eMachines E216T5W User Manual

Flat Panel Monitor
User Guide

Contents

Using Your eMachines Flat-Panel Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Unpacking the monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Connecting the monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Attaching the base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Connecting video and audio inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Connecting power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Adjusting monitor tilt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Starting the monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Adjusting monitor settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Monitor buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

On-screen display options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Using the Direct Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Changing Windows screen settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Video modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Unknown video modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Power management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

ENERGY STAR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Energy declaration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Maintaining . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

No power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

No picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Display colors are wrong . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Picture has shadows or “ghosts” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Color is not uniform . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Image is not sized or centered correctly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

The image remains after switching off the monitor . . . . . . . . . . . . . . . . . . .15

The image is unstable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

The message “No Input Signal” appears on the screen . . . . . . . . . . . . . . . . .15

The monitor has pixels that are alw ays dark or too bright . . . . . . . . . . . . .15

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Safety, Regulatory, and Legal Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Recycling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

i

Contents

ii

Using Your eMac hines

Flat -P anel Monitor

• Unpacking the monit or

• Connecting t he monitor

• Starting the monitor

• Adjusting monitor settings

• Power management

• Maintaining

• Troubleshooting

• Specifications

1

Using Your eMachines Flat-Panel Monitor

Unpacking t he monitor

Your monitor box should contain the following items:

• Monitor (with neck attached)

• Base

• This Us er Gu ide

• VGA c ab l e

• Audio cab le

• Powe r c o rd

If you are mis s ing an y items, call C u st omer Car e . F or telephone numbers, se e t he labe l on t he bac k
of your monitor.

Connec ting the monit or

To set up the monitor, first atta ch the base, then m ake your cabl e con nections .

Attachi ng the bas e

To attach the base:

• Place the monitor base on a t able top, then slide th e mon itor neck down onto the base until

it clicks into place.

2

www.emachines.com

Connec ting vi deo and audio inputs

To connect video and audio inputs to your monitor:

1 Position your computer and the monitor so you can reach the back of each.
2 Connect the VGA video cable to the VGA video connector under the back of the display.

Power o utl et

Powe r cable

3 Make sure that your computer is turned off, then connect the other end of the video cable

to the matching video port on the back of your computer.

4 Connect the sp eaker (green) ca ble fro m the speaker jac k on the mon i tor t o your comp u ter’s

audio out jack.

Video cable

Audio cable

Connec ting pow er

To connect power:

1 Position your monitor so you can reac h t he back, then connect the power cord to the power

connector under the back of the monitor.

2 Plug the power cord into a correctly grounded power outlet. We recommend using a surge

protector to protect your monitor from voltage spikes.

Adjusting monit or tilt

To adjust your monitor’s tilt:

• Adjust th e til t of the moni tor for your viewing c omfort.

3

Using Your eMachines Flat-Panel Monitor

Ergonomic guidelines

The recommen ded sc reen positi oning is ba sed up on the f o llow ing guidel ine s. The s e guideline s ar e
based on available scientific literature and published standards.

Screen heig ht

The recommended screen height for displays (except in special circumstances, such as for bifocal
use) is that the top of the display should be set at or slightly below (about 1 inch or 25mm) your
eye level while you are sitting in a comfortable working posture. This guideline places the center
of the screen at an ideal 15° to 20° viewing angle for most desktop displays.

Screen tilt

The screen should be tilted so your line of sight is perpendicular to the screen. This angle creates
the m ost co ns iste nt viewi ng di st anc e w hen sc an nin g fro m th e to p of t he scree n to th e bo ttom .
You may need to adjust lighting to avoid screen glare when the screen is tilted upward.

Screen distance from user

The screen should first be placed at arm’s length from the user, then adjusted back and forth to
suit individual preference.

Starting the monit or

To s t a rt t h e m o n i to r :

1 Press the po wer bu tton on the fro nt of you r m on ito r. The p owe r L ED tu rn s fro m o ra ng e to

green.

