Elpas Solutions 5 PBB00433 User Manual

Elpas3 Personnel Identity Badge

P/Ns: 5-PBB00433, 5-PBB00433-1, 5-PBB00433-2, 5-PBB00433-3, 5-PBB00433-5, 5-PBB00433-7, 5-

PBB00433-E, 5-PBB00433-G, 5-PBB00433-K, 5-PBB01433-E

Introduction

This Guide provides basic instructions for the successful usage of the Personnel Identity Badge

CAUTION! Reasonable effort was made to ensure that the specifications and other information in this guide are accurate and complete at the time of its

publication. Nonetheless, all information contained in this document is subject to change at any time without prior notice. Any modifications to this equipment

without prior written consent of Elpas Solutions Ltd. will void all warranties including the pertinent regulatory certifications and as such revoke your authority to
operate this product. Furthermore unauthorized modifications may also result in damage to this device and may cause a safety hazard to the users.

Product Description

The Elpas Personnel Identity Badge is a supervised triple-tech, 2-

way, Active RFID Tag that provides wireless real-time monitoring

and tracking of workers that may be at-risk of workplace related

attacks or injuries.

The unique form factor of the

badge allows it to serve as a

photo ID personnel badge. When

you insert it into its

corresponding card holder (sold

separately), you can bundle the

badge with ISO standard

credentials and wear it horizontally (landscape format) or

vertically (portrait format). Additionally, the badge can also serve

as a proximity ID key with legacy access control installations.

The badge emits EMI safe RF (433MHz) receives IR (800nm)

data messages and then, and receives Ack (Acknowledge) RF

messages that confirm transmission success. This data enables

real-time sub-room level location awareness of the protected

employee, which Elpas Safety, Security & Visibility Solutions or

other management and building access control systems can use.

The badge also features dual call-button duress alerting and an

onboard LF (125 KHz) receiver that enables instantaneous near-

exit location detection for staff/patient/guest escort to administer

procedures in addition to triggering near-exit access control alert

response protocols.

The Personnel Identity Badge is IP66 rated, cleanable with

alcohol based disinfectants and is powered by a field-replaceable
lithium battery

.

.

Supported Event Transmissions

Personnel Identity Badges supports LF, Battery, Motion,

Motionless, Exit from LF and two discrete Button Press supervision

events; designated B1 & B2:

Button Press Events

Upon a button press, an RF

message is transmitted (about

1ms in duration) and receives

an RF Ack message when the

system receives the

transmission. Without Ack, the

badge retries to transmit four more times, 50ms apart prior to

deactivation B1=1 and B2=1.

When the buttons are released, B1=0 and B2=0. Another RF

message is transmitted until it receives the Ack message or tries

five more times. In the steady state (no button press / button

release) B1=0 and B2=0.

IMPORTANT: The badge does not support the transmission of two
simultaneous button press supervision events.

Event Transmission Rates in LF Zones

Moving Badge

LF Response Time: Onboard LF receiver polls every 250ms to

check if the badge is in an LF zone.

Transmission Rate: One RF supervision transmission (about 1ms

in duration). If does not receive Ack transmission, retries four times,

50ms apart.

Transmitted Message Type: RF Data Message includes ID code of

LF Beacon. Motion bit, M=1.

User Guide

Motionless Badge

LF Response Time: Onboard LF receiver polls every 250ms to

check if the badge is in an LF zone

Transmission Rate: One RF supervision transmission (about 1ms

in duration). If does not receive Ack transmission, retries four times,

50ms apart.

Transmitted Message Type: RF Data Message includes ID code of

LF Beacon. Motion bit, M=0

.

www.elpas.com

Page 1 of 4

V3/Jan 2016

Elpas3 Personnel Identity Badge – User Guide

Badge Activation - Initial Usage

1. Orient the badge back-cover side

up. Then press & hold down the

larger of two emergency call

buttons for

at least 6 seconds

2. If the activation process was

successful the red LED on the

front of the badge will illuminate
for about six seconds

.

Attaching a Paper Photo ID

1. Ensure that the photo ID paper

label is trimmed so that it lies

flatly (picture/text side up) in

the recessed area on the front

of the badge.

2. Peel off the protective

layer on the front and

rear of the label cover

(P/T: 5-PBA90004).

3. Finally, remove the label cover’s adhesive backing and carefully

place it (adhesive edge down) onto the badge so that it neatly

holds the paper label correctly in place.

Battery Replacement

1. Temporarily disable the Badge in the Eiris software.

2. Place the badge back cover side up on a clear dry level surface.

Using a Phillips-type screwdriver that fits the battery cover

screws, unscrew the 4 screws that holds the battery cover in

place.

3. Separate the battery cover from the back of the badge by

inserting a small screw driver into either of the square slots

adjacent to the battery cover. Gently lever the screw driver

outwards until the battery cover releases from the badge.

4. Remove the worn-out battery from the badge and dispose of it
according to manufacturer’s instructions.

CAUTION! After removing the battery please wait at least 30 seconds

before installing the replacement battery so as to not cause damage to the tag

or to negatively affect the tag’s operational performance.

Caution! Risk of explosion if battery is replaced by an incorrect type.

Dispose of used batteries according to the instructions.

5. Insert a new battery into the compartment, ensuring that that the

positive (+) side of the battery faces up.

6. Align the battery cover so that its flat edge fits correctly into the

badge’s back cover prior to seating the cover into place.

7. Once the battery cover is in place, tighten its 4 screws into place.

8. Finally, in Eiris, re-enable the Badge.

Cleaning & Disinfection Procedures

Elpas recommends that you use an appropriate antibacterial disinfectant such as Dispatch® Hospital Cleaner Disinfectant with Bleach from

Caltech Industries, Inc. (

http://www.caltechind.com) to clean the Elpas Personnel Identity Badge Badges.

Since ‘Cleaning Procedures’ may vary according to facility guidelines, thus the procedures given below are for illustrative purposes only:

Option 1 – Using Dispatch Disinfectant Spray

1. Lightly wet a disposable towel with Dispatch spray

2. Do not saturate the towel

3. Wipe the outer surfaces of the badge

4. Next wipe the badge with a dry disposable towel

5. Allow the badge to air dry

6. Return the clean badge to inventory or usage

Option 2 – Using Dispatch Disinfectant Towels

1. Open a new Dispatch pre-moistened towel

2. Wipe the outer surfaces of the badge

3. Next wipe the badge with a dry disposable towel

4. Allow the badge to air dry

5. Return the clean badge to inventory or usage

6. Dispose of used towels per facility policies

7. Dispose of used towels per facility policies
