Touchmonitor User Guide
1215L 12¨ LCD Desktop Touchmonitor
1000 Series
Revision A
User Guide
12" LCD Desktop
ET1215L Series
Revision A
P/N E378269
Copyright © 2006 Elo TouchSystems Inc. All Rights Reserved.
No part of this publication may be reproduced, tra nsmitted, transcribed, stored in a retrieval system,
or tra nslated into a ny language or computer language, in a ny f orm or by a ny mea ns, including, but not
limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior written permission of Elo TouchSystems.
Disclaimer
The information in this document is subject to change without notice. Elo T ouchSyste ms makes no
representations or warranties with respect to the contents hereof, and specifically disclaims any
implied warranties of merchantability or fitness for a particular purpose. Elo TouchSystems reserves the right to revise this publication and to make changes from time to time in the content
hereof without obligation of Elo T ouchSyste ms to notify any person of such revisions or changes.
Trademark Acknowledgments
AccuT ouch, AT4, CarrollT ouch, Entuitive, IntelliTouch, iTouch, MonitorMouse a nd SecureTouch
are trade marks of Elo TouchSystems, Inc.
Other product names mentioned here in may be tra de marks or registered tra de marks of the ir respective compa nies.
iii
Table of Contents
Chapter 1 Regulatory Information 33
Introduction 7 Warranty 37
Product Description ...................................................7
Precautions ................................................................7
Chapter 2
Installation and Setup .................................... 9
Unpacking Your Touchmonitor...................................9
Product Overview ......................................................10
Main Unit ..............................................................10
Rear View ............................................................10
Touch Interface Connection .......................................11
Installing the Driver Software .....................................12
Installing the Serial Touch Driver .........................13
Installing the Serial Touch Driver for Windows
XP, Windows 2000, Me, 95/98 and NT 4.0 .....13
Installing the Serial Touch Driver for MS-DOS
and Windows 3.1..................................................14
Installing the USB Touch Driver...........................15
Installing the USB Touch Driver for Windows
XP, Windows 2000, Me, 95/98 and NT 4.0 .....15
Index 39
Chapter 3
Operation 17
About Touchmonitor Adjustments ..............................17
Front Panel Controls ............................................18
Controls and Adjustment ............................................19
OSD Menu Functions ..........................................19
OSD Control Options ...........................................20
Preset Modes.......................................................21
Power Management System ................................22
Display Angle .............................................................22
Chapter 4
Troubleshooting 23
Solutions to Common Problems .................................23
Appendix A.................................................... 25
Appendix B
Care and Handling of Your Touchmonitor ..................28
Appendix C
Touchmonitor Specifications ......................................30
AccuTouch Touchscreen Specifications .............31
12" LCD Touchmonitor (ET1215L-XXWA-1)
Dimensions ..........................................................32
v
Product Description
Your new touchmonitor combines the relia ble perf ormance of touch technology with the latest
advances in LCD display design. This combination of features creates a natural flow of inf ormation
between a user and your touchmonitor.
This LCD monitor incorporates 12” color active matrix thin-film-transistor (TFT) liquid crystal
display to provide superior display performa nce. A maximum resolution of SVGA 800x600 is ideal
for displaying graphics and images. Other outstanding de signs that enhance this LCD monitor’s
performa nce are Plug & Play compatibility, and OSD (On Screen Display) controls.
CHAPTER
1
INTRODUCTION
NOTE Some monitors do not have the touchscreen capability.
Precautions
Follow all warnings, precautions a nd maintena nce a s recommended in this user’s manual to
maximize the life of your unit. See Appendix B for more information on touchmonitor safety.
1-7
About the Product
Your LCD Desktop Touchmonitor is a 12” SVGA TFT color display with the following features:
• The internal microprocessor digitally controls auto-scanning. For horizontal sca n frequencies
between 31.5 KHz a nd 48 KHz, and vertical scan frequencies between 56.3 Hz a nd 75.0 Hz. In
each frequency mode, the microprocessor -based circuitry allows the monitor to function at the
precision-of a fixed frequency.
• High contrast color TFT LCD display support resolution up to SVGA 800x600. Compatible with
V GA, SVGA(non-interlaced) a nd most Ma cintosh compatible color video cards.
• Power ma nagement syste m conforms to VESA DPMS sta ndard.
• Supports DDC1/2B f or Plug & Play compatibility.
• Adva nced OSD control for picture quality adjustment.
• Detacha ble sta nd for wall-mounting a pplication.
• Optional touch screen function.
For full Product Specifications refer to Appendix C.
1-8 User Guide
CHAPTER
2
INSTALLATION AND SETUP
This chapter discusses how to install your LCD touchmonitor and how to install the driver software.
