Elo TouchSystems 15D1 User Manual
15D1 Touchcomputer User Guide
15D1 15-inch LCD Multi-function Touchcomputer
[Model 15D1]
Elo TouchSystems
15D1 Touchcomputer User Guide
15-inch Multi-function Touchcomputer
Revision A
P/N E674343
Elo TouchSystems
1-800-ELOTOUCH (1-800-356-8682)
www.elotouch.com
Copyright © 2009 Tyco Electronics. All Rights Reserved.
No part of this publication may be reproduced, transmitted, transcribed, stored in a
retrieval system, or translated into any language or computer language, in any
form or by any means, including, but not limited to, electronic, magnetic, optical,
chemical, manual, or otherwise without prior written permission of Elo
TouchSystems.
Disclaimer
The information in this document is subject to change without notice. Elo
TouchSystems makes no representations or warranties with respect to the
contents hereof, and specifically disclaims any implied warranties of
merchantability or fitness for a particular purpose. References in this publication to
Elo TouchSystems products or services do not imply that Elo TouchSystems
intends to make them available in all countries in which Elo TouchSystems
operates. Elo TouchSystems reserves the right to revise this publication and to
make changes from time to time in the content hereof without obligation of Elo
TouchSystems to notify any person of such revisions or changes.
Trademark Acknowledgments
Elo TouchSystems, IntelliTouch, SecureTouch, AccuTouch, MonitorMouse, TE
logo, and Tyco Electronics are trademarks. Other product names mentioned
herein may be trademarks or registered trademarks of their respective companies.
Tyco Electronics claims no interest in trademarks other than its own.
15D1 TOUCHCOMPUTER USER GUIDE iii
Table of Contents
Chapter 1: Setup......................................................................................1
Unpacking Your Touchcomputer ....................................................................................................1
Adjusting the Display ......................................................................................................................2
Setting Up the Operating System.....................................................................................................2
Testing Peripherals...........................................................................................................................5
Calibrating the Touchscreen............................................................................................................5
Securing the Base.............................................................................................................................7
Advertising Brackets........................................................................................................................7
Chapter 2: Operation...............................................................................9
On-Screen Display (OSD) .............................................................................................................10
LED Functionality .........................................................................................................................11
Using the Input/Output Panel.........................................................................................................13
Chapter 3: Options and Upgrades .......................................................16
Adding Optional Peripherals..........................................................................................................16
Magnetic Stripe Reader (MSR) .....................................................................................................17
Customer Display...........................................................................................................................19
Fingerprint Reader (FPR) ..............................................................................................................21
Barcode Scanner ............................................................................................................................22
Third-Party Peripherals..................................................................................................................27
Chapter 4: Safety and Maintenance.....................................................29
Safety .............................................................................................................................................29
Care and Handling .........................................................................................................................30
Recovering the Operating System .................................................................................................31
Chapter 5: Technical Specifications....................................................32
Touchcomputer Specifications.......................................................................................................32
Connector Specifications...............................................................................................................35
Cash Drawer Port Specifications...................................................................................................36
Display Screen Specifications........................................................................................................37
Environmental Specifications........................................................................................................38
15D1
TOUCHCOMPUTER USER GUIDE iv
Chapter 6: Technical Support...............................................................39
Technical Assistance......................................................................................................................39
Regulatory Information............................................................................41
Warranty ...................................................................................................44
Index ..........................................................................................................46
15D1
TOUCHCOMPUTER USER GUIDE v
This chapter discusses how to set up and test your touchcomputer. For information
on peripheral options, refer to Chapter 3, “Options and Upgrades.”
Unpacking Your Touchcomputer
C H A P T E R
1
SETUP
Check that the following items are present and in good condition:
Power cable Europe
Optional
security screw
Touchcomputer
Recovery DVD and
Quick Install Guide
Power cable US/Canada
Advertising
brackets
15D1
TOUCHCOMPUTER USER GUIDE 1
Adjusting the Display
The display screen can be adjusted from 0 to 60 degrees, as shown below.
CAUTION: To protect the LCD, be sure to hold the base when adjusting t he display,
and take care to not touch the screen.
Setting Up the Operating System
The initial setup of the operating system takes approximately 5-10 minutes.
Additional time might be needed for different touchcomputer hardware
configurations and connected devices.
To set up the Windows OS for the touchcomputer, turn on the touchcomputer by
pressing the power button, and then follow the instructions on the screen.
Selecting the Language
Windows uses English as the default language in menus and dialog boxes. You
can change this language to suit your preferences. Follow these steps:
1. From the desktop, click Start > Settings > Control Panel (in Windows XP) or
Start > Control Panel (in Vista).
2. In the Control Panel screen, select Regional and Language Options.
15D1
TOUCHCOMPUTER USER GUIDE 2
3. Click Customize. The Regional and Language Options window appears.
Select the Languages tab.
4. If required, check the boxes for “Install files for complex script and right-to-left
languages” and “Install files for East Asian languages.”
5. Select the Regional Options tab.
6. Select your preferred language from the drop-down list in the Standards and
formats pane.
15D1
TOUCHCOMPUTER USER GUIDE 3
7. Click Apply.
8. Select your location from the drop-down list in the Locations pane.
9. Click OK.
15D1
TOUCHCOMPUTER USER GUIDE 4
Selecting the Time Zone
When the following window appears, you can change the time zone, date, and time
of the touchcomputer.
After making any changes, click Next to finish. Windows Setup completes the
installation of the touchcomputer.
