Embedded Solutions ADLE3800SEC User Manual

ADL Embedded Solutions GmbH, Eiserfelder Str. 316, ADL Embedded Solutions Inc. 4411 Morena Blvd., Suite 101

57080 Siegen, Germany San Diego, CA 92117-4345 P. +49 (0) 271 250 810 0 F. +49 (0) 271 250 810 20 P. +1 858 490-0597 F. +1 858 490-0599 e-mail: sales@adl-europe.com; web: http://www.adl-europe.com e-mail: sales@adl-usa.com; web: http://www.adl-usa.com

ADLE3800SEC

Manual

Rev. 1.0

Contents

ADL Embedded Solutions ADLE3800SEC page 3

Contents

0 Document History................................................................................................................................. 6

1 Introduction .......................................................................................................................................... 7

1.1 Important Notes ............................................................................................................................ 7

1.2 Technical Support ......................................................................................................................... 7

1.3 Warranty ....................................................................................................................................... 7

1.4 Return Authorization ..................................................................................................................... 7

1.5 Description of Safety Symbols ...................................................................................................... 8

1.6 RoHS ............................................................................................................................................ 8

1.7 FCC Approval for Canada ............................................................................................................ 8

1.8 FCC Approvals for the United States of America ......................................................................... 8

2 Overview .............................................................................................................................................. 9

2.1 Features ........................................................................................................................................ 9

2.2 Feature List ................................................................................................................................. 10

2.3 Specifications and Documents ................................................................................................... 11

3 Detailed Description ........................................................................................................................... 12

3.1 CPU ............................................................................................................................................ 12

3.2 Memory ....................................................................................................................................... 12

3.3 M.2 .............................................................................................................................................. 12

4 Connectors ......................................................................................................................................... 13

4.1 Connector Map ........................................................................................................................... 14

4.2 Front Panel Connectors .............................................................................................................. 15

4.2.1 Power Supply ...................................................................................................................... 15

4.2.2 USB ..................................................................................................................................... 16

4.2.3 LAN ..................................................................................................................................... 18

4.3 Memory and internal connectors ................................................................................................ 19

4.3.1 DRAM Memory ................................................................................................................... 19

4.3.2 M.2 2242 (Keying B) ........................................................................................................... 20

4.3.3 Display Port ......................................................................................................................... 22

4.3.4 BAseCon140 Connector ..................................................................................................... 23

4.3.5 External Battery .................................................................................................................. 26

4.3.6 FAN Connector ................................................................................................................... 27

4.4 LED Signaling ............................................................................................................................. 28

4.4.1 RGB LED ............................................................................................................................ 28

4.4.2 Harddisk-LED...................................................................................................................... 29

4.4.3 TwinCAT-LED ..................................................................................................................... 30

5 BIOS Settings ..................................................................................................................................... 31

5.1 General Remarks ........................................................................................................................ 31

5.2 Main ............................................................................................................................................ 32

5.3 Advanced .................................................................................................................................... 33

5.3.1 ACPI Settings...................................................................................................................... 35

5.3.2 H/W Monitor ........................................................................................................................ 36

5.3.3 CPU Configuration .............................................................................................................. 37

5.3.4 PPM Configuration .............................................................................................................. 40

5.3.5 SATA Configuration ............................................................................................................ 41

5.3.6 Miscellaneous Configuration ............................................................................................... 42

5.3.7 Network Stack ..................................................................................................................... 43

Contents

page 4 ADL Embedded Solutions ADLE3800SEC

5.3.8 Power Controller Options .................................................................................................... 44

5.3.9 CSM Configuration ............................................................................................................. 45

5.3.10 Advanced-Menü-NVMe Configuration ................................................................................ 46

5.3.11 SDIO Configuration ............................................................................................................. 47

5.3.12 USB Configuration .............................................................................................................. 48

5.3.13 Security Configuration ........................................................................................................ 49

5.3.14 Intel(R) I210 Gigabit Network Connection .......................................................................... 50

5.3.15 Driver Health ....................................................................................................................... 52

5.4 Chipset ........................................................................................................................................ 54

5.4.1 North Bridge ........................................................................................................................ 55

5.4.2 South Bridge ....................................................................................................................... 59

5.5 Security ....................................................................................................................................... 63

5.5.1 Secure Boot menu .............................................................................................................. 64

5.6 Boot ............................................................................................................................................. 66

5.6.1 Advanced Fixed Boot Order Parameters ............................................................................ 67

5.7 Save & Exit ................................................................................................................................. 68

5.8 BIOS Update ............................................................................................................................... 69

6 Mechanical Drawings ......................................................................................................................... 70

6.1 PCB: Outlines ............................................................................................................................. 70

6.2 PCB: Die Center ......................................................................................................................... 71

7 Technical Data ................................................................................................................................... 72

7.1 Elektrische Daten ........................................................................................................................ 72

7.2 Environmental Conditions ........................................................................................................... 72

7.3 Thermal Specifications ............................................................................................................... 73

I Annex: Post-Codes ............................................................................................................................ 75

II Annex: Resources .............................................................................................................................. 76

Interrupt .................................................................................................................................................. 76

PCI Devices ............................................................................................................................................ 76

Important Notes Chapter: Document History

ADL Embedded Solutions ADLE3800SEC page 5

Chapter: Document History Important Notes

page 6 ADL Embedded Solutions ADLE3800SEC

0 Document History

Version

Changes

0.1

first pre-release

1.0

first released version

All company names, brand names, and product names referred to in this manual are registered or unregistered trademarks of their respective holders and are, as such, protected by national and international law.

Important Notes Chapter: Introduction

ADL Embedded Solutions ADLE3800SEC page 7

1 Introduction

1.1 Important Notes

Please read this manual carefully before you begin installation of this hardware device. To avoid Electrostatic Discharge (ESD) or transient voltage damage to the board, adhere to the following rules at all times:

o You must discharge your body from electricity before touching this board. o Tools you use must be discharged from electricity as well. o Please ensure that neither the board you want to install, nor the unit on which you want to install this

board, is energized before installation is completed.

o Please do not touch any devices or components on the board.

As soon as the board is connected to a working power supply, touching the board may result in electrical shock, even if the board has not been

switched on yet. Please also note that the mounting holes for heat sinks are connected to ground, so when using an externally AC powered device, a substantial ground plane differential can occur if the external device's AC power supply or cable does not include an earth ground. This could also result in electrical shock when touching the device and the heat sink simultaneously.

1.2 Technical Support

Technical support for this product can be obtained in the following ways:

o By contacting our support staff at +1 858-490-0597 or +49 (0) 271 250 810 0 o By contacting our staff via e-mail at support@adl-usa.com or support@adl-europe.com o Via our website at www.adl-usa.com/support or www.adl-europe.com/support

1.3 Warranty

This product is warranted to be free of defects in workmanship and material. ADL Embedded Solutions' sole obligation under this warranty is to provide replacement parts or repair services at no charge, except shipping cost. Such defects which appear within 12 months of original shipment of ADL Embedded Solutions will be covered, provided a written claim for service under warranty is received by ADL Embedded Solutions no less then 30 days prior to the end of the warranty period of within 30 days of discovery of the defect – whichever comes first. Warranty coverage is contingent upon proper handling and operation of the product. Improper use such as unauthorized modifications or repair, operation outside of specified ratings, or physical damage may void any service claims under warranty.

1.4 Return Authorization

All equipment returned to ADL Embedded Solutions for evaluation, repair, credit return, modification, or any other reason must be accompanied by a Return Material Authorization (RMA) number. ADL Embedded Solutions requires a completed RMA request form to be submitted in order to issue an RMA number. The form can be found under the Support section at our website: www.adl-usa.com or www.adl-europe.com. Submit the completed form to support@adl-usa.com or fax to +1 858-490-0599 for the USA office, or to rma@adl-europe.com or fax to +49 (0) 271 250 810 20 to request an RMA from the European office in Germany. Following a review of the information provided, ADL Embedded Solutions will issue an RMA number.

WARNING

Chapter: Introduction Description of Safety Symbols

page 8 ADL Embedded Solutions ADLE3800SEC

1.5 Description of Safety Symbols

The following safety symbols are used in this documentation. They are intended to alert the reader to the associated safety instructions.

DANGER indicates a hazardous situation which, if not avoided, will

result in death or serious injury.

WARNING indicates a hazardous situation which, if not avoided, could

result in death or serious injury.

CAUTION indicates a hazardous situation which, if not avoided, could

result in minor or moderate injury.

NOTICE is used to address practices not related to physical injury.

1.6 RoHS

The PCB and all components are RoHS compliant (RoHS = Restriction of Hazardous Substances Directive). The soldering process is lead free.

1.7 FCC Approval for Canada

FCC: Canadian Notice This equipment does not exceed the Class A limits for radiated emissions as described in the Radio

Interference Regulations of the Canadian Department of Communications.

1.8 FCC Approvals for the United States of America

FCC: Federal Communications Commission Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant

to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

DANGER

WARNING

CAUTION

NOTICE

Features Chapter: Overview

ADL Embedded Solutions ADLE3800SEC page 9

2 Overview

2.1 Features

The ADLE3800SEC is designed as mini computing unit. It combines basic I/O functions, onBoard memory and an efficient CPU on a minimum of space.

The frontpanel provides standard interfaces, such as DisplayPort/HDMI, 1x USB2.0, 1x USB3.0 and 2x Gbit-LAN interfaces.

