AM/FM STEREO CLOCK RADIO
COMPACT DISC PLAYER
with DUAL ALARMS
and NAP TIMER
OWNER'S MANUAL
CKD3630
Visit our web site at www.emersonradio.com
CKD3630_060404.p65 |
25 |
|
4/6/2004, 15:19 |
|
|
|
|
|
|
|
|
|
|
|
CAUT I ON
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated ‘dangerous voltage’ within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
CAUT I O N
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER ( O R B A C K ) , N O U S E R SERVICEABLE PARTS INSIDE R E F E R S E R V I C I N G T O Q U A L I F I E D S E R V I C E PERSONNEL.
!
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
IMPORTANT SAFETYNSTRUCTIONS
1.) Read these instructions.
2.) Keep these instructions.
3.) Heed all warnings.
4.) Follow all instructions.
5.) Do not use this apparatus near water.
6.) Clean only with dry cloth.
7.) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8.) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9.) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10.) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
11.) Only use attachments / accessories specified by the manufacturer.
12.) Unplug this apparatus during lightning storms or when unused for long periods of time.
13.) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
14.) This appliance shall not be exposed to dripping or splashing water and no object filled with liquids such as vases shall be placed on the apparatus.
15.) Do not overload wall outlet. Use only power source as indicated. 16.) Use replacement parts as specified by the manufacturer.
17.) The product may be mounted to a wall only if recommended by the manufacturer.
18.) Upon completion of any service or repairs to this product, ask the service technician to perform safety checks.
1
CKD3630_060404.p65 |
1 |
|
4/6/2004, 15:19 |
|
|
|
|
|
|
|
|
|
|
|
Thank you… … … … … … …
for purchasing this Emerson Dual Alarm Stereo Clock Radio with CD Player, and Nap Timer. This compact sized unit has been designed to fit comfortably on any desk or bedside table.
The CD Player has a 20-track programmable memory plus one-track/all tracks automatic repeat playback. The clock radio features a large, easily readable, 0.9” green LED display that is visible from anywhere in the room. The display brightness can also be reduced if you feel it is too bright in a darkened room. The dual alarms can be set and used independently. You can set either or both alarms to wake you to an electronic buzzer tone, your favorite radio station, or your favorite CD. The programmable 99-minute Nap Timer is like having a 3rd alarm. Use it to wake you up after a short Nap without having to change your regular alarm settings.
And of course there’s a battery back up system that will maintain the time and alarm settings in the event of a temporary power interruption
This system was designed to give you many years of enjoyment with an absolute minimum of care and maintenance.
Please read this Owners Manual carefully and completely to ensure that you get the maximum benefit from all the outstanding features we have included in this product. If you encounter any problem with the set up or operation of this model please do not return it to the retail store.
Please call the Emerson Customer Service Hotline toll free at 1-800-898-9020. One of our service technicians will try to diagnose the problem for you.
Once again thanks for choosing this Emerson audio product.
For future reference, record the Serial Number in the space provided:
Model No: CKD3630
Serial No:
2
CKD3630_060404.p65 |
2 |
|
4/6/2004, 15:19 |
|
|
|
|
|
|
|
|
|
|
|
IMPORTANT NOTES
•Avoid installing this unit in places exposed to direct sunlight or close to heat radiating appliances such as electric heaters, on top of other stereo equipment that radiates too much heat, places lacking ventilation or dusty areas, places subject to constant vibration and/ or humid or moist areas.
•Do not attempt to clean this unit with chemical solvents as this might damage the finish. Use a clean dry cloth.
•Operate controls and switches as described in the manual.
•Before turning ‘On’ the power, make certain that power cord is properly installed.
•Store your CDs in a cool area to avoid damage from heat.
•When moving the set, be sure to first disconnect the power cord.
CLASS 1 LASER PRODUCT
CLASS 1 LASER PRODUCT APPAREIL Á LASER DE CLASSE 1 PRODUCTO LASER DE CLASE 1
CAUTION
INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCKS DEFEATED.
AVOID EXPOSURE TO BEAM
This product contains a low power Laser Device.
FCC INFORMATION
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2)This device must accept any interference received, including interference that may cause undesired operation.
3
CKD3630_060404.p65 |
3 |
|
4/6/2004, 15:19 |
|
|
|
|
|
|
|
|
|
|
|
PREPARATION FOR USE
UNPACKING AND SET UP
•Carefully remove the unit from the display carton. Remove all the packing material from the unit and remove any small strips of tape that may have been used to prevent the CD door from opening in transit.
•Unwind and extend the FM lead wire antenna.
•This unit was shipped with a dummy CD transit card in the CD player. This dummy CD prevents the laser pick up from moving during shipment. This card must be removed before you can insert your own CDs. Raise the CD door, remove the transit card and discard it.
