Ematic eGlide X User Guide

Precautions

 Do not drop the device or subject it to severe impacts.

 Do not use the device in extreme hot or cold, dusty or damp conditions. Do not

expose it to direct sunlight.

 Avoid using the device near strong magnetic fields.

 Normal functioning of the product may be disturbed by ESD. If so, simply reset

and restart the device following the instruction manual. During file transmission,

please handle with care and operate in a static-free environment.

 Keep the device away from water and other liquids. In the event that water or

other liquids enter the device, power off the product immediately and clean the

device.

 Do not use chemicals to clean the device in order to avoid corrosion. Clean it with

a dry cloth.

 Do not install this equipment in a confined space such as a book case or similar

unit. The ventilation should not be impeded by covering the ventilation openings

with items such as newspaper, table-cloths, curtains etc.

 No naked flame sources, such as lighted candles, should be placed on the

apparatus.

 Attention should be drawn to environmental aspects of battery disposal.

 Use the apparatus in moderate climates.

 We are not responsible for damage or lost data caused by malfunction, misuse,

modification of the device or battery replacement.

 Do not attempt to disassemble, repair or modify the product. This will invalidate

the warranty.

 If the device will not be used for an extended period of time, please charge the

battery at least once per month to maintain battery life.

 Charge the battery if:

a) The battery level icon displays (An empty battery)

b) The device powers off automatically when restarted.

c) There is no response when pressing keys with keys unlocked and battery full.

 Do not interrupt the connection when the device is being formatted or transferring

files. Otherwise, data may be corrupted or lost.

 When the device is used as a portable HD, please use only per the instructions.

Otherwise, permanent data loss could occur.

 Please use and install data using the attachments/accessories provided and only

according to the manufacturer’s instruction.

 Please refer to the information on the bottom of the device for electrical and

safety information before installing data or operating the device.

 To reduce the risk of fire or electric shock, do not expose this device to rain or

moisture. The device should not be exposed to dripping or splashing. Never

place objects filled with liquids, such as vases, on the device.

 There is danger of explosion if the battery is replaced incorrectly. Replace only

with the same or equivalent type.

 The battery (battery or batteries or battery pack) should not be exposed to

excessive heat such as sunlight, fire or the like.

 Please follow responsible procedures for battery disposal.

 If the power adaptor disconnected from the device, the device will remain

operable as long as the battery has sufficient charge.

 The power adaptor is a CLASS II apparatus with double insulation, and no

external ground is provided.

 Safety symbol explanation:

- The lightning flash with arrowhead symbol within an equilateral triangle is

intended to alert the user to the presence of non-insulated “dangerous

voltage” within the product’s enclosure that may be of sufficient magnitude

to constitute a risk of electric shock.

- To reduce the risk of electric shock, do not remove the cover (or back) as

there are no user-serviceable parts inside. Refer servicing to qualified

personnel.

- The exclamation point within an equilateral triangle is intended to alert the

user to the presence of important operating and maintenance instructions in

the literature accompanying the device.

- Correct Disposal of this product. This marking indicates that this product should not be disposed of with other household waste in the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To dispose of your used device, please use the return and collection systems available in your area or contact the retailer where the product was purchased. They can take this product for safe environmental recycling.

 This equipment should be installed and operated with minimum distance 20cm

between the radiator & your body.

 CE in which countries where the product may be used freely: Germany, UK, Italy,

Spain, Belgium, Netherlands, Portugal, Greece, Ireland, Denmark, Luxembourg,

Luxembourg, Austria, Finland, Sweden, Norway and Iceland. In France, except

the channel 10 through 13, law prohibits the use of other channels.

Listening Cautions

 This product respects the current regulations for limiting the output volume of

consumer audio devices to a safe level. By listening to your device with

headphones or earbuds at high volumes, you run the risk of permanent damage

to your ears. Even if you get used to listening at high volumes and it seems

normal to you, you still risk the possibility of damaging your hearing. Reduce the

volume of your device to a reasonable level to avoid permanent hearing damage.

If you hear ringing in your ears, reduce the volume or shut off your device. This

device has been tested with the supplied earphones. In order to preserve your

hearing, it is advised that you use only the following headphone models: the

earphones supplied with your device, or any other headphones that respect the

current regulations. Other types of headphones may produce higher volume

levels.At full power ,the prolonged listening of the walkman can damage the ear

of the use

 Maximum output voltage<=150mv

 Do not use while operating a motorized vehicle. It may create a traffic hazard and

is illegal in many areas.

 You should use extreme caution or temporarily discontinue use in potentially

hazardous situations created by obstructed hearing.

 Even if your headphones or earphones are the open-air type designed to let you

hear outside sounds, don’t turn up the volume so high that you can’t hear what’s

around you.