With the BAseCon140 connector on its reverse side, the ADLE3800SEC provides a flexible option for additional IOs. The connector offers up to 8 PCIe-lanes, from which 4 can be muxed with SATA and further 4 with USB3.0 signals. A backplane takes over the IO configuration. All configuration data are stored in an EEProm on the backplane. The backplane communicates the data to the board via SMB and therefore enables an uncomplicated and self-configuring IO extension.

An RGB LED signals the state of powercontroller. Input voltage is 24V. Even though the ADLE3800SEC is designed in an extremely compact and small format, it offers the full

motherboard functionality.

DP/HDMI

Intel® Atom™

4GB

SDRAM

DDR3L-667

MEMORY

Power

BIOS

M.2

SPI

2x PCIe

1x PCIe

BAseCon140

1x SATA

LAN1

LAN2

USB3

DP/HDMI

Power IN

Intel®

LAN i210

Intel®

LAN i210

4x PCIe

2x USB

USB2

4x USB2.02x SATA

1x PCIe

Option

1x SATA

Input-

Protection

DP/HDMI

USB3.0

1x USB

Status LEDs:

Harddisk

Powercontroller

TwinCAT

Chapter: Overview Feature List

page 10 ADL Embedded Solutions ADLE3800SEC

2.2 Feature List

ADLE3800SEC

3,5"-Board

CPU

Atom™ E3845 (QC, 2M, 1.91 GHz), TDP 10W

Atom™ E3827 (DC, 1M, 1.75 GHz), TDP 8W

Atom™ E3815 (SC, 1M, 1.46 GHz), TDP 5W

Memory

OnBoard DRAM-1,35V / DDR3 (depending on CPU up to 1333MHz, up to 2GB)

OnBoard DRAM-1,35V / DDR3 (depending on CPU up to 1333MHz, up to 4GB)

I/O

2x LAN 10/100/1000 via frontpanel

1x USB 2.0 via frontpanel

1x DisplayPort via frontpanel

1x USB 3.0 via frontpanel

1x M.2 Key B 2242 with SATA 2.0 (3G)

1x BAseCon140 with DisplayPort, 1x SATA 2.0, 2x PCIe x1, 1x USB 2.0, SM-Bus, 1-Wire-Interface

Graphics

HDMI1.4 / DVI: 1920 x 1200

DP1.1a: 2560 x 1600

RTC

With external CMOS battery (via 2-pin connector or backplane)

BIOS

AMI® Aptio V

Power Supply

16V - 30V input voltage range

Overvoltage- and undervoltage protection

Reverse voltage protection

Not galvanically isolated

Format

75 mm x 75 mm

The feature list specifies all suitable CPUs. Their actual availability is

manufacturer-specific.

NOTICE

Specifications and Documents Chapter: Overview

ADL Embedded Solutions ADLE3800SEC page 11

2.3 Specifications and Documents

In making this manual and for further reading of technical documentation, the following documents, specifications and web-pages were used and are recommended.

 PCI specification

Version 2.3 bzw. 3.0

www.pcisig.com

 PCI Express® Base specification

Version 2.0

www.pcisig.com

 ACPI specification

Version 3.0

www.acpi.info

 ATA/ATAPI specification

Version 7 Rev. 1

www.t13.org

 USB specifications

www.usb.org

 SM-Bus specification

Version 2.0

www.smbus.org

 Intel® Chip Description

Intel® Atom™ Processor E3800 Product Family datasheet

www.intel.com

 Intel® Chip Description

i210 Datasheet

www.intel.com

 American Megatrends®

Aptio™ Text Setup Environment (TSE) User Manual

www.ami.com

 American Megatrends®

Aptio™ 4.x Status Codes

www.ami.com

 M.2 specification

Version 1.0

www.pcisig.com

 DisplayPort specification

Version 1.2

www.vesa.org

Chapter: Detailed Description CPU

page 12 ADL Embedded Solutions ADLE3800SEC

3 Detailed Description

3.1 CPU

The motherboard employs an Intel® Atom™ processor of the E3800 family, which is a system-on-chip (SoC) being optimized for low power consumption, while at the same time providing state-of-the-art computing performance. The processors include a second level cache of 256 KByte. They also offer many features known from the desktop range such as SSE4.1/4.2, loadable microcode etc. The Atom™ CPU operates in an extended range of thermal conditions and therefore is capable for use in industrial systems.

3.2 Memory

The ADLE3800SEC is equipped with four fixed DRAM memory modules. Depending on the product variant, there are different memory modules in use, as there are a DDR3 variant with 2GByte and another one with 4GByte memory. The ADLE3800SEC supports a maximum frequency of 1333MHz, depending on the CPU type.

3.3 M.2

Depending on the type of card, add-in cards, which comply with the M.2 specification, come in a very small format and with flexible dimensions. Different key IDs support different interfaces, as there are up to four PCI Express lanes, SATA and/or USB3.0 (see table below).

M.2 cards can be easily inserted: just plug them into the slot and fix it with a fixing screw. Cards of different types have different keyings. Depending on the supported type, one port can receive

add-in cards of one ore various types.

Key ID

Available Interfaces

A

PCIe x2, USB 2.0, I²C and DP

B*

PCIe x2, SATA, USB 2.0/3.0 Audio, UIM, HSIC, SSIC, I²C, SMBus

C, D

Reserved

E

PCIe x2, USB2.0, I²C, SDIO, UART, PCM

F

Future Memory Interface (FMI)

G, H, J, K, L

Reserved

M

PCIe x4, SATA and SMBus

* With its M.2 socket the ADLE3800SEC supports keying B M.2 modules.

For optimal driver compatibility we recommend the use of a Microsoft®

Windows® 8 operating system.

If you use an add-in card, which is not or not fully supported, the BIOS

will display an error message.

NOTICE

M.2 Chapter: Connectors

ADL Embedded Solutions ADLE3800SEC page 13

4 Connectors

This section describes all the connectors found on the ADLE3800SEC.

Please consider the requirements on the cabling!

For most interfaces, the cables must meet certain requirements. For

instance, USB 2.0 requires twisted and shielded cables to reliably maintain full speed data rates. Restrictions on maximum cable length are also in place for many high speed interfaces and for power supply. Please refer to the respective specifications and use suitable cables at all times.

NOTICE

Chapter: Connectors Connector Map

page 14 ADL Embedded Solutions ADLE3800SEC

4.1 Connector Map

Please use the connector map below for quick reference. Only connectors on the component side are shown. For more information on each connector refer to the table below.

Ref.-No.

Function

Page

U500/01/02/03

"DRAM Memory"

p. 19

P800

"M.2 2242 (Keying B)"

p. 20

P801

"External Battery"

p. 26

P802

"FAN Connector"

p. 27

P900/03

"LAN"

p. 18

P901/02

"USB"

p. 16

P904

"Power Supply"

p. 15

P905

"Display Port"

p. 22

X800

"BAseCon140 Connector"

p. 23

Front Panel Connectors Chapter: Connectors

ADL Embedded Solutions ADLE3800SEC page 15

4.2 Front Panel Connectors

A range of standard connectors are available: You can connect displays, USB, LAN etc. The following connectors are located on the front panel of the ADLE3800SEC.

4.2.1 Power Supply

The power supply of the ADLE3800SEC is realized via a 2x2pin connector (P20THR-1787014). The main 24V power lines are assigned to pin 3.

Manufacturer

Description

Mating Connector

Phoenix

P20THR-1787014

DFMC 1,5/ 2-ST-3,5-LR- 1790292

Since this is a 90-degree connector, the symbol in the drawing below

represents the connector face as seen from the side (PCB on bottom)

rather than from above.

Description

Name

Description

PC Start

PC_START

1 3 Vin

Power Supply 24V

PC Status

PC-AKTIV

2 4 GND

Ground

NOTICE

Chapter: Connectors Front Panel Connectors

page 16 ADL Embedded Solutions ADLE3800SEC

4.2.2 USB

USB channels 1 and 2 are provided via two standard USB connectors. USB channel 1 supports USB 2.0 and provides up to 500 mA current.

USB channel 2 supports USB 3.0. Contrary to the USB3.0 specification, channel 2 only provides 500mA current. For higher power requirements, you must use devices with an integrated power supply.

Both interfaces, USB 2.0 and USB 3.0, are protected by an electronically resettable fuse. You may note that the setting of USB keyboard or USB mouse support in the BIOS-setup is only

necessary and advisable, if the OS offers no USB-support. BIOS-setup can be changed with a USB keyboard without enabling USB keyboard support. Running Windows with these features enabled may lead to significant performance or functionality limitations.

Both Standard USB ports are protected by a combined overcurrent

detection. In case of an overcurrent, even at one port, the overcurrent

protection will turn off both USB ports.

Pinout USB2.0 connector for channel X:

Name

Description

1

VCC

5 volt for USBX

2

USBX#

minus channel USBX

3

USBX

plus channel USBX

4

GND

ground

Pinout USB3.0 connector for channel X:

Name

Description

1

VCC

5 volt for USBX

2

USBX#

Minus channel USBX

3

USBX

Plus channel USBX

4

GND

ground

5

StdA_SSRX-

SuperSpeed Receiver -

NOTICE

Front Panel Connectors Chapter: Connectors

ADL Embedded Solutions ADLE3800SEC page 17

Name

Description

6

StdA_SSRX+

SuperSpeed Receiver +

7

GND

ground

8

StdA_SSTX-

SuperSpeed Transmitter -

9

StdA_SSTX+

SuperSpeed Transmitter +

Chapter: Connectors Front Panel Connectors

page 18 ADL Embedded Solutions ADLE3800SEC

4.2.3 LAN

The module has two LAN interfaces both of which support 10BaseT, 100BaseT, and 1000BaseT compatible net components with automatic bandwidth selection. Controller chip is Intel®'s i210. Auto-cross and auto-negotiate functionality is available as is PXE and WOL.