Power butto n

2 Tu r n on y ou r c om put e r.

After your computer is running, the po wer LED (centered abo ve the monitor but t ons) should
be green. Allow about 10seconds for the display image to appear. If the power LED is not
green or you do not see a display image, check the connections. For more troubleshooting
information, see “Troubleshooting” on page13.

3 Adjust the tilt of the mon itor for the best viewing angl e.

Important

When adjusting the monitor settings, always press the Auto button b efore
entering the OSD. T his will automaticall y adjust the displa y image to the ideal settings
for the current screen resolution.

4

4 After you see the Windows desktop, press the Auto button (the second button from the

righ t o n th e fro nt of the mo ni tor ) to auto ma ti cal ly a dj ust you r di sp lay im age to t he id eal
settings. See “Monitor buttons” on page5.

5 Use the on-screen display (OSD) to adjust other monitor settings. For more information, see

“Adjusting monitor settings” on page5.

www.emachines.com

Adjusting monit or set tings

Use the monitor controls (locat ed on t he monitor itself) and computer contr ols (acces sible thr ough
Windows) to adjust the display image. For more information about computer controls, see

“Changing Windows screen settings” on page 10.

Monitor but tons

This monitor features an on-screen display (OSD) that lets you adjust contrast, brightness, and
other settings for the monitor. The monitor saves changes you make to the settings, even if you
turn off the monitor. (The appearance of your monitor may vary from that shown.)

Power L ED

– (Minus)
button

+ (Plus)
button

Menu
button

Mute
button

Auto
button

Power
button

• – (Minus) button

OSD active: Press to move to the next menu and decrease setting levels.
OSD inactive: Press to activate the Audio menu.

• + (Plus) button

OSD active: Press to move to the previous menu and increase setting levels.
OSD inactive: Press to activate the Audio menu.

• Menu button

Press to open a menu, select an item, or close the menu.

• Mute button

Press to mute the sound. Press again to restore the sound.

• Auto button

Press to automatically fine-tune the image quality.

• Power button

Press to turn the monitor on or off.

• Powe r LE D

Powered on = Green
Power saving mode = Orange

5

On-scr een display optio ns

Adjusti ng OSD settin gs

To adjust the OSD settings:

1 Press the Auto button. The display image is automatically adjusted to the ideal settings for

your current screen resolutio n.

2 Press the Menu button. The OSD opens.
3 Press the + or – button to h ig hli gh t a sett in g, the n p ress the Menu button to o pe n t he

selected menu or setting.

4 Press the + or – button to a dj ust the sett in g or ch ang e t he o pti on .
5 Select the EXIT icon, the n press th e Menu b utton to ret urn to a top l evel me nu.
6 Select the EXIT icon, the n press th e Menu b utto n to exi t t he OSD.

OSD menus

OSD Menu Description

Using Your eMachines Flat-Panel Monitor

Main menu

Management menu

Auto—Automatically adjusts your monitor to its

optimum settings.

Management—Opens the Management menu,

where you can adjust brightness, contrast,
horizontal position, and vertical position.

Clock/Phase—Opens the Clock/Phase menu,

where you can adjust the clock and phase
settings o f the moni tor.

Color—Opens the Color menu, where you can

adjust color temperature, the sRGB, and custom
color.

OSD—Opens the OSD menu, where you can set

the horizontal and vertical position of the
OSD menus.

Factory Recall—Resets the monitor to its factory

settings.

Language—Opens the Language menu, where

you can select the language of the OSD menus.
Settings take effect immediately.

EXIT—Exits the submenu to a top level menu.

Exits the OSD menu system.

Brightness—Adjusts the amount of light in the

darkest portion of the picture. Use the lowest
brightness setting you are comfortable with to
maxim ize the l ife of th e mo nitor backl igh ts.
You may need to readjust brightness after the
monitor warms up .

Contrast—Adjusts the level of white between the

lightest and da rkest portions of an i mage.

H.Position—Adjusts the horizontal position of the

display on the monitor.

V.Pos it io n—Adj usts the vert ical posi tion o f the

display on the monitor.

Customer Scaling—Adjusts the aspect ratio of the

display . Selec t Fill to Screen or Fill to Aspect Ratio.