 Sound can be deceiving. Over time your hearing “comfort level” adapts to higher

volumes of sound. What sounds “normal” can actually be loud and harmful to

your hearing. Guard against this by setting the volume of your device at a safe

level BEFORE your hearing adapts.

To establish a safe volume level:

a. Start your volume control at a low setting.

b. Slowly increase the sound until you can hear it comfortably and clearly,

and without distortion. Once you have established a comfortable sound

level, leave it there.

This manual may not reflect your actual device’s operation. All information is subject to change

without prior notification. Please follow your actual device’s operational procedures.

Table of Content

Feature Summary................................................................................................5!

Package Content .................................................................................................5!

Buttons & Ports....................................................................................................5!

Installing Memory card ........................................................................................6!

Transferring Files.................................................................................................6!

Turning On/Off.....................................................................................................7!

Home Screen.......................................................................................................8!

Using the Touch Screen ....................................................................................10!

Using the Virtual Keyboard................................................................................10!

Access Internet..................................................................................................11!

Reading E-Books...............................................................................................13!

Playing Music ....................................................................................................25!

Playing Video.....................................................................................................29!

Viewing Photos..................................................................................................31!

File Explorer ......................................................................................................32!

E-mail ................................................................................................................34!

Manage Applications .........................................................................................36!

System Settings.................................................................................................37!

Troubleshooting.................................................................................................38!

Specifications…………………………………………………………………………38

Feature Summary

 Built-in Android Operating System

With the built-in Android OS, your Internet Tablet supports most of the popular third-party applications. Applications are available on the Internet or directly in your Internet Tablet.

 Wi-Fi Connectivity

With the latest Wi-Fi technology, your Internet Tablet can connect you to the Internet wherever you are.

 7-inch Touch Screen

Touch or slide your finger in the screen, the screen responds instantly.

 Built-in G-sensor

Allow the user interface to rotate its orientation to landscape or portrait automatically if the device rotates.

 Entertainment

Allow you to enjoy music, movie or pictures anytime and anywhere.

Package Content

 Main Unit  Stereo earphones  USB cable

Buttons & Ports

Top View

Front View

 AC Adaptor  User Manual  Warranty Card  User Manual

g a

a. USB Port: connect to computer,

USB flash drive, mouse or keyboard through USB cable.

b. HDMI interface (optional):

connects to LCD or monitor devices with HDMI port.

c. Power button: press and hold to

turn on or off the device; briefly press to turn on or off the screen.

d. LCD Display e. Camera Lens (optional) f. Home: Go to the Home Screen. g. Menu: Display an overlay menu. h. SCROLL button: Roll in all ways to

make selection; press to confirm selection.

i. ESC: Return

Bottom View

Side View

Charging Battery

The device has a built-in rechargeable battery. No extra battery installation is required. Just charge the device when it indicates low battery. To charge the battery, connect the device to any standard wall outlet through the AC adaptor via the DC-IN port. It takes about 5 hours to fully charge the battery.

Note:

a. You are strongly recommended to charge the battery immediately when the

device indicates the battery is lower than 15%!

b. You can operate the device even when it is being charged. But for extending the battery

life, you are suggested NOT to use the device when it is in charge. c. You are recommended to charge the battery when you use the device for the first time. d. For maximum performance, lithium-ion batteries need to be used often. If you don’t use

the device often, be sure to recharge the battery at least once per month.

Installing a Memory Card

In addition to the built-in memory, your Internet Tablet features a memory card slot to extend its memory space. You can read e-book, music, image or video files from a MicroSD card directly. To install a memory card, find the card slot at the bottom of the machine, and then insert a MicroSD card into the slot with the correct direction. To access the memory card, enter the Explorer mode and then select the “SD Card” directory.

Transferring Files

Before reading or playing files, make sure your Internet Tablet’s internal memory or the external memory card has media files. If not, transfer files from computer

l" n"

j. Micro-SD Card Slot

k. Earphone Jack l. DC-IN Port: connect to any

standard electronic outlet through AC adaptor.

m. Built-in microphone n. Reset pin hole o. Desktop Stand/ 3G Card

Slot (optional)

to your Internet Tablet. (1) Connect your Internet Tablet to a computer with the supplied USB cable. (2) Once connected, two removable disk drives appear in your computer. One

represents the internal memory of your Internet Tablet, and the other

represents the memory card inserted into your Internet Tablet. Now you can

copy files from or to these disk drives. (3) Once the data transfer completes, drag from the top bar downwards to

display the USB notification message. Choose “Turn off USB Storage” and

then tap on “Turn Off” to disconnect the device from computer.

(4) Remove the player from the PC safely.

a) Left-click the icon at the right bottom corner of the computer desktop. b) Click the pop-up mini-window with message of “Stop the USB Mass

Storage Device – Drive (X)”.

c) Remove the player from the computer.