Testing Peripherals
The touchcomputer can be configured with several different optional peripherals,
such as a MSR or cash drawer. To test an optional peripheral that is installed on
the touchcomputer, refer to the instructions in Chapter 3, “Options and Upgrades.”
NOTE: Testing icons are located on the desktop. Testing a particular peripheral
can only be done after
Calibrating the Touchscreen
The touchscreen is pre-calibrated for accurate touch response.
If for any reason the touchscreen needs to be recalibrated, right-click the Elo icon
in the Task bar and then click “Properties.” The following window opens.
the device is properly installed.
NOTE: Calibration is not applicable to APR models.
15D1
TOUCHCOMPUTER USER GUIDE 5
Click the Align button. This launches the calibration program. The window shown
below opens. Follow the instructions to calibrate the touchscreen.
15D1
TOUCHCOMPUTER USER GUIDE 6
Securing the Base
There are two mounting options for the 15D1 touchcomputer. In both cases, the
base must be mounted on a horizontal surface.
• Option 1: Secure from below. Use the four pretapped holes to secure the
touchcomputer from below the mounting surface. The holes are designed to
work with ISO metric m6 screws. These screws are not contained in the
package, but should be readily available at any hardware store.
• Option 2: Secure from top. Use the two through holes to secure the base to
the surface.
NOTE: Mounting screws are not provided with the shipment.
Refer to the figure below for the location of the holes. All dimensions are in
millimeters.
Advertising Brackets
Option 2 Through holes
Option 1 Pretapped holes
Advertising brackets are provided to allow the user to display paper ads on the
back of the 15D1 touchcomputer. These brackets are included separately in the
accessory box. The maximum size of the advertising material is 220mm X 320mm
(8.6” X 12.6”).
15D1
TOUCHCOMPUTER USER GUIDE 7
To install these brackets, simply push them onto the sides of the back door of the
15D1 touchcomputer, as shown in the figure below.
Then insert the advertising material as shown below.
15D1
TOUCHCOMPUTER USER GUIDE 8
C H A P T E R
2
OPERATION
This chapter describes how to control the On-Screen Display (OSD), power
buttons, and I/O panel.
All adjustments made to the OSD and power controls are automatically saved.
User settings remain unchanged after powering off/on or in the case of a power
failure.
1
2
3 4 5 6 7 8 9
1. HDD status LED
2. Computer power LED
3. Head power LED
4. Touch power LED
5. Menu button
6. Left button
7. Right button
8. Select button
9. Power ON/OFF button
15D1
TOUCHCOMPUTER USER GUIDE 9
On-Screen Display (OSD)
OSD Menu
1. To display the OSD Menu, press the Menu button.
Press the RIGHT button or LEFT button to toggle and the SELECT button to
select from the different OSD sub-menus and functions.
2. When the function you want to change is shown, press the SELECT button.
3. To adjust the value of the function:
4. Pressing the RIGHT button increases the value of the selected OSD control
option.
5. Pressing the LEFT button decreases the value of the selected OSD control
option.
The OSD provides the following settings.
Feature Description
Auto adjust Automatically adjusts system clock.
Brightness Adjust brightness and contrast.
• Brightness: Adjusts the backlight of the monitor.
• Contrast: Adjusts the maximum luminance level of the
monitor.
Image setting Adjusts H position, V position, clock, and phase.
• H position: Moves the screen horizontally right and left (1 pixel
pitch increment).
• V position: Moves the screen vertically up and down (1 line
increment).
• Clock: Adjusts the ratio of dividing frequency of the dot clock.
• Phase: Adjusts the phase of the dot clock.
Color Sets color temperature (9300K, 7500K, 6500K, 5500K, or User
Preset).
OSD Adjusts H position, V position, and OSD timeout.
• H position: Adjusts the OSD menu screen position left or right.
• V position: Adjusts the OSD menu screen position up or down.
• Timeout: Adjusts the amount of time that the OSD menu is
displayed.
15D1
TOUCHCOMPUTER USER GUIDE 10
Feature Description
Language Changes language to English, French, Italian, German, Spanish,
Japanese, Simplified Chinese, or Traditional Chinese.
Recall Sets color recall and recall defaults. Restores original factory
settings.
Miscellaneous Adjusts sharpness, enables/disables DDCCI function.
• Sharpness: Adjusts sharpness of video.
Exit Exits the OSD.
OSD and Power Button Control
The OSD menu and power button are enabled by default.
To enable or disable the OSD function:
1. Simultaneously press Menu/Exit and the Left (<-) key for two seconds. A
window appears displaying OSD ENABLE or OSD DISABLE.
2. When the OSD is disabled, the OSD menu is not visible.
To enable or disable the power button (PWR) lock function:
1. Simultaneously press Menu/Exit and the Right (->) key for two seconds. A
window appears displaying PWR ENABLE or PWR DISABLE.
2. When the power button lock feature is activated, the power button is disabled.
LED Functionality
Base Power Status LED
The 15D1 base has two LEDs that indicate the power status and hard drive status.
See the figure on page 9, item 1 for the location of this LED. The light can be green,
flashing green, red, or off. The table below shows LED state and corresponding
color.
LED Color to Observer State
Off No input power — Off mode
Red Input power present, power switch off — Off mode
Flashes green Input power present — Sleep mode
Green Input power present — On mode
15D1
TOUCHCOMPUTER USER GUIDE 11
Loading...