Manufacturer

Description

Mating Connector

Foxconn

JFM3811F-2101-4F

(Standard LAN connector)

Pinout LAN 10/100/1000:

Name

Description

1

LAN1-0

LAN1 channel 0 plus

2

LAN1-0#

LAN1 channel 0 minus

3

LAN1-1

LAN1 channel 1 plus

4

LAN1-1#

LAN1 channel 1 minus

5

LAN1-2

LAN1 channel 2 plus

6

LAN1-2#

LAN1 channel 2 minus

7

LAN1-3

LAN1 channel 3 plus

8

LAN1-3#

LAN1 channel 3 minus

The LEDs show activity and speed of data transfer:

Mbit/s

flashing at data transfer

permanent

1000

green

100

green

orange

10

green

-

Memory and internal connectors Chapter: Connectors

ADL Embedded Solutions ADLE3800SEC page 19

4.3 Memory and internal connectors

4.3.1 DRAM Memory

The ADLE3800SEC is equipped with four fixed DRAM memory modules DDR3-667. Depending on the hardware variant, there are two different memory modules in use, which are one DDR3 variant with 2GByte and one DDR3L variant with 4GByte memory. All timing parameters for different memory modules are automatically set by BIOS.

Chapter: Connectors Memory and internal connectors

page 20 ADL Embedded Solutions ADLE3800SEC

4.3.2 M.2 2242 (Keying B)

The ADLE3800SEC is equipped with a further M.2 socket, in which M.2-2242 cards (keying B) can be inserted. The socket leads SATA signals (up to 3 Gb/s) through, and therefore enables the use of an M.2 SSD card.

Manufacturer

Description

Mating Connector

FCI

10128796-0004RLF

(M.2 card)

Description

Name

Description

Configuration pin

CONFIG_3

1 2 3.3V1

Standby power supply S3,3V

ground

GND1

3 4 3.3V2

Standby power supply S3,3V

ground

GND2

5

6

FCPWROFF #

Full Card Power OFF active low

USB channel 3 data +

USB_D+

7 8 WDISABLE#

(not available)

USB channel 3 data -

USB_D-

9

10

GPIO9 DAS DDS LED1

(not available)

ground

GND3

11

12

connector key

connector key 13

14

15

16

17

18

19

20

GPIO5

(not available)

Configuration pin

CONFIG_0

21

22

GPIO6

(not available)

GPIO11

23

24

GPIO7

(not available)

DPR

25

26

GPIO10

(not available)

ground

GND4

27

28

GPIO8

(not available)

PER1# USB3RX# SSICRX#

29

30

UIM_RST

(not available)

PER1 USB3RX SSICRX

31

32

UIM_CLK

(not available)

Memory and internal connectors Chapter: Connectors

ADL Embedded Solutions ADLE3800SEC page 21

Description

Name

Description

ground

GND5

33

34

UIM_DATA

(not available)

PET1# USB3TX# SSICTX#

35

36

UIM_PWR

(not available)

PET1 USB3TX SSICTX

37

38

DEVSLP

(not available)

ground

GND6

39

40

GPIO0

(not available)

SATA lane 2 receive +

PER0# SATAB

41

42

GPIO1

(not available)

SATA lane 2 receive -

PER0 SATAB#

43

44

GPIO2

(not available)

ground

GND7

45

46

GPIO3

(not available)

SATA lane 2 transmit -

PET0# SATAA#

47

48

GPIO4

(not available)

SATA lane 2 transmit +

PET0 SATAA

49

50

PRST#

PCIe Reset active low

ground

GND8

51

52

CLKREQ#

(not available)

REFCLK#

53

54

PEWAKE#

(not available)

REFCLK

55

56

N/C

(not available)

ground

GND9

57

58

N/C

(not available)

ANTCTL0

59

60

COEX3

(not available)

ANTCTL1

61

62

COEX2

(not available)

ANTCTL2

63

64

COEX1

(not available)

ANTCTL3

65

66

SIM_DETEC T

(not available)

Powergood

RESET#

67

68

SUSCLK

system clock

Configuration pin

CFG1

69

70

3.3V3

Standby power supply S3,3V

ground

GND10

71

72

3.3V4

Standby power supply S3,3V

ground

GND11

73

74

3.3V5

Standby power supply S3,3V

configuration pin

CFG2

75

The column 'Name' lists all ressources, provided by the chipset. Those ressources, which are made available, are listed in the column 'Description'. Items marked with (*) are optional ressources. If you use

an add-in card, which is not or not fully supported, the BIOS will display an error message.

NOTICE

Chapter: Connectors Memory and internal connectors

page 22 ADL Embedded Solutions ADLE3800SEC

4.3.3 Display Port

For DisplayPort devices, a suitable standard connector is available. Additionally, the interface offers HDMI/DVI signaling which can be made available using an adapter.

Mating adapters are available, please contact your distributor.

Manufacturer

Description

Mating Connector

Foxconn

3VD21207-H7U0-4H

(Standard DisplayPort connector)

Pinout DisplayPort connector:

Description

Name

Description

Displayport Lane 0 +

DPL0

1 2 GND

Ground

Displayport Lane 0 -

DPL0#

3 4 DPL1

Displayport Lane 1 +

Ground

GND

5 6 DPL1#

Displayport Lane 1 -

Displayport Lane 2 +

DPL2

7 8 GND

Ground

Displayport Lane 2 -

DPL2#

9

10

DPL3

Displayport Lane 3 +

Ground

GND

11

12

DPL3#

Displayport Lane 3 -

Configuration pin 1

Config1

13

14

Config2

Configuration pin 2

Displayport Aux +

DPAUX

15

16

GND

Ground

Displayport Aux -

DPAUX#

17

18

HPD

Hotplug Detect

Ground

GND

19

20

3.3V

Power supply 3,3V

Switching to HDMI

By default, the interface offers DisplayPort signals. According to

DisplayPort specification 1.1., the ADLE3800SEC will automatically

switch to HDMI, when using a level shifter cable.

NOTICE

Memory and internal connectors Chapter: Connectors

ADL Embedded Solutions ADLE3800SEC page 23

4.3.4 BAseCon140 Connector

With the BAseCon140 connector the ADLE3800SEC provides a flexible and uncomplicated add-on of additional IO interfaces. The BAseCon140 connector offers up to 8 PCIe lanes, from which 4 can be muxed with SATA2.0 (3G) and the other 4 can be muxed with USB3.0 signals. It also leads through DisplayPort-, HSIC-, SMBus- and 1Wire-signals. All configuration data are saved on the backplane EEProm. The backplane communicates the data to the board via SMB and therefore enables an uncomplicated and self-configuring IO extension.

Notice current limits as follows: maximum load for S3.3V and 3.3V is 1A. For SVCC and VCC the maximum load is 1.5A.

Pinout BAseCon140

Description

Name

Description

SUPS output

SUSV OUT1

1 2 SUSV IN1

SUPS input

SUPS output

SUSV OUT2

3 4 SUSV IN2

SUPS input

VCC

5V1 5 6

GND16

Ground

VCC

5V2 7 8

GND17

Ground

GND1

9

10

3,3V1

Power supply 3.3V

Ground

GND2

11

12

3,3V2

Power supply 3.3V

SVCC

S5V

13

14

S3,3V

Standby power supply 3.3V Ground

GND3

15

16

GND18

Ground

PCIe Lane 1 transmit +

PE1 TX/ SATA4 TX

17

18

SATA4 RX/ PE1 RX

PCIe Lane 1 receive +

PCIe Lane 1 transmit -

PE1 TX#/ SATA4 TX#

19

20

SATA4 RX #/ PE1 RX#

PCIe Lane 1 receive Ground

GND4

21

22

GND19

Ground

PCIe Clock Lane 1 +

PECLK1

23

24

PECLK2

PCIe clock Lane 2 +

PCIe Clock Lane 1 -

PECLK1#

25

26

PECLK2#

PCIe clock Lane 2 -

Ground

GND5

27

28

GND20

Ground

PCIe Lane 2 transmit +

PE2 TX/ SATA3 TX

29

30

SATA3 RX/ PE2 RX

PCIe Lane 2 Receive +

PCIe Lane 2 transmit -

PE2 TX#/ SATA3 TX#

31

32

SATA3 RX #/ PE2 RX#

PCIe Lane 2 Receive -

Chapter: Connectors Memory and internal connectors

page 24 ADL Embedded Solutions ADLE3800SEC

Description

Name

Description

Ground

GND6

33

34

GND21

Ground

(not available)

PE3-TX/ SATA2-TX

35

36

SATA2 RX/ PE3 RX

(not available)

PE3-TX#/ SATA2-TX#

37

38

SATA2 RX#/ PE3 RX#

(not available)

Ground

GND7

39

40

GND22

Ground

(not available)

PECLK3

41

42

PECLK4

(not available)

PECLK3#

43

44

PECLK4#

(not available)

Ground

GND8

45

46

GND23

Ground

SATA Lane 2 transmit +

PE4-TX/ SATA1-TX

47

48

SATA1 RX/ PE4 RX

SATA Lane 2 receive +

SATA Lane 2 transmit -

PE4-TX#/ SATA1-TX#

49

50

SATA1 RX #/ PE4 RX #

SATA Lane 2 receive Ground

GND9

51

52

GND24

Ground

PCIe Clock Enable Lane 1 active low

PCKE1#

53

54

PCKE2#

PCIe Lane 2 Clock Enable active low

(not available)

PCKE3#

55

56

PCKE4#

(not available)