Unpacking Your Touchmonitor
Check that the following 8 items are present and in good condition:
LCD monitor V GA cab le USB cable
Serial Ca ble European power cable Power cable US/Canada
Elo QuickStart
CD
Software
CD and Quick Install Guide
2-9
Touch Interface Connection
Note: Before connecting the cables to your touchmonitor and PC, be sure that the computer and
touchmonitor are turned off.
1. Connect one end of the power cord to the monitor and the other end to the outlet.
2. Connect one end of either the touchscreen serial(RS232) cable or the touch screen USB ca ble
(but not both) to the rear side of the computer a nd the other end to the LCD monitor. Tighten by
turning the two thumb screws clockwise to ensure proper grounding(optional module USB cable
does not have thumb screws)
3. Connect one end of the video ca ble to the rear side of computer a nd the other to the LCD monitor .
Tighten by turning the two thumb screws clockwise to ensure proper grounding.
4. Press the power button on the front panel to turn the monitor power on.
2-10 User Guide
Product Overview
Main Unit
Rear View
2-11
Installing the Driver Software
Elo TouchSystems provides driver software that allows your touchmonitor to work with your
computer. Drivers are located on the enclosed CD-ROM for the following operating syste ms:
• Windows XP
• Windows 2000
• Windows Me
• Windows 98
• Windows 95
• Windows NT 4.0
Additional drivers and driver information for other operating systems are available on the Elo
T ouchSystems web site at www .elotouch.com.
Your Elo touchmonitor is plug-and-play compliant. Information on the video ca pabilities of your
touchmonitor is sent to your video display ad a pter when Windows starts. If Windows detects your
touchmonitor, follow the instructions on the screen to install a generic plug-and-play monitor.
Refer to the appropriate following section for driver installation instructions.
Depending upon whether you connected the serial communication cable or the USB
communication cable, you should install only the serial driver or the USB driver.
2-12 User Guide
Installing the Serial Touch Driver
Installing the Serial Touch Driver for Windows XP,
Windows 2000, Me, 95/98 and NT4.0
NOTE: For Windows 2000 and NT 4.0 you must have administrator access rights to install
the driver.
1 Insert the Elo CD-ROM in your computer's CD-ROM drive.
2 If the AutoStart feature f or your CD-ROM drive is a ctive, the syste m automatically detects the
CD and starts the setup program.
3 Follow the directions on the screen to complete the driver setup for your version of Windows.
4 If the AutoStart feature is not a ctive:
5 Click Start > Run.
6 Click the Browse button to locate the EloCd.exe program on the CD-ROM.
7 Click Open, then OK to run EloCd.exe.
8 Follow the directions on the screen to complete the driver setup for your version of Windows.
To install Windows 2000 a nd Windows XP, you must use the "update driver" method; you will not
find a setup.exe file within the download.
2-13
Installing the Serial Touch Driver for MS-DOS and Windows 3.1
You must have a DOS mouse driver (MOUSE.COM) installed for your mouse if you wish to
continue using your mouse along with your touchmonitor in DOS.
T o install Windows 3.x a nd MS-DOS from W indows 95/98, f ollow the directions below:
1 Insert the CD-ROM in your computer’s CD-ROM drive.
2 From DOS, type d:\EloDos_W31 to change to the correct directory on the CD-ROM (your
CD-ROM drive may be mapped to a different drive letter).
3 T ype install and press Enter to start the installation.
4 Align the touchscreen.
You must have already completed Steps 1 a nd 2 before proceeding.
T o run the INST ALL progra m:
1 T ype INSTALL at the DOS prompt in the directory containing the driver install files.
2 INST ALL asks you to select the software to install. Then choose d:\EloDos_W31 from the
displayed list.
3 INST ALL also a sks you for the paths to use during installation, or you may use its defaults.
INST ALL create s directories a s necessary, and warns you if they exist.
If you are updating your software, you may wish to specify the paths containing the earlier versions,
a nd overwrite the obsolete files. All executable progra ms are upward compatible. For a list of
differences from ea ch previous version of the drivers, be sure to select "Diff erence s from Previous
Versions" during the installation process.
INST ALL update s your AUT OEXEC.BA T file with the drivers you select. INST ALL makes a copy
of your original AUTOEXEC.BAT file, called AUTOEXEC.OLD. If you alrea dy have Elo driver
comma nds in your AUTOEXEC.BAT file, they will be commented out.
When INSTALL is finished, it leaves a file called GO.BAT in the subdirectory you specified. GO
loa ds the touchscreen driver, runs the calibration program ELOCALIB, and gives you some final
instructions.
