Embed RAD000 User Manual

Embed Wireless

U

.

S

.

A

.

www.

embedcard.com

Equipment Installation
Guide

Revised – 20th April, 2012

Copyright © by Embed International Pty Ltd

Notice of Rights

All rights reserved. No part of this document may be reproduced or transmitted in any form
or by any means, electronic, mechanical, photocopying, recording, or otherwise, without
prior written permission of Embed. For more information on getting permission for reprints
and excerpts, contact Embed.

Notice of Liability

The information in this document is distributed on an “as is” basis, without warranty. While
every precaution has been taken in the preparation of this document, neither the author or
Embed shall have any liability to any person or entity with respect to any loss or damage
caused or alleged to be caused directly or indirectly by the instructions contained in this
document or by the computer software or hardware products described herein.

www.embedcard.com

Asia-Pacific – Head Office

Embed International Pty Ltd
2 Neil St.
Osborne Park, WA 6017
Australia

Telephone [phone]
Facsimile [phone]

Information: [e-mail]
Sales: [e-mail]
Support: [e-mail]

North & South America

Embed USA LLC
1621 West Crosby Rd.
Suite 100A
Carrollton, TX 75006
USA

Telephone [phone]
Facsimile [phone]

Information: [e-mail]
Sales: [e-mail]
Support: [e-mail]

Middle East

Embed International Pty Ltd - Middle East
Q3-197, PO Box: 122113
Sharjah Airport International Free (SAIF) Zone
Sharjah, UAE

Telephone [phone]
[phone]

Information: [e-mail]
Sales: [e-mail]
Support: [e-mail]

UK and Europe

Embed Playsafe
14 The Maltings
Brassmill Lane
Bath BA1 3JL
United Kingdom

Telephone [phone]

Information: [e-mail]
Sales: [e-mail]
Support: [e-mail]

Table of Contents

Overview ................................................................................................................................................. 4

Do not use in life critical or applications requiring high reliability ......................................................... 4

Protecting against electrostatic discharge ............................................................................................ 4

Power Supply Details Range................................................................................................................. 4

Other information and warnings: ......................................................................................................... 4

Product Directory .................................................................................................................................... 5

Embed Wireless Device/Client ............................................................................................................. 5

Embed Wireless Coordinator/Server .................................................................................................... 5

Embed Wireless Client/Device Game Installation ..................................................................................... 6

Embed Wireless Server/Coordinator Game Installation ........................................................................... 7

FCC Compliance Statement ..................................................................................................................... 8

Waste Electrical and Electronic Equipment (WEEE) Statement................................................................. 9

DECLARATION OF CONFORMITY ............................................................................................. 10

Overview

This document outlines the process of installation and setup for the Embed Wireless
hardware. Topics to be covered include Coordinator and Device installation, wiring details,
and wireless settings. This guide assumes that the installer has basic electronic skills.

Do not use in life critical or applications requiring high reliability

The Embed Wireless system is not intended for use in systems that may
affect human life or that require a very high degree of reliability such as
medical equipment, nuclear facilities, aerospace equipment or
transportation equipment. Embed does not assume any liability for
accidents resulting in injury or death, or for any damages to property that
may occur as a result of using the product in such facilities, equipment, or
control systems.

Protecting against electrostatic discharge

Electrostatic discharge can damage electronic components including the
Embed Wireless System. Please observe electrostatic discharge precautions
for handling or installing this equipment.

Power Supply Details Range

The Embed Wireless should be operated with a power supply with a voltage between 9 –
15 V, which can supply at least 300 mA.

Other information and warnings:

• Embed Wireless is intended for operation between 55 0C and -20 OC.

• Embed Wireless is not intended for use at home.

Embed International PTY LTD 4 www.embedcard.com

Embed International PTY LTD

Embed Wireless Device/Client

The wireless client allows for a cable

ontroller and Embed

Wireless Coordinator/Server’s.

Embed Wireless Coordinator/Server

The wireless coordinator/Server enables for

communications with Embed Wireless

devices/clients and the Game Server.

Product Directory

connection between C

:

-free

:

5

www.embedcard.com

Embed Wireless Client/Device Game Installation

Step 1: Connect the RS485 patch cable to the wireless client J1.

Step 2: Connect 12 V (minimum of 300 m.A.) to J1 on the Embed Wireless Client/Device.