Turning On/Off

To turn on the device, press and hold the Power button on the unit until you see the boot-up screen. It may take a few minutes to start up the system, please wait before you proceed.

You should see the following locked screen once the device turns on. Before you start using the device, you need to unlock the screen first. To unlock the screen, drag the lock icon upward.

To turn off the device, press and hold the Power button until you see the option “Power Off”, tap on “Power Off” and then tap on “OK”.

Tip: Your Internet Tablet will sleep with the screen off if it stays inactive for a few seconds.

You can briefly press the Power button to turn on the screen and wake it up.

Drag downwards

Home Screen

Indications

a. Home: Go back to the Home Screen wherever you are in the interface. b. Memory Card: the exclamation mark indicates no available memory card,

and it should disappear once a memory card is available.

c. Wi-Fi/ 3G Network d. Battery Charge e. Current Time f. Volume Down: Tap briefly or continuously to decrease the volume. g. Volume Up: Tap briefly or continuously to increase the volume. h. Return: Return to the previous directory. i. Menu: Tap to display an overlay setting menu. j. Address Inputting Area. You can input the website address by tapping

this field. A virtual keyboard should appear. Use the keyboard to type in letters. Tapping will hide the keyboard.

k. Applications Tab: Tap on this icon to reveal all applications installed on

your Internet Tablet (alarm clock, calculator, GlobalTime etc.).

- You can copy the applications onto the Home screen by pressing and holding on their icons.

- You can delete the application from the Home Screen by dragging their icons to the Application Tab. To delete a Home screen item, hold your finger onto it until it is highlighted, then drag it to the Application

a b c d e f g h i

Tab which has become a trash icon.

l. Default shortcuts (“Browser”, “Video Player”, “Audio Player”, etc.)

- Tap on an icon to open the corresponding application.

- Roll the SCROLL button on the unit to select an item.

- You can customize the Home Screen by adding/removing shortcuts

and widgets, changing the wallpaper, etc.

 Customizing the Home screen items

- To add a Home screen item (shortcuts, widgets, folders etc.), tap on the

Menu icon and then select “Add” , or hold your tap on the Home Screen until a pop-up menu displays.

- To move a Home screen item, hold your finger onto it until it is highlighted, then drag it to the desired location, and release it.

 Changing the wallpaper Tap on the Menu icon , and then tap on “Wallpaper”. Tap on one picture and then tap on “Set Wallpaper” to confirm.

 Go to the extended Home Screen Slide your finger horizontally on the screen OR roll the SCROLL button to go to the left or right panel of the extended Home Screen.

You may see the following extended Home Screen in which you have some useful shortcuts. Tapping on these shortcuts can activate their function.

 Changing the System Settings

Tap on the Menu icon , and then tap on “Settings” . Choose a category: “Wireless & Networks”, “Sound & Display”, “Date & Time”, etc. For more

a. Connect to an available Wi-Fi

network

b. Connect to an available 3G

network c. Refresh the media library d. Adjust the screen brightness

a b c d

information on the different settings, see the System Settings section.

Using the Touch Screen

Your Internet Tablet is equipped with a touch screen. Below are a few tips on how to use the touch screen.

Main Touch Screen Actions

 In different applications, you can go back one level in the interface by tapping

on the Back icon (at the top right corner of the screen).

 Wherever you are in the interface, you can go back directly to the Home

Screen by tapping on the Home icon (in the top left corner of the screen).

Other Touch Screen Actions

 When watching a video or listening to music,

you can tap on the progression bar to go directly to a different location in the video or song. You can also use your finger to drag the cursor in the progression bar to another location in the video or song.

 In the different browsers (File, Music, Video,

Photo, etc.), you can drag your finger up and down to scroll the file list up and down.

 In the Web browser, you can scroll up and

down by tapping on the page and dragging it up or down (be careful however not to tap on a link!).

 Tap on the link to open the page.

Using the Virtual Keyboard

Tap on any text input field and the virtual keyboard will pop up. With the virtual keyboard, you can enter website address or any text if required.

Indications

Selecting Input Method

If you have installed more than one input method on your Internet Tablet, you can

select one method by a) holding your tap on the button until the Android

keyboard settings appear; b) choosing “Input Method” and then choosing your desired

a. Caps Lock b. Backspace. c. Number and Characters

/Letter keyboard. d. Space e. Enter

c b

one.

Access Internet

You can surf on the Internet with your slim Internet Tablet. Your Internet Tablet features built-in Wi-Fi technology so that you can access the internet via Wi-Fi network. First of all, you need to configure a Wi-Fi network. For the Wi-Fi configuration procedure to work, you need to be in a Wi-Fi zone that will allow you to connect to it. Every time Your Internet Tablet is in range of a network that you have already configured once, it will attempt to make a connection.

