CHAPTER
1
INTRODUCTION
Product Description
Your new touchmonitor combines the relia ble perf ormance of touch technology with the latest
advances in LCD display design. This combination of f eatures creates a natural flow of inf ormation
between a user and your touchmonitor.
This LCD monitor incorporates 19” color active matrix thin-film-transistor (TFT) liquid crystal
display to provide superior display performance. A maximum resolution of SXGA 1280x1024 is
ideal for displaying graphics and images. Other outsta nding designs that enha nce this LCD monitor’s
performa nce are Plug & Play compatibility, and OSD (On Screen Display) controls.
Precautions
Follow all warnings, precautions a nd maintena nce a s recommended in this user’s manual to
maximize the life of your unit. See Appendix B f or more inf ormation on touchmonitor safety.
1-7
About the Product
Your LCD Desktop Touchmonitor is a 19” SXGA TFT color display with the f ollowing features:
• The internal microprocessor digitally controls auto-sca nning, f or horizontal scan frequencies
between 31.5 KHz a nd 80 KHz, and vertical scan frequencies between 56.3 Hz a nd 75.0 Hz. In
each frequency mode, the microprocessor -based circuitry allows the monitor to function at the
precision-of a fixed frequency.
• High contrast color TFT LCD display supports resolutions up to SXGA 1280x1024. It is
Compatable with V GA, SV GA, XGA, SXGA (non-interlaced) a nd most Ma cintosh compatible color
video cards.
• Power manage ment system conf orms to VESA DPMS standard.
• Supports DDC1/2B f or Plug & Play compatibility.
• Advanced OSD control for picture quality adjustment.
• Detacha ble sta nd for wall-mounting a pplication.
• Integrated touch screen function.
For full Product Specifications refer to Appendix C.
1-8 Elo Entuitive T ouchmonitor User Guide
CHAPTER
2
INSTALLATION AND SETUP
This chapter discusses how to install your LCD touchmonitor and how to install the driver software.
Unpacking Your Touchmonitor
Check that the following 8 items are present and in good condition:
LCD monitor V GA cab le USB cable
Serial Ca ble European power cable Power cable US/Canada
CD and Quick Install Guide
2-9
Elo QuickStart
CD
Software
Touch Interface Connection
Note: Before connecting the cables to your touchmonitor and PC, be sure that the computer and
touchmonitor are turned off.
DC JACK
1. Connect one end of the power cord to the monitor and the other end to the outlet.
2. Connect one end of either the touchscreen serial(RS232) cable or the touch screen USB ca ble
(but not both) to the rear side of the computer a nd the other end to the LCD monitor. Tighten by
turning the two thumb screws clockwise to ensure proper grounding(USB cable does not have
thumb screws)
3. Connect one end of the video cable to the rear side of computer and the other to the LCD monitor.
Tighten by turning the two thumb screws clockwise to ensure proper grounding.
4. Press the power button on the side panel to turn the monitor power on.
2-10 Elo Entuitive T ouchmonitor User Guide
Product Overview
Main Unit
Rear View
2-11
Installing the Driver Software
Elo TouchSystems provides driver software that allows your touchmonitor to work with your
computer. Drivers are located on the enclosed CD-ROM for the following operating systems:
• Windows XP
• Windows 2000
• Windows Me
• Windows 98
• Windows 95
• Windows NT 4.0
Additional drivers and driver information for other operating systems are available on the Elo
T ouchSystems web site at www .elotouch.com.
Your Elo touchmonitor is plug-and-play compliant. Information on the video capabilities of your
touchmonitor is sent to your video display adapter when Windows starts. If Windows detects your
touchmonitor, follow the instructions on the screen to install a generic plug-and-play monitor.
Refer to the appropriate following section for driver installation instructions.
Depending upon whether you connected the serial communication cable or the USB
communication cable, you should install only the serial driver or the USB driver.
2-12 Elo Entuitive T ouchmonitor User Guide
Installing the Serial Touch Driver
Installing the Serial Touch Driver for Windows XP,
Windows 2000, Me, 95/98 and NT4.0
NOTE: For Windows 2000 and NT 4.0 you must have administrator access rights to install
the driver.
1 Insert the Elo CD-ROM in your computer's CD-ROM drive.
2 If the AutoStart f eature f or your CD-ROM drive is a ctive, the syste m automatically detects the
CD and starts the setup program.