If you are using W indows 3.1, you will also calibrate the touchscreen within Windows 3.1 with the
T ouchscreen Control Panel.
2-14 User Guide
Installing the USB Touch Driver
Installing the USB Touch Driver for Windows XP,
Windows 2000, Me, 95/98 and NT4.0
1 Insert the Elo CD-ROM in your computer’s CD-ROM drive.
If W indows 98, W indows Me or W indows 2000 starts the Add New Hardware Wizard:
2 Choose Next. Select “Search for the best driver for your device (Recommended)” and choose
Next.
3 When a list of search locations is displayed, place a checkmark on “Specify a location” and use
Browse to select the \EloUSB directory on the Elo CD-ROM.
4 Choose Next. Once the Elo USB touchscreen driver has been detected, choose Next again.
5 You will see several files being copied. Insert your W indows 98 CD if prompted. Choose Finish.
If Windows 98, W indows Me or W indows 2000 does not start the Add New Hardware W izard:
NOTE: For Windows 2000 you must have administrator access rights to install the driver.
1 Insert the Elo CD-ROM in your computer’s CD-ROM drive. If the AutoStart f eature for your
CD-ROM drive is active, the system automatically detects the CD and starts the setup program.
2 Follow the directions on the screen to complete the driver setup for your
version of Windows.
If the AutoStart f eature is not a ctive:
1 Click Start > Run.
2 Click the Browse button to locate the EloCd.exe program on the CD-ROM.
3 Click Open, then OK to run EloCd.exe.
4 Follow the directions on the screen to complete the driver setup for your version of Windows.
To install Windows 2000 a nd Windows XP, you must use the "update driver" method; you will not
find a setup.exe file within the download.
2-15
2-16 User Guide
About Touchmonitor Adjustments
CHAPTER
3
OPERATION
Y our touchmonitor will unlikely require adjustment. V ari ations in video output a nd a pplication may
require adjustments to your touchmonitor to opti mize the quality of the display.
For best performa nce, your touchmonitor should be operating in native re solution, that is 800 x 600
at 60k-75 Hz. Use the Display control panel in Windows to choose 800 x 600 resolution.
Operating in other resolutions will degrade video perf ormance. For further information, please
refer to Appendix A.
All adjustments you make to the controls are automatically me morized. This feature saves you from
having to reset your choices every ti me you unplug or power your touchmonitor off and on. If there
is a power failure, your touchmonitor settings will not default to the factory specifications.
3-17
Front Panel Controls
1
2
3
4
5
Control Function
1 Menu/Exit Display/Exits the OSD menus.
2 1. Enter contrast of the OSD.
2. Increase value of the a djustment ite m.
3. Select item.
3 1. Enter brightness adjustment.
2. Decrease value of the adjustment ite m.
3. Select item counter-clockwise.
4 Select Selects the adjustment ite ms from the OSD menus.
5 Power Switch Switches the power of the monitor.
3-18 User Guide
Controls and Adjustment
OSD Menu Functions
T o Display and Select the OSD Functions:
1 Press the Menu key to activate the OSD menu.
2 Use or to move clockwise or counterclockwise through the menu. Press the Enter key,
the parameter will be highlighted when selected.
3 T o quit the OSD screen at a ny ti me during the operation, press the Menu key. If no keys are
pressed for a short time period, the OSD automatically disappears.
NOTE: The OSD screen will disappear if no input activities are detected for 45 seconds.
3-19
OSD Control Options
Control Description
Brightness Increases or decrea se s brightness
Contrast Increases or decreases contrast
H-Position Moves the screen left or right
V-Position Moves the screen up or down
Phase Increases or decrea ses the snow noise of the image after auto
adjustment is ma de.
Clock The dot clock is fine-adjusted after auto adjust.
OSD H-Position Moves the OSD position horizontally on the screen. When the
button is pressed, the OSD control menu will move to the right
side of the screen. Likewise, when the button is pressed, the
OSD control menu will move to the left side.
OSD V-Position Moves the OSD position vertically on the screen. When the
button is pressed, the OSD control menu will move to the top side
of the screen. Likewise, when the button is pressed, the OSD
control menu will move to the lower side.
Color Balance Press or to select 9300, 6500, 5500, 7500 a nd USER. Only when
selecting USER ca n you make a djustments to the R/G/B content.
Press Enter to restore to factory default setting.
Auto-Adjust Press Auto to ena ble this function. The Auto-Adjust will automatically
adjust V-Position, H-Position, Clock and Clock-Pha se.
Recall Defaults Returns the monitor to its default settings.
OSD Language Select from English, French, German ,Spanish a nd Ja pa ne se.