PCIe reset active low

PERST#

57

58

PEWAKE#

PCIe Wake active low

SMBus clock

SMBCLK

59

60

SMBDAT

SMBus data active high

Key SMBus alert active low

SMB-Alert#

61

62

1Wire

1-Wire

(not available)

PCKE5/OC4 #

63

64

PCKE6#/ OC3#

(not available)

PCKE7/OC2 #

65

66

PCKE8#/ OC1#

USB Overcurrent active low Ground

GND10

67

68

GND25

Ground

(not available)

PE5-TX/ USB3-4-TX/ USBC1-TX

69

70

USBC1 RX/ USB3-4 RX/ PE5 RX

(not available)

PE5-TX#/ USB3-4-TX#/ USBC1_TX#

71

72

USBC1 RX#/ USB3-4 RX#/ PE5 RX#

(not available) (not available)

USB2-4 (GND)

73

74

USB2-3 (GND)

(not available)

PECLK5/US BC_SBU1 (GND)

75

76

PECLK6 (GND)

(not available)

PECLK5#/ USBC-SBU2 (GND)

77

78

PECLK6# (GND)

(not available) (not available)

USB2-4# (GND)

79

80

USB2-3 (GND)

(not available)

PE6-TX/ USB3-3-TX/ USBC2-TX

81

82

USBC2 RX/ USB3-3 RX/ PE5 RX

(not available)

PE6-TX#/ USB3-3-TX#/ USBC2-TX#

83

84

USBC2 RX#/ USB3-3 RX#/ PE5 RX#

(not available)

Ground

GND11

85

86

GND26

Ground

Memory and internal connectors Chapter: Connectors

ADL Embedded Solutions ADLE3800SEC page 25

Description

Name

Description

(not available)

PE7-TX/ USB3-2-TX/ SSIC-TX

87

88

SSIC RX/ USB3-2 RX/ PE7 RX

(not available)

PE7-TX#/ USB3-2-TX#/ SSIC-TX#

89

90

SSIC RX#/ USB3-2 RX#/ PE6 RX#

(not available)

USB 2.0 channel 3 +

USB2-2 (GND)

91

92

USB2-1 (GND)

USB 2.0 channel 4 +

Ground

PECLK7 (GND)

93

94

PECLK8 (GND)

Ground

PECLK7# (GND)

95

96

PECLK8# (GND)

Ground

USB 2.0 channel 3 -

USB2-2# (GND)

97

98

USB2-1# (GND)

USB 2.0 channel 4 -

(not available)

PE8-TX/ USB3-1-TX

99

100

USB3-1 RX/ PE8 RX

(not available)

PE8-TX#/ USB3-1-TX#

101

102

USB3-1 RX#/ PE8 RX#

(not available)

Ground

GND12

103

104

GND27

Ground

Key

SATA GP1

GPIO1/ SATAGP1

105

106

SATAGP2/ GPIO2

(not available)

N/A

107

108

USB-CC2/ SATAGP4/ GPIO4

(not available)

TwinCAT LED red

GPIO5/ TCLEDR

109

110

GPIO6/ TCLEDG

TwinCAT LED green

TwinCAT LED blue

GPIO7/ TCLEDB

111

112

GPIO8

(not available)

SATA LED active low

SATA-LED

113

114

USBPWREN

USB Power Enable

RTC-Battery

BATT

115

116

PWRFAIL

SUSV

Power Management Event active low

PME#

117

118

PWRGOOD

Powergood Powerbutton active low

PWRBTN#

119

120

MRST#

Resetbutton active low

PSON

121

122

ATXPWRGD

ATX Powergood

Ground

GND13

123

124

GND28

Ground

DisplayPort + / DVI -

DP/DVI#

125

126

DDCC/ DPAUX

DisplayPort Aux +

DisplayPort Hot Plug Detect

DPHPD

127

128

DDCD/ DPAUX#

DisplayPort Aux Ground

GND14

129

130

GND29

Ground

DisplayPort Lane 0 +

DPL0

131

132

DPL1

DisplayPort Lane 1 +

DisplayPort Lane 0 -

DPL0#

133

134

DPL1#

DisplayPort Lane 1 -

Ground

GND

135

136

GND30

Ground

DisplayPort Lane 2 +

DPL2

137

138

DPL3

DisplayPort 3 +

DisplayPort Lane 2 -

DPL2#

139

140

DPL3#

DisplayPort 3 -

The column 'Name' lists all ressources, provided by the chipset. Those

ressources, which are made available, are listed in the column

'Description'. Items marked with (*) are optional ressources. If you use an add-in card, which is not or not fully supported, the BIOS will display an error message.

NOTICE

Chapter: Connectors Memory and internal connectors

page 26 ADL Embedded Solutions ADLE3800SEC

4.3.5 External Battery

In order to supply the ADLE3800SEC in case of a powerfail, it can be plugged into an external RTC battery via a 2pin connector. The maximum battery voltage is 3.3V.

Manufacturer

Description

Mating Connector

JST

BM02B-SRSS-TB(LF)(SN)

e.g. JST455-1392-ND

UL Conformity: The board already implements all required technical

measures for UL conformity. Connect the battery directly. There are no

further technical measures required!

Synchronicity of RTC: The RTC quartz is sensitive to thermal

fluctuation. Therefore the synchronicity can only be achieved with

sufficient cooling!

Name

Description

1

BATT

battery 3.3 volt

2

GND

ground

NOTICE

Memory and internal connectors Chapter: Connectors

ADL Embedded Solutions ADLE3800SEC page 27

4.3.6 FAN Connector

A 3-pin connector is available for controlling and monitoring an external fan (5 volt). For the monitoring the fan must provide a corresponding speed signal.

Manufacturer

Description

Mating Connector

JST

BM03B-SRSS-TB(LF)(SN)

z.B. JST SHR-03V-S

Name

Description

1

FANON

Control signal FAN

2

VCC

Power supply 5V regulated

3

FANCTRL

Monitoring signal FAN

Chapter: Connectors LED Signaling

page 28 ADL Embedded Solutions ADLE3800SEC

4.4 LED Signaling

4.4.1 RGB LED

The ADLE3800SEC has a tricolor LED, which signals status messages by using different colors and flash intervals.

Color

Interval

Meaning

non

solid

Invalid system state

White

once

Powerfail

Cyan

solid

Reserved

Magenta

solid

SUPS active

Blue

solid

Reserved

Yellow

solid

S5 state

Green

solid

S0 state

Red

solid

Reset/Start

Green/Yellow

flashing

Bootloader operates normal

Red/Yellow

flashing

Bootloader starting (running starting sequence)

Yellow

flashing (6s)

S4 state

Yellow

flashing (3s)

S3 state

Magenta

flashing (0,5s)

SUPS test of capacity

Red/Magenta

flashing

Bootloader: checksum error at I2C transmission

The status codes can be customized, e.g. for TwinCAT LED. The system

colors can be altered via SMB command. The alteration remains until the

following restart or reset of the system. Additionally, a flashing white LED light displays the change of default colors.

NOTICE

LED Signaling Chapter: Connectors

ADL Embedded Solutions ADLE3800SEC page 29

4.4.2 Harddisk-LED

An additional RGB LED signals the harddisk activity.

Colours

Interval

State

Red

intermittent

active

Chapter: Connectors LED Signaling

page 30 ADL Embedded Solutions ADLE3800SEC

4.4.3 TwinCAT-LED

The TwinCAT activity is signaled through a further RGB LED:

Colour

Interval

State

Green

permanent

TwinCAT Run Mode

Blue

permanent

TwinCAT Config Mode

Red

permanent

TwinCAT Stop

General Remarks Chapter: BIOS Settings

ADL Embedded Solutions ADLE3800SEC page 31

5 BIOS Settings

5.1 General Remarks

In each setup page, standard values for all setup entries can be loaded. Previously saved settings are loaded by pressing F2 and factory defaults are loaded with F3. Both F2 and F3, and also F4 ("Save & Exit") always affect the whole set of setup entries. Setup entries starting with a „►" sign represent submenus. Navigation between entries is done using the arrow keys on the keyboard, with the <Enter> key being used to select an entry, which either opens up a dialog box or opens a whole new submenu of setup entries. Each setup entry has a short help text associated with it. This is displayed in the upper right hand corner of the screen.

BIOS features and setup options are subject to change without notice.

The settings displayed in the screenshots on the following pages are

meant to be examples only. They do not represent the recommended settings or the default settings. Determination of the appropriate settings is dependent upon the particular application scenario in which the board is used.

NOTICE

Chapter: BIOS Settings Main

page 32 ADL Embedded Solutions ADLE3800SEC

5.2 Main

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ │Set the Date. Use Tab to │ │ Board Information │switch between Data elements. │ │ Board ADLE3800SEC │ │ │ Revision f │ │ │ Bios Version 0.08 │ │ │ │ │ │ CPU Configuration │ │ │ Microcode Patch 321 │ │ │ BayTrail SoC B2 Stepping │ │ │ │ │ │ Memory Information │ │ │ Total Memory 8192 MB (LPDDR3) │ │ │ │────────────────────────────────│ │ System Date [Sun 12/05/2014] │→←: Select Screen │ │ System Time [00:47:04] │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 Board

Options: none

 Revision

Options: none

 Bios Version

Options: none

 Microcode Patch

Options: none

 BayTrail SoC

Options: none

 Total Memory

Options: none

 System Date

Options: The system date can be adjusted here.

 System Time

Options: The system time can be adjusted here.

