Emerson DCF Optimized Racks Brochures and Data Sheets

DCF™ Optimized Rack System from Emerson Network Power

A Flexible Foundation For Infrastructure Support

DCF™ Optimized Rack System:
Optimized Design, Optimized Delivery, Optimized Value

A Rack System Designed to Meet
The Challenges Your Data Center
Faces Today

Your mission-critical networks are carrying
an ever-increasing amount of voice, data and
video. Looming on the horizon is a critical
mass of VoIP, high speed access, wireless
applications and increasing demand for
blade server deployment.

The DCF optimized rack system from
Emerson Network Power integrates your
computing hardware, power management
technologies and peripherals in your data

center.Itgivessuperiordesignandexibility,

allowing optimal data center equipment
performance and easy installation.

DCF Optimized Rack Systems offer these advantages:

Flexibility:

Available in nine standard sizes, to meet site needs

Compatible with Emerson Network Power Rack PDUs,

Liebert® rackmount UPS, Aisle Containment and Liebert
MB™ modular busway — all from a single source

Factory installation of rack PDUs, for fast deployment

 Tool-lessaccessoriessimplifycablemanagement,airow

management and component mounting

Static load capacity up to 3000lbs/1,363kg

Simple integration of power, cooling and

monitoring equipment

Higher Availability

75% front and rear door perforation provides maximum

airowtointernalequipment

Easy access to and management of equipment

Front and rear locks for security

Fast on-site deployment

:

Lowest Total Cost of Ownership:

Easy installation saves time and money: lift off hinges, dual

side panels, 19” rail adjustment, U markings on 19” rails, low

prolecasters,tool-lessaccessories

Excellent value for features, durability and price

Integral part of the total data center solutions from

Emerson Network Power saves time and money on

congurationandintegration

DCF Rack 42U

DCF Rack 24U

2

Improve Data Center Efficiency
With A Solid Foundation

Welded Steel
Construction

Tool-less Cable
Management Cable
management

requires just inserting
and twisting the
tool-less accessories
on 19” vertical
mounting rail.

Roof Top Ready
for Cabling

Removable opening
for cable entry —
ready for front/rear/
side cabling.

Can accomodate over
2500 Cat 5e cables.

75% Perforation
On Doors

Optimal door
perforation allows
greater airflow
through the
cabinet, reducing
heat buildup.

Integrated 19”
rail alignment.

Insures 19” rails
are positioned
correctly without
measuring.

Split, Locking
Side Panels

For quick and easy
installation and security

Height of 42U
Rack With Low
Caster

42U rack height
and low profile
casters enable
easy access
through a
standard doorway.

3

™

Specifications – DCF™ Rack

Part Number U Height mm (in) Width mm (in) Depth mm (in)

F4 611 24 1200 (4 7.2”) 600 (23.6”) 1100 (43.3”)

F2611 42 2000 (78.1”) 600 (23.6”) 1100 (43.3”)

F2612 42 2000 (78.1”) 600 (23.6”) 1200 (4 7.3”)

F2811 42 2000 (78.1”) 800 (31.4”) 1100 (43.3”)

F2812 42 2000 (78.1”) 80 0 (31.4 ”) 120 0 (4 7.3”)

F8611 48 2250 (88.6”) 600 (23.6”) 1100 (43.3”)

F8 612 48 2250 (88.6”) 600 (23.6”) 12 00 (47. 3”)

F8811 48 2250 (88.6”) 800 (31.4”) 1100 (43.3”)

F8 812 48 2250 (88.6”) 800 (31.4 ”) 120 0 (4 7.3”)

Standard Features

Single perforated locking front door
Split rear door, locking
Split side panels, locking
High density cable entry roof (2500+

cat 5 cables)

 Lowprolecasterandlevelingfeet

2 Sets 19” EIA rails
2 Full height rack PDU/cable

management brackets

Door Perforation Rate – 75%
Material and Coating – welded steel frame, powder coating for rack surface, RAL 7021 black
Static Load Capacity – Up to 3,000 lbs./1,363 kg
Standard Compliance: (19”) rack mount equipment, EIA310E
Environmental Compliance: RoHS

Hardware Kit (Qty 50 M6 Cage Nuts

and Screws)
Bolt down brackets
Keys
Central grounding point
Tool-less accessories available
Liebert MB attachment option
UL 2416 approval

Emerson Network Power-

Global Headquarters
1050 Dearborn Drive

P.O. Box 29186

Columbus, Ohio 43229

United States Of America

800 877 9222 Phone (U.S. & Canada Only)

614 888 0246 Phone (Outside U.S.)

614 841 6022 FAX

[e-mail]

Emerson Network Power

Caribbean and Latin America

Ofce–UnitedStatesofAmerica

[phone] Phone

[e-mail]

24x7 Tech Support

800 222 5877 Phone

614 841 6755 (outside U.S.)

liebert.com

While every precaution has been taken to ensure

accuracy and completeness in this literature, Liebert

Corporation assumes no responsibility, and disclaims

all liability for damages resulting from use of this

information or for any errors or omissions.

© 2013 Liebert Corporation. All rights reserved
throughout the world. Specifications subject to change
without notice. All names referred to are trademarks or

registered trademarks of their respective owners.

® Liebert and the Liebert logo are registered trademarks

of the Liebert Corporation. Business-Critical Continuity,

Emerson Network Power and the Emerson Network

Power logo are trademarks and service marks of Emerson

Electric Co. ©2013 Emerson Electric Co.

SL-11365 (R12-13) Printed in USA

Total Rack Solutions From
Emerson Network Power

A broad choice of racks and enclosures
to fit every application and budget

DCF and DCM rack systems are a part of
the Emerson Network Power portfolio of
Infrastructure Management solutions that
can provide business-critical continuity for
data centers of any size.

The DCF optimized rack system is a cost­effective, pre-engineered rack for general
data center needs. The optimized features,
delivery and pricing make this rack a great
value for most IT needs.

Available in industry-standard sizes, the
DCF rack system also offers many tool-less
options to enhance cable management

andairow.

The DCM™ modular rack system
provides a wide variety of features and
customizable options to suit unique data
center needs. It offers all the advanced

featuresandinnovativeexibilityrequired

to accommodate today’s dense and
complex IT systems and network gear.
The DCM rack system is ideal for users

whorequirespeciccongurations,non-

standard sizes, system integration and
factory installed components.