Information Descri ption Indicates the current resolution, H-Frequency a nd V-Frequency.
3-20 User Guide
Preset Modes
T o reduce the need f or adjustment for different modes, the monitor has default setting mode s that
are most commonly used as given in the ta ble below . If any of these display modes are detected, the
monitor automatically adjusts the picture size and centering. When none of the mode is matched,
the user ca n store the ir pref erred modes in the user modes. The monitor is capable of storing up to
7 user modes. The only condition to store a s a user mode is the new display information must have
1 KHz difference for horizontal frequency or 1 Hz for vertical frequency or the sync signal
polarities are different from the default modes.
H. Freq. Ba nd W idth
Mode Resolution (KHz) (MHz) H V
1 V GA 640 x 35070 Hz 31.47 28.322
2 V GA 720 x 40070 Hz 31.47 28.322
3 V GA 640 x 48060 Hz 31.47 25.175
4 MAC 640 x 48066 Hz 35.00 32.24 - -
5 VESA 640 x 480 72 Hz 37.86 31.5 - -
6 VESA 640 x 480 75 Hz 37.50 31.5 - -
7 VESA 800 x 600 56 Hz 35.16 36 + +
8 VESA 800 x 600 60 Hz 37.88 40 + +
9 VESA 800 x 600 75 Hz 46.88 49.5 + +
10 VESA 800 x 600 72 Hz 48.08 50 + +
3-21
Power Management System
The monitor is equipped with the power ma nagement function which automatically reduces the power
consumption when not in use.
Power
Mode Consumption
On <20W
Sleep <4W
Off <2W
We recommend switching the monitor off when it is not in use for a long ti me.
NOTE: The monitor automatically goes through the Power Management System (PMS) steps
when it is idle. To release the monitor from PMS condition, press any key on the keyboard
or move mouse.
Display Angle
For viewing clarity , you ca n tilt the LCD forward (up to -5 degrees) or backward (up to 90 degrees.)
CAUTION In order to protect the LCD, be sure to hold the base when adjusting the LCD,
and take care not to touch the screen.
3-22 User Guide
CHAPTER
4
TROUBLESHOOTING
If you are experiencing trouble with your touchmonitor, refer to the f ollowing ta ble. If the proble m
persists, please conta ct your local dealer or our service center.
Solutions to Common Problems
Problem Suggestion(s)
The monitor does not respond Check that the monitor’s Power Switch is on.
after you turn on the system. Turn off the power and check the monitor’s power cord
a nd signal ca ble f or proper connection.
Characters on the screen are di m Refer to the About Touchmonitor Adjustments section to
adjust the brightness.
The screen is bla nk During operation, the monitor screen may automatically turn
off as a result of the Power Saving feature. Pre ss any key to see
if the screen reappears.
Refer to the About Touchmonitor Adjustments section to
adjust the brightness.
Screen flashes when initi alized Turn the monitor off then turn it on again.
“Out of Ra nge” display Check to see if the resolution of your computer is higher than
that of the LCD display.
Reconfigure the resolution of your computer to make it less
tha n or equal to 800x600. See Appendix A for more inf ormation
on resolution.
T ouch doe sn’t work Make sure the touch ca ble is securely attached at both ends.
4-23
4-24 User Guide
APPENDIX
A
NATIVE RESOLUTION
The native resolution of a monitor is the resolution level at which the LCD panel is designed to
perform best. For the LCD touchmonitor, the native resolution is 800 x 600 for the 12 inch size. In
almost all cases, screen images look best when viewed at their native resolution. You can lower the
resolution setting of a monitor but not increase it.
Input Video 12" LCD
640x480 (VGA) Transforms input format to 800x600
800x600 (SV GA) Displays in Native Resolution
The native resolution of an LCD is the actual number of pixels horizontally in the LCD by the
number of pixels vertically in the LCD. LCD resolution is usually represented by the
following symbols:
VGA 640x480
SVGA 800x600
XGA 1024x768
SXGA 1280x1024
UXGA 1600x1200
A-25
As a n exa mple, a SVGA resolution LCD panel has 800 pixels horizontally by 600 pixels vertically.
Input video is also represented by the same terms. XGA input video has a format of 1024 pixels
horizontally by 768 pixels vertically. When the input pixels contained in the video input format
match the native resolution of the panel, there is a one to one correspondence of mapping of input
video pixels to LCD pixels. As an example, the pixel in column 45 and row 26 of the input video is in
column 45 a nd row 26 of the LCD. For the case when the input video is at a lower re solution tha n the
native resolution of the LCD, the direct correspondence between the video pixels and the LCD
pixels is lost. The LCD controller ca n compute the correspondence between video pixels and LCD
pixels using algorithms contained on its controller . The accuracy of the algorithms determines the
fidelity of conversion of video pixels to LCD pixels. Poor fidelity conversion can result in artifacts
in the LCD displayed i mage such a s varying width characters.