Advanced Chapter: BIOS Settings

ADL Embedded Solutions ADLE3800SEC page 33

5.3 Advanced

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ Power-Supply Type [ATX] │Select the Type of the Power │ │► PCI RT32 Service [Disabled] │Supply: AT/ATX │ │► ACPI Settings │ │ │► Hardware Monitor │ │ │► CPU Configuration │ │ │► PPM Configuration │ │ │► SATA Configuration │ │ │► Miscellaneous Configuration │ │ │► Network Stack Configuration │ │ │► Power Controller Options │ │ │► CSM Configuration │ │ │► NVMe Configuration │ │ │► SDIO Configuration │ │ │► USB Configuration │────────────────────────────────│ │ │→←: Select Screen │ │► Intel(R) I210 Gigabit Network Connection - 00:01:05:... │↑↓: Select Item │ │► Intel(R) I210 Gigabit Network Connection - 00:01:05:... │Enter: Select │ │► Intel(R) I210 Gigabit Network Connection - 00:01:05:... │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 Power-Supply Type

Options: ATX / AT

 PCI RT32 Service

Options: Enabled / Disabled

 ACPI Settings

Sub menu: see "ACPI Settings" (page 35)

 H/W Monitor

Sub menu: see "H/W Monitor" (page 36)

 CPU Configuration

Sub menu: see "CPU Configuration" (page 37)

 PPM Configuration

Sub menu: see "PPM Configuration" (page 40)

 SATA Configuration

Sub menu: see "SATA Configuration" (page 41)

 Miscellaneous Configuration

Sub menu: see "Miscellaneous Configuration" (page 42)

 Network Stack

Sub menu: see "Network Stack" (page 43)

 Power Controller Options

Sub menu: see "Power Controller Options" (page 44)

 CSM Configuration

Sub menu: see "CSM Configuration" (page 45)

Chapter: BIOS Settings Advanced

page 34 ADL Embedded Solutions ADLE3800SEC

 NVMe Configuration

Sub menu: see "Advanced-Menü-NVMe Configuration" (page 46)

 SDIO Configuration

Sub menu: see "SDIO Configuration" (page 47)

 USB Configuration

Sub menu: see "USB Configuration" (page 48)

 Security Configuration

Sub menu: see "Security Configuration" (page 49)

 Intel(R) Gigabit Network Connection

Sub menu: see "Intel(R) I210 Gigabit Network Connection" (page 50)

 Driver Health

Sub menu: see "Driver Health" (page 52)

Advanced Chapter: BIOS Settings

ADL Embedded Solutions ADLE3800SEC page 35

5.3.1 ACPI Settings

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ ACPI Settings │Enables or Disables BIOS ACPI │ │ │Auto Configuration. │ │ Enable ACPI Auto Configuration [Disabled] │ │ │ │ │ │ Enable Hibernation [Enabled] │ │ │ ACPI Sleep State [Suspend Disabled] │ │ │ Lock Legacy Resources [Disabled] │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 Enable ACPI Auto Configuration

Options: Enabled / Disabled

 Enable Hibernation

Options: Enabled / Disabled

 ACPI Sleep State

Options: Suspend Disabled / S1 (CPU Stop Clock)

 Lock Legacy Resources

Options: Enabled / Disabled

Chapter: BIOS Settings Advanced

page 36 ADL Embedded Solutions ADLE3800SEC

5.3.2 H/W Monitor

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ Pc Health Status │ │ │ │ │ │ CPU dig. : +44 'C │ │ │ MB Temp : +44 'C │ │ │ PwrCtrlVCC : +5.20 V │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 CPU dig.

Options: none

 MB Temp

Options: none

 PwrCtrlVCC

Options: none

Advanced Chapter: BIOS Settings

ADL Embedded Solutions ADLE3800SEC page 37

5.3.3 CPU Configuration

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ CPU Configuration │Socket specific CPU Information │ │ │ │ │► Socket 0 CPU Information │ │ │► CPU Thermal Configuration │ │ │ │ │ │ CPU Speed 1467 MHz │ │ │ 64-bit Supported │ │ │ │ │ │ Limit CPUID Maximum [Disabled] │ │ │ Execute Disable Bit [Enabled] │ │ │ Intel Virtualization Technology [Enabled] │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 Socket 0 CPU Information

Sub menu: see "Socket CPU Information" (page 38)

 CPU Thermal Configuration

Sub menu: see "CPU Thermal Configuration" (page 39)

 CPU Speed

Options: none

 64-bit

Options: none

 Limit CPUID Maximum

Options: Enabled / Disabled

 Execute Disable Bit

Options: Enabled / Disabled

 Intel Virtualization Technology

Options: Enabled / Disabled

Chapter: BIOS Settings Advanced

page 38 ADL Embedded Solutions ADLE3800SEC

5.3.3.1 Socket CPU Information

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ Socket 0 CPU Information │ │ │ │ │ │ Intel(R) Atom(TM) CPU E3845 @ 1.91GHz │ │ │ CPU Signature 30679 │ │ │ Microcode Patch 901 │ │ │ Max CPU Speed 1910 MHz │ │ │ Min CPU Speed 500 MHz │ │ │ Processor Cores 4 │ │ │ Intel HT Technology Not Supported │ │ │ Intel VT-x Technology Supported │ │ │ │ │ │ L1 Data Cache 24 kB x 4 │ │ │ L1 Code Cache 32 x kB 4 │ │ │ L2 Cache 1024 kB x 2 │ │ │ L3 Cache Not Present │ │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 CPU Signature

Options: none

 Microcode Patch

Options: none

 Max CPU Speed

Options: none

 Min CPU Speed

Options: none

 Processor Cores

Options: none

 Intel HT Technology

Options: none

 Intel VT-x Technology

Options: none

 L1 Data Cache

Options: none

 L1 Code Cache

Options: none

 L2 Cache

Options: none

 L3 Cache

Options: none

Advanced Chapter: BIOS Settings

ADL Embedded Solutions ADLE3800SEC page 39

5.3.3.2 CPU Thermal Configuration

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ CPU Thermal Configuration │Enabled/Disable Digital │ │ DTS [Disabled] │Thermal Sensor. │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 DTS

Options: Enabled / Disabled

Chapter: BIOS Settings Advanced

page 40 ADL Embedded Solutions ADLE3800SEC

5.3.4 PPM Configuration

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ PPM Configuration │Enable/Disable CPU C state │ │ │report to OS │ │ CPU C state Report [Enabled] │ │ │ Max CPU C-state [ C7] │ │ │ Soix [Disabled] │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 CPU C state Report

Options: Disabled / Enabled

 Max CPU C-state

Options: C7 / C6 / C1

 S0ix

Options: Disabled / Enabled

Advanced Chapter: BIOS Settings

ADL Embedded Solutions ADLE3800SEC page 41

5.3.5 SATA Configuration

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ SATA Configuration │Enable or disable SATA Device. │ │ │ │ │ Serial-ATA (SATA) [Enabled] │ │ │ SATA Test Mode [Disabled] │ │ │ │ │ │ SATA Speed Support [Gen2] │ │ │ SATA ODD Port [No ODD] │ │ │ SATA Mode [AHCI Mode] │ │ │ │ │ │ Serial-ATA Port 0 [Enabled] │ │ │ SATA Port0 HotPlug [Disabled] │ │ │ │ │ │ Serial-ATA Port 1 [Enabled] │────────────────────────────────│ │ SATA Port1 HotPlug [Disabled] │→←: Select Screen │ │ │↑↓: Select Item n │ │ SATA Port0 │Enter: Select │ │ Not Present │+/-: Change Opt. │ │ │F1: General Help │ │ SATA Port1 │F2: Previous Values │ │ Not Present │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 Serial-ATA (SATA)

Options: Enabled / Disabled

 SATA Test Mode

Options: Enabled / Disabled

 SATA Speed Support

Options: Gen1 / Gen2

 SATA ODD Port

Options: Port0 ODD / Port1 ODD / No ODD

 SATA Mode

Options: IDE Mode / AHCI Mode

 Serial-ATA Port X

Options: Enabled / Disabled

Chapter: BIOS Settings Advanced

page 42 ADL Embedded Solutions ADLE3800SEC

5.3.6 Miscellaneous Configuration

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ Miscellaneous Configuration │Enable or Disable the High │ │ High Precision Timer [Enabled] │Precision Event Timer │ │ Boot Timer with HPET Timer [Disabled] │ │ │ PCI Express Dynamic Clock Gating [Disabled] │ │ │ OS Selection [Windows 7] │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 High Precision Timer

Options: Disabled / Enabled

 Boot Timer with HPET Timer

Options: Enabled / Disabled

 PCI Express Dynamic Clock Gating

Options: Enabled / Disabled

 OS Selection

Options: Windows 8.X / Windows 7

Advanced Chapter: BIOS Settings

ADL Embedded Solutions ADLE3800SEC page 43

5.3.7 Network Stack

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ Network stack [Enabled] │Enable/Disable UEFI network │ │ IPv4 PXE Support [Enabled] │stack │ │ IPv6 PXE Support [Enabled] │ │ │ PXE boot wait time 0 │ │ │ Media detect count 1 │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 Network stack

Options: Disabled / Enabled

 IPv4 PXE Support

Options: Disabled / Enabled

 IPv6 PXE Support

Options: Disabled / Enabled

 PXE boot wait time

Options: 0..5

 Media detect count

Options: none

Chapter: BIOS Settings Advanced

page 44 ADL Embedded Solutions ADLE3800SEC

5.3.8 Power Controller Options

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ Bootloader Version 1.00-23 │Select Power line for external │ │ Firmware Version 1.00-43 │USB devices, if powered-down │ │ Mainboard Serial No 0948251130007 │ │ │ Mainboard Prod. Date (Week.Year) 14.14 │ │ │ Mainboard BootCount 114 │ │ │ Mainboard Operation Time 10470min (17h) │ │ │ Voltage (Min/Max) 3.10V / 4.80V │ │ │ Temperature (Min/Max) 24'C /59'C │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 Bootloader Version