3 Follow the directions on the screen to complete the driver setup for your version of Windows.
4 If the AutoStart f eature is not a ctive:
5 Click Start > Run.
6 Click the Browse button to locate the EloCd.exe program on the CD-ROM.
7 Click Open, then OK to run EloCd.exe.
8 Follow the directions on the screen to complete the driver setup for your version of Windows.
To install Windows 2000 and W indows XP, you must use the "update driver" method; you will not
find a setup.exe file within the download.
2-13
Installing the Serial Touch Driver for MS-DOS and Windows 3.1
You must have a DOS mouse driver (MOUSE.COM) installed for your mouse if you wish to
continue using your mouse along with your touchmonitor in DOS.
T o install Windows 3.x and MS-DOS from W indows 95/98, follow the directions below:
1 Insert the CD-ROM in your computer’s CD-ROM drive.
2 From DOS, type d:\EloDos_W31 to change to the correct directory on the CD-ROM (your
CD-ROM drive may be mapped to a different drive letter).
3 T ype install and press Enter to start the installation.
4 Align the touchscreen.
You must have already completed Steps 1 a nd 2 before proceeding.
T o run the INST ALL progra m:
1 T ype INSTALL at the DOS prompt in the directory containing the driver install files.
2 INST ALL asks you to select the software to install. Then choose d:\EloDos_W31 from the
displayed list.
3 INST ALL also a sks you for the paths to use during installation, or you may use its defaults.
INST ALL creates directorie s a s necessary, and warns you if they exist.
If you are updating your software, you may wish to specify the paths containing the earlier versions,
a nd overwrite the obsolete files. All executable progra ms are upward compatible. For a list of
differences from ea ch previous version of the drivers, be sure to select "Diff erences from Previous
Versions" during the installation process.
INST ALL updates your AUT OEXEC.BA T file with the drivers you select. INST ALL makes a copy
of your original AUT OEXEC.BAT file, called AUTOEXEC.OLD. If you alrea dy have Elo driver
comma nds in your AUTOEXEC.BAT file, they will be commented out.
When INSTALL is finished, it leaves a file called GO.BAT in the subdirectory you specified. GO
loads the touchscreen driver, runs the calibration program ELOCALIB, and gives you some final
instructions.
If you are using W indows 3.1, you will also calibrate the touchscreen within W indows 3.1 with the
T ouchscreen Control Panel.
2-14 Elo Entuitive T ouchmonitor User Guide
Installing the USB Touch Driver
Installing the USB Touch Driver for Windows XP,
Windows 2000, Me, 95/98 and NT4.0
1 Insert the Elo CD-ROM in your computer’s CD-ROM drive.
If W indows 98, W indows Me or W indows 2000 starts the Add New Hardware Wizard:
2 Choose Next. Select “Search for the best driver for your device (Recommended)” and choose
Next.
3 When a list of search locations is displayed, place a checkmark on “Specify a location” and use
Browse to select the \EloUSB directory on the Elo CD-ROM.
4 Choose Next. Once the Elo USB touchscreen driver has been detected, choose Next again.
5 Y ou will see several files be ing copied. Insert your Windows 98 CD if prompted. Choose Finish.
If Windows 98, W indows Me or Windows 2000 does not start the Add New Hardware Wizard:
NOTE: For Windows 2000 you must have administrator access rights to install the driver.
1 Insert the Elo CD-ROM in your computer’s CD-ROM drive. If the AutoStart f eature for your
CD-ROM drive is active, the system automatically detects the CD and starts the setup program.
2 Follow the directions on the screen to complete the driver setup for your
version of Windows.
If the AutoStart f eature is not a ctive:
1 Click Start > Run.
2 Click the Browse button to locate the EloCd.exe program on the CD-ROM.
3 Click Open, then OK to run EloCd.exe.
4 Follow the directions on the screen to complete the driver setup for your version of Windows.
To install Windows 2000 and W indows XP, you must use the "update driver" method; you will not
find a setup.exe file within the download.
2-15
2-16 Elo Entuitive T ouchmonitor User Guide
CHAPTER
3
OPERATION
About Touchmonitor Adjustments
Y our touchmonitor will unlikely require adjustment. Variations in video output and application may
require adjustments to your touchmonitor to opti mize the quality of the display.
For best performa nce, your touchmonitor should be operating in native resolution, that is 1280x1024
at 80k-75 Hz. Use the Display control panel in Windows to choose 1280x1024 resolution.
Operating in other resolutions will degrade video perf ormance. For further information, please
refer to Appendix A.
All adjustments you make to the controls are automatically me morized. This feature saves you from
having to reset your choices every time you unplug or power your touchmonitor of f and on. If there
is a power failure, your touchmonitor settings will not default to the factory specifications.
3-17
Front Panel Controls
Control Function
1 Menu/Exit Display/Exits the OSD menus.
2 1. Enter contrast of the OSD.