EXIT—Returns to top level menu.

6

www.emachines.com

OSD Menu Description

Clock/Phase menu

Color menu

Custom Color submenu

Clock—Minimizes any vertical bars or stripes visible on
the screen background. The horizontal screen size will
also change.
Phase—Minimize s an y h or izontal dist or tion and c le ars or
sharpens the displayed characters.

EXIT—Returns to top level menu.

Color Temp—Customizes the color temperature of the

display. Select Cool, Neutral, sRGB, and Custom Color.

Exit—Returns to top level menu.

Custom Color—Changes the levels of the three primary

colors (red, gr een, and blue) in the dis pla y to help ac hie v e
a more natural appearance in graphic images and a
closer color match between the display and printer.

OSD Display menu

H.Position—Adjusts the horizontal position of the OSD
menus on the monitor.
V.Position—Adjusts the vertical position of the OSD
menus on the monitor.
Exit—Returns to top level menu.

7

Using Your eMachines Flat-Panel Monitor

OSD Menu Description

Factory R ecall

Language menu

Using the Direct Ke ys

While the OSD Mai n Menu is inactive, you can use three direct fun ction keys to change settings.

Press the + or – button to highlight the Factory icon

, then press the Menu button to reset the monitor

to fact or y d efa ul t s ett in gs .

Press the + or – button to highlight the OSD menu
language of your choice. then press the Menu button to
select it. Settings take effect immediately.

Auto setup by direct k ey

Use auto setup whenever you apply a new video mode or change the refresh rate. While auto
setup is running, you should have a stable image displayed on the screen. Do not move items
around the screen, play games, or view video during auto setup.

After you have executed auto setup for a particular mode, the display will store the new values
in its permanent memory.

To use auto setup by direct key:

1 With no OSD menu open, press the Auto butto n. This st art s t he auto setu p.

The image will change color and appear to jitter during auto setup. After auto setup is
complete, you are asked whether the image is OK.

8

www.emachines.com

2 If the image looks correct, choose Yes. The OSD will close automatically.

-OR­If the imag e req ui res furth e r a dj ust me n t, cho ose No. The Phase bar opens to let you ad just

the setting man ually.

3 Adjust the phase by pressing the + or – buttons. When all text appears well focused and

there is no instability in the image, press Menu to end the adjustment and close the OSD
menu.

Audio setup by direct ke y

To adjust the volume by direct key:

1 With no OSD menu open, press the + or – buttons. The Volume bar opens.

2 Press the + or – buttons one or more times to set the volume to a comfortable level.

9

Using Your eMachines Flat-Panel Monitor

Changing Windo ws s creen s ettings

Color depth and screen resolution are two of the most basic monitor settings you may need to
change to suit your needs.

Color depth is the number of colors your computer uses to display images on your monitor. Most
images look best displayed with the maximum number of colors available. If the color in your
images seems “false” or “jump y,” especially af t er y ou ha v e pla yed a game or run a video-intensive
program, check the color depth setting and return it to the highest color setting, if necessary.

Screen resol uti on is the number of pixels (individual colored dots) your computer uses to display
images on your monitor. The higher the resol ution, the more information and screen components
(such as icons and menu bars) can be displayed on the monitor.

Help

For more information about adjusting the screen, click Start, then click Help and

Support. Type adjusting monitor se ttings in the Search Help box, then press E

To change the color depth and screen resolution in WindowsVista

1 Click (Start), Control Panel, then under Appearance and Personali zation, c lick Adjust

Screen Resolution. The Display Settings dialog box opens.

Shortcut

You can also right-click on your Windows desktop, then click Personalize.

2 To change the color depth, click the Colors list, then click the color d epth you want.

Color depth settings:

• Low (8-bit) = 256 colors

• Medium (16-bit) = 65,500 colors

• Highest (32-bit) = 16,700,000 colors
3 To change the screen resolution, drag the Resolution slider to the size you prefer.
4 Click Apply. If the new settings do not look right, click No. If the new settings make the

screen illegible and you cannot click No, the settings return to their previous values after
several seconds.