A-26 User Guide
APPENDIX
B
TOUCHMONITOR SAFETY
This manual contains information that is important for the proper setup and maintenance of your
touchmonitor. Bef ore setting up a nd powering on your new touchmonitor , read through this manual,
especially Cha pter 2 (Installation), and Chapter 3 (Operation).
1 To reduce the risk of electric shock, follow all safety notices and never open the touchmonitor
case.
2 Turn off the product bef ore cleaning.
3 Y our new touchmonitor is equi pped with a 3-wire, grounding power cord. The power cord plug
will only fit into a grounded outlet. Do not attempt to fit the plug into a n outlet that has not been
configured for this purpose. Do not use a da maged power cord. Use only the power cord that
comes with your touchmonitor . Use of a n unauthorized power cord may invalidate your warranty.
4 The slots located on the sides and top of the touchmonitor case are for ventilation. Do not block
or insert a nything inside the ventilation slots.
5 It is important that your touchmonitor remains dry. Do not pour liquid into or onto your
touchmonitor. If your touchmonitor becomes wet do not attempt to repair it yourself.
B-27
Care and Handling of Your Touchmonitor
The following tips will help kee p your touchmonitor functioning at the opti mal level.
• T o avoid risk of electric shock, do not disa ssemble the brick supply or display unit cabinet. The
unit is not user serviceable. Reme mber to unplug the display unit from the power outlet bef ore
clea ning.
• Do not use alcohol (methyl, ethyl or isopropyl) or a ny strong dissolvent. Do not use thinner or
benzene, abra sive cleaners or compressed air.
• T o clea n the display unit ca binet, use a cloth lightly da mpened with a mild deter gent.
• A void getting liquids inside your touchmonitor . If liquid does get inside, have a qualified service
technician check it before you power it on again.
• Do not wipe the screen with a cloth or sponge that could scratch the surface.
• To clean the touchscreen, use window or glass clea ner. Put the clea ner on the rag and wipe the
touchscreen. Never a pply the cleaner directly on the touchscreen.
B-28 User Guide
APPENDIX
C
TECHNICAL SPECIFICATIONS
C-29
Touchmonitor Specifications
Model ET1215L
LCD Display 12” TFT Active M atrix Pa nel
Display Size 246(H) x 184.5(V) mm
Pixel Pitch 0.3075(H) x 0.3075(V) mm
Display Mode V GA 640 x 350 (70Hz)
V GA 720 x 400 (70Hz)
VGA 640 x 480 (60 / 72/ 75Hz)
Max. Resolution SVGA 800 x 600 (56 / 60 / 72/ 75Hz) M aximum
Contrast Ratio 500 : 1 (typical)
Brightness Non T ouch: typical 200 Cd/m2 ; Min 160 Cd/m
AccuTouch: typical 164 Cd/m2 ; Min 131 Cd/m
IntelliTouch: typical 184 Cd/m2 ; Min 147 Cd/m
Capa citive: typical 170 Cd/m2 ; Min 136 Cd/m
Response Time Tr: 10 ms Tf: 25ms (Typ.)
Display Color 262K
Viewing Angle Vertical -60o ~ +50
Horizontal -70o ~+70
Input Signal Video R.G.B. Analog 0.7V p-p, 75 ohm
Sync TTL Positive or Negative
Signal Connector Mini D-Sub 15 pin
Front Control Menu, , , Select, Power
OSD Contrast, Brightness, H-Position, V-Position,
Color T emperature, Pha se, Clock, OSD T ime, Recall,
La nguage: English, French, German, Spanish, Jap a nese
Plug & Play DDC1 / 2B
Touch Panel (optional) AccuT ouch /IntelliTouch/Ca pacitive
Power Adapter Input AC 100-240V , 50/60Hz
Operating Conditions Temperature 0oC ~ 40oC (32oF ~ 104oF)
Humidity 20% ~ 80% (No Condensation)
Altitude To 12,000 Feet
Storage Conditions Temperature -20oC ~ 60oC (-4oF ~ 140oF)
Humidity 10% ~ 90% (No Condensation)
Dimensions (HxWxD) 301 x 285 x 168mm
Weight (Net) 3.8Kg
Certifications TUV , UL, C-UL, FCC-B, CE, VCCI, C-Tick, MPRII
o
o
2
2
2
2
C-30 User Guide
AccuTouch Touchscreen Specifications
Mechanical
Construction Top: Polye ster with outside hard-surfa ce coating with clear or antiglare finish.