2. Increase value of the a djustment ite m.
3. Shuffle item clockwise.
3 1. Enter brightness adjustment.
2. Decrea se value of the adjustment item.
3. Shuffle item counter-clockwise.
4 Select Select the adjustment ite ms from the OSD menu.
5 Power Switch Switches the power of the monitor from off to on to off.
3-18 Elo Entuitive T ouchmonitor User Guide
1
2
3
4
5
Controls and Adjustment
OSD Menu Functions
T o Display and Select the OSD Functions:
1 Press the Menu key to activate the OSD menu.
2 Use or to move clockwise or counterclockwise through the menu. Press the select key on
the monitor. The para meter will be highlighted when selected.
3 T o quit the OSD screen at any time during the operation, press the Menu key . If no keys are
pressed for a short time period, the OSD automatically disappears.
NOTE: The OSD screen will disappear if no input activities are detected from 45 seconds to 255
seconds, depending on the setting set on the osd of the monitor. The monitor default is 45
seconds.
3-19
OSD Control Options
Control Description
Contrast Increases or decrease s contrast.
Brightness Increases or decrease s brightness.
V-Position Moves the screen up or down.
H-Position Moves the screen left or right.
Recall Defaults Returns the monitor to its default settings.
Color Balance Press or and “Select” button to select 9300, 6500, 5500, 7500
a nd USER. Only when selecting USER ca n you make a djustments to
the R/G/B content. Press Select to restore to factory default setting.
OSD Exit Escape OSD icon.
Sharpness Adjust Sharpness.
Phase Increases or decrease s the snow noise of the image after auto
adjustment is ma de.
Clock The dot clock is fine-adjusted after auto adjust.
OSD H-Position Moves the OSD position horizontally on the screen. When the
“SELECT” button and the button is pre ssed, the OSD control menu
will move to the rightside of the screen. Likewise, when the “Select”
button and the button is pre ssed, the OSD control menu will move to
the left side.
OSD V-Position Moves the OSD position vertically on the screen. When the
“SELECT” button a nd the button is pressed, the OSD control menu
will move to the top side of the screen. Likewise, when the “Select”
button and the button is pre ssed, the OSD control menu will move to
the lower side.
OSD T ime Adjsuts the time of OSD icon stays on monitor.
Auto-Adjust Press Auto to ena ble this function. The Auto-Adjust will automatically
adjust V-Position, H-Position, Clock and Clock-Phase.
OSD La nguage Select from English, French, German ,Spanish a nd Ja pa ne se.
Information Descri ption Indicates the current resolution, H-Frequency a nd V-Frequency.
3-20 Elo Entuitive T ouchmonitor User Guide
Preset Modes
To reduce the need for adjustment for different modes, the monitor ha s default setting modes that
are most commonly used as given in the ta ble below . If any of these display modes are detected, the
monitor automatically adjusts the picture size and centering. When none of the mode is matched,
the user can store their preferred modes in the user modes. The monitor is ca pable of storing up to
7 user modes. The only condition to store a s a user mode is the new display information must have
1 KHz difference for horizontal frequency or 1 Hz for vertical frequency or the sync signal
polarities are different from the default modes.
H. Freq. Ba nd W idth
Mode Resolution (KHz) (MHz) H V
1 V GA 640x350 70 Hz 31.47 28.322 + -
2 V GA 720x400 70 Hz 31.47 28.322 - +
3 V GA 640x480 60 Hz 31.47 25.175 - -
4 MAC 640x480 66 Hz 35.00 32.24 - -
5 VESA 640x480 72 Hz 37.86 31.5 - -
6 VESA 640x480 75 Hz 37.50 31.5 - -
7 VESA 800x600 56 Hz 35.16 36 + +
8 VESA 800x600 60 Hz 37.88 40 + +
9 VESA 800x600 75 Hz 46.88 49.5 + +
10 VESA 800x600 72 Hz 48.08 50 + +
11 MAC 832x624 75 Hz 49.72 57.283 - -
12 VESA 1024x768 60 Hz 48.36 65 - -
13 SUN 1024x768 65 Hz 52.45 70.49 - -
14 VESA 1024x768 70 Hz 56.48 75 - -
15 VESA 1024x768 75 Hz 60.02 78.75 + +
16 SXGA 1280x1024 60 Hz 64 108 + +
17 SXGA 1280x1024 75 Hz 80 135 + +
18 SXGA 1 152x864 75 Hz 67.5 108 + +
19 SXGA 1280x960 60 Hz 60 108 + +
3-21
Power Management System
The monitor is equipped with the power ma nagement function which automatically reduces the power
consumption when not in use.