Making WIFI Connection

(1) Go on the Home screen, tap on the Menu icon and then select

“Settings”.

(2) In the “Settings” screen, select “Wireless & Networks”.

(3) If the WiFi is off, tap on the “Wi-Fi” setting to turn it on. Then select “Wi-Fi

settings”. Your Internet Tablet will scan automatically for available WiFi

networks and display them. The list of available networks shows all the

wireless networks in range of your device.

- The list is constantly refreshed automatically.

- When the WiFi is enabled, Your Internet Tablet will connect automatically

to your configured networks when they are in range.

- If Your Internet Tablet finds a network that has never been configured, it

will display a notification icon.

(4) Tap on the network you want to connect to, enter the required network

information (password) and then tap on “Connect”. Your Internet Tablet will

now attempt to establish a connection to that WiFi hot spot with the network

parameters you entered. If the connection is successful, the message

Connected to XXX will appear under the WIFI setting.

Note:

a) The available network list is constantly refreshed automatically. b) When the Wi-Fi is enabled, Your Internet Tablet will connect automatically to your

configured networks when they are in range.

c) If Your Internet Tablet finds a network that has never been configured, it will display a

notification icon.

Advanced Connection

To manually scan for available Wi-Fi networks,

(1) In the “Wi-Fi settings” screen, tap on the Menu icon , and then tap on

“Scan”.

(2) If the Wi-Fi network you want to connect to does not appear in the list, scroll

down the screen, then tap on “Add a Wi-Fi network”. Enter the required

settings, then tap on “Save”.

To access the advanced network parameters (“Regulatory domain”, “IP address”,

etc), tap on the Menu icon , and then tap on “Advanced”. Other parameters

will appear. The required information can be obtained from the person who

manages the network.

Making 3G Network Connection (optional)

(1) Go on the Home screen, tap on the Menu icon and then select

“Settings”.

(2) In the “Settings” screen, select “Wireless & Networks”.

(3) If the 3G network is off, tap on “Mobile Network” to turn it on.

Optionally, you can set up the Access Point manually by a) selecting “Mobile network

Settings”; b) selecting “Access Point Names”; c) pressing MENU button to edit the

APN; d) selecting “New APN”; e) filling in all required parameters. APN, MCC, MNC,

Dial-up and APN type are necessary; f) tapping to save your settings.

Launching the WEB browser

Tap on the “Browser” icon in the Home Screen to launch the WEB browser. If you are already connected to a network, the Web browser will simply open and you can start browsing the Web.

Note: Not all wireless networks offer access to the Internet. Some WiFi networks only link several computers together, without any Internet connection.

Using WEB Browser

 You can scroll up and down the screen by tapping on the page and dragging

it up or down (be careful however not to tap on a link!).

 To open a link, simply tap on it.  You can open several web pages at a time, view them all at once on the

screen, and then tap on one of them to view it in full screen.

 To go back to the previous page that you browsed, tap on the Back icon .  To display the available menu items, tap on the Menu icon .  To go back directly to the Home screen, tap on the Home icon .  Depending on where you are in the web browser, holding down on an item

will give you access to more options.

 To fill in a text field, tap in the field, then use the virtual keyboard to type in the

required text.

WEB Browser Menu Items

When you are viewing page, you can tap on the menu icon to display the menu items.

New window

Allows you to open new windows.

Bookmarks

Will open the “Bookmarks” manager. You will see three tabs:

“Bookmarks”, “Most visited”, and “History”.

“Bookmarks” show you a list of bookmarks. Just tap on one of

them to open it in the current window. Holding down on a

bookmark will give you access to several options (you will be

able to edit it, rename it, delete it, etc.). You can also use the

Menu icon which will allow you to bookmark the

last-viewed page.

“Most visited” and “History” allow you to access your “Most

visited” sites and your “History”. In the “History” tab, the Menu

icon allows you to clear the history.

indows

When you have several windows currently opened, tap on

“Windows” to display them all at once on the screen. Just tap

on one of the small windows to view it in full screen, or tap on

the Close icon in the small window to close the window.

efresh/ Stop

“Stop” will stop loading the web page, if it is currently loading.

“Refresh” will refresh the current web page, if it has stopped

orward

Will go to the next page that you browsed.

ore

Will give you access to other options (“Find on page”, “Select

text”, “Page info”, “Downloads”, “Settings” etc.).

Reading eBooks

Transfer eBooks from Computer

Before reading, you need to transfer or download eBooks to the device. You can copy

eBooks from your computer’s local drive to the device by USB connection (see the

“Transferring files” section mentioned before).

Note: Make sure your e-books are in format of PDF, EPUB, TXT, FB2, RTF or PDB supported by the device.

Download eBooks with Adobe Digital Editions

The Adobe Digital Edition application allows you download e-books protected by DRM

to your Internet Tablet.

+ 28 hidden pages