Options: none

 Firmware Version

Options: none

 Mainboard Serial No

Options: none

 Mainboard Prod. Date (Week.Year)

Options: none

 Mainboard Boot Count

Options: none

 Mainboard Operation Time

Options: none

 Voltage (Min/Max)

Options: none

 Temperature (Min/Max)

Options: none

Advanced Chapter: BIOS Settings

ADL Embedded Solutions ADLE3800SEC page 45

5.3.9 CSM Configuration

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ Compatibility Support Module Configuration │Enable/Disable CSM Support. │ │ │ │ │ CSM Support [Enabled] │ │ │ │ │ │ CSM16 Module Version 07.76 │ │ │ │ │ │ GateA20 Active [Upon Request] │ │ │ Option ROM Messages [Force BIOS] │ │ │ │ │ │ Boot option filter [UEFI and Legacy] │ │ │ │ │ │ Option ROM execution order │ │ │ │────────────────────────────────│ │ Network [UEFI only] │→←: Select Screen │ │ Storage [UEFI only] │↑↓: Select Item │ │ Video [Legacy only] │Enter: Select │ │ Other PCI devices [UEFI only] │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 CSM Support

Options: Disabled / Enabled

 CSM16 Module Version

Options: none

 GateA20 Active

Options: Upon Request / Always

 Option ROM Messages

Options: Force BIOS / Keep Current

 Boot option filter

Options: UEFI and Legacy / Legacy only / UEFI only

 Network

Options: Do not launch / UEFI only / Legacy only

 Storage

Options: Do not launch / UEFI only / Legacy only

 Video

Options: Do not launch / UEFI only / Legacy only

 Other PCI devices

Options: Do not launch / UEFI / Legacy

Chapter: BIOS Settings Advanced

page 46 ADL Embedded Solutions ADLE3800SEC

5.3.10 Advanced-Menü-NVMe Configuration

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ NVMe controller and Drive information │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 NVMe controller and Drive information

Options: none

Advanced Chapter: BIOS Settings

ADL Embedded Solutions ADLE3800SEC page 47

5.3.11 SDIO Configuration

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ SDIO Configuration │Auto Option: Access SD device │ │ │in DMA mode if controller │ │ SDIO Access Mode [AUTO] │supports it, otherwise in PIO │ │ │mode. DMA Option: Access SD │ │ │device in DMA mode.PIO Option: │ │ │Access SD device in PIO mode. │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 SDIO Access Mode

Options: Auto / DMA / PIO

Chapter: BIOS Settings Advanced

page 48 ADL Embedded Solutions ADLE3800SEC

5.3.12 USB Configuration

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ USB Configuration │Enables Legacy USB support. │ │ │AUTO option disables legacy │ │ USB Module Version 10 │support if no USB devices are │ │ │connected. DISABLE option will │ │ USB Devices: │keep USB devices available │ │ 1 Keyboard, 2 Hubs │only for EFI applications. │ │ │ │ │ Legacy USB Support [Enabled] │ │ │ XHCI Hand-off [Enabled] │ │ │ EHCI Hand-off [Disabled │ │ │ USB Mass Storage Driver Support [Enabled] │ │ │ Port 60/64 Emulation [Enabled] │ │ │ │────────────────────────────────│ │ USB hardware delays and time-outs: │→←: Select Screen │ │ USB transfer time-out [20 sec] │↑↓: Select Item │ │ Device reset time-out [20 sec] │Enter: Select │ │ Device power-up delay [Manual] │+/-: Change Opt. │ │ Device power-up delay in seconds 5 │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 USB Devices

Options: none

 Legacy USB Support

Options: Enabled / Disabled / Auto

 XHCI Hand-off

Options: Enabled / Disabled

 EHCI Hand-off

Options: Enabled / Disabled

 Mass Storage Driver Support

Options: Disabled / Enabled

 USB transfer time-out

Options: 5 sec / 10 sec / 20 sec

 Device reset time-out

Options: 10 sec / 20 sec / 30 sec / 40 sec

 Device power-up delay

Options: Auto / Manual

 Device power-up delay in seconds

Options: 1..40

Advanced Chapter: BIOS Settings

ADL Embedded Solutions ADLE3800SEC page 49

5.3.13 Security Configuration

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ Intel(R) TXE Configuration │Send EOP Message Before Enter OS│ │ TXE [Enabled] │ │ │ TXE HMRFPO [Disabled] │ │ │ TXE Firmware Update [Enabled] │ │ │ TXE EOP Message [Enabled] │ │ │ TXE Unconfiguration Perform │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 TXE

Options: Enabled / Disabled

 TXE HMRFPO

Options: Enabled / Disabled

 TXE Firmware Update

Options: Enabled / Disabled

 TXE EOP Message

Options: Enabled / Disabled

 TXE Unconfiguration Perform

Options: none

Chapter: BIOS Settings Advanced

page 50 ADL Embedded Solutions ADLE3800SEC

5.3.14 Intel(R) I210 Gigabit Network Connection

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ ► NIC Configuration │Click to configure the network │ │ │device port. │ │ Blink LEDs 0 │ │ │ │ │ │ │ │ │ UEFI Driver Intel(R) PRO/1000 5.7.06 │ │ │ Adapter PBA: FFFFFF-0FF │ │ │ Device Name Intel(R) I210 Gigabit N │ │ │ Chip Type Intel i210 │ │ │ PCI Device ID 153A │ │ │ PCI Address 01:00:00 │ │ │ │ │ │ Link Status [Disconnected] │────────────────────────────────│ │ │→←: Select Screen │ │ MAC Address 00:01:05:24:7D:2E │↑↓: Select Item │ │ Virtual MAC Address 00:01:05:24:7D:2E │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 NIC Configuration

Sub menu: see "NIC Configuration" (page 51)

 Blink LEDs

Options: none

 UEFI Driver

Options: none

 Adapter PBA

Options: none

 Device Name

Options: none

 Chip Type

Options: none

 PCI Device ID

Options: none

 PCI Address

Options: none

 Link Status

Options: none

 MAC Address

Options: none

 Virtual MAC Address

Options: none

Advanced Chapter: BIOS Settings

ADL Embedded Solutions ADLE3800SEC page 51

5.3.14.1 NIC Configuration

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ Link Speed [Auto Neg] │Specifies the port speed used │ │ Wake On LAN [Enabled] │for the selected boot protocol. │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 Link Speed

Options: Auto Negotiated / 10Mbps Half / 10Mbps full / 100Mbps Half / 100Mbps Full

 Wake On LAN

Options: Enabled / Disabled

Chapter: BIOS Settings Advanced

page 52 ADL Embedded Solutions ADLE3800SEC

5.3.15 Driver Health

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │► Intel(R) PRO/1000 5.7.06 PCI-E Healthy │Provides Health Status for the │ │ │Drivers/Controllers │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 Intel(R) PRO/1000 5.7.06 PCI-E

Sub menu: see "Intel(R) PRO/1000 PCI-E" (page 53)

Advanced Chapter: BIOS Settings

ADL Embedded Solutions ADLE3800SEC page 53

5.3.15.1 Intel(R) PRO/1000 PCI-E

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ Controller b7c95c18 Child 0 Healthy │Provides Health Status for the │ │ Intel(R) I210 Gigabit Network Connection Healthy │Drivers/Controllers │ │ Controller b7c95718 Child 0 Healthy │ │ │ Intel(R) I210 Gigabit Network Connection Healthy │ │ │ Controller b7c95318 Child 0 Healthy │ │ │ Intel(R) I210 Gigabit Network Connection Healthy │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 Controller x Child n

Options: none

Chapter: BIOS Settings Chipset

page 54 ADL Embedded Solutions ADLE3800SEC

5.4 Chipset

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │► North Bridge │North Bridge Parameters │ │► South Bridge │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 North Bridge

Sub menu: see "North Bridge" (page 55)

 South Bridge

Sub menu: see "South Bridge" (page 59)

Chipset Chapter: BIOS Settings

ADL Embedded Solutions ADLE3800SEC page 55

5.4.1 North Bridge

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │► Intel IGD Configuration │Config Intel IGD Settings. │ │► Graphics Power Management Control │ │ │ │ │ │ Memory Information │ │ │ │ │ │ Total Memory 8192 MB (LPDDR3) │ │ │ │ │ │ Memory Slot0 8192 MB (LPDDR3) │ │ │ Memory Slot1 Not Present │ │ │ │ │ │ Max TOLUD [Dynamic] │ │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 Intel IGD Configuration

Sub menu: see "Intel IGD Configuration" (page 56)

 Graphics Power Management Control

Sub menu: see "Graphics Power Management Control" (page 58)