Inside: Tra nsparent conductive coating.
Bottom: Gla ss substrate with unif orm resistive coating. Top and bottom layers
separated by patented separator dots.
Positional Accuracy Standard deviation of error is less than 0.080 in. (2.03 mm). This equates to less
tha n ±1%.
T ouchpoint Density More than 100,000 touchpoints/in2 (15,500 touchpoints/cm2).
T ouch Activation Force Typically less tha n 4 ounce s (1 13 gra ms).
Surface Durability Meets T aber Abrasion Test (ASTM D1044), CS-10F wheel, 500 g. Meets pencil
hardness 3H.
Expected Life AccuTouch technology has been operationally tested to greater tha n 35 million
Performance touches in one location without failure, using a stylus similar to a finger.
Optical
Light T ransmission Typically 85% at 550-nm wavelength (visible light spectrum).
(per ASTM D1003)
Visual Resolution All measurements made using USAF 1951 Resolution Chart, under 30 X
magnification, with test unit located approxi mately 1.5 in. (38 mm) from surfa ce
of resolution chart.
Antiglare surface: 6:1 mini mum.
Haze (per ASTM D1003) Antiglare surface: Less tha n 15%.
Gloss (per ASTM D2457) Antiglare surface: 90 ± 20 gloss units tested on a hard-coated front surface.
C-31
12” LCD Touchmonitor (ET1215L-XXXA-1) Dimensions
C-32 User Guide
REGULATORY INFORMATION
I. Electrical Safety Information:
A) Compliance is required with respect to the voltage, frequency , and current requirements
indicated on the manufacturer’s label. Connection to a dif ferent power source than those
specified herein will likely result in i mproper operation, da mage to the equipment or pose a fire
hazard if the limitations are not followed.
B) There are no operator serviceable parts inside this equi pment. There are hazardous voltages
generated by this equipment which constitute a safety hazard. Service should be provided only
by a qualified service technician.
C) This equi pment is provided with a detacha ble power cord which ha s an integral safety ground
wire intended for connection to a grounded safety outlet.
1) Do not substitute the cord with other than the provided approved type. Under no
circumsta nces use an adapter plug to connect to a 2-wire outlet a s this will def eat the
continuity of the grounding wire.
2) The equipment requires the use of the ground wire as a part of the safety certification,
modification or misuse can provide a shock hazard that can result in serious injury or
death.
3) Contact a qualified electrici an or the manufacturer if there are que stions a bout the
installation prior to connecting the equipment to mains power .
II. Emissions and Immunity Information
A) Notice to Users in the U nited States: This equipment has been tested and found to comply
with the limits for a Cla ss B digital device, pursuant to Part 15 of FCC Rules. These limits are
designed to provide reasona ble protection against harmful interference in a residenti al installation.
This equipment generates, uses, and can ra di ate ra dio frequency energ y , and if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications.
B) Notice to Users in Canada: This equi pment complies with the Class B limits for radio noise
emissions from digital apparatus a s established by the Ra dio Interf erence Regulations of Industrie
Canada.
C) Notice to Users in the European Union: Use only the provided power cords and
interconnecting cabling provided with the equi pment. Substitution of provided cords a nd cabling
may compromise electrical safety or CE Mark Certification f or e missions or immunity as
required by the following sta ndards:
33
This Information T echnology Equipment (ITE) is required to have a CE M ark on the manufa cturer’s
label which mea ns that the equi pment ha s been tested to the f ollowing Directives and Standards:
This equipment has been tested to the require ments f or the CE M ark a s required by EMC
Directive 89/336/EEC indicated in European Standard EN 55022 Class B a nd the Low Voltage
Directive 73/23/EEC as indicated in Europea n Standard EN 60950.
D) General Inf ormation to all Users: This equi pment generates, uses and can radiate radio
frequency energy . If not installed and used according to this ma nual the equipment may cause
interference with radio and television communications. There is, however, no guarantee that
interference will not occur in a ny particular installation due to site-specific factors.
1) In order to meet emission and immunity requirements, the user must observe the f ollowing:
a) Use only the provided I/O cables to connect this digital device with any computer.
b) T o ensure compli ance, use only the provided manufacturer’s a pproved line cord.
c) The user is cautioned that changes or modifications to the equipment not expressly
approved by the party responsible for complia nce could void the user’s authority to operate
the equipment.
