. [ POWER ] - Power ON/Off switch / lock

3. Mini-USB jack

4. Speaker (listen to music or video without headphones)

1

2

3

5.

Touch Screen display

6. [ M ] - Select an option / Return / Menu

7. [−] - Volume down

8.

Mini SD card slot

9. [+] - Volume up

10.

Reset hole

4

5

6

7

8

9

10

6

CONNECTING TO A COMPUTER

System requirements

You computer system must meet the following specifications:

Pentium 200MHz or above
Microsoft Windows 2000/ME/XP/Vista
USB port supported

music

ebook

video

record

settings

photos

browser

PC

USB High Speed Connection Cable MP3 Player

PC connection

In order to enjoy the multimedia capabilities of your MP3 Player, you have to first copy your favorite files from your PC to it’s internal memory.
Connect your MP3 Player to the computer using the included USB 2.0 cable. The device will be detected automatically without installing any driver.

Once detected, you can read/write to the device’s memory just as if you where using a regular disk drive.
Make sure your computer is powered on, and follow the steps below to connect the player to your computer.

1. Plug the larger USB connector of the USB cable into the USB port on the computer.

2. Plug the other end (small) of the USB cable to the player.

3. The computer system detects “New hardware” and starts to install the driver automatically. Wait for the system to finish the installation.
When it has finished, “Emerson MP3” will be created in “My Computer”.

Important: To avoid any data loss, always perform a safe USB device extraction before disconnecting the USB cable from the PC.

In Windows XP, for example, you can find the safe extraction icon in the task bar next to the system clock.

7

Disconnecting the USB cable

After completing the file transfer, please disconnect the USB cable the following way:

1. Double click the green arrow “Safely Remove Hardware” in the task bar on the bottom right of the window.

2. Select “USB Device” and click “Stop”.

3. When the “Stop a Hardware device” appears, click “OK” to disconnect the USB mass storage device, and unplug the player safely.

8

CHARGING THE BATTERY

Your MP3 Player has an integrated rechargeable Li-ion battery. It is recommended to fully charge the player before using it for the first time.
Recharge the battery by connecting the player to a computer using the included USB 2.0 cable.

Charging time is between 3-5 hours, depending if the player is powered off or working. To keep the battery in good condition, we recommend not
charging it for more than 8 hours.

Battery level indication:

Full Two-thirds full Half full Low Empty

Important:

● Fully charge it before you use the player for the first time or when you haven’t used it for a long time.

● Charge the player immediately when the “Low battery” message is displayed.

● Do not over charge or discharge the player. Over charging or discharging will shorten the battery life.

● The battery could be over discharged if the player is not used for a long time (over three months). To avoid over discharge, fully charge the player
every three months and always keep the voltage of the battery above 50 %.

MINI SD

The player supports MINI SD cards which enable you to add up to 8 GB of additional memory to your player
(mini SD card not included).

music

video

ebook

record

settings

photos

browser

1. Insert the MINI SD card into the card slot with the metallic contacts facing towards the back of the player, and gently push it in
until it clicks.

2. To access the MINI SD card, select “browser” > mini SD.

3. Touch a file or folder to select it, and press the [ M ] or button.

4. Press and HOLD the or [ M ] button to get back to the main menu.

Return

Enter

INSERT MINI SD CARD

5. To remove the card, gently push it in until it pops out.

Note: ●

●

Do not use force while inserting the memory card
Do not remove the card during data transfers

9