5 Click OK, then click Yes to save yo ur cha ng es.

NTER.

®

:

10

To change the color depth and screen resolution in WindowsXP:

1 Click Start, then click Control Panel. The Contro l Panel opens. If your Control Panel is in

Category View, click Appearance and Themes.

Shortcut

You can also right-click on your Windows desktop, then click Properties.

2 Click Display. The Display P ropert ies dialog box opens.
3 Click the Settings tab.
4 To change the color depth, click the arrow button to open the Color quali ty list, then click

the color depth you want.
Color quality settings:

• Low (8-bit) = 256 colors

• Medium (16-bit) = 65,500 colors

• Highest (32-bit) = 16,700,000 colors
5 To change the screen resolution, drag the Screen resolution slider to the size you prefer.

The optimum resolution for your display is 1680 × 1050.

6 Click OK.

Video mo des

www.emachines.com

Your monitor supports several video modes. If you do not use the best mode for the monitor,
the display image may look slightly “fuzzy.”

Mode Mode name and

resolution

1 640 × 350 31.469 59.94
2 640 × 480 37.50 75.00
3 720× 400 31.47 70.08
4 800 × 600 37.88 60.32
5 800 × 600 46.88 75.00
6 832 × 624 49.72 74.55
7 1024 × 768 48.3 6 60.00
8 1024 × 768 60.02 75.03
9 1152 × 720 44.86 60.00
10 1152× 870 68.68 75.06
11 1152× 900 61.80 65.96
12 1280 × 768 47.3 96 60.00
13 1280 × 960 60.00 60.00
14 1280 × 1024 63.98 60.02

Horizontal
freq uen cy ( kHz )

Vertical
freq uen cy (H z)

15 1280 × 1024 79.98 75.02
16 1440 × 900 55.94 59.89
17 1600 × 1000 61.648 60.00
18 1680×1050 65.29 60.00

Unknow n video modes

Like all ot her monitors, the LCD monitor is designed t o work w ith standar d v ideo modes. Ho wever,
not all video/graphic cards use only standard display modes. Your LCD monitor uses
state-of-the-art technology, which is designed to synchronize to any display mode. We
recommend choosing one of the supported modes listed above. If you choose an unknown mode,
you will need to manually adju st the c lock, phas e , and image position. If you mu st use an unknow n
mode, you can run Auto Adjust first. If Auto Adjust does not provide adequate image adjustment,
then you must manually adjust the clock, phase, horizontal position, and vertical position.

11

Using Your eMachines Flat-Panel Monitor

P ower man agement

ENERG Y STAR

As an ENERG Y STAR® Partner, eMachines has det ermined that this pr oduct meets the ENER G Y STAR
guidelines for energy efficiency.

This monitor complies with the EPA’s International ENERGY STAR Program, which is a program
designed to encourage manufactur ers of computer equipment to build cir cuitry into t heir products
to reduce energy consumption during time of non-use.

Energy declar ation

When connected to a computer that supports the VESA Display Power Management Signaling
(DPMS) Protocol, the monitor can conserve significant energy by reducing power consumption
during periods of non-use. When your computer goes into the energy saving mode, the monitor
enters the ActiveOff mode (sleep) . In the ActiveOff mode the Power LED turns orange.

Use these conventions and the power can be reduced to the following levels:

VESA state LED indicator Power co nsu mp tio n

On Green < 55 W
ActiveOff Orange < 2W

To “wake” the monitor when it is in Active Off mode, move the mouse or press any keyboard key.
Access the power management options in the Control Panel to change the period of time after

which the monitor enters these low power states.

12

Maintaining

To keep the monitor in optimal working order:

• Do not block the ventilation holes.

• Do n ot exp ose the mo nito r to ra in o r u se n ea r wa ter.

• Keep th e m on itor away fr om rad iato rs or he at ven ts.

• Keep the monitor out of direct sunlight.

Caution

Do not use any type of abrasive pad or glass cleaner. You will permanently

scratch the screen.

• To clean the monitor, use a soft cloth slightly moistened with water only. Wipe the cabinet,

screen, and controls.

