EMAY TECHNOLOGY IMYSC21 User Manual

Interface:

DC-OUT

DC-IN

OFF ON OFF

DC-OUT SWITCH

BT SWITCH

Keyboard Specification :

Battery Lithium Polymer

Capacity : 3000mAH

Working Current : 2.5mA

Sleeping Current : 600µA

DC-in : 5V 1.0A

DC-out : 5V 1.6A

Size : 247 x 195 x 24 mm

Weight : 620g

Features:

-2.4G Bluetooth connection

-Support iPad function keys

-Protect iPad with clamshell

-Convenience keyboard design

-Large capacity battery as PowerBank

Packing Contents :

-Bluetooth keyboard

-USB charging cable

-User manual

How to use?

-Turn on Bluetooth on your iPad

Select Settings>General>Bluetooth>On

-Turn on the Bluetooth keyboard by sliding the power switch

The Bluetooth indicator light will be on 5 seconds then go off.

-Press the connect button. The Bluetooth indicator light will be blinking

The keyboard is now ready to be connected

-“Bluetooth keyboard for iPad” will show on your iPad screen as an

Available Bluetooth device

-Select “Bluetooth keyboard for iPad” and a four-digit code will show.

-Type the four-digit code by the Bluetooth keyboard and press Enter

-Your keyboard and iPad should automatically connect

Bluetooth Keyboard User Manual

O I O I

CONNECT DC-OUT

Federal Communication Commission Interference Statement

This Equipment has been tested and found to comply with the limits for a Class B digital device Pursuant to Part 15 of the FCC Rules, these limits are designed to provide reasonable protection against harmful interference in a residential installation This equipment generates uses and can radiate radio frequency energy and, if no installed and used in accordance with the instructions, may cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna —Increase the separation between the equipment and receiver —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected —Consult the dealer or an experienced radio/TV technician for help

This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation

FCC Caution : Any change or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment

IMPORTANT NOTE:

FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment

iPad is trademarks of Apple Inc