Step 3: Connect and orient the antenna straight up or down.

Note 1: Embed Wireless should not be installed in, nearby or on metal enclosures (such as a

full metal cabinet), otherwise performance may be severely degraded.

Note 2: Embed Wireless should be installed so that it is more than 20cm from any possible

human bodies.

Note 3: Embed Wireless should be installed away from sources of electrical noise (such as

motors, air conditioner units etc).

Embed International PTY LTD 6 www.embedcard.com

Embed Wireless Server/Coordinator Game Installation

Step 1: Connect the RS485 patch cable to the wireless client J1.

Step 2: Connect and orient the antenna straight up or down.

Note 1: Embed Wireless should not be installed in, nearby or on metal enclosures (such as a

full metal cabinet), otherwise performance may be severely degraded.

Note 2: Embed Wireless should be installed so that it is more than 20cm from any possible

human bodies.

Note 3: Embed Wireless should be installed away from sources of electrical noise (such as

motors, air conditioner units etc).

Embed International PTY LTD 7 www.embedcard.com

FCC Compliance Statement

The following product has been tested and certified as compliant with the regulations and
guidelines set forth in Part 15 of FCC Rules:

Manufacturer: Embed International Pty Ltd

Model: RAD-002

Part 15 of FCC Rules

This equipment complies with the limits for a Class B digital device as specified in Part 15 of
FCC Rules which provide reasonable protection against harmful interference in a residential
area.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
conditions:
(1) This device may not cause harmful interference, and (2) this device must accept and
interference received including interference that may cause undesired operation.
This equipment complies with the limits for a Class B digital device as specified in Part 15 of
FCC Rules which provide reasonable protection against harmful interference in residential
area.
This equipment generates and uses radio frequency energy, and if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
In the unlikely event that there is interference to radio or television reception (which can be
determined by turning the equipment off and on), the user is encouraged to try to correct
the interference by one or more of the following measures:

•

Reorient or relocate the receiving antenna

•

Increase the separation between the equipment and receiver

•

Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.

•

Consult with the dealer or ask an experienced radio/TV technician for help.

Any changes or modifications to this equipment not expressly approved by Embed could
void the user’s authority to operate this equipment.

Embed International PTY LTD 8 www.embedcard.com

Waste Electrical and Electronic Equipment (WEEE) Statement

Embed complies with Directive 2002/96/EC OF THE EUROPEAN PARLIAMENT AND OF THE
COUNCIL of 27 January 2003 on waste electrical and electronic equipment (WEEE).

This product has required the extraction and use of natural resources for its production. It
may contain hazardous substances that could impact health and the environment, if not
properly disposed. In order to avoid dissemination of those substances in our environment
and to diminish the pressure on the natural resources, we encourage you to use the
appropriate take-back systems for product disposal. Those systems will reuse or recycle
most of the materials of the product you are dispensing in a sound way.

For proper disposal instructions go to,

http://www.embedcard.com/recycle

For more information about the disposal of Waste Electrical and
Electronic Equipment (WEEE), please go to,

http://ec.europa.eu/environment/waste/weee/index_en.htm

Please retain this for future reference.

Embed International PTY LTD 9 www.embedcard.com

DECLARATION OF CONFORMITY

With regard to the R&TTE Directive 1999/5/EC

We,

Embed International Pty Ltd

2 Neil St
Osborne Park, WA
Australia 6017

Declare under our sole responsibility that the product,

Product: EI-WIR-180

Fulfills the essential requirements of the directive 1999/5/EC as attested by the conformity with the
following harmonized standards:

Health & Safety

EMC

Radio

The conformity assessment procedure referred to in Article 10.4 and Annex III of Directive
1999/5/EC has been followed. In addition, complies with Low Voltage Directive 2006/95/EC.

This product carries the CE Mark:

Date & Place of Issue: 31st March 2011, Perth, Australia

Signature:

Mark Easte

Managing Director
Embed International Pty Ltd
2 Neil St
Osborne Park, WA
Australia 6017

Embed Network Adapter 2.4GHz IEEE 802.15.4

RAD-002

Embed Network Adapter 2.4GHz IEEE 802.15.4

ETSI EN 60950-1

ETSI EN 301 489-1
ETSI EN 301 489-3

ETSI EN 300 440-2
ETSI EN 300 420-1