Troubleshooting

Caution

Immediatel y unplug t he monit or fr om th e power outlet and r ef er servic ing t o qualifie d

service personnel if any of the following occurs:

• The power supply cord or plug is damaged.

• Li qu id has be en s p ill ed or ob ject s h ave fa lle n into the mo ni tor.

• The m onitor h as been e xpose d to rain or water.

• The monitor has been dropped or the cabinet damaged.

www.emachines.com

No power

No picture

Important

Make sure that the monitor has warmed up for approximately 30 minutes before

making any judgments about the picture quality.

If you have problems with the monitor, the information in this troubleshooting section may help
you solve them.

• Make sure that the power cord is connected correctly to both the back of the monitor and

the wall outle t. F or mor e information ab out conne c ting t he po w er cord, s ee “C onnec ting the

monitor” on page 2.

• Make sure that the power cord is connected correctly to both the back of the monitor and

the wall outle t. F or mor e information ab out conne c ting t he po w er cord, s ee “C onnec ting the

monitor” on page 2.

• Make s ure tha t th e vi de o c ab le i s c on necte d se cure ly to the ba ck o f th e m on itor an d

computer. For more information about connecting the video cable, see “Connecting the

monitor” on page 2.

• Make s ure th at the mo nito r i s t urn ed on .

• If you have the monitor connected to your notebook’s video port, you have two options:

• If your notebook supports dual displays, you can use both your notebook’s display and

this monitor in extended desktop multi-monitor mode. See Windows Help to learn how
to enable multiple monitors.

• You can also use this monitor as your primary monitor and not use the notebook’s

screen. Notebook computers typically have an F
between your notebook’s display, an externally attached display, and both at the same
time. See your notebook’s user guide for more information.

N key combination that lets you toggle

13

• If the power LED is orange :

• Make sure that your computer is turned on.

• Move the mouse or press any key on the keyboard to bring the monitor out of sleep

mode.

• Restart your computer with the monitor turned on.

• Make sure that the video cable is not damaged.

• Check the end of the video cable for any pins that might be bent or pushed in.

• Turn off the monitor and unplug the video cable from the back of your computer. Turn the

moni tor ba ck o n a nd wai t for ten sec on ds. If th e m oni tor is fun cti on ing co rre ctly, a “No
Signal” message appears. For more information about connecting the video cable, see

“Connecting the monitor” on page 2.

Display colors ar e wrong

• Press the Menu button, then the Auto bu tto n to a uto m a t i ca l ly a dj u st th e d i s pl ay i ma g e to

the ide al setting s.

• Restart your computer with the monitor turned on.

• Make s ure tha t th e vi de o ca bl e is co nn ected secu rely to th e b ack of the mo nito r a nd your

computer. For more information about connecting the video cable, see “Connecting the

monitor” on page 2.

• Make sure that the video cable is not damaged.

• Check the end of the video cable for any pins that might be bent or pushed in.

Using Your eMachines Flat-Panel Monitor

Pic ture has shado ws or “ gho sts”

• Press the Menu button, then the Auto butto n to a u tom a t i c al ly a d j us t th e d i s p l ay i m a ge to

the ide al setting s.

• Remove any extens ion cab les o r switchb oxes.

• Make s ure tha t th e vi de o ca bl e is co nn ected secu rely to th e b ack of the mo nito r a nd your

computer. For more information about connecting the video cable, see “Connecting the

monitor” on page 2.

• Make sure that the video cable is not damaged.

• Check the end of the video cable for any pins that might be bent or pushed in.

• Make sure that your monit or connection is using the VGA cable that came with y our monitor.

Color is not unif or m

• Press the Menu button, then the Auto butto n to a u tom a t i c al ly a d j us t th e d i s p l ay i m a ge to

the ide al setting s.

• Make s ure th at th e m on ito r wa rms up for a t l eas t 30 min utes be fore m ak in g a fina l

judgment about color uniformity or brightness.

Image is not siz ed or cent ered correc tly

• Press the Menu button, then the Auto butto n to a u tom a t i c al ly a d j us t th e d i s p l ay i m a ge to

the ide al setting s.