2) If this equipment a ppears to cause interference with radio or television reception, or any other
device:
a) Verify as an e mission source by turning the equi pment off and on.
b) If you determine that this equipment is causing the interference, try to correct the
interference by using one or more of the following measures:
i) Move the digital device away from the affected receiver.
ii) Reposition (turn) the digital device with respect to the affected receiver.
ii i) Reorient the af f ected rece iver’s antenna.
iv) Plug the digital device into a different AC outlet so the digital device and the
receiver are on different branch circuits.
v) Disconnect and remove any I/O ca ble s that the digital device does not use.
(Unterminated I/O cable s are a potenti al source of high RF e mission levels.)
vi) Plug the digital device into only a grounded outlet receptacle. Do not use AC
ada pter plugs. (Re moving or cutting the line cord ground may increa se RF e mission
levels and may also pre sent a lethal shock hazard to the user.)
If you need additional help, consult your dealer , manufacturer, or an experienced ra dio or television
technician.
34 User Guide
U
C
LISTED
L
US
6K70
E141667
ITE
N10051
EN60950-1
MPR II
WARRANTY
Except as otherwise stated herein or in an order acknowledgment delivered to Buyer, Seller warra nts
to Buyer that the Product shall be free of defects in materials and workmanship. The warranty for the
touchmonitors a nd components of the product is 3 (three) years.
Seller makes no warra nty regarding the model life of components. Seller’s suppliers may at a ny ti me
and from time to time make changes in the components delivered as Products or components.
Buyer shall notify Seller in writing promptly (a nd in no case later tha n thirty (30) days after discovery)
of the failure of a ny Product to conf orm to the warranty set forth above; shall describe in commercially rea sona ble detail in such notice the symptoms a ssoci ated with such failure; and shall provide
to Seller the opportunity to inspect such Products as installed, if possible. The notice must be received by Seller during the Warranty Period for such product, unless otherwise directed in writing
by the Seller. W ithin thirty (30) days after submitting such notice, Buyer shall package the allegedly
defective Product in its original shipping carton(s) or a functional equivalent and shall ship to Seller
at Buyer’s expense a nd risk.
Within a rea sonable time after recei pt of the allegedly def ective Product and verification by Seller
that the Product fails to meet the warranty set forth above, Seller shall correct such failure by, at
Seller’s options, either (i) modifying or repairing the Product or (ii) replacing the Product. Such
modification, repair, or re placement and the return shipment of the Product with mini mum insura nce to Buyer shall be at Seller’s expense. Buyer shall bear the risk of loss or da mage in transit, and
may insure the Product. Buyer shall reimburse Seller f or transportation cost incurred for Product
returned but not found by Seller to be defective. Modification or repair, of Products may, at Seller’s
option, take place either at Seller’s facilities or at Buyer’s premises. If Seller is unable to modify,
repair, or repla ce a Product to conf orm to the warranty set forth above, then Seller shall, at Seller’s
option, either refund to Buyer or credit to Buyer’s account the purchase price of the Product less
depreciation calculated on a straight-line ba sis over Seller’s stated Warranty Period.
37
THESE REMEDIES SHALL BE THE BUYER¡¦S EXCLUSIVE REMEDIES FOR BREACH OF
W ARRANTY. EXCEPT FOR THE EXPRESS W ARRANTY SET FORTH ABOVE, SELLER GRANTS
NO OTHER W ARRANTIES, EXPRESS OR IMPLIED BY ST A TUTE OR OTHERWISE, REGAR DING THE PRODUCTS, THEIR FITNESS FOR ANY PURPOSE, THEIR QUALITY, THEIR
MERCHANT ABILITY, THEIR NONINFRINGEMENT, OR OTHERWISE. NO EMPLOYEE OF
SELLER OR ANY OTHER PAR TY IS AUTHORIZED TO MAKE ANY W ARRANTY FOR THE
GOODS OTHER THAN THE W ARRANTY SET FOR TH HEREIN. SELLER’S LIABILITY UNDER
THE WARRANTY SHALL BE LIMITED T O A REFUND OF THE PURCHASE PRICE OF THE
PRODUCT . IN NO EVENT SHALL SELLER BE LIABLE FOR THE COST OF PROCUREMENT
OR INSTALLATION OF SUBSTITUTE GOODS BY BUYER OR FOR ANY SPECIAL,
CONSEQUENTIAL, INDIRECT , OR INCIDENTAL DAMAGES.
Buyer assumes the risk and agrees to indemnify Seller against and hold Seller harmless from all
lia bility relating to (i) assessing the suitability for Buyer’s intended use of the Products and of any
system design or drawing and (ii) determining the compli ance of Buyer’s use of the Products with
applica ble laws, regulations, code s, and standards. Buyer retains a nd accepts full responsibility for
all warra nty a nd other clai ms relating to or arising from Buyer’s products, which include or incorporate Products or components manufactured or supplied by Seller. Buyer is solely responsible for
a ny a nd all representations a nd warra nties regarding the Products ma de or authorized by Buyer . Buyer
will indemnify Seller and hold Seller harmless from any liability, claims, loss, cost, or expenses
(including reasona ble attorney’s fees) attributa ble to Buyer’s products or representations or warranties concerning same.
