Elo TouchSystems SW601960 User Manual
USER MANUAL
Elo Touch Solutions
3243L Touchmonitors
4243L Touchmonitors
SW601960 Rev B
Copyright © 2014 Elo Touch Solutions, Inc. All Rights Reserved.
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated
into any language or computer language, in any form or by any means, including, but not limited to, electronic,
magnetic, optical, chemical, manual, or otherwise without prior written permission of Elo Touch Solutions, Inc.
Disclaimer
The information in this document is subject to change without notice. Elo Touch Solutions, Inc. and its Afffiliates
(collectively "Elo") makes no representations or warranties with respect to the contents herein, and specifically
disclaims any implied warranties of merchantability or fitness for a particular purpose. Elo reserves the right to
revise this publication and to make changes from time to time in the content hereof without obligation of Elo to
notify any person of such revisions or changes.
Trademark Acknowledgments
AccuTouch, CarrollTouch, Elo, Elo (logo), Elo Touch, Elo Touch Solutions, Elo TouchSystems, IntelliTouch, iTouch,
SecureTouch, TouchTools and VuPoint are trademarks of Elo and its Affiliates. Windows is a trademark of Microsoft
Corporation.
User Manual: 43L Series
SW601960 Rev B, Page 2 of 24
Table of Contents
Chapter 1: Introduction
Chapter 2: Installation
Chapter 3: Mounting
Chapter 4: Operation
Chapter 5: Technical Support
Chapter 6: Safety & Maintenance
...........................................................................................4
.............................................................................................5
................................................................................................7
............................................................................................. 10
............................................................................. 15
...................................................................... 17
Chapter 7: Regulatory Information
Chapter 8: Warranty Information
....................................................................... 23
................................................................... 19
User Manual: 43L Series
SW601960 Rev B, Page 3 of 24
Chapter 1: Introduction
Product Description
Your new touchmonitor combines the reliable performance of Elo Touch Solutions touch
products with the latest developments in touch technology and display design. This combination
of features creates a natural flow of information between a user and the touchmonitor.
This widescreen touchmonitor incorporates a 24-bit color, active matrix thin-film-transistor LCD
panel to provide high quality display performance. Its Full HD resolution of 1920x1080 is
suitable for displaying graphics and images. Its LED backlight significantly reduces power
consumption and eliminates mercury (compared to CCFL-backlit panels). Other features that
enhance this LCD monitor’s performance are Plug & Play compatibility and on-screen display
(OSD) controls.
Precautions
Follow all warnings, precautions and maintenance as recommended in this user manual to
maximize the life of your unit and prevent risks to user safety. See the Safety & Maintenance
chapter for more information.
This manual contains information that is important for the proper setup and maintenance of the
unit. Before setting up and powering on your new touchmonitor, read through this manual,
especially the Installation, Mounting, and Operation chapters.
User Manual: 43L Series
SW601960 Rev B, Page 4 of 24
Chapter 2: Installation
Unpacking the Touchmonitor
Open the carton and verify that the following items are present:
• Touchmonitor
• User Manuals CD
• Mounting brackets
• Quick Install Guide
• VGA cable
• HDMI cable (ETX243L-XXWA models only)
• DVI cable (ETX243L-XXAA models only)
• USB cable (not available for ETX243L-0NXX models)
• International power cables
• Japanese language regulatory information pamphlet
User Manual: 43L Series
SW601960 Rev B, Page 5 of 24
Connector Panel & Interfaces
Note: DVI or HDMI are available on certain models only.
Touchmonitor Connections
1. Connect a video cable from your host computer to the monitor. For VGA cables, tighten the
video cables screws for best performance.
2. Connect the USB touch cable between the monitors USB connector and your PC’s USB port.
(Not applicable for No Touch models)
3. Connect the power cable to the monitors input power jack and the AC power outlet.
4. The touchmonitor ships in the ON state.
User Manual: 43L Series
SW601960 Rev B, Page 6 of 24
Chapter 3: Mounting
General Mounting Information
The OSD text can be rotated between portrait and landscape mode through the OSD menu to
better suit your mounting orientation.
Side Bracket Mount
Threaded holes are provided on the sides of the monitor for mounting using the provided
brackets.
ET3243L
User Manual: 43L Series
SW601960 Rev B, Page 7 of 24
For 4243L monitors:
User Manual: 43L Series
SW601960 Rev B, Page 8 of 24