• Use the position controls to adjust the image. For instructions on how to adjust the display

image position, see “Adjusting monitor settings” on page 5 .

14

www.emachines.com

The image re mains aft er swit ching of f the monit or

• Image persistence is when a “ghost” of an image remains on the screen, even after

switchi ng th e mo ni tor off. To al levi ate ima ge pe rs is tenc e, t urn off the mo ni tor for a s l ong
as an im age was d isp layed .

If, for example, the image was on the monitor for one hour and a “ghost” remains, you
should switch off the monitor for at least one hour to erase the image.

• We recommend the use of a screen saver whenever the screen is idle.

The image is unstable

• Set your computer to a supported video mode, preferably 1680 x 1050 at 60 Hz.

• Try plugging the monitor into a different, earthed (grounded), power outlet, preferably on

a different circuit.

• Check the display settings of your computer. Make sure that a supported mode is selected.

• Check the display specifications section for more information.

The mes sage “No Input Signal” appears on the s creen

• Make sure that the video cab le is corre ctly plu gg ed into the ana log vid eo p ort on th e b ack

of the monitor.

• Make sure that the other end is correctly plugged into the VGA port of your computer.

The monit or has pi xels that are alw a ys dark or t oo bright

• This condition is normal and inherent in the TFT technology used in active-matrix LCD

screens. eMachines’ inspection standards keep these to a minimum. If you feel these pixels
are unacceptably numerous or dense on your display, contact eMachines Customer Care
to identify whether a repair or replacement is justified based on the number of pixels
affected.

15

Specif ications

Specifications are subject to change without notice or obligation. Many products for eMachines
are custom engineered by our suppliers to eMachines specifications and may vary from similarly
marketed products.

Using Your eMachines Flat-Panel Monitor

Panel s ize
Panel t ype
Viewable image size
Pixel resolution
Pixel pitc h
Tex t m o de
Aspect ratio
Horizontal frequency
Verti cal refr esh rate
Tilt
Colors
OSD languages
Connections and inputs

Cables

21.6 inches
TFT LCD

21.6-inch diagonal
1680 × 1050 (60 Hz )

0.0109× 0.0109 inches (0.27675 mm × 0.27675 mm)
720× 400
16:10
30 to 81 KHz
56 to 76 H z

-5° to 20°

16.2 million
English, French, Spanish, Italian, Japanese
Analog (VGA): 15-pin mini d-sub VGA

Audio: mini-plug
AC pow er

15-pin mini d-sub analog VGA (included)
Audio cable with mini-plug

16

Audio power output
Speaker (R/L)
Power consumption
Power input
Temperature

Altitude

Relative humidity
Power ma nag em ent
Certifications
Dimensions

Weight

2 W/channel @ PC 1 Vrms
2 W/16 ohm speaker
Normal operation: <55W
100-240 VAC, 50/60Hz
Operating: 41° to 104°F (5° to 40°C)

Non-operating: -4° to 140°F (-20° to +60°C)
Operating: 0 to 6561.68 feet (0 to 2000 m)

Non-operating: 0 to 40,000 feet (0 to 12192 m)
20% to 85% (non-condensing)

Energy Star
UL, CSA, FCC Class B

17.18× 20.79 × 8.09 inches (436.6× 526.8× 205.5 mm)
with bas ic sta nd

14.5 lb (6.6 kg)

®

Saf et y , R egulat ory , and

• Important safety information

• Envir onmental infor mation

• Regulatory compliance statements

• Notices

Legal Notices

17

Safety, Regulatory, and Legal Notices

Important saf ety inf ormation

Warning

Alway s follow the se inst ruc tion s t o help gu ar d aga inst pe rsonal i njury and da mage t o you r Gat e w a y product.

Warning

Do not use Gat e w ay produc ts in ar ea s c la s si fie d a s ha zar do u s locat ions. Suc h ar ea s include patient car e ar ea s

of medical and dental facilities, oxygen-laden environments, or industrial facilities.