 Total Memory

Options: none

 Memory SlotX

Options: none

 Max TOLUD

Options: Dynamic / 1GB / 1.25GB / .. / 3GB

Chapter: BIOS Settings Chipset

page 56 ADL Embedded Solutions ADLE3800SEC

5.4.1.1 Intel IGD Configuration

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ GOP Configuration │Enable: Enable Integrated │ │ Enable GOP-driver via CSM Configuration-Video │Graphics Device (IGD) when │ │ │selected as the Primary Video │ │ Intel IGD Configuration │Adaptor. Disable: Always │ │ │disable IGD │ │ Integrated Graphics Device [Enabled] │ │ │ │ │ │ IGD Turbo Enable [Enabled] │ │ │ Primary Display [IGD] │ │ │ PAVC [LITE Mode] │ │ │ DVMT Pre-Allocated [64M] │ │ │ DVMT Total Gfx Mem [256MB] │────────────────────────────────│ │ Aperture Size [256MB] │→←: Select Screen │ │ DOP CG [Enabled] │↑↓: Select Item │ │ GTT Size [2MB] │Enter: Select │ │ Spread Spectrum Clock [Disabled] │+/-: Change Opt. │ │ │F1: General Help │ │ ISP Enable/Disable [Enabled] │F2: Previous Values │ │ ISP PCI Device Selection [Disabled] │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ Vcc, Vnn Configuration for Power state2: │ESC: Exit │ │ Vcc_Vnn Config for Power state2 [Disabled] │ │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 Integrated Graphics Device

Options: Enabled / Disabled

 IGD Turbo Enable

Options: Enabled / Disabled

 Primary Display

Options: IGD / PCI

 PAVC

Options: Disabled / LITE Mode / SERPENT Mode

 DVMT Pre-Allocated

Options: 32M / 64M ... 480M / 512M

 DVMT Total Gfx Mem

Options: 128M / 256M / MAX

 Aperture Size

Options: 128MB / 256MB / 512MB

 DOP CG

Options: Enabled / Disabled

 GTT Size

Options: 1MB / 2MB

 Spread Spectrum clock

Options: Enabled / Disabled

 ISP Enable/ Disable

Options: Enabled / Disabled

Chipset Chapter: BIOS Settings

ADL Embedded Solutions ADLE3800SEC page 57

 ISP PCI Device Selection

Options: Disabled / ISP PCI Device as B0D2F0 / ISP PCI Device as B0D3F0

 Vcc_Vnn Config for Power state2

Options: Enabled / Disabled

Chapter: BIOS Settings Chipset

page 58 ADL Embedded Solutions ADLE3800SEC

5.4.1.2 Graphics Power Management Control

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ Graphics Power Management Control │Check to enable render standby │ │ RC6(Render Standby) [Enabled] │support. │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 RC6 (Render Standby)

Options: Enabled / Disabled

Chipset Chapter: BIOS Settings

ADL Embedded Solutions ADLE3800SEC page 59

5.4.2 South Bridge

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │► Azalia HD Audio │Azalia HD Audio Options │ │► USB Configuration │ │ │► PCI Express Configuration │ │ │ │ │ │ High Precision Timer [Enabled] │ │ │ Restore AC Power Loss [Power On] │ │ │ │ │ │ Onboard Device Configuration │ │ │ Onboard Gigabit LAN 1 [Enabled] │ │ │ Onboard Gigabit LAN 2 [Enabled] │ │ │ Onboard Gigabit LAN 3 [Enabled] │ │ │ │────────────────────────────────│ │ M.2-PCIe Configuration Pins M.2-PCIe │→←: Select Screen │ │ M.2-SATA Configuration Pins M.2-SATA │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 Azalia HD Audio

Sub menu: see "Azalia HD Audio" (page 60)

 USB Configuration

Sub menu: see "USB Configuration" (page 61)

 PCI Express Configuration

Sub menu: see "PCI Express Configuration" (page 62)

 High Precision Timer

Options: Disabled / Enabled

 Restore AC Power Loss

Options: Power Off / Power On / Last State

 Onboard Gigabit LAN X

Options: Enabled / Disabled

 M.2-PCIe Configuration Pins

Options: none

 M.2-SATA Configuration Pins

Options: none

Chapter: BIOS Settings Chipset

page 60 ADL Embedded Solutions ADLE3800SEC

5.4.2.1 Azalia HD Audio

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ Audio Configuration │Control Detection of the │ │ │Azalia device. Disabled = │ │ │Azalia will be unconditionally │ │ Audio Controller [Enabled] │ │ │ Azalia VCi Enable [Enabled] │ │ │ Azalia PME Enable [Enabled] │ │ │ Azalia HDMI Codec [Enabled] │ │ │ HDMI Port B [Enabled] │ │ │ HDMI Port C [Enabled] │ │ │ │ │ │ │ │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 Audio Controller

Options: Disabled / Enabled

 Azalia VCi Enable

Options: Disabled / Enabled

 Azalia PME Enable

Options: Disabled / Enabled

 Azalia HDMI Codec

Options: Disabled / Enabled

 HDMI Port X

Options: Disabled / Enabled

Chipset Chapter: BIOS Settings

ADL Embedded Solutions ADLE3800SEC page 61

5.4.2.2 USB Configuration

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ USB Configuration │Mode of operation of xHCI │ │ │controller │ │ USB Mode [XHCI] │ │ │ │ │ │ USB Per Port Control [Enabled] │ │ │ USB Port 0 [Enabled] │ │ │ USB Port 1 [Enabled] │ │ │ USB Port 2 [Enabled] │ │ │ USB Port 3 [Enabled] │ │ │ │ │ │ │ │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 USB Mode

Options: EHCI / XHCI

 USB Per Port Control

Options: Enabled / Disabled

 USB Port x

Options: Disabled / Enabled

Chapter: BIOS Settings Chipset

page 62 ADL Embedded Solutions ADLE3800SEC

5.4.2.3 PCI Express Configuration

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ PCI Express Configuration │Enable or Disable the PCI │ │ │Express Port 2 and Port 3 in │ │ PCI Express Port 0 is assigned to LAN 1 │the Chipset. │ │ PCI Express Port 1 is assigned to LAN 2 │ │ │ PCI Express Port 2 is assigned to LAN 3 │ │ │ │ │ │ PCI Express Port 3 is assigned to M.2-PCIe │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 PCIe Port x is assigned to

Options: none

Security Chapter: BIOS Settings

ADL Embedded Solutions ADLE3800SEC page 63

5.5 Security

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ Password Description │Set Administrator Password │ │ │ │ │ Minimum length 3 │ │ │ Maximum length 20 │ │ │ │ │ │ │ │ │ Administrator Password │ │ │ │ │ │ │ │ │ │ │ │► Secure Boot menu │ │ │ │ │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 Secure Boot menu

Sub menu: see "Secure Boot menu" (page 64)

Chapter: BIOS Settings Security

page 64 ADL Embedded Solutions ADLE3800SEC

5.5.1 Secure Boot menu

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ │Secure Boot can be enabled if │ │ Sytem Mode Setup │1.System running in User mode │ │ Secure Boot Not Active │with enrolled Platform Key(PK) │ │ Vendor Keys Not Active │2.CSM function is disabled │ │ │ │ │ Secure Boot [Disabled] │ │ │ Secure Boot Mode [Custom] │ │ │► Key Management │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 System Mode

Options: none

 Secure Boot

Options: none

 Vendor Keys

Options: none

 Secure Boot Mode

Options: Standard / Custom

 Key Management

Sub menu: see "Key Management" (page 65)

Security Chapter: BIOS Settings

ADL Embedded Solutions ADLE3800SEC page 65

5.5.1.1 Key Management

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ Provision Factory Default [Disabled] │Install factory default Secure │ │ │Boot keys when System is in │ │► Enroll all Factory Default Keys │Setup Mode. │ │► Save all Secure Boot Variables │ │ │ │ │ │ Secure Boot variable | Size| Key#| Key source │ │ │► Platform Key(PK) | 0| 0| │ │ │► Key Exchange Keys | 0| 0| │ │ │► Authorized Signatures| 0| 0| │ │ │► Forbidden Signatures | 0| 0| │ │ │► Authorized TimeStamps| 0| 0| │ │ │ │ │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 Provision Factory Default keys

Options: Enabled / Disabled

 Enroll All Factory Default Keys

Options: Press [Enter]

 Save All Secure Boot Variables

Options: Press [Enter]

 Platform Key(PK)

Options: Set New Key

 Key Exchange Keys

Options: Set New Key / Append Key

 Authorized Signatures

Options: Set New Key / Append Key

 Forbidden Signatures

Options: Set New Key / Append Key

 Authorized TimeStamps

Options: Set New Key / Append Key

Chapter: BIOS Settings Boot

page 66 ADL Embedded Solutions ADLE3800SEC

5.6 Boot

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ Boot Configuration │Number of 1/10 sec. to wait │ │ Setup Prompt Timeout 5 │for setup activation key. 0 │ │ Bootup NumLock State [On] │means no wait. │ │ │ │ │ Full Screen Logo [Enabled] │ │ │ Fast Boot [Enabled] │ │ │ VGA Support [EFI Driver] │ │ │ USB Support [Partial Initial] │ │ │ PS2 Devices Support [Enabled] │ │ │ NetWork Stack Driver Support [Disabled] │ │ │ │ │ │ Boot mode select [LEGACY] │ │ │ │────────────────────────────────│ │ FIXED BOOT ORDER Priorities │→←: Select Screen │ │ Boot Option #1 [Hard Disk] │↑↓: Select Item │ │ Boot Option #2 [CD/DVD] │Enter: Select │ │ Boot Option #3 [USB Hard Disk] │+/-: Change Opt. │ │ Boot Option #4 [USB CD/DVD] │F1: General Help │ │ Boot Option #5 [USB Key] │F2: Previous Values │ │ Boot Option #6 [USB Floppy] │F3: Optimized Defaults │ │ Boot Option #7 [Network] │F4: Save & Exit │ │ │ESC: Exit │ │► Advanced Fixed Boot Order Parameters │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 Setup Prompt Timeout

Options: 0...65535 [x 1/10 sec.]

