Emerson CKS3095S, CKS3095B User Manual

0 (0)

SmartSet ® Clock Radio

with Auto-Time Setting System, Jumbo Display, Dual Alarms,

Sure Alarm, Time Projection System

and Rechargeable Flashlight

(U.S. Patent No. 6,567,344)

OWNER’S MANUAL

CKS3095B

CKS3095S

(Black Color)

(Silver Color)

Visit our web site at www.emersonradio.com

CKS3095_041707.p65	36	17/4/2007, 16:06

CAUT I ON

TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated ‘dangerous voltage’ within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

CAUT I O N

RISK OF ELECTRIC SHOCK

DO NOT OPEN

WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER ( O R B A C K ) , N O U S E R SERVICEABLE PARTS INSIDE R E F E R S E R V I C I N G T O Q U A L I F I E D S E R V I C E PERSONNEL.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

The Caution Marking maybe located at the bottom enclosure of the apparatus.

IMPORTANT SAFETY INSTRUCTIONS

1.) Read these instructions. Keep these instructions. Follow all instructions. Heed all warnings.

2.) Do not use this apparatus near water.

3.) Clean only with dry cloth.

4.) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

5.) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

6.) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

7.) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

8.) Only use attachments / accessories specified by the manufacturer.

9.) Unplug this apparatus during lightning storms or when unused for long periods of time.

10.) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

11.) This appliance shall not be exposed to dripping or splashing water and no object filled with liquids such as vases shall be placed on the apparatus.

12.) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution

when moving the cart/apparatus combination to avoid injury from tip-over.

13.) Do not overload wall outlet. Use only power source as indicated. 14.) Use replacement parts as specified by the manufacturer.

15.) The product may be mounted to a wall only if recommended by the manufacturer.

16.) Upon completion of any service or repairs to this product, ask the service technician to perform safety checks.

CKS3095_041707.p65	1	17/4/2007, 16:06

Thank you for purchasing this Emerson SmartSet® Dual Alarm Clock Radio with Time Projection System, and Rechargeable Flashlight.

This clock radio uses Emerson’s patented SmartSet® Automatic Time Setting System. The first time you connect this clock radio to your AC outlet, and after every power interruption, within seconds the clock will automatically set itself to the correct Year, Month, Date, Day, and Time. You will never see that annoying, flashing “12:00” display again. In addition all changes from Standard Time to Daylight Saving Time, and back to Standard Time, are made automatically.

There are dual alarms that can be set and used independently, which means that you can set one alarm to wake you to the buzzer and the other to wake you to music. And both of the alarms can be programmed for everyday operation, weekdays only, or weekends only.

This model also includes an integrated clock time projector that will project the time in large RED numerals on the wall or ceiling of a dark room. This allows you to see the time without actually looking at the clock itself. We’ve even included a built-in rechargeable, removable flashlight that’s always ready to use whenever you need it.

There is a long life lithium battery installed in this clock radio when you buy it. This battery can maintain the time and alarm settings for 3 to 5 years, or even longer, so there is no need to pay for a new 9-volt battery every 6 months, as is recommended in other clock radios with normal battery back up.

We have taken every precaution to make sure this radio was in perfect working order when it left our factory. If you encounter any problems with the set up or operation of this item, please call the Emerson Consumer Products Corp., Customer Service Hotline, toll free, at 1-800-898-9020.

Once again, thank you for purchasing this Emerson SmartSet® Clock Radio.

CKS3095_041707.p65	2	17/4/2007, 16:06

IM PORTANT NOTES

•Avoid installing this unit in places exposed to direct sunlight or close to heat radiating appliances such as electric heaters, on top of other stereo equipment that radiates too much heat, places lacking ventilation or dusty areas, places subject to constant vibration and/or humid or moist areas.

•Operate controls and switches as described in the manual.

•Before turning on the power, make certain that the AC power cord is properly installed.

•When moving the set, be sure to first disconnect the AC power cord.

FCC Information

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1)This device may not cause harmful interference, and

(2)This device must accept any interference received, including interference that may cause undesired operation.

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

CKS3095_041707.p65	3	17/4/2007, 16:06

PREPARATION FOR USE

Unpacking And Set Up

•Remove the flashlight and the radio from the carton and remove all packing materials from both components. We suggest that you save the carton and packing materials if possible in the event that your unit ever needs to be returned for service. Using the original carton and packing materials is the only way to protect your unit from damage in shipment.

•Place the flashlight in the charging cradle as shown. Push the back end of the flashlight into the charging tube in the direction of the arrow as shown until the front end of the flashlight is positioned behind the flashlight retaining tab. This tab holds the flashlight in the charging tube. The flashlight must be held in this position in order for charging to begin.

(Flashlight Retaining Tab)

IMPORTANT: The flashlight must be charged in the charging cradle for 24 hours before initial use. When the radio is connected to the AC outlet and the flashlight is properly positioned in the charging cradle the Red “Charging” indicator in the flashlight AUTO/OFF switch comes ‘on’.