Your Gate wa y product is designed and tested t o meet the latest standards for safety of information technology equipment.
However, to ensure safe use of this product, it is important that the safety instructions marked on the product and in the
documentation are followed.

Setting up your syst em

■

Read and follow all instructions marked on the pr oduct and in the documentation before you operat e your sy stem. R etain all
safety and operating instructions for future u se.

■

Do not us e th is pr odu ct ne ar w at er o r a heat sou rce suc h as a ra diat or.

■

Set up the system on a stable work surfa ce.

■

The product should only be operated from the type of power source indicated on the rating label.

■

If your product has a voltage select or swit ch, mak e sure that the sw itc h is in the proper position for y our area. The voltage
selector swit ch is s et at the fac tory to the correc t voltage.

■

Openings in the monitor case are provided f or ventilation. Do not block or cover t hese openings. Make sure y ou prov ide adequate
space, at least 6 inches (1 5cm), around the system for ventilation when you set up your work area. Never inser t objects of any
kind into the monitor ventilation openings.

■

Some products are equipped with a three-wire power cord to make sure that the product is properly grounded when in use. The
plug on this cord will only fit into a grounding-type outlet. This is a saf ety f eature. If y ou are unable to insert t he plug into an
outlet, contact an electrician to install the appropriat e outlet.

■

If you use an extension cord with this system, make sure that the total ampere rating on the products plugged into the extension
cord does not exceed the extension cord ampere rating.

Care during use

Warning

To prevent electric shock, never remove the cover. No user serviceable parts inside. Refer servicing to

qualified service personnel.

■

Do not walk on the power cord or allow anything to rest on it.

■

Do not spill anything on the system. Th e best wa y to av oid spills is to a v oid eating and drinking near your system.

■

Do not ex pos e t he mon it or t o r ain or us e ne ar w at er. If the monitor d oes get exp os ed t o m oistur e , unpl ug it an d allo w it to dry for
24 hours. Call Gateway Customer Care for advice on whether the monitor is safe to turn back on.

■

When the monitor is turned off, a small amount of electrical curr ent still flow s through the monitor. To avoid electrical shock,
always unplug all power cables and modem cables from the wall outlets before cleaning the system.

■

Unplug the system fr om the wall outlet and ref er servic ing to qualified personnel if:

■

The power cord or plug is damaged.

■

Liquid has been spilled into the system.

■

The system does not operate pr operly when the operating instructions are follo wed.

■

The system wa s dropped or the cabinet is damaged.

■

The system perf ormance changes.

Replacement parts and accessories

Use only replacement parts and accessories recommended by Gateway.

18

www.emachines.com

Env ironmental inf ormation

Recycling

Mercury Warning

Lamp(s) inside this product contain mercury and must be recycled or disposed of according to local, state,
or federal laws.

Hg

The product you have purchased contains extract ed natural resources t hat have been used in the manufacturing process. This
product may contain substances known to be hazardous to the environment or to human health.

To pre vent release s of harmful substances into the environment and to maximize the use of our natural resources, Gate wa y provides
the following information on how you can responsibly recycle or reu se most of the materials in your “end of lif e” product.

Waste Electrical and Electronic Equipment (commonly known as WEEE) should never be disposed of in the municipal waste
stream (residential garbage collection). The “Crossed-Out Waste Bin” label aff ixed to t his product is y our reminder to
dispose of your “end of life” product properl y .

Substances such as glass, plastics, and certain chemical compounds are highly recoverable , recy clable, and reus able. You
can do y our p art f or t he e nv i ronm ent b y following the se s impl e st ep s:

■

When your electrical or electronic equipment is no longer useful to you, “take it back ” to your local or regional w ast e collection
administration for recycling.

■

In some cases, your “end of life” pr oduct may be “traded in” for cr edit towa rds the purchase of ne w Gatewa y equipment. Call
Gateway t o see if this pr ogram is a vailable in your ar ea.

■

If you need further assistance in recycling, reusing, or trading in your “end of life” product, you may contact us at the Customer
Care number listed in your product’s us er guide and we will be glad to help you with y our eff ort.