Power
Mode Consumption
On <50W
Sleep <4W
Off <2W
We recommend switching the monitor off when it is not in use for a long time.
NOTE: The monitor automatically goes through the Power Management System (PMS) steps
when it is idle. To release the monitor from PMS state, press any key on the keyboard
or move mouse.
Display Angle
For viewing clarity , you ca n tilt the LCD forward (up to -5 degrees) or backward (up to 90 degrees.)
CAUTION In order to protect the LCD, be sure to hold the base when adjusting the LCD,
and take care not to touch the screen.
3-22 Elo Entuitive T ouchmonitor User Guide
CHAPTER
4
TROUBLESHOOTING
If you are experiencing trouble with your touchmonitor, refer to the f ollowing ta ble. If the proble m
persists, please contact your local dealer or our service center.
Solutions to Common Problems
Problem Suggestion(s)
The monitor does not respond Check that the monitor’s Power Switch is on.
after you turn on the system. Turn off the power a nd check the monitor’s power cord
a nd signal ca ble f or proper connection.
Characters on the screen are di m Refer to the About T ouchmonitor Adjustments section to
adjust the brightness.
The screen is bla nk During operation, the monitor screen may automatically turn
off as a result of the Power Saving feature on the PC. Pre ss any key on the
keyboard, mouse or touch the screen to see if the screen reappears.
Refer to the About Touchmonitor Adjustments section to
adjust the brightness.
Screen flashes when initi alized Turn the monitor off then turn it on again.
“Out of Ra nge” display Check to see if the resolution of your computer is higher than
that of the LCD display.
Reconfigure the resolution of your computer to make it less
than or equal to 1280x1024. See Appendix A for more information
on resolution.
T ouch doesn’t work M ake sure the touch ca ble is securely atta ched at both ends.
4-23
4-24 Elo Entuitive T ouchmonitor User Guide
APPENDIX
A
NATIVE RESOLUTION
The native resolution of a monitor is the resolution level at which the LCD panel is designed to
perform best. For the LCD touchmonitor, the native resolution is 1280 x 1024 for the 19 inch size.
In almost all cases, screen image s look be st when viewed at the ir native re solution. You ca n lower
the resolution setting of a monitor but not increase it.
Input Video 19" LCD
640x480 (VGA) Transforms input format to 1280x1024
800x600 (SV GA) Transforms input format to 1280x1024
1024x768 (XGA) Transforms input format to 1280x1024
1280x1024(SXGA) Displays in native Resolution
The native resolution of an LCD is the actual number of pixels horizontally in the LCD by the
number of pixels vertically in the LCD. LCD resolution is usually represented by the
following symbols:
VGA 640x480
SVGA 800x600
XGA 1024x768
SXGA 1280x1024
UXGA 1600x1200
A-25
As a n exa mple, a XGA resolution LCD panel ha s 1024 pixels horizontally by 768 pixels vertically.
Input video is also represented by the same terms. SXGA input video has a format of 1280 pixels
horizontally by 1024 pixels vertically. When the input pixels contained in the video input format
match the native resolution of the panel, there is a one to one correspondence of mapping of input
video pixels to LCD pixels. As an example, the pixel in column 45 and row 26 of the input video is in
column 45 a nd row 26 of the LCD. For the case when the input video is at a lower re solution tha n the
native resolution of the LCD, the direct correspondence between the video pixels and the LCD
pixels is lost. The LCD controller can compute the correspondence between video pixels and LCD
pixels using algorithms contained on its controller. The accuracy of the algorithms determines the
fidelity of conversion of video pixels to LCD pixels. Poor fidelity conversion can result in artifacts
in the LCD displayed i mage such a s varying width characters.
A-26 Elo Entuitive T ouchmonitor User Guide
APPENDIX
B
TOUCHMONITOR SAFETY
This manual contains information that is important for the proper setup and maintenance of your
touchmonitor. Bef ore setting up a nd powering on your new touchmonitor , rea d through this manual,
especially Chapter 2 (Installation), and Chapter 3 (Operation).
1 T o reduce the risk of electric shock, f ollow all saf ety notices and never open the touchmonitor
case.
2 Turn off the product bef ore cleaning.
3 Y our new touchmonitor is equi pped with a 3-wire, grounding power cord. The power cord plug
will only fit into a grounded outlet. Do not atte mpt to fit the plug into an outlet that has not been
configured for this purpose. Do not use a da maged power cord. Use only the power cord that
comes with your touchmonitor. Use of an unauthorized power cord will void your warranty.