38 User Guide
INDEX
Numerics
12" LCD Touchmonitor (ET1215L-XXWA-1)
Dimensions, 32
A
About the Product, 8
About Touchmonitor Adjustments, 17
AccuTouch Touchmonitor Specifications, 31
B
Brightness, 30
C
Care and Handling of Your Touchmonitor, 28
Certifications, 30
Cleaning Your Touchmonitor, 28
Construction, AccuTouch, 31
Contrast Ratio, 30
Controls and Adjustment, 19
D
Dimensions (HxWxD), 30
Display Angle, 22
Display Color, 30
Display Mode, 30
Display Size, 30
E
Electrical Safety Information, 33
Emissions and Immunity Information, 33
Expected Life Performance, AccuTouch, 31
F
Front Control, 30
Front Panel Controls, 18
G
Gloss, AccuTouch, 31
H
Haze, AccuTouch, 31
I
Image problem, 23
Image, scrolling, 23
Input Signal, 30
Installation and Setup, 9
Installing the Driver Software, 12
Installing the Serial Touch Driver, 13
Installing the Serial Touch Driver for MS-DOS and
Windows 3.1, 14
Installing the Serial Touch Driver for Windows XP,
Windows 2000, Me, 95/98 and NT 4.0, 13
Installing the USB Touch Driver, 15
Installing the USB Touch Driver for Windows XP,
Windows 2000, Me, 95/98 and NT 4.0, 15
L
Light Transmission, AccuTouch, 31
M
Main Unit, 10
Max. Resolution, 30
Mechanical, AccuTouch, 31
N
Native Resolution, 25
O
Operating Conditions, 30
Optical, AccuTouch, 31
OSD, 30
OSD Control Options, 20
OSD Menu Functions, 19
P
Pixel Pitch, 30
Plug & Play, 30
Positional Accuracy, AccuTouch, 31
Power Adapter, 30
Power Management System, 22
Precautions, 7
Product Description, 7
Product Overview, 10
R
Rear View, 10
Regulatory Information, 33
Response Time, 30
I N D E X - 39
S
Signal Connector, 30
Solutions to Common Problems, 23
Storage Conditions, 30
Surface Durability, AccuTouch, 31
SVGA, 25
T
Technical Specifications, 29
Touch Activation Force, AccuTouch, 31
Touch Interface Connection, 11
Touch not working, 23
Touch Panel (optional), 30
Touchmonitor Safety, 27
Touchmonitor Specifications, 30
Touchpoint Density, AccuTouch, 31
Troubleshooting, 23
U
Unpacking Your Touchmonitor, 9
UXGA, 25
V
VGA, 25
Viewing Angle, 30
Visual Resolution, AccuTouch, 31
W
Warranty, 37
Weight (Net), 30
I N D E X - 40
Recommended Disassembly Sequence
LCD Touchmonitor
Power Cord A
Power Cord B
VGA Cord
Serial Cord
USB Cord
Compact Disc Assembly
Check out Elo’s Web site!
www.elotouch.com
Get the latest...
• Product information
• Specifications
• News on upcoming events
• Press release
• Software drivers
Getting in Touch with Elo
To find out more about Elo’s extensive range of touch solutions, visit our Web site at www.elotouch.com or simply
call the office nearest you:
USA & Headquarters Germany Belgium Japan
Elo TouchSystems, Inc. Elo TouchSystems GmbH & Co. KG Elo TouchSystems Touch Panel Systems K.K
301 Constitution Drive, Haidgraben 6 Diestsesteenweg 692 Sun Homada Bldg. 2F
Menlo Park, CA 94025 D-85521 Ottobrunn B-3010 Kessel-Lo 1-19-20 Shin-Yokohama
USA Germany Belgium Kanagawa 222-0033
Japan
(800) ELO-TOUCH(800-356-8682)
Tel 650-361-4700 Tel +49(89)60822-0 Tel +32(16)35-2100 Tel +81(45)478-2161
Fax 650-361-4747 Fax +49(89)60822-150 Fax +32(16)35-2101 Fax +81(45)478-2180
eloinfo@elotouch.com elosales@elotouch.com elosales@elotouch.com www.tps.co.jp
© 2006 Elo T ouchSystems Inc. Printed in USA
Loading...