CKS3095_041707.p65	4	17/4/2007, 16:06

•Remove any descriptive labels or stickers on the front or top of the cabinet. Do not remove any labels or stickers from the back or bottom of the cabinet.

•Note the serial number on the bottom of your radio and write this number in the space provided on the Warranty page of this manual.

•Place your radio on a level surface such as a table, desk or shelf, convenient to an AC outlet, out of direct sunlight, and away from sources of excess heat, dirt, dust, moisture, humidity, or vibration.

•Unwind the AC power cord and extend it to its full length. The FM antenna is built in to this cord. It must be fully extended to provide the best FM reception.

Protect Your Furniture

This model is equipped with non-skid rubber ‘feet’to prevent the product from moving when you operate the controls. These ‘feet’are made from non-migrating rubber material specially formulated to avoid leaving any marks or stains on your furniture. However certain types of oil based furniture polishes, wood preservatives, or cleaning sprays may cause the rubber ‘feet’to soften, and leave marks or a rubber residue on the furniture. To prevent any damage to your furniture we strongly recommend that you purchase small self-adhesive felt pads, available at hardware stores and home improvement centers everywhere, and apply these pads to the bottom of the rubber 'feet' before you place the product on fine wooden furniture.

CKS3095_041707.p65	5	17/4/2007, 16:06

Power Source

This radio is designed to operate on normal 120V 60Hz AC power only. Do not attempt to operate the radio on any other power source. You could cause damage to the radio that is not covered by your warranty.

This radio should be connected to an AC outlet that is always ‘live’. Do not connect it to an outlet that is controlled by a wall switch. When the power to the radio is interrupted, the built in lithium battery takes over to maintain the time and alarm settings. To maximize the life of the lithium battery keep the radio connected to a ‘live’AC outlet at all times.

You will note that this system is equipped with a polarized AC power plug having one blade wider than the other. This is a safety feature. If this plug does not fit into your existing AC outlet, do not try to defeat this safety feature by filing the wide blade to make it fit into your outlet.

If this plug will not fit into your outlet, you probably have an out-dated non-polarized AC outlet. You should have your outlet changed by a qualified licensed electrician.

AC Outlet

AC Plug

Sure Alarm battery Back-Up System

This SmartSet® Clock Radio includes a Sure Alarm battery back-up circuit that can wake you up even if the power is ‘Off’at the selected wake up time. If your power is ‘Off’at the selected wake up time the clock display will be off and the radio will not operate, but a separate mini-buzzer will turn ‘On’automatically to wake you up, even if you had selected the “Wake to Radio” option.

The Sure Alarm will sound for 30 seconds and then shut off automatically.

To stop the Sure Alarm buzzer immediately, press the RADIO ON/OFF button. Pressing the SNOOZE button has no effect during Sure Alarm operation.

Note: In order to maximize the life of the built in lithium battery, please be sure to set the ALARM 1 and ALARM 2 switches to the “OFF” position if the radio will be disconnected from the AC outlet for more than a few hours. This will prevent the Sure Alarm from turning ‘On’unnecessarily.

CKS3095_041707.p65	6	17/4/2007, 16:06

LOCATIO N OF CONTRO LS AND I NDICATORS

Front Panel

2 3

9 8

Top Panel

12								15
12
11								16
								17
10
26	25	24	23	22	21	20	19	18
			27
			7

CKS3095_041707.p65	7	17/4/2007, 16:06

Front Panel

1.) Projector.

2.) AM Indicator.

3.) MON / TUE / WED / THU / FRI / SAT / SUN (Day Of Week) Indicators. 4.) Time/Date/Year/Radio Frequencies Display.

5.) WAVE SENSOR.

6.) AL 2 (Alarm 2 ‘On’) Indicator.

7.) LOW (Battery Low) Indicator.

8.) Back Up Battery Compartment (Bottom Cabinet).

9.) AL 1 (Alarm 1 ‘On’) Indicator.

	Top Panel
10.)	Projector Lens.
11.)	Flashlight AUTO (On) /OFF Button and Charger ‘On’Indicator.
12.)	Flashlight Retaining Tab.
13.)	AC Power Cord (Back Cabinet).
14.)	Rechargeable Flashlight.
15.)	Flashlight Charging Tube.
16.)	SET + Button.
17.)	SET – Button.
18.)	RADIO ON/OFF Button.
19.)	ALARM 2 setting Button.
20.)	ALARM 1 setting Button.
21.)	ALARM MODE (Weekdays / Weekends / Everyday Alarm) Button.
22.)	TIME ZONE Button.
23.)	TIME Setting Button.
24.)	MONTH/DATE Setting Button.
25.)	SLEEP Button (Sleep To Music Timer).
26.)	PROJECTOR (On/Off) Button.
27.)	SNOOZE Button.
	8