4 The slots located on the sides and top of the touchmonitor case are for ventilation. Do not block
or insert a nything inside the ventilation slots.
5 It is important that your touchmonitor remains dry. Do not pour liquid into or onto your
touchmonitor. If your touchmonitor becomes wet do not attempt to repair it yourself.
B-27
Care and Handling of Your Touchmonitor
The following tips will help kee p your touchmonitor functioning at the opti mal level.
• T o avoid risk of electric shock, do not disasse mble the brick supply or display unit ca binet. The
unit is not user serviceable. Reme mber to unplug the display unit from the power outlet bef ore
clea ning.
• Do not use alcohol (methyl, ethyl or isopropyl) or a ny strong dissolvent. Do not use thinner or
benzene, abra sive cleaners or compressed air.
• To clean the display unit cabinet, use a cloth lightly dampened with a mild detergent.
• A void getting liquids inside your touchmonitor . If liquid does get inside, have a qualified service
technician check it before you power it on again.
• Do not wipe the screen with a cloth or sponge that could scratch the surface.
• To clean the touchscreen, use window or glass clea ner. Put the cleaner on the rag and wipe the
touchscreen. Never a pply the cleaner directly on the touchscreen.
B-28 Elo Entuitive T ouchmonitor User Guide
APPENDIX
C
TECHNICAL SPECIFICATIONS
C-29
Touchmonitor Specifications
Model ET1915L
LCD Display 19” TFT Active M atrix Pa nel
Display Size 376.32(H) x 301.06(V) mm
Pixel Pitch 0.294(H) x 0.294(V) mm
Display Mode V GA 640 x 350 (70Hz)
V GA 720 x 400 (70Hz)
V GA 640 x 480 (60 / 72/ 75Hz)
SV GA 800 x 600 (56 / 60 / 72/ 75Hz)
XGA 1024 x 768 (60 / 70 / 75Hz)
Max. Resolution SXGA 1280 x 1024 (60 / 70 / 75Hz)
SXGA (1280 x 1024) at 75Hz maxi mum
Contrast Ratio 550 : 1 (typical)
Brightness NonTouch: typical 270 Cd/m2 ; Min 215 Cd/m
2
AccuTouch: typical 221 Cd/m2 ; Min 176 Cd/m
2
IntelliTouch: typical 248 Cd/m2 ; Min 197 Cd/m
2
Response Ti me Tr: 5.6 ms Tf: 2.4 ms (Typ.)
Display Color 16.2M
Viewing Angle Vertical -60o ~ +75o (T yp.)
Horizontal -70o ~+70o (T yp.)
Input Signal Video R.G.B. Analog 0.7Vp-p, 75 ohm
Sync TTL Positive or Negative
Signal Connector Mini D-Sub 15 pin
Front Control Menu, , , Select, Power
OSD Contrast, Brightness, H-Position, V-Position, Sharpness
Color T emperature, Pha se, Clock, OSD T ime, Recall,
La nguage: English, French, German, Spanish, Jap a nese
Plug & Play DDC1 / 2B
Touch Panel (optional) IntelliTouch and AccuT ouch Touch
Power Adapter Input AC 100-240V , 50/60Hz
Operating Conditions Temperature 0oC ~ 40oC (32oF ~ 104oF)
Humidity 20% ~ 80% (No Condensation)
Altitude To 12,000 Feet
Storage Conditions Te mperature -20oC ~ 60oC (-4oF ~ 140oF)
Humidity 10% ~ 90% (No Condensation)
Dimensions (HxWxD) 429 x 390 x 212mm
Weight (Net) 8.4Kg
Certifications UL, C-UL, FCC-B, CE, VCCI, C-Tick, MPRII , TUV
C-30 Elo Entuitive T ouchmonitor User Guide
C-31
IntelliTouch Touchmonitor Specifications
Mechanical
Positional Accuracy Standard deviation of error is less tha n 0.080 in. (2.03 mm).
Equates to less tha n ±1%.
T ouchpoint Density More than 100,000 touchpoints/in2 (15,500 touchpoints/cm2).
T ouch Activation Typically less tha n 3 ounces (85 grams).
Force
Surface Durability Surfa ce dura bility is that of gla ss, Mohs’hardne ss rating of 7.
Expected Life No known wear-out mecha nism, a s there are no layers, coatings,
Performance or moving parts. IntelliTouch technology has been operationally tested
to more tha n 50 million touches in one location without failure, using
a stylus similar to a finger.
Sealing Unit is sealed to protect against splashed liquids, dirt, and dust.