Finally, we suggest that you practice other environmentally friendl y actions by understanding and using the energy-saving features
of this product (where applicable), recycling the inner and outer packaging (including shipping containers) this product was delivered
in, and by disposing of or recycling used batt eries properl y .

With your help, we can reduce the amount of natural resources needed to produce electrical and electronic equipment, minimize the
use of landfills for the disposal of “end of life” products, and generally improv e our quality of life by ensuring that potentially
hazardous substances are not released into the en vironment and are disposed of properly .

For additional recycling inf ormation specific t o your area, pleas e go to www.gateway.com/recycle

.

Re gulatory compliance statements

United State s of America

Federal Communications Commission (FCC) Unint entional emitter per FCC P art 15

This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These
limits are designed to provide rea sonable protec tion against harmful interference in a r esidential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may caus e
harmful interference to r adio or telev ision reception. Howe ver, there is no guarantee that int erfer ence will not occur in a particular
installation. If this equipment does cause interference t o radio and tele vision reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the f ollowing measures:

■

Reorient or relocate the r eceiv ing ante nna

■

Increase the separation between the equipment and receiver

■

Connect the equipment to an outlet on a different circuit from that to which the receiver is connected

■

Consult the dealer or an experienced radio/TV technician for help.

Compliance Accessories: The accessories associated with this equipment are: shielded video cable. These accessories are required to
be used in order to ensure compliance with FCC rules.

19

Canada

Safety, Regulatory, and Legal Notices

FCC declar ation of conf ormity

Responsible party:
Gateway, Inc.

7565 Irvine Center Drive
Irvine, CA 926 18USA

This device complies with Part15 of the FCC Rules. Operation of this de vice is subject t o the f ollowing two conditions: ( 1 ) this dev ice
may not caus e harmfu l inter fe rence , and (2) t his de vice mu st accept an y interf erence recei ved, including inter ference that ma y cause
undesired operation.

Caution

Changes or m odifi cations not e xpressly approved by Gateway could void the FCC com plianc e and negate

your authority to operate the product.

California Proposition65 warning

This product contains chemicals known to the State of California to cause cancer, birth defects, and/or other
reproductive harm. For additional information regarding this product warning, go to

www.gateway.com/prop65

.

Industry Canada (IC) Unintentional emitter per ICES-003

This digital apparatus does not exceed the Clas sB limits for radio noise emissions from digital apparatus as set out in the radio
interference regulations of Industry Canada.

Le pré se nt appa re il numé riqu e n’é met pa s de br uits radi oé lec tri que s dé pa ssa nt le s l imit es appl icabl es a ux appar ei ls nu mér iqu es de
ClasseB prescrites dans le règlement sur le brouillage radioélectrique édicté par Industrie Canada.

Notices

© 2007 Gate wa y , Inc.
All rights reserved.

Gateway, Inc.
7565 Irvine Center Drive
Irvine, CA 926 1 8 U SA
All Rights Reserved

This publication is protected b y copyr ight and all rights are reserved. No part of it may be r eproduced or transmitte d by any means or
in any form, without prior consent in wr iting from Gat ew ay .

The information in this manual has been carefully check ed and is believ ed to be accur ate . Howe ver, changes are made periodically.
These changes are incorporated in new er publication editions. Gatewa y may impro ve and/ or change products des cribed in this
publication at any time. Due to continuing system improv ements, Gatew ay is not re sponsible for inaccurat e inf ormation which may
appear in this manual. For the latest product updates, consult the Gateway Web site at www.gateway.com
be liable for direct, indirec t, special, exemplary , inc idental, or consequential damages resulting from any defec t or omission in this
manual, even if advised of t he possibility of such damages.

In the interest of continued product development, Gateway res erves the right to mak e improvements in this manual and the
products it describes at an y time, wit hout notices or obligation.

T rademark acknow ledgments

Gatew a y and eM achin es are tr adema rks or r egist er ed tr ademark s of Gat e w ay, Inc. in the United St ate s and othe r count ries . All o ther
brands and product names are trademarks or registered trademarks of their respective companies.

. In no event will Gateway

20

MAN E216T5W USR GDE R1 8/07