•Place the unit on a flat, level surface such as a table, desk, counter, shelf, etc, convenient to a 120V 60Hz AC outlet, out of direct sunlight, and away from sources of excess heat, dust, moisture, or strong magnet fields.
PROTECT YOUR FURNITURE
This model is equipped with non-skid rubber 'feet' to prevent the product from moving when you operate the controls. These 'feet' are made from non-migrating rubber material specially formulated to avoid leaving any marks or stains on your furniture. However certain types of oil based furniture polishes, wood preservatives, or cleaning sprays may cause the rubber 'feet' to soften, and leave marks or a rubber residue on the furniture. To prevent any damage to your furniture we strongly recommend that you purchase small self-adhesive felt pads, available at hardware stores and home improvement centers everywhere, and apply these pads to the bottom of the rubber 'feet' before you place the product on fine wooden furniture.
4
CKD3630_060404.p65 |
4 |
|
4/6/2004, 15:19 |
|
|
|
|
|
|
|
|
|
|
|
BATTERY BACK UP SYSTEM
This model includes a battery back up circuit that will maintain the clock and alarm settings in the event of a temporary power interruption. The battery back up system requires one 9-Volt battery, not included. The battery compartment is located on the back of the cabinet.
1.) Press the battery door-locking tab in the direction of the arrow and remove the battery door.
2.) Connect a fresh 9-Volt alkaline battery to the battery terminal in the battery compartment. It can only be connected one way.
3.) Replace the battery door.
If the power is interrupted the display will go off and the radio will not work. However the battery will maintain the clock and alarm settings in memory. When the power is restored the display will come on again and the clock and alarm settings will be correct.
The life of the back up battery will depend on the frequency and length of the power interruptions that you experience. For best results we suggest you install a fresh battery every 9 to 12 months. Always use a well-known brand of alkaline battery.
5
CKD3630_060404.p65 |
5 |
|
4/6/2004, 15:19 |
|
|
|
|
|
|
|
|
|
|
|
POWER SOURCE
This radio is designed to operate on 120V 60Hz AC only. Attempting to operate this radio on any other power source could cause damage to the unit and such damage is not covered by your warranty.
Make sure the radio is connected to an AC outlet that is always “live”. Do not connect the radio to an outlet that is controlled by a wall switch.
NOTE:
This unit has a polarized AC plug with one wide blade and one narrow blade. This plug will only fit into a matching polarized AC outlet. This is a safety feature to reduce the possibility of electric shock.
If this plug will not fit in your AC outlet, you probably have an outdated non-polarized outlet. You should have your outdated outlet changed by a qualified, licensed electrician.
Do not file the wide blade on the plug, or use an adapter to make the plug fit into your outlet. This defeats the safety feature and could expose you to electric shock.
AC Outlet
AC Plug
6
CKD3630_060404.p65 |
6 |
|
4/6/2004, 15:19 |
|
|
|
|
|
|
|
|
|
|
|
LOCATION OF CONTROLS AND INDICATORS
FRONT PANEL
9 |
10 |
|
11 |
|
12 |
13 |
8 |
|
|
|
|
|
14 |
|
|
|
|
|
|
15 |
7 |
|
|
|
|
|
16 |
6 |
|
|
|
|
|
|
5 |
|
|
|
|
|
17 |
4 |
|
|
|
|
|
18 |
3 |
|
|
|
|
|
|
2 |
|
|
|
|
|
19 |
1 |
|
|
|
|
|
20 |
|
25 |
24 |
23 |
22 |
21 |
|
1.) |
PLAY/PAUSE |
Button. |
14.) |
LED Display. |
2.) |
SKIP REV. |
Button. |
15.) |
NAP Indicator. |
3.) |
REPEAT Indicator. |
16.) |
ALM (Alarm) 2 Indicator. |
|
4.) |
POWER ‘On’Indicator. |
17.) |
PLAY/PAUSE / FM ST. Indicator. |
|
5.) |
SLEEP Indicator. |
18.) |
PROG. (Program) Indicator. |
|
6.) |
Radio Dial Scale. |
19.) |
SKIP FWD. Button. |
|
7.) |
ALM (Alarm) 1 Indicator. |
20.) |
STOP Button. |
|
8.) |
AM Indicator. |
|
21.) |
ALARM 1 Button. |
9.) |
SLEEP Button. |
|
22.) |
ALARM 2 Button. |
10.) |
NAP Button. |
|
23.) |
REPEAT Button. |
11.) CD Door. |
|
24.) |
PROGRAM Button. |
|
12.) |
SNOOZE Button. |
25.) |
TIME/DISPLAY Button. |
|
13.) |
POWER ON/OFF Button. |
|
|
|
7