Optical
Light T ransmission IntelliTouch 92%, AccuT ouch 82%, Surface Ca pa citive T ouch 84%
(per ASTM D1003)
Visual Resolution All measurements ma de using USAF 1951 Resolution Chart, under
30X magnification, with test unit located approxi mately 1.5 in (38 mm)
from sur face of resolution chart. Clear surfa ce: Excellent, with no
noticeable degra dation. Antiglare surfa ce: 6:1 mini mum.
Gloss (per ASTM Antiglare surface: Curved: 60 ±20 gloss units or 75 ± 15 gloss units.
D2457 using a 60degree gloss meter)
C-32 Elo Entuitive T ouchmonitor User Guide
Environmental
Chemical Resistance The active area of the touchscreen is resistant to all chemicals
that do not affect glass, such a s:
Acetone
Toluene
Methyl ethyl ketone
Isopropyl alcohol
Methyl alcohol
Ethyl acetate
Ammonia-based glass cleaners
Gasoline
Kerosene
Vinegar
Electrostatic Meets Level 4 (15kV air/8 kV contact dischar ges)
Protection (per EN 61
000-4-2, 1995)
19” LCD Touchmonitor (ET1915L-XXXA-1-G) Dimensions
C-33
C-34 Elo Entuitive T ouchmonitor User Guide
REGULATORY INFORMATION
I. Electrical Safety Information:
A) Compliance is required with respect to the voltage, frequency, a nd current requirements
indicated on the manufa cturer’s label. Connection to a different power source than those
specified herein will likely result in improper operation, damage to the equipment or pose a fire
hazard if the limitations are not followed.
B) There are no operator serviceable parts inside this equi pment. There are hazardous voltages
generated by this equipment which constitute a safety hazard. Service should be provided only
by a qualified service technician.
C) This equi pment is provided with a detacha ble power cord which ha s an integral safety ground
wire intended for connection to a grounded safety outlet.
1) Do not substitute the cord with other than the provided approved type. Under no
circumstance s use an adapter plug to connect to a 2-wire outlet a s this will def eat the
continuity of the grounding wire.
2) The equipment requires the use of the ground wire a s a part of the safety certification,
modification or misuse can provide a shock hazard that can result in serious injury or
death.
3) Contact a qualified electrici an or the manufacturer if there are questions about the
installation prior to connecting the equipment to mains power .
II. Emissions and Immunity Information
A) Notice to Users in the U nited States: This equipment has been tested and found to comply
with the limits for a Cla ss B digital device, pursuant to Part 15 of FCC Rules. These limits are
designed to provide reasona ble protection against harmful interference in a residenti al installation.
This equipment generates, uses, and can radi ate radio frequency energy, a nd if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications.
B) Notice to Users in Canada: This equi pment complies with the Class B limits for radio noise
emissions from digital apparatus a s established by the Ra dio Interf erence Regulations of Industrie
Canada.
C) Notice to Users in the European Union: Use only the provided power cords and
interconnecting cabling provided with the equipment. Substitution of provided cords and cabling
may compromise electrical safety or CE Mark Certification f or e missions or immunity as
required by the following sta ndards:
35
This Information T echnology Equipment (ITE) is required to have a CE M ark on the manufa cturer’s
label which mea ns that the equi pment ha s been tested to the f ollowing Directives and Standards:
This equipment has been tested to the require ments f or the CE M ark a s required by EMC
Directive 89/336/EEC indicated in European Standard EN 55022 Class B a nd the Low Voltage
Directive 73/23/EEC as indicated in Europea n Standard EN 60950.
D) General Inf ormation to all Users: This equipment generates, uses and ca n ra diate radio
frequency energy . If not installed and used according to this manual the equi pment may cause
interference with radio and television communications. There is, however, no guara ntee that
interference will not occur in a ny particular installation due to site-specific factors.
1) In order to meet emission and immunity requirements, the user must observe the following:
a) Use only the provided I/O cables to connect this digital device with any computer.
b) T o ensure compli ance, use only the provided manufacturer’s a pproved line cord.
c) The user is cautioned that changes or modifications to the equipment not expressly
approved by the party responsible for complia nce could void the user’s authority to operate
the equipment.
2) If this equipment a ppears to cause interference with radio or television reception, or any other
device:
a) Verify as an e mission source by turning the equi pment off and on.
b) If you determine that this equipment is causing the interference, try to correct the
interference by using one or more of the following measures:
i) Move the digital device away from the affected receiver.
ii) Reposition (turn) the digital device with respect to the aff ected receiver.
iii) Reorient the af f ected rece iver’s antenna.
iv) Plug the digital device into a different AC outlet so the digital device and the
receiver are on different branch circuits.
v) Disconnect and remove any I/O ca ble s that the digital device does not use.