 Bootup NumLock State

Options: On / Off

 Full Screen Logo

Options: Disabled / Enabled

 Fast Boot

Options: Disabled / Enabled

 VGA Support

Options: Auto / EFI Driver

 USB Support

Options: Disabled / Full Initial / Partial Initial

 PS2 Devices Support

Options: Disabled / Enabled

 NetWork Stack Driver Support

Options: Disabled / Enabled

 Boot mode select

Options: Legacy / UEFI / DUAL

 Boot Option Priorities

Options: Reihenfolge der Boot-Devices überprüfen/ändern

 Advanced Fixed Boot Order Parameters

Sub menu: see "Advanced Fixed Boot Order Parameters" (page 67)

Boot Chapter: BIOS Settings

ADL Embedded Solutions ADLE3800SEC page 67

5.6.1 Advanced Fixed Boot Order Parameters

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ Max. CFast/SSD capacity (GB) 200 │Enable or Disable the High │ │ Max. USB Stick capacity (GB) 64 │Precision Event Timer │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 Max. CFast/SSD capacity (GB)

Options: none

 Max USB Stick capacity (GB)

Options: none

Chapter: BIOS Settings Save & Exit

page 68 ADL Embedded Solutions ADLE3800SEC

5.7 Save & Exit

┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ Save Changes and Reset │Reset the system after saving │ │ Discard Changes and Reset │the changes. │ │ │ │ │ Restore Optimized Defaults │ │ │ │ │ │ Boot Override │ │ │ IBA GE Slot 0100 v1553 │ │ │ WinCE │ │ │► Reset System with ME disable ModeMEUD000 │ │ │ │ │ │ │ │ │ │ │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/-: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘

 Save Changes and Reset

Options: Press [Enter]

 Discard Changes and Reset

Options: Press [Enter]

 Restore Defaults

Options: Press [Enter]

 Reset System with ME disable ModeMEUD000

Options: Press [Enter]

BIOS Update Chapter: BIOS Settings

ADL Embedded Solutions ADLE3800SEC page 69

5.8 BIOS Update

If a BIOS update needs to be done, the program “DecdFlash” as well as a bootable medium which

contains the newest BIOS version is used for this. It is important, that the program is started from a DOS

environment without a virtual memory manager, for example “EMM386.EXE”. In case such a memory

manager is loaded, the program will stop with an error message. DescdFlash is a program which provides automatic BIOS updates on any AMI-BIOS boards. All files need

to be copied from the .zip-file in another directory. The system may not be interrupted during the flash process, otherwise the update is stopped and the BIOS is destroyed afterwards. The program should be started as follows:

DecdFlsh BIOS-Filename

After checking the name of the BIOS file and its length the BIOS will be programmed. The flashing takes nearly 75 seconds. The firmware will get updated automatically.

A faulty BIOS-Update process may cause damages on the board!

Updating the BIOS in an improper way can render the board unusable.

Therefore, you should only update the BIOS if you really need the changes/corrections which come with the new BIOS version.

Before you proceed to update the BIOS you need to make absolutely sure that you have the right BIOS file which was issued for the exact board and exact board revision that you wish to update. If you try to update the BIOS using the wrong file the board will not start up again.

NOTICE

Chapter: Mechanical Drawings PCB: Outlines

page 70 ADL Embedded Solutions ADLE3800SEC

6 Mechanical Drawings

All dimensions are in mil (1 mil = 0,0254 mm)

6.1 PCB: Outlines

63.8

2511.80

5

196.90

78.60

24.84

978.00

5

196.80

2

78.70 2

78.80 2

21.26

837.00

196.80

236.30

236.40

1.8

71.00

5

6

62.02

2441.70

196.90 5

63.8

2511.80

2952.80 75

51.43

2025.00

2952.80

2677.50

dimension = mil [mm]

75

68.01

NOTICE

PCB: Die Center Chapter: Mechanical Drawings

ADL Embedded Solutions ADLE3800SEC page 71

6.2 PCB: Die Center

30.61

27.55

26.56

H1-H3 =1,8mm x 3mm

dimension=mm

41.71

H2

15.14

10.49

H1

15.14

CPU DIE Center and size

9.73

H3

43.56

Chapter: Technical Data Elektrische Daten

page 72 ADL Embedded Solutions ADLE3800SEC

7 Technical Data

7.1 Elektrische Daten

Power Supply:

Board: 16-30 Volt (5 Volt Fan) RTC: >= 3 Volt

Electric Power Consumption:

RTC: <= 10A

7.2 Environmental Conditions

Temperature Range:

Operating: -25°C to +70°C (using approved thermal solution)

-40°C up to +85°C (when pre-screened for use with an approved thermal solution)

Storage: -40°C up to +85°C Shipping: -40°C up to +85°C, for packaged boards

Temperature Changes:

Operating: 0.5°C per minute, 7.5°C per 30 minutes Storage: 1.0°C per minute Shipping: 1.0°C per minute, for packaged boards

Relative Humidity:

Operating: 5% up to 85% (non condensing) Storage: 5% up to 95% (non condensing) Shipping: 5% up to 100% (non condensing), for packaged boards

Shock:

Operating: 150m/s2, 6ms Storage: 400m/s2, 6ms Shipping: 400m/s2, 6ms, for packaged boards

Vibration:

Operating: 10 up to 58Hz, 0.075mm amplitude 58 up to 500Hz, 10m/s2 Storage: 5 up to 9Hz, 3.5mm amplitude 9 up to 500Hz, 10m/s2 Shipping: 5 up to 9Hz, 3.5mm amplitude 9 up to 500Hz, 10m/s2, for packaged boards

Shock and vibration figures pertain to the motherboard alone and do not include additional components such as heat sinks, memory modules, cables etc.

NOTICE

Thermal Specifications Chapter: Technical Data

ADL Embedded Solutions ADLE3800SEC page 73

7.3 Thermal Specifications

The board is specified to operate in an environmental temperature range from -25°C to +70°C when using an approved thermal solution, and an extended temperature range of -40°C to +85°C when pre-screened for use with an approved thermal solution. Maximum die temperature is 100°C. To keep the processor under this threshold an appropriate cooling solution needs to be applied. This solution has to take typical and maximum power consumption into account. The maximum power consumption may be twice as high and should be used as a basis for the cooling concept. Additional controllers may also affect the cooling concept. The power consumption of such components may be comparable to the consumption of the processor. The board design includes thermal solution mounting points that will provide the best possible thermal interface between die and solution. Since we take thermal solutions seriously we have several advanced, aggressive cooling solutions in our product portfolio. Please contact your sales representative to order or discuss your thermal solution needs.

The end customer has the responsibility to ensure that the die temperature of the processor does not exceed 100°C. Permanent overheating may destroy the board!

In case the temperature exceeds 100°C the environmental temperature must be reduced. Under certain circumstances sufficient air circulation must be provided.

NOTICE

Annex: Post-Codes

page 74 ADL Embedded Solutions ADLE3800SEC

Annex: Post-Codes

ADL Embedded Solutions ADLE3800SEC page 75

I Annex: Post-Codes

During boot, the BIOS generates a sequence of status codes (so-called "POST codes"), which can be viewed using a special output device (POST code card). The meaning of these codes is described in the document "Aptio™ 4.x Status Codes" by American Megatrends®, which can be downloaded from their website http://www.ami.com. The following additional OEM POST codes are generated:

Code

Description

87h

BIOS-API started

88h

PCA9535 started

89h

PWRCTRL-Firmware started

Annex: Resources

page 76 ADL Embedded Solutions ADLE3800SEC

II Annex: Resources

Interrupt

The used resources depend on setup settings. The listed interrupts and their use are given through AT compatibility. If interrupts must exclusively be available on the ISA side, they have to be reserved through the BIOS setup. The exclusivity is not given and not possible on the PCI side.

Adress

Function

IRQ0

Timer

IRQ1

IRQ2 (8)

IRQ3

IRQ4

IRQ5

IRQ6

IRQ7

IRQ8

RTC

IRQ9

IRQ10

IRQ11

SMBus Controller

IRQ12

IRQ13

IRQ14

IRQ15

IRQ16

PCI Bridge(0-1) x1(x1)

IRQ17

PCI Bridge(0-2) x1(x1)

IRQ18

PCI Bridge(0-3) x1(x1)

IRQ19

PCI Bridge(0-4) x0(x1)

IRQ20

IRQ21

IRQ22

High Def Audio

PCI Devices

All listed PCI devices exist on the board. Some PCI devices or functions of devices may be disabled in the BIOS setup. Once a device is disabled other devices may get PCI bus numbers different from the ones listed in the table.

AD

INTA

REQ

Bus

Dev.

Fkt.

Kontroller / Slot

- - 0 0 0

Host Bridge ID0F00h

A - 0 2 0

VGA Graphics ID0F31h

A - 0

19 0 SATA (AHCI 1.0) ID0F23h

A - 0

20 0 XHCI Controller ID0F35h

A - 0

27 0 HD Audio ID0F04h

A - 0

28 0 PCI Express Port 1 ID0F48h

B - 0

28 1 PCI Express Port 2 ID0F4Ah

C - 0

28 2 PCI Express Port 3 ID0F4Ch

D - 0

28 3 PCI Express Port 4 ID0F4Eh

- - 0

31 0 ISA Bridge ID0F1Ch

B - 0

31 3 SMBus Interface ID0F12h

A - 1 0 0

Ethernet Controller x1 ID1533h

A - 2 0 0

Ethernet Controller x1 ID1533h

Annex: Resources

ADL Embedded Solutions ADLE3800SEC page 77

Embedded Solutions ADLE3800SEC User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