(Unterminated I/O cable s are a potenti al source of high RF e mission levels.)
vi) Plug the digital device into only a grounded outlet receptacle. Do not use AC
ada pter plugs. (Re moving or cutting the line cord ground may increa se RF emission
levels and may also pre sent a lethal shock hazard to the user.)
If you need additional help, consult your dealer , manufacturer, or a n experienced radio or television
technician.
36 Elo Entuitive T ouchmonitor User Guide
37
38 Elo Entuitive T ouchmonitor User Guide
WARRANTY
Except as otherwise stated herein or in an order acknowledgment delivered to Buyer, Seller warra nts
to Buyer that the Product shall be free of defects in materials and workmanship. The warranty for the
touchmonitors and components of the product is 3 (three) years.
Seller makes no warra nty regarding the model life of components. Seller’s suppliers may at a ny ti me
and from time to time make changes in the components delivered a s Products or components.
Buyer shall notify Seller in writing promptly (a nd in no case later tha n thirty (30) days after discovery)
of the failure of a ny Product to conf orm to the warranty set forth above; shall describe in commercially rea sona ble detail in such notice the symptoms a ssoci ated with such failure; and shall provide
to Seller the opportunity to inspect such Products as installed, if possible. The notice must be received by Seller during the Warranty Period for such product, unless otherwise directed in writing
by the Seller. W ithin thirty (30) days after submitting such notice, Buyer shall package the allegedly
defective Product in its original shipping carton(s) or a functional equivalent and shall ship to Seller
at Buyer’s expense a nd risk.
Within a rea sonable time after recei pt of the allegedly def ective Product and verification by Seller
that the Product fails to meet the warranty set forth above, Seller shall correct such failure by, at
Seller’s options, either (i) modifying or repairing the Product or (ii) replacing the Product. Such
modification, repair, or replacement and the return shipment of the Product with minimum insura nce to Buyer shall be at Seller’s expense. Buyer shall bear the risk of loss or da mage in transit, and
may insure the Product. Buyer shall reimburse Seller for transportation cost incurred for Product
returned but not found by Seller to be defective. Modification or repair, of Products may, at Seller’s
option, take place either at Seller’s facilities or at Buyer’s premises. If Seller is una ble to modify,
repair, or repla ce a Product to conf orm to the warranty set forth above, then Seller shall, at Seller’s
option, either refund to Buyer or credit to Buyer’s account the purchase price of the Product less
depreciation calculated on a straight-line basis over Seller’s stated Warra nty Period.
39
THESE REMEDIES SHALL BE THE BUYER¡¦S EXCLUSIVE REMEDIES FOR BREACH OF
W ARRANTY. EXCEPT FOR THE EXPRESS W ARRANTY SET FORTH ABOVE, SELLER GRANTS
NO OTHER W ARRANTIES, EXPRESS OR IMPLIED BY ST A TUTE OR OTHERWISE, REGAR DING THE PRODUCTS, THEIR FITNESS FOR ANY PURPOSE, THEIR QUALITY, THEIR
MERCHANT ABILITY, THEIR NONINFRINGEMENT, OR OTHERWISE. NO EMPLOYEE OF
SELLER OR ANY OTHER PAR TY IS AUTHORIZED TO MAKE ANY W ARRANTY FOR THE
GOODS OTHER THAN THE W ARRANTY SET FORTH HEREIN. SELLER¡¦S LIABILITY UNDER
THE WARRANTY SHALL BE LIMITED T O A REFUND OF THE PURCHASE PRICE OF THE
PRODUCT . IN NO EVENT SHALL SELLER BE LIABLE FOR THE COST OF PROCUREMENT
OR INSTALLATION OF SUBSTITUTE GOODS BY BUYER OR FOR ANY SPECIAL,
CONSEQUENTIAL, INDIRECT , OR INCIDENTAL DAMAGES.
Buyer assumes the risk and agrees to indemnify Seller against and hold Seller harmless from all
lia bility relating to (i) assessing the suitability for Buyer’s intended use of the Products and of any
system design or drawing and (ii) determining the compli ance of Buyer¡¦s use of the Products with
applica ble laws, regulations, codes, and standards. Buyer retains and accepts full responsibility for
all warra nty a nd other clai ms relating to or arising from Buyer’s products, which include or incorporate Products or components manufactured or supplied by Seller. Buyer is solely responsible for
a ny a nd all representations a nd warra nties regarding the Products ma de or authorized by Buyer . Buyer
will indemnify Seller and hold Seller harmless from any liability, claims, loss, cost, or expenses
(including reasonable attorney’s f ee s) attributable to Buyer¡¦s products or representations or warra nties concerning same.
40 Elo Entuitive T ouchmonitor User Guide
Numerics
19" LCD Touchmonitor (ET1915L-XXWA-1-G)
Dimensions, 3
A
About the Product, 8
About Touchmonitor Adjustments, 17
B
Brightness, 30
C
Care and Handling of Your Touchmonitor, 28
Certifications, 30
Cleaning Your Touchmonitor, 28
Contrast Ratio, 30
Controls and Adjustment, 19
D
Dimensions (HxWxD), 30
Display Angle, 22
Display Color, 30
Display Mode, 30
Display Size, 30
E
Electrical Safety Information, 35
Electrostatic Protection, 32
Environmental Chemical Resistance, 32
Emissions and Immunity Information, 35
Expected Life Performance, 31
F
Front Control, 30
Front Panel Controls, 18
G
Gloss, IntelliTouch, 31
I
Image problem, 23
Image, scrolling, 23
Input Signal, 30
Installation and Setup, 9
Installing the Driver Software, 12
Installing the Serial Touch Driver, 13
Installing the Serial Touch Driver for MS-DOS and
Windows 3.1, 14
Installing the Serial Touch Driver for Windows XP,
Windows 2000, Me, 95/98 and NT 4.0, 13
Installing the USB Touch Driver, 15
Installing the USB Touch Driver for Windows XP,
Windows 2000, Me, 95/98 and NT 4.0, 15
Intellitouch Touchmonitor Specifications, 31
M
Main Unit, 10
Max. Resolution, 30
N
Native Resolution, 25
O
Operating Conditions, 30
OSD, 30
OSD Control Options, 20
OSD Menu Functions, 19
P
Pixel Pitch, 30
Plug & Play, 30
Positional Accuracy, 31
Power Adapter, 30
Power Management System, 22
Precautions, 7
Product Description, 7
Product Overview, 10
I N D E X - 41
INDEX
R
Rear View, 10
Regulatory Information, 35
Response Time, 30
S
Sealing Optical, 31
Signal Connector, 30
Solutions to Common Problems, 23
Storage Conditions, 30
Surface Durability, 31
SVGA, 25
SXGA, 25
T
Technical Specifications, 29
Touch Activation Force, 31
Touch Interface Connection, 11
Touch not working, 23
Touch Panel (optional), 30
Touchpoint Density, 31
Touchmonitor Safety, 27
Touchmonitor Specifications, 30
Troubleshooting, 23
U
Unpacking Your Touchmonitor, 9
UXGA, 25
V
VGA, 25
Viewing Angle, 30
Visual Resolution, 31
W
Warranty, 39
Weight (Net), 30
X
XGA, 25
I N D E X - 42
© 2006 Elo T ouchSystems Inc. Printed in USA
Check out Elo’s Web site!
www.elotouch.com
Get the latest...
• Product information
• Specifications
• News on upcoming events
• Press release
• Software drivers
Getting in Touch with Elo
To find out more about Elo’s extensive range of touch solutions, visit our Web site at www.elotouch.com or simply
call the office nearest you:
USA & Headquarters Germany Belgium Japan
Elo TouchSystems, Inc. Elo TouchSystems GmbH & Co. KG Elo TouchSystems Touch Panel Systems K.K
301 Constitution Drive, Haidgraben 6 Diestsesteenweg 692 Sun Homada Bldg. 2F
Menlo Park, CA 94025 D-85521 Ottobrunn B-3010 Kessel-Lo 1-19-20 Shin-Yokohama
USA Germany Belgium Kanagawa 222-0033
Japan
(800) ELO-TOUCH(800-356-8682)
Tel 650-361-4700 Tel +49(89)60822-0 Tel +32(16)35-2100 Tel +81(45)478-2161
Fax 650-361-4747 Fax +49(89)60822-150 Fax +32(16)35-2101 Fax +81(45)478-2180
eloinfo@elotouch.com elosales@elotouch.com elosales@elotouch.com www.tps.co.jp
LCD T ouchmonitor / ET1915L
⇓
Seat Assembly→Enclosure Assembly→PCB Board/Protection CoverAssembly
→ Front Frame Asse mbly→ LCD Asse mbly→ BacklightModule→La mp/Rear CoverAssembly
⇓
Power Cord A
⇓
Power Cord B
⇓
V GA Cord
⇓
Serial Cord
⇓
USB Cord
Loading...
